1 2 3 4 5 6
7 8 9
10 11 12
5V 2A
-10℃-45℃
10%-90% RH(no condensation)
Micro USB DC5V
WiFi 802.11b/g/n
ZigBee 802.15.4
Product Specifications
Product name
Electrical Parameters
Operating Temperature
Operating Humidity
Charge Type
Wireless Protocol
Wireless ZigBee Gateway
Product Description Preparation For Use
Packing list
Add Devices
Electronic Information Products
Toxic And hazerdous substance
Declaration
CE Notice
Zigbee smart gateway x 1
Instruction manual x 1
Power cable x 1
The smart gateway is the control center of the ZigBee
device.Users can design and implement smart application
scenarios by adding ZigBee devices
Connect the gateway to the power supply , then
press and hold "reset button"
Once the device has been added successfully,you
will be able to find the device on“My Home” page
The connection will take about 30-120 seconds,
depending on your network condition
Select 2.4GHz Wi-Fi network and enter password.
Confirm when the blue light is on and the red light is
blinking fast
Open the “MOES” App and click the“+” on the
upper right corner of the screen and choose “Wireless
Gateway (Zigbee)” to add
Confirm that the blue light is on and the red light is
blinking fast (if the indicator is in another status, press
and hold the reset button until the blue light is on and
the red light is blinking fast)
Part
name
Lead
Pb
Mercury
Hg
Cadmium
Cd
Hexavalent
chromium
Cr(VI)
Polybrominated
biphenyl
PBB
PCB
board
Housing
Cable
Toxic or harmful substances or elements
Indicates that the content of this toxic and hazardous substance in
all homogeneous materials of this part is below the maximum limit
specified in SJ/T1163-2006 Requirements for Concentration Limits for
Certain Hazardous Substances in Electronic Information Products;
CE Products with the CE marking comply with the Radio Equipment
Directive (2014/53/EU),the Electromagnetic Compatibility Directive
(2014/30/EU),the Low Voltage Directive (2014/35/EU) - issued by
the Commission of the Euroean.
Compliance with these directives implies conformity to the following
European Standards:
EN300328 V2.1.1
EN301489-1/17 V2.1.1
EN62368-1:2014+A11:2017
EN55032:2015+AC:2016(ClassB);
EN62311:2008
Indicates that the toxic or hazardous substance contained in at least
one of the homogeneous materials of the part exceeds the maximum
limit specified in the SJ/T1163-2006 standard
The figures in this label indicate that the product has an
environmental protection use period of 10 years under
conditions of normal use, and some parts may also have an
environmentally friendly use period mark. The environmental
protection use period is based on the number indicated by
the mark.
Please read the instruction manual carefully before using the
product
Wi-Fi Indicator
Reset Button
Power Socket
Zigbee Indicator
Thank you for your support and purchase at we Moes,
we are always here for your complete satisfaction,just
feel free to share your great shopping experience
with us.
If you have any other need,please do not hesitate to
contact us first,we will try to meet your demand.
SERVICE
RECYCLING INFORMATION
Product Information
Product Name__________________________________________
Product Type___________________________________________
Purchase date__________________________________________
Warranty Period________________________________________
Dealer Information______________________________________
Customer's Name_______________________________________
Customer Phone________________________________________
Customer Address______________________________________
_______________________________________________________
Maintenance Records
WARRANTY CARD
Failure date Cause Of Issue Fault Content Principal
CL11
English English
English English
English
EnglishEnglish
EnglishEnglishEnglish English
English
Wireless ZigBee Gateway
ZHUB-W
Instruction Manual
HOME, SMART MOES HOME
Thank you for your trust and support to our products, we will
provide you with a two-year worry-free after-sales service
(freight is not included), please do not alter this warranty
service card, to safeguard your legitimate rights and interests.
If you need service or have any questions, please consult the
distributor or contact us.
Product quality problems occur within 24 months from the
date of receipt, please prepare the product and the packaging,
applying for after-sales maintenance in the site or store where
you purchase; If the product is damaged due to personal
reasons, a certain amount of maintenance fee shall be
charged for repair.
We have the right to refuse to provide warranty service if:
1. Products with damaged appearance, missing LOGO or
beyond the service term
2. Products that are disassembled, injured, privately repaired,
modified or have missing parts
3. The circuit is burned or the data cable or power interface is
damaged
4. Products damaged by foreign matter intrusion (including but
not limited to various forms of fluid, sand, dust, soot, etc.)
All products marked with the symbol for separate collection
of waste electrical and electronic equipment (WEEE Directive
2012/19 / EU) must be disposed of separately from unsorted
municipal waste. To protect your health and the environment,
this equipment must be disposed of at designated
collection points for electrical and electronic
equipment designated by the government or local
authorities. Correct disposal and recycling will help
prevent potential negative consequences for the
environment and human health. To find out where these
collection points are and how they work, contact the installer
or your local authority.
MOES.Official
@moes_smart
@moessmart
@moes_smart
@moes_smart
www.moes.net
EVATOST CONSULTING LTD
Address: Suite 11, First Floor, Moy Road Business Centre, Taffs
Well, Cardiff, Wales, CF15 7QR
Tel: +44-292-1680945
Email: [email protected]
E‐CrossStu‐GmbH
MainzerLandstr.69,60329FrankfurtamMain
Made in China
Manufacturer:
WENZHOU NOVA NEW ENERGY CO.,LTD
Address: Power Science and Technology Innovation Center,
NO.238, Wei 11 Road, Yueqing Economic Development Zone,
Yueqing, Zhejiang, China
Tel: +86-577-57186815
After-sale Service: [email protected]
1. Download MOES APP
MOES App is upgraded as much more compatibility than
Tuya Smart/Smart Life App, functional well for scene
controlled by Siri, widget and scene recommendations as
the fully new customized service.
(Note: Tuya Smart/Smart Life App still works, but MOES
App is highly recommended)
Mobile number/e-mail address
Region
Obtain verification code
Enter the Register/Login interface;
tap “Register” to create an account
by entering your phone number to
get verification code and “Set
password”. Choose “Log in” if you
already have a
MOES
account.
请扫描二维码获取中文的说
明书、安装视频及功能介绍
ZHUB-W-MS-CL11
Bitte scannen Sie den QR-Code, um das deutsche Handbuch, das
Installationsvideo und die Funktionseinführung zu erhalten
Escanee el código QR para obtener el manual en español, el video
de instalación y la introducción de la función
Veuillez scanner le code QR pour obtenir le manuel en français, la
vidéo d'installation et l'introduction des fonctions
Отсканируйте QR-код, чтобы получить руководство на русском
языке, видео по установке и описание функций
Scansionare il codice QR per ottenere il manuale in italiano, il video
di installazione e la guida alle funzionalità. Video di installazione e
funzionalità
Leia o código QR para obter o manual em português, o vídeo de
instalação e a introdução das funções
Zeskanuj kod QR, aby uzyskać instrukcję obsługi, film instalacyjny i
wprowadzenie do funkcji
潘通色号：4249C
51.7mm
72.3mm
