Englishv. 1.1SENIXTOOLS.COM
CORDLESS LEAF BLOWER
Instruction Manual
Model: BLAX2-M2
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
For customer support, please call 1-800-261-3981 or email us at [email protected]
• SAFETY
• ASSEMBLY
• OPERATION
• MAINTENANCE
• WARRANTY
CAUTION: Before using this tool, please read this manual completely,
and follow all operating safety measures.
EN - 2
SENIXTOOLS.COM
SAFETY &
INTERNATIONAL
SYMBOLS
The following table depicts and describes
safety symbols that may appear on this
product. Read, understand and follow all
instructions on the machine before attempting
to assemble and operate.
Caution / Warning.
WARNING - To reduce the risk of
injury, user must read instruction
manual.
Wear eye protection.
Wear ear protection.
Wear respiratory protection.
Do not expose the product to rain or
wet conditions.
Wear protective, slip-resistant
footwear.
Wear protective gloves.
Failure to keep long hair away
from the air intake could result in
personal injury.
Failure to keep loose clothing from
being drawn into air intake vents
could result in personal injury.
Do not operate without tube
properly connected.
Keep all bystanders at least 50 ft.
away.
Thrown objects can ricochet and
result in personal injury or property
damage.
Do not dispose of battery packs in
rivers or immerse in water.
Do not dispose of battery packs in
fire. They will explode and cause
injury.
Do not disassemble, crush, heat
above 212°F (100°C); Never expose
the battery to microwaves or high
pressures.
Indoor use only. Only use battery
charger indoors.
Mexican Certification Mark.
Complies with ETL standards.
TABLE OF CONTENTS
SAFETY & INTERNATIONAL SYMBOLS ..............2
SAFETY INSTRUCTIONS .........................................3
KNOW YOUR UNIT .....................................................6
SPECIFICATIONS .......................................................7
ASSEMBLY ................................................................... 7
OPERATION ..................................................................9
MAINTENANCE .........................................................10
TROUBLESHOOTING ...............................................11
WARRANTY ................................................................12
3 - EN
SENIXTOOLS.COM
SAFETY INSTRUCTIONS
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions,
illustrations and specications provided with
this power tool. Failure to follow all instructions
listed below may result in electric shock, re
and/or serious injury.
Save all warnings and instructions for
future reference.
The term "power tool" in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
• Keep out of reach of children.
• Dress Properly – Do not wear loose
clothing or jewelry. They can be caught in
moving parts. Use of rubber gloves and
proper footwear is recommended when
working outdoors. Secure long hair to
prevent contact with moving parts.
• Use Safety Glasses.
• Wear Appropriate Personal Hearing
Protection During Use – Under some
conditions and duration of use, noise from
this product may contribute to hearing loss.
• Do not use product for any job except that
for which it is intended.
• Check for damaged parts before use of
product. If a part is damaged it should
be repaired or replaced. Please call our
customer service help line for assistance.
• Lighting – Only operate blower in daylight.
• Don’t overreach – Keep proper footing and
balance at all times.
• Avoid Dangerous Environments – Don’t
use blower in rain, damp or wet locations.
Do not operate blower near gasoline or
explosive materials. Motors in these tools
normally spark, and the sparks might ignite.
• Stay Alert when operating the blower.
• When not in use, products should be
stored indoors in dry conditions.
• Maintain Blower Properly - Keep clean for
best performance.
BLOWER SAFETY
WARNINGS
• This blower is intended for consumer use
only. Commercial use of this product is
prohibited and will void the manufacturer’s
warranty.
• Prevent unintentional use. Ensure the
throttle trigger is released and variable
speed control is in the off position before
connecting to battery pack, picking up or
carrying the product.
• Disconnect the battery pack from the
product before making any adjustments,
changing accessories, or storing product.
Such preventive safety measures
reduce the risk of starting the product
accidentally.
• When operating the unit, never point the
blower nozzle in the direction of people or
pets or in the direction of windows. Use
extra caution when blowing debris near
solid objects, such as trees, automobiles,
and walls.
• Secure the unit properly when
transporting it.
• Never douse or squirt the unit with water
or any other liquid. Clean the unit after
each use as described in the cleaning and
storage section.
• Carefully inspect the blower prior to
use and follow all label and marking
instructions.
• Do not use the blower with any
obstructions in the openings.
• Service on the blower must be performed
by Authorized Service Centers.
BATTERY PACK AND
BATTERY CHARGER SAFETY
WARNINGS
• Only charge SENIX Batteries with the
appropriate SENIX Charger. The use of any
other charger may create a fire risk.
• Use SENIX products with the appropriate
battery pack. The use of any other battery
packs may create a fire risk.
WARNING!
Only use following batteries: B20X2/B25X2/
B40X2/B50X2/B60X2/B80X2 and chargers:
CHX2-L/CHX2/CHQX2/CHQX2-M/CHDX2-M.
• When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
EN - 4
SENIXTOOLS.COM
Shorting the battery terminals together
may cause burns or a fire.
• Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, seek medical
help.
• Do not use a battery pack or product
that is damaged or modified. Damaged
or modified batteries may result in fire,
explosion or risk of injury.
• Do not expose a battery pack or product
to fire or excessive temperature. Exposure
to fire or temperature above 212°F (100°C)
may cause explosion.
• Follow all charging instructions and do not
charge the battery pack or product outside
of the temperature range specified in the
instructions. Charging improperly or at
temperatures outside of the specified
range may damage the battery and
increase the risk of fire.
• Do not modify or attempt to repair the
battery pack.
RESIDUAL RISKS
Even if you are operating this product in
accordance with all the safety requirements,
potential risks of injury and damage remain.
WARNING!
This product produces an electromagnetic
eld during operation. This eld may under
some circumstances interfere with active or
passive medical implants! To reduce the risk
of serious or fatal injury, please consult with
doctor before operating this product!
INTENDED USE
The blower is designed to clear hard surfaces
and debris.
5 - EN
SENIXTOOLS.COM
APPLICATIONS
Model: BLAX2-M2
Designed as a blower to clear light debris.
1 Blower Nozzle
2 Nozzle-release Button
3 Blower Tube
4 Tube-release Button
5 Cruise Control Switch
6 Turbo Boost Button
7 Variable Speed Trigger
8 Handle
9 Intake
KNOW YOUR UNIT
1 2 3 4 5 6 7 8 9
EN - 6
SENIXTOOLS.COM
SPECIFICATIONS
Model BLAX2-M2
Input Voltage 36V
(40V Max*)
Motor Type Brushless
No-Load Speed 0-22500 RPM (Max)
Air Speed 145 MPH
Air Volume 700 CFM
Weight (Tool Only) 5.51 Ibs / 2.5 Kg
*40 V Max battery, maximum initial battery
voltage is 40 V. The nominal voltage is 36 V.
ASSEMBLY
1. Unpack all parts and lay them on a flat
surface.
2. Remove all packing materials and shipping
devices, if applicable.
3. Included in the box:
• (1) Cordless Leaf Blower
• (2) 4.0 Ah Battery
• (1) 20V Dual Port Charger
• (3) Instruction Manual
4. If you find that parts are missing or
damaged, do not use the product and
contact the dealer.
5. Ensure that you have all the accessories
and tools needed for assembly and
operation.
WARNING!
Wear protective gloves for
assembly work and always lay the
product on a flat and stable surface
while assembling.
Follow the assembly instructions
step-by-step and use the pictures
provided as a visual guide to easily
assemble the product. Do not insert
the battery pack before the blower
is completely assembled.
INSTALLING/REMOVING
THE BLOWER TUBE
WARNING!
To avoid serious personal injury and damage
to the blower, shut the blower o before
removing or installing an attachment.
WARNING!
Use only as described in this manual. Use only
manufacturer’s recommended attachments.
1. Align the groove on the tube with the notch
on the blower housing. Push the tube onto
the blower housing until the latch snaps
into place.
Fig. 2
Fig. 3
2. To remove the tube, press and hold the
tube-release button to disengage the
latch, then pull the tube away from the
blower (Fig.4).
Fig. 4
7 - EN
SENIXTOOLS.COM
INSTALLING/REMOVING
THE BLOWER NOZZLE
1. Align the groove on the blower nozzle with
the notch on the tube. Push the nozzle
onto the tube until it snaps into place.
Fig. 5
Fig. 6
2. To remove the blower nozzle, press
and hold the nozzle-release button to
disengage the latch, then pull the nozzle
away from the blower tube.
Fig. 7
INSTALLING/REMOVING
BATTERY PACK
WARNING!
Always remove the battery pack from the
product when you are assembling parts,
making adjustments, cleaning, or when not in
use.
To install:
Align and slide the battery packs into the slots
on the battery docking port until it locks in
place.
Fig. 8
To remove:
Press the battery-release button and remove
the battery pack from the blower.
Battery-Release Button
Fig. 9
NOTE:
Refer to the manuals for the charger and
battery pack for more details.
OPERATION
SWITCHING ON/OFF
NOTE:
Before use, turn the cruise control dial
counterclockwise to the o position.
VARIABLE SPEED TRIGGER.
1. Press the air-speed trigger to turn on the
blower.
2. The air speed of the blower is controlled
with the variable speed trigger. More
pressure on the trigger results in higher air
speed; less pressure on the trigger results
in lower air speed.
EN - 8
SENIXTOOLS.COM
3. Release the air-speed trigger to turn off
the blower.
CRUISE CONTROL DIAL FUNCTION
The blower can be locked at any speed with
the cruise control dial.
1. Turn the cruise control dial clockwise
to start the blower. The air speed will
increase as the dial is rotated clockwise.
2. To decrease the air speed, turn the cruise
control dial counterclockwise.
3. Keep turning the cruise control dial
counterclockwise to the off position to
stop the blower.
NOTE:
If the cruise control dial is not turned back to
the o position before the battery is removed,
the blower will not start when a fully charged
battery is installed. This is a protection feature
to help prevent accidental startup. Turn the
cruise control dial counterclockwise to the
o position to deactivate the protection.
Then press the air-speed trigger to power the
blower.
NOTE:
Press and hold the turbo boost button while
working to increase the air speed to the
maximum level. The blower will resume the
previous speed when the turbo boost button
is released.
Variable Speed Trigger
Turbo Boost Button
Cruise Control Dial
Fig. 9
GENERAL
1. Always hold the product by its handle.
Keep the blower dry and clean.
2. Ensure that the air vents are always
unobstructed and clear. Blocked air vents
may lead to overheating and damage the
product.
3. Before operating the blower, make sure to
check each function is working properly.
4. While operating the blower, it is crucial to
avoid contact with any objects, as this may
lead to damage.
WARNING!
Always wear eye, respiratory, hearing, hand,
foot, and body protection to reduce the risk of
injury when operating the blower.
BLOWING
1. When operating the blower, hold the tube
approximately 4 inch (10cm) above the
ground and walk slowly forward using a
sweeping motion from side to side.
MAINTENANCE
WARNING!
Always switch the blower o, remove the
battery pack, and let the blower cool down
before performing cleaning and maintenance
work! Only perform cleaning and maintenance
work according to these instructions! Any
additional maintenance or repairs must be
performed by an Authorized Service Center.
CLEANING
• Clean the debris from the blower tube with
a soft cloth.
• Clean the intake vents from debris to
prevent any damage.
• Do not use strong detergents. Household
cleaners that contain aromatic oils such
as pine and lemon, can damage plastic.
• Clean any additional debris with a soft
cloth. The tool should never come in
contact with water.
TRANSPORTATION
• Always carry the product by its handle.
• Secure the blower properly when
transporting.
9 - EN
SENIXTOOLS.COM
STORAGE
• Store the blower and its accessories in a
dry, well-ventilated place.
NOTE:
To prolong battery life, never store battery
pack in a completely discharged condition.
Make sure the battery pack is charged every
six months.
DISPOSAL
When the blower is no longer usable, do not
dispose of it with household waste. It must be
recycled at a proper facility.
Electrical products should not be
discarded with household products.
Used electrical products must be
collected separately and disposed
of at collection points provided
for this purpose. Talk with local
authorities or dealer for advice on
recycling.
EN - 10
SENIXTOOLS.COM
TROUBLESHOOTING
Suspected malfunctions are often due to causes that the users can x themselves. Therefore,
check the blower using this section. In most cases the problem can be solved quickly.
Problem Possible Cause Solution
Blower does not
start
Battery pack not properly
attached
Remove from blower and
reattach
Battery pack capacity too low Remove and charge battery pack
Battery pack damaged
Contact an Authorized Service
Center for repair
Variable Speed Trigger not set on
start position
Refer to chapter "SWITCHING
ON/OFF"
Blower does not
reach full power
Battery pack capacity too low Charge battery pack
Air vents are blocked Clean the air vents
Vibration or noise is
excessive
Stop operating the blower to
prevent further damage
Contact an Authorized Service
Center for repair
Blower suddenly
stops
Battery pack capacity too low
Remove and recharge battery
pack
Battery too hot
Remove battery pack and let it
cool down
Englishv. 1.1SENIXTOOLS.COM
WARRANTY
SENIX TOOLS LIMITED WARRANTY
FOR FIVE YEARS from the date of original purchase this product is warranted against defects in material or
workmanship. WITH PROOF OF ORIGINAL PURCHASE a defective product will receive free repair. If the product
cannot be repaired it will be replaced free of charge.
For details to obtain warranty coverage, visit senixtools.com, email senix.support@yatusa.com
or call 1-800-261-3981.
• This warranty does not cover repairs necessary due to product accident or abuse, or failure to operate or
maintain the product according to all supplied instructions.
• This warranty does not cover an included battery pack or charger, which offer three-year, replacement-only
coverage. See battery pack or charger instruction manuals for complete warranty details.
• This warranty does not cover expendable items that can wear out from normal use within the warranty
period, including but not limited to drill bits, cutting blades and trimmer spool or line.
• This warranty does not apply to damage resulting from repairs to the product made or attempted by other
than SENIX authorized agents.
• This warranty does not cover the cost of mailing or transporting the power tool to receive warranty
coverage.
• The warranty is void if the product has been used for commercial, professional, or rental service purposes.
• The warranty applies to the original retail purchaser and is not transferable.
• Proof of purchase is required to obtain warranty coverage.
THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, AND EXCLUDES ALL INCIDENTAL OR CONSEQUENTIAL DAMAGE.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
or consequential damages, so these limitations may not apply to you. This warranty gives you specic legal rights
and you may have other rights which vary in certain states or provinces.
NOTE: Battery pack warranty voided if the battery pack is tampered with in any way. SENIX is not responsible for
any injury caused by tampering and may prosecute warranty fraud to the fullest extent permitted by law.
60-DAY MONEY-BACK GUARANTEE. If for any reason within 60 days from the date of original purchase you are
not completely satised with the performance of this SENIX product, you can return it with the original sales receipt
for a full refund.
Latin America: This warranty does not apply to products sold in Latin America. For products sold in Latin America,
see the country-specic warranty information contained in the packaging, call the retailer from which it was
purchased, or visit the website for warranty information.
Free warning label replacement: If your warning labels become illegible or are missing, call 1-800-261-3981 for
a free replacement.
REGISTER ONLINE - senixtools.com/pages/product-registration
Thank you for your purchase! Register your product now for:
Warranty Service: Registering your product will help you obtain more efficient warranty service in case of a problem
with your product.
Confirmation of Ownership: In case of an insurance loss, such as re, flood, or theft, your ownership registration
will serve as proof of purchase.
For your safety: Registering your product will allow us to contact you in the unlikely event a safety notication is
required under the Federal Consumer Safety Act.
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
For customer support, please call 1-800-261-3981 or email us at senix.support@yatusa.com
WARRANTY
Françaisv. 1.1SENIXTOOLS.COM
GARANTIE
SENIX TOOLS GARANTIE LIMITÉE
POUR CINQ ANS à partir de la date d'achat originale, ce produit est garanti contre tout défaut de matériau ou de fabrication. AVEC
LA PREUVE DE L'ACHAT D'ORIGINE, un produit défectueux sera réparé gratuitement. Si le produit ne peut pas être réparé, il sera
remplacé gratuitement.
Pour obtenir des détails sur la couverture de la garantie, visitez senixtools.com, envoyez un courriel à
[email protected] ou appelez 1-800-261-3981.
• Cette garantie ne couvre pas les réparations nécessaires en raison d'un accident ou d'un abus du produit, ou d'un manque
d'utilisation ou d'entretien du produit conformément à toutes les instructions fournies.
• Cette garantie ne couvre pas le bloc-piles ou le chargeur inclus, qui offrent une couverture de remplacement de trois ans
seulement. Consultez les manuels d'instructions du bloc-piles ou du chargeur pour plus de détails sur la garantie.
• Cette garantie ne couvre pas les articles non durables qui peuvent s'user dans le cadre d'une utilisation normale pendant la
période de garantie, y compris, mais sans s'y limiter, les mèches, les lames de coupe et la bobine ou le fil de la débroussailleuse.
• Cette garantie ne s'applique pas aux dommages résultant de réparations du produit effectuées ou tentées par d'autres que les
agents agréés SENIX.
• Cette garantie ne couvre pas les frais d'envoi ou de transport de l'outil électrique pour bénéficier d'une couverture de la
garantie.
• La garantie est annulée si le produit a été utilisé à des fins commerciales, professionnelles ou de location.
• La garantie s'applique au premier acheteur au détail et n'est pas transférable.
• Une preuve d'achat est nécessaire pour obtenir la couverture de la garantie.
CETTE GARANTIE EST DONNÉE EN LIEU ET PLACE DE TOUTES LES AUTRES, Y COMPRIS LA GARANTIE IMPLICITE DE VALEUR
MARCHANDE ET D'ADAPTATION A UN USAGE PARTICULIER, ET EXCLUT TOUT DOMMAGE INCIDENT OU CONSEQUENTIEL.
Certains états n'autorisent pas les limitations sur la durée d'une garantie implicite ou l'exclusion ou la limitation des dommages
accessoires ou indirects, de sorte que ces limitations peuvent ne pas s'appliquer à votre cas. Cette garantie vous donne des droits
légaux spéciques et vous pouvez avoir d'autres droits qui varient dans certains états ou provinces.
NOTE : La garantie du bloc-batterie est annulée si le bloc-batterie est altéré de quelque manière que ce soit. SENIX n'est pas
responsable des blessures causées par une manipulation et peut poursuivre les fraudes à la garantie dans toute la mesure permise
par la loi.
GARANTIE DE REMBOURSEMENT DE 60 JOURS. Si, pour quelque raison que ce soit, vous n'êtes pas entièrement satisfait des
performances de ce produit SENIX dans les 60 jours suivant la date d'achat, vous pouvez le renvoyer avec le ticket de caisse original
pour un remboursement complet.
Amérique latine : Cette garantie ne s'applique pas aux produits vendus en Amérique latine. Pour les produits vendus en Amérique
latine, consultez les informations de garantie spéciques au pays contenues dans l'emballage, appelez le détaillant chez qui vous
avez acheté le produit ou visitez le site Web pour obtenir des informations sur la garantie.
Remplacement gratuit de l'étiquette d'avertissement : Si vos étiquettes d'avertissement deviennent illisibles ou manquent, appelez
1-800-261-3981 pour un remplacement gratuit.
ENREGISTREMENT EN LIGNE - www.senixtools.com/pages/product-registration
Nous vous remercions de votre achat ! Enregistrez votre produit dès maintenant pour bénéficier du service de garantie :
L'enregistrement de votre produit vous permettra d'obtenir un service de garantie plus efficace en cas de problème avec votre produit.
Confirmation de propriété : En cas de sinistre (incendie, inondation ou vol), l'enregistrement de votre produit servira de preuve d'achat.
Pour votre sécurité : L'enregistrement de votre produit nous permettra de vous contacter dans le cas improbable où une notication
de sécurité serait requise en vertu de la loi fédérale sur la sécurité des consommateurs.
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
Pour le service clientèle, veuillez appeler le 1-800-261-3981 ou nous envoyer un courriel à [email protected].
GARANTIE
Françaisv. 1.1SENIXTOOLS.COM
