Bluetooth Turntable
Model: JC-9021
Instruction Manual
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
—Consult the dealer or an experienced radio/TV technician for help.
WARNING
3
Note: The Grantee is not responsible for any changes or modifications not expressly approved
by the party responsible for compliance. Such modifications could void the user's authority to
operate the equipment.
The device has been evaluated to meet general RF exposure requirement.
To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20
cm between the radiator and your body, and fully supported by the operating and installation.
4
7. Hold Down Clip
PRODUCT OVERVIEW
Turntable
1. Turntable Platter
2. Turntable Spindle
3. Counterweight
4. Cue Lever
5. Speed Indicator
6. Speed Selector
8. Tone Arm
9. Cartridge
Front Panel
1. USB Port
2. Disc tray
3. Display
4. Remote sensor
5. AUX IN Jack
6. Power Button
7. Function Knob
8. Repeat/Scan Button
9. Rewind/Previous Button
10. Open/Close Button
11. Record/Erase Button
12. EQ/FM/AM Button
13. USB/MP3/DISC/FOLDER Buttons
14. Play/Pause/Bluetooth OUT/OK Button
15. Fast Forward/Next Button
16. Program/Memory Button
17. Stop/Pair Button
18. Volume Knob
Back Panel
1. FM Antenna
2. DC IN Jack
3. Line Out Jack
1 2 3 4 5 6
7 8 10 12 13 14 16 18
9 11 15 17
DC IN 15V
1
2
3
5
1. OPEN/CLOSE button
Open or close the Disc tray.
2. EQ button
Change the EQ effects(NOR/ROCK/CLASS/
GAME/MOVIE/NEWS/POP/JAZZ).
3. TREBLE+/- buttons
Adjust the treble effect.
4. BASS+/- buttons
Adjust the bass effect.
5. button
Skip to previous track.
button
Skip to next track.
button
Press and hold to rewind to the part you want to
listen.
button
Press and hold to fast forward to the part you want
to listen.
button
Play or pause the track.
6. STOP button
Stop the tracks.
7. NUMERIC buttons
Enter number to choose the desired track.
8. MUTE button
Press to mute the unit, press again to resume.
9. VOL+/- buttons
Adjust the volume.
10.PAIR button
Press to disconnect the Bluetooth device.
11.PROGRAM button
Press to program playback sequences.
12.REPEAT/SCAN button
Repeat the tracks; search and store stations in
Radio mode.
Note: The remote control does not always function
in all modes.
REMOTE CONTROL
6
Essential Setup
1. Unpack the unit and remove all packaging materials.
2. Place the unit on a flat and level surface. The selected location should be stable and free from
vibration.
3. Plug the power adaptor into the electrical outlet and connect another end to the back of the unit.
4. Press the Button on the upper right corner of the front panel. The display will light up and
playback mode will appear on the display.
5. When the unit is playing music, the playback status will appear on the display.
Panel Control
/BT OUT/OK button to pause the playback, press it again to resume playback.
part you want is found.
USB/MP3/DISC/FOLDER Buttons to choose the folder.
STOP/PAlR button to stop playing.
EQ/FM/AM button on unit to change the EQ effects.
REPEAT/SCAN button to select “REP 1” (repeat one) or “REP ALL” (repeat all).
Note: These controls do NOT always function in all playback mode.
Repeat function only works in CD and USB mode.
Program Function
This function enables you to set the playback of tracks into an ordered playlist.
1. Press the STOP/PAlR button; then press the PROG/MEMORY button to activate the
program feature. The display will show “PROG”, “P01” and blinking “000".
2. Press the or button to select your track.
3. Press the PROG/MEMORY button again to confirm.
4. Repeat the step 2 and 3 to program other tracks.
5. After finished, press the /BT OUT/OK button to start playback.
6. Press the STOP/PAlR button once to stop.
7. Press the STOP/PAlR button twice to erase the programmed track, and “PROG" will
disappear from the display.
Note:
automatically erase the programmed playlist.
7
Hook
Belt
Right Twisted Wrong location
Motor
Pulley
1. Unpack the unit and remove all packaging materials.
2. Place the belt on the motor pulley.
Align one of the platter openings with
the motor pulley, and while pulling both
ends of the red ribbon that comes
attached to the belt, place the belt on
the motor pulley, as per the diagram.
When doing this, be careful not to twist the belt.
3. Remove the red ribbon from the belt.
4. Using your hands, slowly rotate the platter 2-3 circles
in a clockwise direction.
This step is for resetting the auto mechanism, getting rid of
any twists in the belt and making sure the belt rides
smoothly along the drive rim on the underside of the platter.
5. Place the slip mat on top of the platter.
Make sure the logo on the mat is facing up.
Note:
irregular rotation occurs. As a rule of thumb, we suggest replacing the belt once a year.
TURNTABLE BELT SETUP
Slip mat
8
The supplied Counterweight is suitable for cartridges
weighing 2.0 - 4.5g. Each mark of the dial represents 0.1g.
The recommended tracking force for the default
cartridge is 3.5 ± 0.5g. You can choose one of the
following methods to adjust the counterweight.
Note: The counterweight is installed by default and
the short line is aligned to “1.5” on the dial.
Method 1
Gently rotate the counterweight in the direction of the arrow until the short line is
aligned to the number “1.5” on the dial.
Method 2
1. Slowly move the tone arm away from the tone arm support. Pull out the stylus protector.
Note: Applying a downward force may cause
the stylus to come off the cartridge. If the
stylus has come off, please reattach the
stylus refer to “HOW TO REPLACE THE
STYLUS”.
2. Carefully rotate the Counterweight until the tone arm achieves a neutral balance.
3. When the tone arm is balanced, move the tone arm to the support.
Hold the counterweight in one hand and rotate the tracking force dial
with the other hand until the “0” is aligned with the center line.
Note: Make sure the tone arm is still neutrally balanced.
4. Gently rotate the counterweight for 1.75 circles
in the direction of the arrow until the center line is aligned
with the number “1.5” on the dial.
Balanced
Counterweight
Tone arm
ADJUST THE COUNTERWEIGHT
Counterweight
Center Line
Short Line
Tracking Force Dial
9
1. Set the Function Knob to TUNER position.
2. Press and hold the EQ/AM/FM button to receive AM or FM signals. Note to extend the FM
antennae when you want to listen to FM stations.
3. To search for available stations, you can:
a. Press and hold the or button on unit.
b. Press the or button on remote control.
c. Press REPEAT/SCAN button on unit or remote control to search and store the available
stations automatically, and it can store 20 stations.
4. Adjust the volume by switching the VOLUME +/- Knob.
5. You can store your favorite station to the unit and listen to it conveniently by following steps:
a. When you are listening to a radio channel, press PROG/MEMORY button on unit or
PROGRAM button on remote control, “P01” will appear and blink on the display.
b. Press USB/MP3/DISC/FOLDER buttons to select a number as the serial number of
the current channel.
c. Press PROG/MEMORY button again to confirm.
d. Repeat the b-c steps to store other your favorite radio channels.
e. To listen to the stored radio channels, just press USB/MP3/DISC/FOLDER buttons on unit
or and button on remote control to select the serial number of your favorite radio
channel, then the selected channel starts to play.
You can improve the signal receiving strength by:
10
AUX IN OPERATION
1. Insert one end of the 3.5mm AUX in cable into the AUX IN Jack on the upper right of
the front control panel, the other end to your playing device.
2. Set the Function Knob to PH/AUX position.
3. Start to play your favourite music on your playing device.
1. Set the Function Knob to USB position.
2. Insert a USB device (only with .mp3 audio files) to the USB Port.
3. The unit will start playback automatically.
4. Use the volume and control buttons to control playback.
Note: Control buttons may not work with all USB devices due to manufacturing differences.
Recording with USB
With this function you can record music from your player onto a USB device in .mp3 format.
1. Insert a USB device into the USB port.
2. Play music in the CD, Phono, AUX, BT mode.
3. The operations are different in specific modes:
a. When playback in CD mode, press the RECORD/ERASE button and then press or
button to select “SEL ONE” (record one) or “SEL ALL” (record all). Finally press the
RECORD/ERASE button to confirm and “REC” will appear on the display. Recording starts.
b. When playback in other modes, press the RECORD/ERASE button and “REC” will appear
on the display which indicating recording starts.
4. Press the STOP/PAlR button on unit to stop recording, and “REC-END” will appear on display.
Now the recording process ends.
Note: If you want to listen to the latest record track, just press button when play in USB mode.
11
Erasing Files on the USB Device
1. Insert a USB device into the USB port and play the song you want to delete.
2. Press and hold the RECORD/ERASE button for about two seconds, “DEL ONE” will appear
on the display.
3. Press the or button to select:
a. DEL ONE - erase the current track
b. DEL FOLD - erase all the audio tracks in the entire folder
c. DEL ALL - erase all the audio tracks of the USB device
4. Press the RECORD/ERASE button again to confirm. “DEL WAIT” will appear, and erasing
process starts.
5. When all tracks and folders erased, “NO SONG" will be shown on display.
With the Bluetooth
®
in function, you can play music from an external Bluetooth
®
device on
the speakers of this unit.
1. Set the Function Knob to BT position. “Disconnect” will blink on display.
2. Turn on your external Bluetooth
®
device and pair with the “JC-9021” device.
3. When the Bluetooth
®
connection is established, you will hear a short confirmation sound
from the unit, and “Connected” will appear on display.
4. Start to play your favorite music on the connected device.
5. To disconnect the current Bluetooth
®
device, press and hold STOP/PAlR button on unit or
press PAIR button on remote control.
Bluetooth
®
Transmitter
You can play music from this unit on external Bluetooth
®
speakers, soundbar, earbuds, or
headphones.
1. Set the unit to CD/ Phono/ AUX/ USB/ Tuner mode.
2. Press and hold /BT OUT/OK button to activate Bluetooth
®
Transmitter function.
“BT” will blink on display.
3. Power on your Bluetooth
®
device and activate its Bluetooth
®
pairing mode.
4. Press and hold REPEAT/SCAN button on the unit or remote control to search for the
external device.
5. After a few seconds, the panel will appear the Bluetooth
®
names of external devices,
then press or button to select the desired one and press /BT OUT/OK
button to confirm.
6. After a few seconds, the external device will connect to this unit successfully.
“BT” will stop blinking.
7. To turn off BT OUT mode, press and hold /BT OUT/OK button.
12
1. Press the Power Button to turn on the unit and open the cover.
2. Set the Function Knob to PH/AUX position.
3. Detach the stylus protector by pulling straight in the direction shown.
4. Place a vinyl record on the Turntable by aligning the Turntable Spindle to the record hole.
5. Press the Speed Selector to select 33, 45 or 78 to match the play speed of the record.
6. Unlock the Hold Down Clip.
7. Raise the Cue Lever to lift the tone arm off the tone arm support.
8. Gently move the tone arm to the edge of the record (or the starting point of a track).
9. Release the Cue Lever to put the tone arm onto the record. Turntable will begin playback.
10. Turn the VOLUME +/- Knob to adjust the volume. To pause/stop during playback, raise
the Cue Lever to lift the tone arm off the record.
11. When finished listening:
a. Raise the Cue Lever to lift the tone arm off the record.
b. Move the tone arm to its support.
c. Lower the Cue Lever to release the tone arm.
d. Lock the Hold Down Clip.
Note:
13
14
15
Remove and install the stylus
1. Pull down the front of the stylus and then pull out in straight direction.
2. Engage the stylus in the cartridge as the follow diagram. Lift the stylus up until you hear a
click.
Note: Make sure there is no gap between the stylus and the cartridge.
HOW TO REPLACE THE STYLUS
The stylus should last about 200 hours under normal use. However, it is recommended that the stylus
be replaced as soon as you notice a change in sound quality. Prolonged use of a worn-out stylus
may damage the record. Wear and tear on the stylus will be accelerated when playing 78 RPM
records. The higher speed of 78 RPM records can wear the stylus more quickly .
16
In case of trouble with the unit, please look through the problems below and see if you can solve them
yourself before calling your dealer.
General
Radio
Record
Player
CD Player
Bluetooth
®
No power
No sound
The sound has
interference
Cannot listen to
any station or
signal is weak
Will not play
Sound skips
Will not play
Will not play
Check the connection to the AC power source. Make sure the AC source is not a
switched outlet and if it is, turn the switch on. Make sure there is power to the AC
outlet by plugging another item such as a lamp or fan.
Adjust the volume.
Connect the AUX IN cables into the correct jack.
The unit is too close to a TV set or similar appliance. Relocate the unit further away
from them or turn the other appliances off.
Tune in the station properly.
If a TV is near the unit, turn it off.
Rotate the unit or antenna wire for the best reception position.
Turn the VOLUME KNOB clockwise.
Loosen the screw and detach the stylus guard. The stylus guard is a white plastic
cover that protects the stylus during transportation. Failing to remove this guard will
not allow the needle to contact the grooves of the record and no sound will be heard!
If the stylus is worn-out, change the stylus. Select the correct playback speed.
Place the unit on a stable surface to avoid vibration and shock. Make sure the unit is
level both front to back and side to side.
Clean the surface of the record/disc.
Do not use scratched, damaged or warped records/discs.
Turn the VOLUME knob clockwise and rotate the FUNCTION KNOB to “CD”.
Load a disc with the playback side facing down.
If the disc is dirty, clean the surface of the disc.
A blank disc has been loaded. Load a pre-recorded disc.
Depending on the disc, it may not be possible to play back CD-R/CD-RW discs. Try
again with another disc.
You cannot play unfinalized CD-R/CD-RW discs. Finalize and try again.
Device is NOT paired properly; turn OFF Bluetooth, turn ON Bluetooth and repair
device.
Function Problem Solution
17
SPECIFICATIONS
Made in China
Turntable Speed: 33-1/3, 45, 78 RPM
Speaker Output: 10W x 2
Speaker Frequency: 20Hz-20KHz
Compatible CD Formats: CD / CD-R / CD-RW / CD-MP3
AM Frequency Range: 520 - 1710 KHz
FM Frequency Range: 87.5-108 MHz
Bluetooth
®
Version: 5.3
Input: Aux In, USB
Output: Line Out
Power Source: AC 100-240V~50/60Hz, DC 15V/1.5A
Accessories Included: AC Adaptor, Felt Slipmat,
Remote Control, 45RPM Adapter, Aux In Cable, User Manual
Support@otic.shop
Shenzhen Junlan Electronic Ltd.
Add: No. 71 Lijing South Road, Pingshan District, Shenzhen, CHINA
18
