INSTRUCTION MANUAL
VPT-1500 | VPT-2500
HI-RES
OVERVIEW
AC POWER PORT
PRE-AMP
SWITCH
RCA OUTPUT
WITH GROUND
CONTROL
BUTTON
CARTRIDGE
TONEARM
TONEARM
HOLDER
TONEARM
LIFT LEVER
ANTI-SKATE
KNOB
SLIPMAT
PLAT TER
COUNTER
WEIGHT
SPEED
SELECTOR
45 RPM
ADAPTOR
REMOVABLE
HEADSHELL
DUST
COVER
AUTO-STOP
SWITCH
TOP VIEW
BACK VIEW
IN THE BOX
CARTRIDGE
RECOMMENDED
DOWNFORCE
MODEL
NUMBER
COUNTERWEIGHT
ALIGNMENT
ORTOFON
2M SERIES
AUDIO TECHNICA
AT-VM95E SERIES
ORTOFON
OM SERIES
1.6-2.0g
1.8-2.2g
1.5-2.0g
BACK LINE
REQUIRES DOWN-
FORCE SCALE
REQUIRES DOWN-
FORCE SCALE
FRONT LINE
BACK LINE
FRONT LINE
VPT-250 0
(DEFAULT)
VPT-1500
(DEFAULT)
VPT-1500
VPT-250 0
VPT-250 0
VPT-1500
TURNTABLE
DUST COVER POWER CORD RCA CABLE
REMOVABLE
HEADSHELL
45 RPM
ADAPTOR
COUNTER
WEIGHT
PL ATTER
SILICONE
SLIPM AT
SPECIFICATIONS
GENERAL
POWER INPUT:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC 100-240V ~ 50HZ/60HZ
BLUETOOTH VERSION / PROFILE / FREQUENCY: . . . . . . Bluetooth V5.4 / A2DP, AVRCP
2.402GHZ-2.480GHZ
SUPPORTED BLUETOOTH CODECS: . . . . . . . . . . . . . . . . Qualcomm
®
aptX
™
Adaptive,
aptX
™
HD, aptX
™
, SBC
OUTPUTS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA (Built-in pre-amp)
200-280 MV (5 CM/SEC AT 1 KHZ-10DB)
PHONO
2.5MV±3DB (5 CM/SEC AT 1 KHZ-10DB)
DIMENSIONS:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . W 16.93” x L 14.25“ x H 4.53”
W 430mm x L 362mm x H 115mm
WEIGHT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VPT-1500: 5.66 kgs / 12.48 lbs (w/ cover)
VPT-2500: 6.15 kgs / 13.56 lbs (w/ cover)
ACCESSORIES INCLUDED:. . . . . . . . . . . . . . . . . . . . . . . . . Dust Cover, 45 RPM Adapter,
6’ RCA cable with ground
TURNTABLE
DRIVE METHOD: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Belt-drive
PLATTER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Die-cast aluminum
CARTRIDGE:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Audio Tecnhica VM95E (VPT-1500)
Ortofon 2M Red (VPT-2500)
MOTOR: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC Servo-Controlled
SPEEDS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33-1/3 RPM & 45 RPM
PHONO PRE-AMP GAIN:. . . . . . . . . . . . . . . . . . . . . . . . . . . 35 dB Nominal, RIAA Equalized
SIGNAL-TO-NOISE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >45 dB
WOW & FLUTTER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <0.175
TONEARM LENGTH: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225mm
OVERHANG: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18.50mm
TRACKING ERROR ANGLE: . . . . . . . . . . . . . . . . . . . . . . . . <2 Degrees
SPECIFICATIONS
GENERAL
POWER INPUT:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC 100-240V ~ 50HZ/60HZ
BLUETOOTH VERSION / PROFILE / FREQUENCY: . . . . . . Bluetooth V5.4 / A2DP, AVRCP
2.402GHZ-2.480GHZ
SUPPORTED BLUETOOTH CODECS: . . . . . . . . . . . . . . . . Qualcomm
®
aptX
™
Adaptive,
aptX
™
HD, aptX
™
, SBC
OUTPUTS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA (Built-in pre-amp)
200-280 MV (5 CM/SEC AT 1 KHZ-10DB)
PHONO
2.5MV±3DB (5 CM/SEC AT 1 KHZ-10DB)
DIMENSIONS:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . W 16.93” x L 14.25“ x H 4.53”
W 430mm x L 362mm x H 115mm
WEIGHT: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VPT-1500: 5.66 kgs / 12.48 lbs (w/ cover)
VPT-2500: 6.15 kgs / 13.56 lbs (w/ cover)
ACCESSORIES INCLUDED:. . . . . . . . . . . . . . . . . . . . . . . . . Dust Cover, 45 RPM Adapter,
6’ RCA cable with ground
TURNTABLE
DRIVE METHOD: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Belt-drive
PLATTER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Die-cast aluminum
CARTRIDGE:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Audio Tecnhica VM95E (VPT-1500)
Ortofon 2M Red (VPT-2500)
MOTOR: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC Servo-Controlled
SPEEDS: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33-1/3 RPM & 45 RPM
PHONO PRE-AMP GAIN:. . . . . . . . . . . . . . . . . . . . . . . . . . . 35 dB Nominal, RIAA Equalized
SIGNAL-TO-NOISE: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >45 dB
WOW & FLUTTER: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <0.175
TONEARM LENGTH: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225mm
OVERHANG: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18.50mm
TRACKING ERROR ANGLE: . . . . . . . . . . . . . . . . . . . . . . . . <2 Degrees
PRE-AMP SWITCH
LINE: Set the switch to line if connecting to line line-level input on speakers or amplifier.
PHONO:
Set the switch to phono if using external pre pre-amp or amplifier with phono input.
AUTO-STOP SWITCH
ON: Platter will begin spinning when tonearm hovers over the edge of the
record
and stop spinning at the end of the record to prevent stylus wear.
OFF: Platter will spin when speed control is set to 33 or 45, regardless of tonearm position.
ADDITIONAL NOTES
• Unit automatically powers off if no playback for 15 minutes.
• Wired RCA output is disabled when mode is set to Bluetooth Out.
• Unit automatically starts Bluetooth pairing when entering Bluetooth Out mode.
• To reset the unit, press and hold the function button (5 seconds).
This will remove and forget all previously paired Bluetooth devices.
For user guide and more product information, please visit www.victrola.com/hi-res
USER GUIDE
Important Safety Instruction
1. Read these instructions – All the safety and operating instructions should be read before this product is
operated.
2. Keep these instructions – The safety and operating instructions should be retained for future reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water or moisture –
for example, in a wet basement or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at the plugs, convenience
receptacles, and at the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
12. Unplug the apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged
in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
14. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
a. Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no
user-serviceable parts inside. Refer servicing to qualified personnel.
b. The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions in the literature accompanying the appliance.
15. This equipment is a Class II or double insulated electrical appliance. It has been designed in
such a way that it does not require a safety connection to electrical earth.
16. The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
17. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such
as vases, shall not be placed on apparatus.
18. The use of the equipment in moderate climate.
WARNINGS
Safety Information
1. In order to shut off power to this product completely, unplug the power cord from the wall outlet. Be
sure to unplug the unit if you do not intend to use it for an extended period of time, such as during a
vacation.
2. Use of controls, adjustments and performance of procedures other than those specified herein may
result in hazardous radiation exposure.
3. To prevent electric shock, match wide blade of plug to wide slot, fully insert.
4. If this product is experience problems during operation, contact qualified service centers, and do not
use the product in defective states.
Before Use
1. Choose unit installation location carefully. Avoid placing it in direct sunlight or close to a source of heat.
Also avoid locations subject to vibrations and excessive dust, cold or moisture. Keep away from
sources that hum, such as transformers or motors.
2. Do not open the cabinet as this may result in damage to the circuitry or electrical shock. If a foreign
object should get into the set, contact Customer Service.
3. Be sure not to handle record with dirty fingers. Never play a record that has a crack on the surface.
4. When removing the power plug from the wall outlet, always pull directly on the plug, never pull the cord.
5. To protect the stylus, don’t forget to put on the white protective needle cover after use.
6. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Use a clean,
dry cloth.
7. In order to shut off the power to this product completely, unplug the power cord from the wall outlet. Be
sure to unplug the unit if you do not intend to use it for an extended period of time, such as a vacation.
8. Keep this manual in a safe place for future reference.
19. WARNING: Please refer the information on exterior bottom/back enclosure for electrical and safety
information before installing or operating the apparatus.
20. The ventilation should not be impeded by covering the ventilation openings with items such as
newspaper, table-cloths, curtains etc.
21. No naked flame sources, such as lighted candles, should be placed on the apparatus.
22. Do not install this equipment in a confined space such as a book case or similar unit.
23. The symbol with indicates AC voltage.
24. CAUTION, These servicing instructions are for use by qualified service personnel only. To reduce the
risk of electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
SAFETY INFO
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC & IC WARNINGS
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
The device must not be co-located or operating in conjunction with any other antenna or transmitter. To
maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from
nearby persons.
IC Radiation Exposure statement
This device complies with RSS247 of Industry Canada. This device complies with Industry Canada
license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
The device must not be co-located or operating in conjunction with any other antenna or transmitter.
This device complies with IC radiation exposure limits set forth for an uncontrolled environment. The device
should be installed and operated with a minimum distance of 20cm between the radiator and your body.
Cet appareil se conforme à RSS247 de Canada d'Industrie. Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux appareils radio exempts de licence. Son fonctionnement est sujet
aux deux conditions suivantes:
(1) le dispositif ne doit pas produire de brouillage prejudiciable, et (2) ce dispositif doit accepter tout
brouillage recu, y compris un brouillage susceptible de provoquer un fonctionnement indesirable.
L'appareil ne doit pas être localisé ou fonctionner avec d'autres antennes ou transmetteurs. Cet appareil est
conforme aux limites d'exposition aux rayonnements de la IC établies pour un incontrôlé environnement.
L'appareil doit être installé et utilisé avec une distance minimale de 20cm entre le radiate et votre corps.
Victrola is a registered trademark of Innovative Technology Electronics, LLC.
United States
Victrola (Innovative Technology Electronics, LLC) warrants to the original retail purchaser that this product
will be free from defective materials and workmanship for one (1) year from the date of purchase, subject to
the limitations below. This warranty period is not extended if we replace the product.
To obtain a replacement under the terms of this warranty, you must contact the dealer from which it was
purchased with your original receipt. If assistance from the dealer from which it was purchased is
impossible, you may contact our customer service for warranty assistance at victrola.com/contact.
Except as limited below, if the product proves defective in either material or workmanship within one (1) year
from the date of purchase, Victrola will replace the product at no charge. If the product model is no longer
available and cannot be replaced with an identical model, Victrola will issue a merchandise credit for the
purchase price to be redeemed at victrola.com.
Limitations:
• This limited warranty does not cover failure of the product arising, in whole or in part, from
improper installation, storage, transportation, misuse, abuse, accident, neglect, mishandling,
unauthorized repair, modification, or wear from ordinary use or environmental deterioration.
• This limited warranty does not cover cosmetic damage, including paint damage, or consequential
damage to other components or premises which may result for any reason from the failure
of the product.
• This limited warranty is null and void for products not used in accordance with Victrola’s instructions.
• This limited warranty terminates if the original retail purchaser sells or otherwise transfers this product.
• This limited warranty is null and void for defects or damage caused by installation or repair
performed by any person or entity other than a Victrola authorized installer or dealer.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state,
jurisdiction to jurisdiction or country to country. All express and implied warranties for the product, including but
not limited to any implied warranties of merchantability and fitness for a particular purpose, are limited in time to
the term of this warranty. Some states, jurisdictions or countries do not allow the exclusion of certain implied
warranties or conditions, or limitations on how long an implied warranty or condition lasts, so this limitation may
not apply to you. Victrola’s responsibility for malfunctions and defects in hardware is limited to replacement or
repair as set forth in this warranty statement. Victrola does not accept liability for special, punitive, consequential
or incidental damages or losses, whether direct or indirect, including without limitation, any liability for third party
claims against you for damages or losses or for products not being available for use. The maximum liability for
which Victrola may be responsible will be no more than the amount you paid for the product that is the subject of
the claim. Some states, jurisdictions or countries do not allow the exclusion or limitation of special, indirect,
incidental or consequential damages, so the above limitation or exclusion may not apply to you.
WARRANTY
Canada and US Territories
The Warranty on this product shall comply with applicable law when sold to a consumer in Canada or a US
Territory. To obtain any applicable warranty service, please contact the dealer from which you purchased
the product, or the distributor that supplied the product, with your original receipt.
If assistance from the dealer from which it was purchased is impossible, you may contact our customer
service for warranty assistance at victrola.com/contact.
If this product proves defective in either material or workmanship, Victrola will replace the product at no
charge. If the product model is no longer available and cannot be repaired effectively or replaced with an
identical model, Victrola at its sole option may replace the unit with a current model of equal or greater
value.
Outside the U.S, Canada, and US Territories
The Warranty on this product shall comply with applicable law when sold to a consumer outside of the
United States, Canada, and US Territories. To obtain any applicable warranty service, please contact the
dealer from which you purchased the product, or the distributor that supplied the product, with your original
receipt.
Please note: As a result of continual improvements, the design and specifications of this product
are subject to change without notice.
Bluetooth is a registered trademark of Bluetooth SIG, Inc. Other trademarks and trade names
are those of their respective owners.
Qualcomm aptX is a product Qualcomm Technologies, Inc. and/or its subsidiaries. Qualcomm
is a trademark of Qualcomm Incorporated, registered in the United States and other countries.
aptX is a trademark of Qualcomm technologies International, Ltd., registered in the United States
and other countries.
Made In China.
