产品使用说明书
碳纤维移动电源C1
包装清单
数据线 × 1移动电源 × 1
说明书 × 2
产品参数
产品型号: C1
产品名称: 碳纤维移动电源
接口类型: USB-C，USB-A
锂电池能量 (额定): 10000mAh 3.85V (38.5Wh)
额定输入电压、电流:
USB-C: 5V⎓3A 9V⎓2A 12V⎓1.5A (18W Max)
额定输出电压、电流:
USB-C: 5V⎓2A 9V⎓2.22A 10V⎓2.25A 12V⎓1.67A (22.5W Max)
USB-A: 5V⎓2A 9V⎓2A 10V⎓2.25A 12V⎓1.5A (22.5W Max)
总输出: USB-C+USB-A: 5V⎓3A
额定容量: 6000mAh (5V⎓2A)
转换效率：≥77%
产品尺寸: 122 × 61 × 11.6mm
产品重量: ≈165g
执行标准：GB 4943.1-2022 GB 31241-2022
*双击按键启动小电流模式后，可以给手表，耳机等小电流智能设备
充电。
使用说明
01. 按键操作逻辑：
a. 长按按键开机/关机。
b. 智能识别输出，支持边充边放。
c. 双击按键启动小电流模式，此时指示灯亮起。
d. 双击按键退出小电流模式，此时指示灯熄灭。
指示灯
×2
03. 当开启快充模式时，快充指示灯亮起：
02. 连接充电线即可给设备充电，并且本移动电源支持边充边放。
04. 按下按钮检查电池电量。
05. 通过USB-C接口为您的移动电源充电。
指示灯
0%-25%
25%-50%
50%-75%
75%-100%
官方微信 官方抖音
官方网站：www.sharge.com
联系方式：400-075-5501
制 造 商：闪极科技（深圳）有限公司
地 址：深圳市龙华区龙华街道 油松社区恒丰小区3号楼新中泰
工业园3楼305室
此符号表明本产品不得作为生活垃圾
处理，相反，应将其交付给适用的收集
点进行电子设备回收。
Made in China 中国制造
JCビジネスサポート
株式会社
USER MANUAL
CarbonBlade Power Bank
Product Information
Package Contents
Cable × 1
User Manual × 2
Power Bank × 1
Product Model: C1
Product Name: CarbonBlade Power Bank
Port Type: USB-C, USB-A
Battery Capacity (rated): 10,000mAh 3.85V (38.5Wh)
Input:
USB-C: 5V⎓3A, 9V⎓2A, 12V⎓1.5A (18W Max)
Output:
USB-C: 5V⎓2A, 9V⎓2.22A, 10V⎓2.25A, 12V⎓1.67A (22.5W Max)
USB-A: 5V⎓2A, 9V⎓2A, 10V⎓2.25A, 12V⎓1.5A (22.5W Max)
Total Output: USB-C+USB-A: 5V⎓3A
Rated Capacity: 6,000mAh (5V⎓2A)
Conversion Rate: ≥77%
Dimensions: 122 × 61 × 11.6mm
Weight: ≈165g
Product Introduction
01. Button Operation：
a. Long press: Power ON/OFF.
b. Double-click the button to activate low current mode, at
this point the indicator light will turn on.
c. Double-click the button to exit low current mode, at this
point the indicator light will turn off.
Indicator Light
×2
After double-clicking the button to activate the low current
mode, you can charge small current smart devices such as
watches and earphones.
*
Indicator Light
0%-25%
25%-50%
50%-75%
75%-100%
04. Press the button to check the battery level.
03. When the fast charging mode is enabled, the fast
charging indicator light will turn on.
05. Charge your power bank through the USB-C port.
02. Connect the charging cable to the power bank to charge
your device. This power bank supports simultaneous
charging and discharging.
Made in China
Join our Discord Follow us on Instagram
@SHARGE_OFFICIALSHARGE
E-mail: [email protected]
Official Website: www.sharge.com
Manufacturer: Sharge Technology (Shenzhen) Co., Ltd.
Address: Room 305, 3rd Floor, Xinzhongtai Industrial Park,
Building 3, Hengfeng Community, Longhua Street,
Longhua District, Shenzhen, Guangdong, China
This symbol indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic
equipment.
