Manual de instrucciones
Instruction manual
Manuel d’instructions
Bedienungsanleitung
Manuale di istruzioni
Manual de instruções
Instructiehandleiding
Instrukcja obsługi
Návod k použití
Freidora dietética/ Air fryer.
CECOFRY ADVANCE DOUBLE
CECOFRY ADVANCE DOUBLEL
51
ENGLISH
1. PARTS AND COMPONENTS
Appliance
Fig. 1
1. Housing
2. Control panel
3. Basket handle
4. Basket
5. Rack
6. Ventilation grille
7. Power cord
Control panel
Fig. 2
8. Power icon
9. Time icons
10. Pre-set programmes
11. Temperature icons
12. Start/Pause icon
13. Left basket icon
14. Cooking synchronisation icon
15. Preheating icon
16. Same conguration on both baskets icon
17. Right basket icon
18. Left basket display
19. Right basket display
The graphics in this manual are schematic representations and may not exactly match the
product.
2. BEFORE USE
- This product includes a safety package to protect it during transport. Unpack the appliance
and keep the original packaging and materials in a safe place. It will help prevent any
damage if the product needs to be transported in the future. In case the original packaging
is disposed of, make sure all packaging materials are recycled accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or not in good condition, immediately contact the Technical Support Service
CECOFRY ADVANCE DOUBLEL
52
ENGLISH
of Cecotec.
- Clean the inside and the outside of the device with a damp cloth. Do not wet the heating
elements.
- Clean the baskets and racks thoroughly with hot water, detergent and a non-abrasive
sponge. (Fig. 3)
- Place the racks properly in the baskets and place the baskets again in the device to be able
to use it. (Fig.4)
- Do not ll the device with oil or any other liquid.
3. OPERATION
With this device you can cook at once with both baskets with a dierent temperature and time,
which will save time to prepare your favourite recipes. This device includes a recipe book with
several recipes which you will be able to cook easily.
1. Place the device on a at, even and waterproof surface. Never place it on a glass-ceramic
hob.
2. Plug the power cord to the electric circuit.
3. Press the power icon (8) to turn the device on.
4. Remove the baskets and place the food on the racks.
5. Carefully match the basket guides and the body of the air fryer to place them again in their
initial position.
6. Select the basket (13/17) or baskets (16) you wish to programme and then select a
programme or set the time and temperature manually.
7. Press the Start/Pause icon (12) for the device to start cooking.
8. When the device nished the cooking, it will warn you with a sound signal.
9. Check if the ingredients are cooked as desired. Otherwise, put the basket back inside the
device and set the timer for a few more minutes.
10. When the food is cooked as desired, remove the baskets and place them on a heatproof
surface. Depending on the type of ingredients, steam may be released, so be careful when
removing the baskets.
11. Empty the baskets in a bowl or plate. Use tongs to remove the ingredients. Be careful not
to burn yourself. Do not place the basket upside down to remove the food.
12. You can use the device again just after having used it.
Note
- The device features a safety system, with which if the baskets are not correctly placed into
position, the device will not start working.
- Do not ll the basket over the ‘Max’ mark (screen-printed in the inside of the basket).
- The fan may continue working after cooking, even if the device is o. This is normal, as the
fan is cooling down the device.
CECOFRY ADVANCE DOUBLEL
53
ENGLISH
- Do not touch the baskets nor the inferior of the air fryer during or after its use, as it reaches
high temperatures. Hold the baskets by their handle.
Control panel
Fig. 2
8. Power icon
- When the baskets and racks are correctly placed in the device, the power icon (8) will
light up. If you press this icon (8), the left basket icon (13), the same conguration on both
baskets icon (16) and the right basket icon (17) will all light up at once.
- To turn o the device, hold down this icon (8) for approximately 3 seconds.
- To cancel the cooking, press this icon (8) once and the word ‘Cool’ will automatically appear
on the display, which means the programme is being cancelled, when it is completely
cancelled the display will show ‘End’. To start cooking again, press the icon (8), the previous
icons will light up.
9. Time icons
- With both icons (9), placed over and below the watch icon, you can increase or decrease
the cooking time as desired.
- However, to set the time, rst you need to select a basket (13 or 17) or both baskets (16).
10. Pre-set programmes
This air fryer features 6 programmes with pre-set temperature and time (10), you can check
them in this table:
Icon Programme Temperature Time Quantity Stir
Chips 200 ºC 20
min
400-500 grams
approx.
Yes
Chicken
wings
200 ºC 25
min
Basket surface Not necessary
Fish 180 ºC 10 min 250 grams
approx.
Not necessary
Dessert 170 ºC 13 min - Not necessary
CECOFRY ADVANCE DOUBLEL
54
ENGLISH
Vegetables 160 ºC 16 min - Depends on the type
of vegetable
Dehydrate 60ºC 6 h Basket surface Not necessary
Note
This information is indicative, as ingredients dier in origin, size, shape and brand, we cannot
guarantee the best setting for the ingredients that you are using.
Tips
- Smaller ingredients require shorter preparation time than the larger ones.
- A larger quantity of ingredients only requires a slightly longer preparation time, and a
smaller quantity of ingredients only requires a slightly shorter preparation time.
- Stirring small ingredients during the frying process optimises the result and can help
prevent unevenly cooked ingredients. To do so, remove the basket and shake it.
- Add some oil to raw chips for a crispier result.
- The optimal amount for preparing crispy fries is 400 grams.
- Do not use the device to fry greasy food (such as sausages).
- Food that can be cooked in an oven can also be cooked with the device.
- Pre-made dough requires a shorter preparation time than home-made dough.
- You can also use the device to reheat ingredients. To do so, set the temperature at 150ºC
for 5-10 minutes.
11. Temperature icons
- With both icons (11), placed over and below the thermometer, you can increase or decrease
the cooking temperature as desired.
- However, to set the time, rst you need to select a basket (13 or 17) or both baskets (16).
12. Start/Pause
This icon (12) will allow you to start or pause the selected cooking.
- If you press this icon (12) after selecting the programme (10) or temperature (11) and time
(9), the device will start cooking.
- If you press this icon (12) when there is a cooking in process, you will pause it. To restart it,
press it again (12).
13. Left basket
Use this icon (13) to set only the left basket. Press the icon (13), select the desired time (9) and
temperature (11) or programme (10). Next, press the Start/Pause icon (12) to start cooking.
CECOFRY ADVANCE DOUBLEL
55
ENGLISH
14. Synchronisation
- This function is useful when you have set dierent cooking times on the baskets and you
wish them to nish at once. With this function, if in the left basket you have selected 20
min and in the right basket you have selected 10 min, it will start the cooking process in the
right basket 10 minutes after so both cooking processes nish at once.
- To programme this function, select rst the left basket (13) or right (17), then the desired
programme (10) or the desired time (9) and temperature (11). Press the ‘Sync’ icon (14) and
it will stop ashing. Next, press the Start/Pause icon (12).
Note
- When this function starts the basket with less time programmed will enter standby mode
and the display will show ‘Hold’ until there is no time dierence between them.
- If you remove any basket when the device is operating: the display will show ‘Pot’ if you
remove the left basket and ‘Out’ if you remove the right basket, if you remove both baskets
it will show ‘Pot Out’. If it takes you more than 90 seconds, but less than 5 minutes on
placing the removed basket, the basket you have removed will resume the cooking
process. When you place the basket back in place, the device will resume the cooking, but
the synchronisation function will be deactivated.
15. Preheating
- With this function, you will start preheating the selected basket, that is, either the right or
left basket or both baskets.
- To select this function, select rst the basket (13, 16 or 17) you wish to use, then select the
preheating function (15) and set the desired preheating temperature (11). The preheating
time is 5 minutes by default, but if you wish to cancel it at any time, press the power button
(8).
- Once the preheating has nished, press the icons 13 or 17, depending on the preheated
basket, and press the programme (10) or set the desired time (9) and temperature (11)
manually and next, press the Start/Pause icon (12).
16. Same conguration on both baskets L=R
- This function is used to use the same cooking process on both baskets, that is, if you press
this icon and then the chips programme, this setting will be activated on both baskets.
- To use it, rst select one of the baskets (13 or 17) and set the desired time (9) and
temperature (11) or programme (10) and then press this function (16). Next, press the
Start/Pause icon (12) to start cooking.
17. Right basket
Use this icon to set only the right basket. Press the icon (17), select the desired time (9) and
temperature (11) or programme (10). Then, press the Start/Pause icon (12) to start cooking.
CECOFRY ADVANCE DOUBLEL
56
ENGLISH
4. CLEANING AND MAINTENANCE
Cleaning
- Always clean the appliance after each use.
- Disconnect the appliance from the power supply and allow it to cool down before cleaning
it.
- Do not use metallic tools or abrasive products to clean the baskets and racks.
- Use a soft, damp cloth to clean the product exterior surface.
- Never immerse the appliance in water or other liquid.
- Do not use abrasive cleaners or scouring pads to clean the product.
- Clean the baskets thoroughly with hot water, detergent and a non-abrasive sponge. Rinse
them well and dry it before introducing them again in the device.
- Do not introduce wet baskets in the main body.
- We recommend the use of a degreasing liquid to remove any remaining dirt.
- If there is dirt stuck in the basket and rack, we recommend lling the basket with hot water
and detergent and then clean it with a non-abrasive sponge.
- Clean the heating element with a soft cleaning brush to remove any food residue. Be
careful not to damage the heating element.
Tip
Remove the basket to let the device to cool down more quickly.
Warning
The baskets and racks are not dishwasher safe.
Storage
- Unplug the device and allow it to cool down.
- Make sure all its parts are clean and dry when you store it.
- Wring the power cord.
CECOFRY ADVANCE DOUBLEL
57
ENGLISH
5. TROUBLESHOOTING
Problem Possible cause Solution
The device does not work. The product is not plugged in. Plug the device in.
You have not set the timer. Press the power icon (8) and
start a programme.
The ingredients inside the
device are not fried.
There are too many
ingredients inside the basket.
Place smaller pieces inside
the basket so they are cooked
more evenly.
The temperature used is too
low.
Increase temperature.
The preparation time is not
enough.
Increase the time.
The ingredients are cooked
unevenly in the air fryer.
Some types of food need to
be sautéed during the cooking
process.
Ingredients that lie on top
of or across each other (e.g.
chips or nuggets) need to be
stirred during the preparation
time.
Fried food is not crispy when
they come out the device.
You used a type of food that
is meant to be prepared in a
traditional deep fryer.
Oil the food a little bit to get a
crispier result.
The container cannot t in the
gap in the device.
There are too many
ingredients inside the basket.
Do not ll the device with
food over the ‘Max’ mark.
The basket is not placed in
the container correctly.
Place the basket inside the
container until it clicks.
White smoke comes out of
the appliance.
You are preparing greasy
ingredients.
When greasy food is cooked,
a large amount of oil will leak
into the container. Cooking oil
produces white smoke, and
the container may heat up
more than usual. This does
not aect the appliance or the
result.
The container is still greasy
from previous uses.
White smoke is caused by
heating up oil in the container.
Make sure you clean the
container properly after each
use.
CECOFRY ADVANCE DOUBLEL
58
ENGLISH
Chips are cooked unevenly in
the device.
The right kind of potato is not
being used.
Use fresh potatoes and make
sure they stay consistent
while being cooked.
If you use frozen chips, use
chips that are special for oven
cooking.
You did not rinse the chips
properly before you cooked
them.
Rinse the potato sticks
properly to remove the
starch.
Fried food is not crispy when
they come out the device.
Make sure you dry the potato
sticks properly before adding
the oil.
Make sure you dry the potato
sticks properly before adding
the oil.
Cut the potato sticks on
smaller pieces for crispier
results.
Add a little bit more of oil for
a crispier result.
6. TECHNICAL SPECIFICATIONS
Product reference: 04338
Product: Cecofry Advance Double air fryer
Power: 2950 W
Voltage: 220-240 V~
Frequency: 50/60 Hz
Maximum operating capacity: 4 litres per basket
Temperature setting: 80°C—200°C
Timer: 0-60 min.
Manufactured in China | Designed in Spain
Technical specications may change without prior notication to improve product quality.
7. DISPOSAL OF OLD ELECTRICAL APPLIANCES
This symbol indicates that, according to the applicable regulations, the
product and/or battery must be disposed of separately from household
waste. When this product reaches the end of its shelf life, you should
CECOFRY ADVANCE DOUBLEL
59
ENGLISH
dispose of the batteries/accumulators and take them to a collection point designated by the
local authorities.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
Compliance with the above guidelines will help to protect the environment.
8. TECHNICAL SUPPORT AND WARRANTY
Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the
time of delivery of the product under the terms, conditions and deadlines established by the
applicable regulations.
It is recommended that repairs be carried out by qualied personnel.
If at any moment you detect any problem with your product or have any doubt, do not hesitate
to contact Cecotec ocial Technical Support Service at +34 963 210 728.
9. Copyright
The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES,
S.L. All rights reserved. The contents of this publication may not, in whole or in part, be
reproduced, stored in a retrieval system, transmitted or distributed by any means (electronic,
mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC
INNOVACIONES, S.L.
Fig./Img./Abb./Afb./ Rys./Obr. 1
1
2
3
4
5
6
7
Fig./Img./Abb./Afb./ Rys./Obr. 2
11
12
9
8
10
13 14 15 16 17
Fig./Img./Abb./Afb./ Rys./Obr. 3 Fig./Img./Abb./Afb./ Rys./Obr. 4
Cecotec Innovaciones S. L.
C/de la Pinadeta s/n, 46930
Quart de Poblet, Valencia, Spain
www.cecotec.es
EA01211202
