Manual de instrucciones
Instruction manual
Manuel d’instructions
Bedienungsanleitung
Manuale di istruzioni
Manual de instruções
Instructiehandleiding
Instrukcja obsługi
Návod k použití
CECOFRY BOMBASTIK 6000 FULL
Freidora dietética de 6 L digital/6 L digital air fryer
CECOFRY BOMBASTIK 6000 FULLCECOFRY BOMBASTIK 6000 FULL
4342
ENGLISHESPAÑOL
1. PARTS AND COMPONENTS
Fig. 1
1. Housing
2. Touch control panel
3. Basket
4. Handle
5. Power cord
6. Silicone brush
7. Silicone spatula
8. Silicone mat
9. Silicone mould
Control panel. Fig. 2
1. Power icon
2. Menu-selection icon
3. Time-increase icon
4. Time-decrease icon
5. Temperature-increase icon
6. Temperature-decrease icon
7. Timer
8. Fan icon
9. Heating icon
Note:
The graphics in this manual are schematic representations and may not exactly match the
product.
2. BEFORE USE
- This product includes a safety package to protect it during transport. Unpack the device
and keep the original packaging and materials in a safe place. It will help prevent any
damage if the product needs to be transported in the future. In case the original packaging
is disposed of, make sure all packaging materials are recycled accordingly.
- Make sure all parts and components are included and in good conditions. If there is any
piece missing or in bad conditions, contact the ocial Cecotec Technical Support Service
immediately.
- Clean the interior and the exterior of the device with a damp cloth. Do not wet the heating
elements.
7. RECICLAJE DE APARATOS ELÉCTRICOS Y ELECTRÓNICOS
Este símbolo indica que, de acuerdo con las normativas aplicables, el
producto y/o la batería deberán desecharse de manera independiente
de los residuos domésticos. Cuando este producto alcance el nal de su
vida útil, deberás extraer las pilas/baterías/acumuladores y llevarlo a un
punto de recogida designado por las autoridades locales.
Para obtener información detallada acerca de la forma más adecuada de
desechar sus aparatos eléctricos y electrónicos y/o las correspondientes
baterías, el consumidor deberá contactar con las autoridades locales.
El cumplimiento de las pautas anteriores ayudará a proteger el medio ambiente.
8. GARANTÍA Y SAT
Cecotec responderá ante el usuario o consumidor nal por las faltas de conformidad que
existan en el momento de la entrega del producto en los términos, condiciones y plazos
establecidos por la normativa aplicable.
Se recomienda que las reparaciones sean realizadas por personal cualicado.
Si detecta una incidencia con el producto o tiene alguna consulta, póngase en contacto con el
Servicio de Asistencia Técnica ocial de Cecotec a través del número de teléfono +34 96 321
07 28.
9. COPYRIGHT
Los derechos de propiedad intelectual sobre los textos de este manual pertenecen a CECOTEC
INNOVACIONES, S.L. Quedan reservados todos los derechos. El contenido de esta publicación
no podrá, ni en parte ni en su totalidad, reproducirse, almacenarse en un sistema de
recuperación, transmitirse o distribuirse por ningún medio (electrónico, mecánico, fotocopia,
grabación o similar) sin la previa autorización de CECOTEC INNOVACIONES, S.L.
CECOFRY BOMBASTIK 6000 FULLCECOFRY BOMBASTIK 6000 FULL
4544
ENGLISH ENGLISH
Icons 5 and 6 – Temperature increase/decrease icons
Press icons “5” and “6” to set the temperature between 80 ºC and 200 ºC.
Icon 7 - Timer
Once the basket and rack are securely in place in the fryer, press the “Icon 1 - Power icon”. The
control panel will fully light up–press “Icon 7” and select how long you want to delay the frying
process for by pressing “Icons 3 and 4”. The time available ranges from 30 minutes to 24 hours
in 30-minute intervals and 1 hour from 10 a.m. onwards.
8. Add 3 minutes to the preparation time when the appliance is cold; you can also let the
appliance preheat for about 4 minutes without any food inside.
9. Some ingredients require shaking halfway through the preparation time. To shake or turn
the food, remove the basket drawer from the appliance by the handle and shake or turn
the ingredients in the basket with a fork (or tongs). Then, put the basket back in the air
fryer.
Caution: be very careful when shaking the basket, as it contains hot food.
10. When you hear the timer acoustic signal, it means the set preparation time has elapsed.
Remove the basket from the appliance and place it on a heat-resistant surface. Make sure
the food is cooked. If the food isn’t cooked enough, slide the basket drawer back into the
air fryer and add a few more minutes to the timer.
11. To remove food, e.g., French fries, remove the basket drawer from the air fryer and place
it on a heat-resistant surface. Use tongs to remove the ingredients. Be careful not to burn
yourself. Do not place the basket upside down to remove the food.
WARNING:
- Do not overll the basket; respect the quantity indicated in the table to avoid aecting the
cooking result.
- Do not touch the basket drawer during or immediately after operation to avoid burns. Hold
the basket only by the handle.
Step 2
The table below shows the basic settings for the ingredients you want to prepare.
Note: keep in mind that these are just indications. Because ingredients dier in origin, size,
shape, and brand, we cannot guarantee that the settings below are the most appropriate.
- Clean the basket and grill thoroughly with hot water, washing-up liquid, and a non-abrasive
sponge.
- Place the rack properly in the basket and place the basket back in the appliance for use.
- Do not ll the device with oil or any other liquid.
3. OPERATION
Using the air fryer
Step 1
1. Place the air fryer on a at, stable, and heat-resistant surface, away from any possible
splashing water or heat source.
2. Properly place the basket in the air fryer.
3. Do not place any objects on top of the product when in use to avoid interrupting the air
ow and aecting the air-frying result.
4. Insert the power cord into an earthed wall socket.
5. Remove the basket from the air fryer with extreme care.
6. Put the ingredients in the basket.
- Note: never exceed the MAX mark on the basket or the quantity indicated in the table
(see “Settings” in this section) to avoid aecting the nal result.
- Tip: to ensure perfect results, it is recommended that you avoid overcrowding the basket
with food, as it will not cook evenly.
7. Use the control panel as follows (Fig. 2):
Plug in the air fryer–the corresponding power light indicator (Icon 1) will come on.
Icon 1 – Power icon
Once the basket and rack are securely in place in the fryer, the power icon will light up. Pressing
the power icon will set the temperature to 185°C and the cooking time to 15 minutes by default.
Pressing the power icon again will start the cooking process. At the start of the process the
“Icons 8 and 9” ash to indicate that the fan and the heating element are in operation. During
the cooking process, the “Icon 9” will stop ashing as soon as the device reaches the set
temperature and will start ashing again when the temperature drops below the set range.
Icon 2 - Menu-selection icon
Use this icon to choose from 12 of the most popular food options. Once the desired option has
been chosen, the cooking time and temperature values will be set by default. The time and
temperature values are manually adjustable.
Icons 3 and 4 – Time increase/decrease icon
Press icons “3” and “4” to set the cooking time from 1 to 60 minutes.
CECOFRY BOMBASTIK 6000 FULLCECOFRY BOMBASTIK 6000 FULL
4746
ENGLISH ENGLISH
Sweet
potatoes
200-500 30 200
Flip halfway
through cooking
Dessert 100-500 25 150 Flip if needed
Bacon
Fill only the rack
base
12 200 Flip if needed
Nuts
Fill only the rack
base
10 200
Flip halfway
through cooking
Keep warm 200-500 15 80 Flip if needed
Tips for cooking
1. Smaller ingredients require a shorter preparation time than the larger ones.
2. A larger quantity of ingredients only requires a slightly longer preparation time, and a
smaller quantity of ingredients only requires a slightly shorter preparation time.
3. Shaking smaller food midway through the cooking process optimises the end result and
prevents uneven cooking.
4. Add some oil to the fresh potatoes for a crispier result. Cook the food in the air fryer just
after adding oil to it.
5. Do not cook extremely fatty ingredients such as sausages in the air fryer.
6. Oven-ready food can also be cooked in the air fryer.
7. The optimal amount for preparing crispy fries is 500 grams.
8. Pre-made dough requires a shorter preparation time. Pre-made dough requires a shorter
preparation time than home-made dough.
9. Place a baking pan or baking dish in the air-fryer’s basket if you want to bake a cake or
quiche or if you want to fry fragile or stued foods.
10. You can also use the air fryer to reheat food.
Default-programmes table
Icon Type Min-Max weight
(g)
Time
(min)
Temperature
(ºC)
Notes
Meat 200-500 15 200
Flip halfway
through cooking
Frozen
chips
200-500 18 200
Add ½
tablespoon of oil
and ip halfway
through the
cooking time
Fish 200-400 10 180
Flipping not
necessary
Vegetables
Fill only the rack
base
15 150
Flip halfway
through cooking
Chicken 450-600 25 200 Flip if needed
Chicken
wings
200-500 20 180
Flip halfway
through cooking
Pizza 200-400 12 180
Flipping not
necessary
CECOFRY BOMBASTIK 6000 FULLCECOFRY BOMBASTIK 6000 FULL
4948
ENGLISH ENGLISH
The ingredients are
fried unevenly in
the air fryer.
Some types of food
need to be shaken
during the cooking
process.
Ingredients that lie on top of or across each
other (e.g., fries) need to be shaken halfway
through the preparation time. See section
“Operation”.
Food is not crispy
when it comes out
of the device.
You used a type of
food that is meant
to be prepared in
a traditional deep
fryer.
Cook oven food or oil the food a bit to get a
crispier result.
The basket does
not slide into the
device properly.
There are too many
ingredients in the
basket.
Do not ll the basket beyond the max.
indication.
The grille is
incorrectly placed
inside the basket.
Push the grille downwards into the basket until
you hear a click sound.
White smoke
comes out of the
appliance.
You are preparing
greasy ingredients.
When you fry greasy ingredients in the air
fryer, a large amount of oil will leak into the
basket drawer. Oil produces white smoke. This
does not aect the appliance or the result.
The basket still
contains grease
residue from
previous use.
White smoke is caused by grease heating up
in the basket drawer. Make sure you clean the
device properly after each use.
Fresh fries are fried
unevenly in the air
fryer.
You did not use the
right potato type.
Use fresh potatoes and make sure they stay
rm during frying. Use potatoes of the types
suggested.
You did not rinse
the potato sticks
properly before
you fried them.
Rinse the potatoes well in water for 3 minutes
to remove the starch and dry thoroughly
afterwards.
Fresh fries are not
crispy when they
come out of the air
fryer.
The right kind of
potato is not being
used.
Make sure you dry the potato sticks properly
before adding the oil.
Cut the potato sticks on smaller pieces for
crispier results.
Add a little bit more of oil for a crispier result.
4. CLEANING AND MAINTENANCE
- Clean the appliance after every use.
- The basket and rack have a non-stick coating. Do not use metal utensils or abrasive
products to clean the basket and/or rack, as this may damage their non-stick surface.
1. Unplug the appliance and allow it to cool down before cleaning.
Note: remove the basket to let the appliance cool down more quickly.
2. Clean the interior and the exterior of the device with a damp cloth.
3. Clean the basket and rack thoroughly with hot water, washing-up liquid, and a
non-abrasive sponge. The use of a degreasing liquid is recommended to remove any
remains.
Tip: if there is dirt stuck to the rack or basket, ll the basket drawer with hot water and a little
dishwashing liquid and soak the basket and rack for about 10 minutes.
4. Clean the inside of the appliance with hot water and a non-abrasive sponge.
5. Clean the heating element with a soft brush to remove any food residue.
6. Make sure all its parts are clean and dry before storing or using the product again.
Storage
- Unplug the appliance and let it cool down.
- Make sure all its parts are clean and dry before storing or using the product again.
- Store the cord in the cord compartment.
5. TROUBLESHOOTING
Problem Possible causes Possible solution
The air fryer does
not work.
The appliance is
not plugged in.
Connect the mains plug to an earthed wall
socket.
The ingredients
fried with the air
fryer are not done.
The amount of
ingredients in the
basket is too big.
Put smaller batches of food in the basket.
Smaller batches are cooked more evenly.
The temperature
used is too low.
Increase the cooking temperature (see the
“Operation” section).
The preparation
time is too short.
Increase the cooking time (see the “Operation”
section).
CECOFRY BOMBASTIK 6000 FULLCECOFRY BOMBASTIK 6000 FULL
5150
FRANÇAISENGLISH
1. PIÈCES ET COMPOSANTS
Img. 1
1. Coque
2. Panneau de contrôle tactile
3. Panier
4. Poignée
5. Câble d’alimentation
6. Pinceau en silicone
7. Spatule en silicone
8. Tapis en silicone
9. Moule en silicone
Panneau de contrôle. Img. 2
1. Icône d’allumage
2. Sélecteur des menus
3. Icône pour augmenter le temps
4. Icône pour diminuer le temps
5. Icône pour augmenter la température
6. Icône pour diminuer la température
7. Minuterie
8. Indicateur du ventilateur
9. Indicateur de préchauage
Note
Les graphiques de ce manuel sont des représentations schématiques et peuvent ne pas
correspondre exactement à ceux du produit.
2. AVANT UTILISATION
- Ce produit possède un emballage conçu pour le protéger pendant son transport. Sortez
l’appareil de sa boîte et conservez celle-ci ainsi que les autres éléments de l’emballage
dans un lieu sécurisé. Cela vous aidera à éviter d’endommager le produit si vous devez le
transporter à l’avenir. Si vous devez vous défaire de l’emballage d’origine, assurez-vous de
recycler tous les éléments correctement.
- Assurez-vous que toutes les pièces et les composants sont inclus et en bon état. S’il
manque une pièce, une partie, un accessoire ou que l’appareil ou ses accessoires ne sont
pas en bon état, veuillez contacter le Service Après-Vente ociel de Cecotec.
6. TECHNICAL SPECIFICATIONS
Product name: CecoFry Bombastik 6000 Full
Reference: 04993
Rated voltage: 220-240 V
Rated frequency: 50/60 Hz
Basket capacity: 6 L
Rated input power: 1700 W
Technical specications may change without prior notice to improve product quality.
Made in China | Designed in Spain
7. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES
This symbol indicates that, according to the applicable regulations, the
product and/or batteries must be disposed of separately from household
waste. When this product reaches the end of its shelf life, you should
dispose of the cells/batteries/accumulators and take them to a collection
point designated by the local authorities.
Consumers must contact their local authorities or retailer for information
concerning the correct disposal of old appliances and/or their batteries.
Compliance with the above guidelines will help protecting the environment.
8. TECHNICAL SUPPORT AND WARRANTY
Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the
time of delivery of the product under the terms, conditions, and deadlines established by the
applicable regulations.
It is recommended that repairs are carried out by qualied personnel.
If at any moment you detect any problem with your product or have any doubt, do not hesitate
to contact the ocial Cecotec Technical Support Service at +34 963 210 728.
9. COPYRIGHT
The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES,
S.L. All rights reserved. The contents of this publication may not, in whole or in part, be
reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic,
mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC
INNOVACIONES, S.L.
Fig./Img./Abb./Rys./Obr. 1
3
1
4
2
5
6
7 8
9
Fig./Img./Abb./Rys./Obr. 2
3
4
8
9
7
1
2
5
6
Cecotec Innovaciones S. L.
C/de la Pinadeta s/n, 46930
Quart de Poblet, Valencia, Spain
www.cecotec.es
EA01221212
