EnglishSENIXTOOLS.COM
Instruction Manual
Model: BLAX6-M1
• SAFETY
• ASSEMBLY
• OPERATION
• MAINTENANCE
• WARRANTY
CAUTION: Before using this tool, please read this manual completely,
and follow all operating safety measures.
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
For customer support, please call 1-800-261-3981 or email us at [email protected]
CORDLESS LEAF BLOWER
EN - 2
SENIXTOOLS.COM
SAFETY &
INTERNATIONAL
SYMBOLS
The following table depicts and describes
safety symbols that may appear on this
product. Read, understand and follow all
instructions on the machine before attempting
to assemble and operate.
Caution / Warning.
WARNING - To reduce the risk of
injury, user must read instruction
manual.
Wear eye protection.
Wear ear protection.
Wear respiratory protection.
Do not expose the product to rain or
wet conditions.
Wear protective, slip-resistant
footwear.
Wear protective gloves.
Failure to keep long hair away
from the air intake could result in
personal injury.
TABLE OF CONTENTS
SAFETY & INTERNATIONAL SYMBOLS ..............2
SAFETY INSTRUCTIONS .........................................3
KNOW YOUR UNIT .....................................................6
SPECIFICATIONS ....................................................... 7
ASSEMBLY ................................................................... 7
OPERATION ..................................................................9
MAINTENANCE .........................................................10
TROUBLESHOOTING ..............................................12
WARRANTY ................................................................13
Failure to keep loose clothing from
being drawn into air intake vents
could result in personal injury.
Do not operate without tube in
place.
Keep all bystanders at least 50 ft.
away.
Thrown objects can ricochet and
result in personal injury or property
damage.
Do not dispose of battery packs in
rivers or immerse in water.
Do not dispose of battery packs in
fire. They will explode and cause
injury.
Do not disassemble, crush, heat
above 212°F (100°C); Never expose
the battery to microwaves or high
pressures.
Indoor use only. Only use battery
charger indoors.
Mexican Certification Mark.
Complies with UL standards.
3 - EN
SENIXTOOLS.COM
SAFETY INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions,
illustrations and specications provided
with this power tool. Failure to follow all
instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for
future reference.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
• Keep Children Away – All visitors should be
kept at a distance from work area.
• Dress Properly – Do not wear loose clothing
or jewelry. They can be caught in moving
parts. Use of rubber gloves and substantial
footwear is recommended when working
outdoors. Wear protective hair covering to
contain long hair.
• Use Safety Glasses – Always use face or
dust mask if operation is dusty.
• Wear Appropriate Personal Hearing
Protection During Use – Under some
conditions and duration of use, noise from
this product may contribute to hearing loss.
• Use Right Product – Do not use product for
any job except that for which it is intended.
• Check Damaged Parts – Before further use
of the leaf blower, a guard or other part that
is damaged should be carefully checked
to determine that it will operate properly
and perform its intended function. Check
for alignment of moving parts, binding of
moving parts, breakage of parts, mounting
and any other condition that may affect
its operation. A guard or other part that is
damaged should be properly repaired or
replaced call our customer service help line
for assistance.
• Lighting – Only operate blower in daylight or
good artificial light.
• Don’t overreach – Keep proper footing and
balance at all times.
• Avoid Dangerous Environments – Don’t use
blower in rain, damp or wet locations. Do
not operate blower in gaseous or explosive
atmospheres. Motors in these tools
normally spark, and the sparks might ignite
fumes.
• Don’t Force product – It will do the job
better and with less likelihood of a risk of
injury at the rate for which it was designed.
• Stay Alert – Watch what you are doing. Use
common sense. Do not operate product
when you are tired.
• Store Idle Products Indoors – When not in
use, products should be stored indoors in
dry, and high or locked-up place – out of
reach of children.
• Maintain Blower With Care – Keep guard
and handles clean for best performance
and to reduce the risk of injury. Keep
handles dry and free from oil and grease.
BLOWER SAFETY
WARNINGS
• The blower has been designed to clear light
debris and leaves from hard surfaces – not
for clearing grassed areas.
• This blower is intended for household use
only. Commercial use of this product is
prohibited and will void the manufacturer’s
warranty.
• Prevent unintentional starting. Ensure the
throttle trigger is released and variable
speed control is in the off position before
connecting to battery pack, picking up or
carrying the product. Carrying the product
with a finger on the throttle trigger or
energizing the product with variable speed
control turned on invites accidents.
• Disconnect the battery pack from the
product before making any adjustments,
changing accessories, or storing product.
Such preventive safety measures reduce
the risk of starting the product accidentally.
• When operating the unit, never point the
blower nozzle in the direction of people or
pets or in the direction of windows. Use
extra caution when blowing debris near
solid objects, such as trees, automobiles,
and walls.
• Be sure to secure the unit when
transporting it.
• Never douse or squirt the unit with water
or any other liquid. Clean the unit after
each use as described in the cleaning and
storage section.
• Carefully inspect your product prior
to use and follow all label and marking
instructions.
EN - 4
SENIXTOOLS.COM
• Keep all parts of your body away from any
moving parts and all hot surfaces of the
unit.
• Do not put any object into the tool’s
openings. Do not use the tool with any
opening blocked; keep openings free of
dust, lint, hair, or any other object that may
reduce air flow.
• Check the work area before each use.
Remove all objects such as rocks, broken
glass, nails, wire, or string, which can
be thrown or become entangled in the
machine.
• Service on the product must be performed
by qualified repair personnel only. Service
or maintenance performed by unqualified
personnel could result in injury to the user
or damage to the product.
• Never run the unit without the proper
equipment attached. Always ensure the
blower tube is properly installed.
• Always grasp the handle when operating
the unit and only operate the machine in its
intended orientation.
BATTERY PACK AND
BATTERY CHARGER
SAFETY WARNINGS
• Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
• Use products only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury
and fire.
WARNING!
Use only with SENIX X6 battery:
B30X6/B40X6/B60X6/B80X6/B120X6
And chargers: CHX6-L/CHQX6/CHQX6-M/
CHDX6-M.
• When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a fire.
• Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from
the battery may cause irritation or burns.
(This advice is considered correct for
conventional NiMh, NiCd, lead acid and
lithium-ion cell types. If this advice is
incorrect for a cell design that differs from
these, then the correct advice may be
substituted.)
• Do not use a battery pack or product
that is damaged or modified. Damaged
or modified batteries may exhibit
unpredictable behavior resulting in fire,
explosion or risk of injury.
• Do not expose a battery pack or product
to fire or excessive temperature. Exposure
to fire or temperature above 212°F(100°C)
may cause explosion.
• Follow all charging instructions and do
not charge the battery pack or product
outside of the temperature range specified
in the instructions. Charging improperly or
at temperatures outside of the specified
range may damage the battery and
increase the risk of fire.
• Do not modify or attempt to repair the
product or the battery pack (as applicable)
except as indicated in the instructions for
use and care.
EMERGENCY
Familiarize yourself with the use of this
product by means of this instruction manual.
Memorize the safety directions and follow
them to the letter. This will help to prevent
risks and hazards.
1. Always be alert when using this product,
so that you can recognize and handle risks
early. Fast intervention can prevent serious
injury and damage to property.
2. Switch off the product and remove the
battery pack if there are malfunctions.
Have the product checked by a qualified
professional and repaired, if necessary,
before you operate it again.
RESIDUAL RISKS
Even if you are operating this product in
accordance with all the safety requirements,
5 - EN
SENIXTOOLS.COM
potential risks of injury and damage remain.
The following dangers can arise in connection
with the structure and design of this product:
3. Health defects resulting from vibration
emission if the product is being used over
long periods of time or not adequately
managed and properly maintained.
4. Injuries and damage to property due to
broken attachments or the sudden impact
of hidden objects during use.
5. Danger of injury and property damage
caused by flying objects.
6. Prolonged use of this product expose the
operator to vibrations and may produce
‘whitefinger’ disease. In order to reduce
the risk, please wear gloves and keep your
hands warm. If any of the ‘whitefinger’
symptoms appear, seek medical advice
immediately. ‘Whitefinger’ symptoms
include: numbness, loss of feeling,
tingling, pricking, pain, loss of strength,
changes in skin colour or condition. These
symptoms normally appear in the fingers,
hands or wrists. The risk increases at low
temperatures.
WARNING!
This product produces an electromagnetic
eld during operation! This eld may under
some circumstances interfere with active or
passive medical implants! To reduce the risk
of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
SAVE THIS INSTRUCTIONS
INTENDED USE
The tool is intended for clearing hard surface,
such as driveways and walkways, keeping
decks and driveways free from leaves and pine
needles.
EN - 6
SENIXTOOLS.COM
KNOW YOUR UNIT
1
2 3
4
5
6
7
8
9
10
APPLICATIONS
Model: BLAX6-M1
As a blower:
Blowing leaves, garden waste such as grass,
twigs and pine needles.
1 Blower nozzle
2 Nozzle-release button
3 Blower tube
4 Tube-release button
5 Speed/Lock-on dial
6 Air-speed trigger
7 Handle
8 Battery-release button
9 High-speed lock button
10 Intake hood
7 - EN
SENIXTOOLS.COM
SPECIFICATIONS
Model BLAX6-M1
Input Voltage 56V (60 V max*)
Rated Output Power 1 300 W
No-Load Speed
0 - 25 000 RPM
(Max)
Maximum Air Speed 170 MPH
Maximum Air Volume 810 CFM
Recommended
Operating
Temperature
5°F~104°F
(-15°C~40°C)
Recommended
Storage Temperature
-4°F~158°F
(-20°C~70°C)
Weight (tool only) 5.51 lbs
*60V Max battery, maximum initial battery
voltage (measured without a workload) is 60V.
The nominal voltage is 56V.
ASSEMBLY
1. Unpack all parts and lay them on a flat,
stable surface:
2. Remove all packing materials and shipping
devices, if applicable.
3. The scope of delivery varies depending on
the country and purchased variant.
Model BLAX6-M1
• Blower x1
• Blower nozzle x1
• Instruction manual x1
4. If you find that parts are missing or show
damage do not use the product but contact
your dealer. Using an incomplete or
damaged product represents a hazard to
people and property.
5. Ensure that you have all the accessories
and tools needed for assembly and
operation. This also includes suitable
personal protective equipment.
WARNING!
Wear protective gloves for this
assembly work and always lay the
product on a flat and stable surface
while assembling.
Follow the assembly instructions
step-by-step and use the pictures
provided as a visual guide to easily
assemble the product!
Do not insert the battery pack
before the power tool is completely
assembled or adjusted!
INSTALLING/REMOVING
THE BLOWER TUBE
WARNING!
To avoid serious personal injury and damage
to the unit, shut the unit o before removing or
installing an attachment.
1. Align the groove in the tube with the knob
on the blower housing. Push the tube onto
the blower housing until the latch snaps
into place.
Fig. 1
Fig. 2
EN - 8
SENIXTOOLS.COM
2. To remove the tube, press and hold the
tube-release button to disengage the latch,
then pull the tube straight from the blower.
Fig. 3
INSTALLING/REMOVING
THE BLOWER NOZZLE
1. Align the groove in the blower nozzle with
the knob on the tube. Push the nozzle onto
the tube until it snaps into place.
Fig. 4
Fig. 5
2. To remove the blower nozzle, press
and hold the nozzle-release button to
disengage the latch, then pull the nozzle
straight from the blower.
Fig. 6
INSTALLING/REMOVING
BATTERY PACK
To install:
1. Align the ribs of the battery pack with the
mounting slots in the blower’s battery port.
2. Press the battery pack into the battery port
until it snaps into position.
Fig. 7
To remove:
1. Press the battery-release button. The
battery pack will disengage from the latch
and the ejection mechanism will assist with
removal.
2. Remove the battery pack from the blower.
9 - EN
SENIXTOOLS.COM
Fig. 8
WARNING!
Always take care to note the location of your
feet, children, or pets when pressing the
battery-release button. Serious injury could
result if the battery pack falls. NEVER remove
the battery pack when in a high location.
NOTE:
Refer to the manuals for the charger and
battery pack for more details about how to
charge the battery pack and other information
regarding to the charger and battery pack.
OPERATION
WARNING!
Inspect the tool for complete installation.
Anything missing, damaged, or misplaced
parts may cause serious injury. Wear
protective equipment at all times while
operating the power tool.
SWITCHING ON/OFF
NOTE:
Before use, turn the speed lock-
on dial counterclockwise to the o
position.
AIR-SPEED TRIGGER ONLY
1. Depress the air-speed trigger to turn on the
blower.
2. The air speed of the blower is controlled
with the variable speed trigger. More
pressure on the trigger results in higher
blowing speeds; less pressure on the
trigger results in lower blowing speeds.
Adjust the speed to suit the task at hand.
3. Release the air-speed trigger to turn off the
blower.
NOTE:
Press the trigger to the end (do not press
the high-speed lock button) to temporarily
increase the air speed to the maximum level.
Then turn the speed/lock-on dial clockwise
to the end, the maximum speed will be locked
automatically. Press the high-speed lock
button to exit the maximum airspeed.
SPEED/LOCK-ON DIAL ONLY
The blower can be locked at any speed with
the speed lock-on dial.
1. Turn the speed/lock-on dial clockwise to
start the blower. The air speed will increase
as the dial is rotated clockwise.
2. To decrease the air speed, turn the speed/
lock-on dial counterclockwise.
3. Keep turning the speed/lock-on dial
counterclockwise to the off position to stop
the blower.
NOTE:
Turn the speed/lock-on dial clockwise to the
end, and the air speed will reach its maximum
and lock automatically. Then press the
high-speed lock button to exit the maximum
airspeed.
Speed/lock-on dial
Air-speed trigger
High-speed lock button
Fig. 9
EN - 10
SENIXTOOLS.COM
GENERAL
1. Double check that accessories or
application tools are properly fixed.
2. Always hold the product by its handle. Keep
the handle dry and clean to ensure safe
support.
3. Ensure that the air vents are always
unobstructed and clear. Clean them if
necessary with a soft brush. Blocked air
vents may lead to overheating and damage
the product.
4. Switch the product off immediately if you
are disturbed while working by other people
entering the working area. Always let the
product come to a complete stop before
putting it down.
5. Do not direct the blower air stream toward
any solid objects such as loose stones or
fallen tree branches.
6. Before switching the product on, check
whether it has been assembled correctly
and all the moving parts are running
smoothly!
7. While working, ensure that the product
does not strike hard objects, as this can
cause damage.
8. Do not blow any solid bodies such as
stones, branches or other debris.
9. In dusty conditions using a misting
attachment or other water source.
WARNING!
Operation risks may occur, such as blown
debris cutting skin, getting into the eyes or
mouth, or being inhaled into the lungs. Always
wear eye, respiratory, hearing, hand, foot, and
body protection to reduce the risk of injury
when operating this unit.
BLOWING
1. Before blowing, loosen leaves that are
stuck to the ground using a broom or rake.
2. Hold the tube approximately 4 inch (10cm)
above the ground and walk slowly forward
using a sweeping motion from side to side.
3. Direct the air stream away from yourself.
4. Ensure that you do not stir up any heavy
objectsat the risk of harming others or
damaging your surroundings.
WARNING!
Immediately power o the blower in the
event of any abnormal vibrations. Abnormal
vibration often shows a mechanical problem
and continuous use could result in injury or
property damage.
MAINTENANCE
WARNING!
Always switch the blower o, remove the
battery pack, and let the product cool down
before performing cleaning and maintenance
work!
Always wear eye, respiratory, hearing, hand,
foot, and body protection to reduce the risk of
injury when operating this unit.
Only perform cleaning and maintenance
work according to these instructions! Any
additional maintenance or repairs must be
performed by a qualied specialist using
genuine replacement parts.
CLEANING
• Switch the product off, remove the battery
pack from the product.
• Clear off debris from blower tube.
• Remove wood chips and other debris from
air vents.
• Use a small brush to clean the outside of
the unit. Do not use strong detergents.
Household cleaners that contain aromatic
oils such as pine and lemon, and solvents
such as kerosene, can damage plastic.
• Wipe off any moisture with a soft cloth.
The tool should never come in contact with
water.
TRANSPORTATION
• Clean the product as described above.
• Always carry the product by its handle.
• Protect the product from any heavy impact
or strong vibrations which may occur
during transportation in vehicles.
• Secure the product to prevent it from
slipping or falling over, becoming damaged,
or falling over and causing damage or
injury.
11 - EN
SENIXTOOLS.COM
STORAGE
• Clean the product as described above.
• Store the product and its accessories in a
dark, dry, frost-free, well-ventilated place.
• Always store the product in a place that is
inaccessible to children.
• We recommend using the original package
for storage or covering the product with
a suitable cloth or enclosure to protect it
against dust.
NOTE:
To prolong battery life, never store battery
pack in a completely discharged condition.
Make sure the battery pack is charged every
six months or when the LED indicator shows
only one light.
DISPOSAL
When this product is no longer usable, do not
dispose of it with household waste. It must be
recycled at a proper facility.
Electrical products should not be
discarded with household products.
Used electrical products must be
collected separately and disposed
of at collection points provided for
this purpose. Talk with your local
authorities or dealer for advice on
recycling.
EN - 12
SENIXTOOLS.COM
TROUBLESHOOTING
Suspected malfunctions are often due to causes that the users can x themselves. Therefore,
check the product using this section. In most cases the problem can be solved quickly.
Problem Possible Cause Solution
Product does not start
Battery pack not properly
attached
Remove from product and reattach
Battery pack capacity too
low
Remove and charge battery pack
Battery pack damaged
Inspection by a specialist
electrician
Air-speed trigger not set on
start position
Refer to chapter "SWITCHING ON/
OFF"
Product does not
reach full power
Battery pack capacity too low Charge battery pack
Air vents are blocked Clean the air vents
Vibration or noise is
excessive
Bolts/nuts are loose Tighten bolts/nuts
Product suddenly
stops
Battery pack capacity too
low
Remove and recharge battery pack
Battery too hot
Remove battery pack and let it cool
down
EnglishSENIXTOOLS.COM
WARRANTY
SENIX TOOLS LIMITED WARRANTY
FOR FIVE YEARS from the date of original purchase this product is warranted against defects in material or
workmanship. WITH PROOF OF ORIGINAL PURCHASE a defective product will receive free repair. If the product
cannot be repaired it will be replaced free of charge.
or call 1-800-261-3981.
• This warranty does not cover repairs necessary due to product accident or abuse, or failure to operate or
maintain the product according to all supplied instructions.
• This warranty does not cover an included battery pack or charger, which oer three-year, replacement-only
coverage. See battery pack or charger instruction manuals for complete warranty details.
• This warranty does not cover expendable items that can wear out from normal use within the warranty
period, including but not limited to drill bits, cutting blades and trimmer spool or line.
• This warranty does not apply to damage resulting from repairs to the product made or attempted by other
than SENIX authorized agents.
• This warranty does not cover the cost of mailing or transporting the power tool to receive warranty
coverage.
• The warranty is void if the product has been used for commercial, professional, or rental service purposes.
• The warranty applies to the original retail purchaser and is not transferable.
• Proof of purchase is required to obtain warranty coverage.
THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE
, AND EXCLUDES ALL INCIDENTAL OR CONSEQUENTIAL DAMAGE.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
and you may have other rights which vary in certain states or provinces.
NOTE: Battery pack warranty voided if the battery pack is tampered with in any way. SENIX is not responsible for
any injury caused by tampering and may prosecute warranty fraud to the fullest extent permitted by law.
60-DAY MONEY-BACK GUARANTEE. If for any reason within 60 days from the date of original purchase you are
for a full refund.
Latin America: This warranty does not apply to products sold in Latin America. For products sold in Latin America,
purchased, or visit the website for warranty information.
Free warning label replacement: If your warning labels become illegible or are missing, call 1-800-261-3981 for a
free replacement.
REGISTER ONLINE - www.senixtools.com/pages/product-registration
Thank you for your purchase! Register your product now for:
Warranty Service:
with your product.
will serve as proof of purchase.
For your safety:
required under the Federal Consumer Safety Act.
YAT USA INC. 10506 Bryton Corporate Center Dr, #500 Huntersville, NC 28078
For customer support, please call 1-800-261-3981 or email us at senix.support@yatusa.com
