Technical Support and E-Warranty Certificate www.vevor.com/support
FREESTANDING WINE REFRIGERATOR
MODEL:JC-94D&JC-208WD
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:JC-94D&JC-208WD
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
COMPRESSOR CIGAR
HUMIDOR
- 2 -
Warning-To reduce the risk of injury, user must read
instructions manual carefully.
This product is subject to the provision of European Directive
2012/19/EC. The symbol showing a wheelie bin crossed
through indicates that the product requires separate refuse
collection in the European Union. This applies to the product
and all accessories marked with this symbol. Products marked
as such may not be discarded with normal domestic waste, but
must be taken to a collection point for recycling electrical and
electronic devices
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND
OPERATING INSTRUCTION.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electrical shock, or injury
when using your appliance, follow these basic
precautions:
• Before using the appliance, please read this user manual to ensure that
you gain the maximum benefit from it.
WARNING:
1)This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
2)Children should be supervised to ensure that they do not play with the
appliance.
3)This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
- 3 -
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
4)If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
5)To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
6)When positioning the appliance, ensure the supply cord is not trapped or
damaged.
7)Do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance.
8)Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
9)Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
10)Do not damage the refrigerant circuit.
11)Do not use electrical appliances inside the drink storage compartments
of the appliance, unless they are of the type recommended by the
manufacturer.
12)Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
13)This appliance is intended to be used in household and similar
applications such as
-staff kitchen areas in shops, offices and other working environments;
-farm houses and by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
14)Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
15)To avoid contamination of drink, please respect the following
instructions:
-Opening the door for long periods can cause a significant increase of the
temperature in thecompartments of the appliance.
- 4 -
-Clean regularly surfaces that can come in contact with drink and
accessible drainage systems.
-Clean water tanks if they have not been used for 48 h; flush the water
system connected to a water supply if water has not been drawn for 5
days.
-If the refrigerating appliance is left empty for long periods, switch off,
defrost, clean, dry, and leave the door open to prevent mould developing
within the appliance.
• Note: This appliance contains flammable refrigerant R600a and foaming
agent
cyclopentane.
Please avoid contact fire when you transport and use it.
Please ask professional for servicing when the machine broke down.
Please send it to your local appointed disposal station when you discard it.
-Save these instructions-
During using, service and disposal the appliance, please
pay attention to symbol similar as left side, which is
located on rear of appliance (rear panel or compressor)
and with yellow or orange color.
It’s risk of fire warning symbol. There are flammable
materials in refrigerant pipes and compressor.
Please be far away fire source during using, service and
disposal.
INSTALLATION INSTRUCTIONS
• This appliance is designed to be free standing only, and should not be
recessed or built-in.
• Place your unit on a floor that is strong enough to support the unit when it
is fully loaded. To level
your unit, adjust the leveling legs at the bottom of the unit.
• This appliance is not designed to be installed inside of a cabinet where
- 5 -
the front is covered by any type of door.
• Allow 10 cm of space between the top, the back and sides of the wine unit,
which allows the proper air circulation to cool the compressor and
condenser.
• Locate the unit away from direct sunlight and sources of heat (stove,
heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may
increase electrical consumption. Extreme cold ambient temperatures may
also cause the unit not to perform properly.
• Avoid locating the unit in moist areas.
• Plug the unit into an exclusive, properly installed-grounded wall outlet. Do
not under any circumstances cut or remove the third (ground) prong from
the power cord. Any questions concerning power and/or grounding should
be directed toward a certified electrician or an authorized Products service
center.
• After plugging the Wine Chiller into a wall outlet, allow the unit to cool
down for 2-3 hours before placing any items in the compartment.
PARTS AND FEATURES
JC-94D
1:Upper Hinge
2:Shelves
3:Door Handle
4:Partitions
5:Door Gasket
6:Display Shelves
7:Adjust Foot
8:Bottom Hinge
- 6 -
JC-208WD
1:Upper Hinge
2:Fan
3:Door Handle
4:Shelves
5:Door Gasket
6:Adjust Foot
7:Bottom Hinge
OPERATING YOUR UNIT
Setting the Temperature Control
Key function
① Unlock key: short press to switch temperature or humidity setting state;
long press for 2 seconds to unlock
② Light / CF key: short press to turn on or off the light; long press for 2
seconds to switch Fahrenheit or centigrade
③ Add key: temperature setting
- 7 -
④ Minus key: temperature setting
Automatic lock function
When all the key no operation for 20 seconds, the key will be locked
automatically. After locking, the Increase key and Decrease key cannot be
operated. The unlock key and light / CF key operate normally
Automatic light off function
When all the key no operation for 10 minutes, the lamp will turn off
automatically
Adjustable range
Upper room:
lowest value: 5°C / 41°F
Maximum value: 18°C / 64°F
Lower chamber:
lowest value: 5°C / 41°F
Maximum value: 18°C / 64°F
Display range
Temperature display range of control board: 0 ~ 37 ° C / 32 ~ 99 ° F
Forced defrosting function
When the compressor works for 12 hours, the compressor will stop
working for 30 minutes
Memory function
The control board is re-energized after each power-off, the temperature
setting value,
Fahrenheit/Celsius state will be the same as before the power-off, and the
length of power-off time is not limited.
Display stability
In the Celsius state: When the temperature measured by the temperature
probe is within ± 1 ° C of the set temperature, the temperature display will
display the set temperature value
In the Fahrenheit state: When the temperature measured by the
temperature probe is within ± 2 ° F of the set temperature, the temperature
display will display the set temperature value
- 8 -
Error code
EE: "EE" is displayed when the temperature probe is short-circuited or
disconnected, flashes, and cooling is stopped
LL: When the temperature measured by the temperature probe is lower
than 0 degrees Celsius, "LL" is displayed, flashing, and the cooling is
stopped
HH: When the temperature measured by the temperature probe is higher
than 37 degrees Celsius, "HH" is displayed, flashing, and cooling is
stopped
Forced defrosting function
When the compressor works for 12 hours, the compressor will stop
working for 30 minutes
Memory function
When the control board is powered on again after each power failure, the
temperature setting value and Fahrenheit / centigrade state will be the
same as before, and the power-off time is not limited
Tips
• It is intended to be used exclusively for the storage of wine.
• This refrigerating appliance is not suitable for the freezing foodstuffs.
• The wine cooler is recommended to be designed at 12°C.
• The shelves placed in factory mode is the most efficient use of energy for
the refrigerating appliances.
• The following combination of shelves is recommended for energy to be
used as efficiently as possible by the refrigeration unit.
GENERAL FAULT DESCRIPTION
If the product is not working properly, please check and handle according
to the following methods. If the situation can not be changed, please
contact the local after-sales service center in time, and be sure to provide
the model name and product number in detail.
- 9 -
The refrigerator doesn’t work
Is the power on?
Is the power supply voltage too low?
It's noisy
Whether the ground is flat andwhether
the product is placed stably.
I Is the product in contact with
external objects or walls
The internal temperature is not low
Improper
setting
temperature,
please select
the appropriate
temperature
The door is not
closed tightly or
opened
frequently, and
the opening time
is too long
Is the location
exposed to
direct sunlight or
too close to the
furnace and
other heat
sources
Poor heat
dissipation,
please check
whether there is
enough cooling
space around
the product
- 10 -
WIRING DIAGRAM
Correct disposal of this product
This symbol on the product, or in its packaging, indicates
that this product may not be treated as household waste.
Instead, it should be taken to the appropriate waste
collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for
the environment and human health, which could otherwise
be caused by the inappropriate waste handling of this
product. For more detailed information about the recycling of
this product, please contact your local council, your
household waste disposal service, or the shop where you
purchased the product.
