www.silverstonetek.com
User manual
1.Press down on the front panel switch to remove the front panel 2. Remove both top and bottom panels 3. Remove the 2.5" SSD tray, and gently flex the tray to facilitate the
installation of the 2.5" SSD
4. Install the 3.5" HDD in a similar manner. The 3.5" HDD can be
inserted into the hard drive cage in either direction
1. Pull the tray out of the chassis
2. Install the drive into the drive tray, secure it with screws, and then
re-insert the assembled drive tray module back into the chassis
6. To facilitate a simple connection of the hard drive backplane
cables, remove the fan bracket by loosening the screws that
secure the backplane to the chassis
Installation Steps
RM600
RM61-312
RM61-312
5.External 2.5"/3.5" drive installation
Motherboard
Standoff
Accessories Content
Motherboard /
5.25" Device Screw
5.25" Guide Rail
Screws
PSU Screw
5.25" Ventilation
Bezel
5.25" Bezel
5.25" Guide Rail x9 Key
Case Feet
Vertical position
accessories
2U Redundant
accessories
Fan Extension
Cable
3.5" HDD 2.5" SSD
RM61-312 RM61-312
RM600 & RM61-312
1
3. If installing a 2U Redundant PSU, also ensure to remove
the ATX PSU bracket first
1. Remove the front 360mm radiator bracket2. If installing a Mini Redundant PSU, please remove the
ATX PSU bracket first
1. If installing dual ATX PSUs, please remove the ventilation
cover beforehand
2. Attach the 5.25 guide rail to the 5.25" device, then slide
the device in and secure it with guide rail screws
3. Install the 5.25" bezel, if 5.25" device mounts are unallocated,
you can replace the 5.25" bezel with 5.25" ventilation panel to
increase intake airflow
1. Remove L-shaped brackets and handle bar on both sides
2. Install handle bar onto the flat bracket and case feet
9.Vertical orientation installation
7.Installation of ATX / Mini Redundant / 2U Redundant PSUs 8.5.25" ODD installation
2
Warranty terms & conditions
Warranty Information
This product has a limited 1 year warranty in North America and Australia.
For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.
本产品自购买之日起，于中国地区（不包含澳门，香港特别行政区）享有一年有限责任保固（部分产品为二年，三年或五年）。
详细保固年限请参照官方网站 https://silverstonetek.com.cn/ 公布之产品型号为依据。
1. Product component defects or damages resulted from defective production is covered under warranty.
Defects or damages with the following conditions will be fixed or replaced under SilverStone
Technology’s jurisdiction.t
a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other
inappropriate actions.
b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc…)
c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.
d) Warranty mark/stickers are not removed or broken.
Loss or damages resulted from conditions other than ones listed above are not covered under warranty.
2. Under warranty, SilverStone Technology’s maximum liability is limited to the current market value for
the product (depreciated value, excluding shipping, handling, and other fees). SilverStone Technolog
y
is not responsible for other damages or loss associated with the use of product.
3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under
no circumstances will SilverStone Technology be liable for damages in connection with the sale,
purchase, or use including but not limited to loss of data, loss of business, loss of profits, loss of use
of the product or incidental or consequential damage whether or not foreseeable and whether or not
based on breach of warranty, contract or negligence, even if SilverStone Technology has been advised
of the possibility of such damages.
4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers
and is not transferable to a second hand purchaser.
5. You must provide sales receipt or invoice with clear indication of purchase date to determine warrant
y
eligibility.
6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone
authorized distributors or SilverStone http://www.silverstonetek.com.
Please note that: (i) You must provide proof of original purchase of the product by a dated itemized
receipt; (ii) You shall bear the cost of shipping
(or otherwise transporting) the product to SilverStone authorized distributors. SilverStone authorized
distributors will bear the cost of shipping (or otherwise transporting) the product back to you after
completing the warranty service; (iii) Before you send the product, you must be issued a Return
Merchandise Authorization (“RMA”) number from SilverStone. Updated warranty information will be
posted on SilverStone’s official website.
Please visit http://www.silverstonetek.com for the latest updates.
Additional info & contacts
For North America (usasupport@silverstonetek.com)
SilverStone Technology in North America may repair or replace defective product with refurbished product that is not new but has been
functionally tested.
Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer. All products should be sent
back to the place of purchase if it is
within 30 days of purchase, after 30 days, customers need to initiate RMA procedure with SilverStone Technology in USA by first downloading
the “USA RMA form for end-users”
form from the below link and follow its instructions. http://silverstonetek.com/contactus.php
For Australia only (support@silverstonetek.com)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacemen
t or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
Please refer to above “Warranty terms & conditions” for further warranty details.
SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C. + 886-2-8228-1238 (standard
international call charges apply)
For Europe (support.eu@silverstonetek.de)
For China (support@silverstonetek.com.cn)
For all other regions (support@silverstonetek.com)
有毒有害物质/元素及其化学含量表
部件名称
风扇
机壳
（金属）
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
○ ○ ○ ○ ○
铅
(Pb)
○
○ ○ ○ ○ ○○
线材
○ ○ ○ ○ ○○
螺丝
○ ○ ○ ○ ○
○
包材
○ ○ ○ ○ ○
○
○：表示该有毒有害物质在该部件所有均质材料中的含量均在GB/T 26572 规定的限量
要求以下。
本表格依据SJ/T 11364的规定编制
×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572 规定的
限量要求。
G11250690
1.Optional 3.5"HDD cooling fan assembly 1. CPU cooler height limitation with expansion card retainer
is 132mm, and 150mm without
3. The maximum length allowed for the graphics card is 341mm.
When combined with the 5.25" device, the total length extends
to 483mm
4. The PSU has a maximum depth limitation of 294mm
The maximum depth limitation for thePSU in RM61-312
is 277mm.
RM600
Optional Installation Component Limitations
3
65mm 62mm
5.25" CD-ROM
151
214
237
481
EEB
CEB
ATX
1
2 3 4
5
6
7
8 9
2. The radiators on both sides of the chassis will each
occupy one 5.25" slot, as illustrated. The allowable total
thickness of the radiators plus fan is depicted in the
figure
The combined length of 5.25” devices and motherboard
equals to 481mm, the length of 5.25” devices allowed by
various motherboard form factor is as shown.
