www.silverstonetek.com
User manual
RM31
3U rackmount server chassis with dual
power supplies and 360mm radiators support
Motherboard
standoff
Motherboard,
CRPS standoff
screws
Secure 2.5” SSD,
CRPS standoff
screws
Secure 2.5” SSD
tray, extension
cable screws
Accessories Content
Secure 3.5” HDD,
power supply
screws
Support CRPS
standoff
CRPS power
supply bracket
CRPS extension
bracket
Secondary SFX
power supply
bracket
Handle bar
bracket screws
Secure SFX
power supply
screws
L-shaped bracket Handle bar
Secondary power supply extension
adapter
1-1.Remove the cage.
Install Hard Drive
1-2.Install 2 × 3.5" HDD or 2 × 2.5" SSD. 1-3.Install the cage into the chassis (three mounting positions available).
Power Supply and Radiator
Limitations
80MM239MM
2-1.PSU space 239mm, front fan/radiator clearance 80mm 2-2. PSU space 264mm, front fan/radiator clearance 55mm
55MM264MM
2-3.PSU space 289mm, front fan/radiator clearance 30mm
30MM
289MM
3-1.Remove the SFX power supply bracket.
2U CRPS Power supply Installation
Replace Power Supply Bracket
3-2.Install the 2U CRPS bracket.
3-3.Check the rear bracket on the CRPS power supply
If the original power supply rear bracket does not align with the chassis
screw holes, replace it with the extension bracket and secure it with one
standoff in the center.
3-4. Remove the rear bracket
3-5. Install the extension bracket 3-6. Secure the extension bracket with one standoff 3-7. Secure with screws
3-1.Remove the SFX power supply bracket.
2U CRPS Power supply Installation
Replace Power Supply Bracket
4-1. If installing a second SFX power supply, the 3.5" × 2 or 2.5" × 2
drive tray cannot be used. Please remove it.
Dual SFX Power Supply Installation
Remove Drive Tray
4-2. Mount the power supply onto the PSU bracket, then install it into
the chassis.
Install Power Supply
4-3. Remove the knockout from the extension cable opening and install
the power supply extension cable.
Install Power Supply Extension Cable
4-4. The available space for the main power supply is 189 mm.
The combined space for the secondary power supply and the front
fan/radiator is 281 mm.
It is recommended that both power supplies be no longer than 140mm
Power Supply Length Limitation
189mm281mm
5. Secure the handle assemblies to both sides of the chassis.
Left and Right Handles Installation
6-1. Remove Front Panel
Radiator Installation
6-2. 120 mm fan + radiator 6-3. Combined radiator and expansion card length: 458 mm
(3 × 120 mm fans, radiator)
458mm
6-4. If the radiator length exceeds 397 mm, the fans must be installed in
the front with the radiator positioned behind.
397mm
6-5. Install Front Panel 7-1. Expansion Card Width Limit: 115 mm
Graphics Card Width Limitation
115mm
7-2. CPU Cooler Height Limit: 110 mm
If no side tray is installed, the CPU cooler may extend up to 6 mm beyond
the edge of the motherboard.
If a side tray with a 2.5" drive is installed, the CPU cooler must remain
within 7 mm inside the edge of the motherboard.
CPU Cooler Height Limitation
Maximum
110mm
6mm
2.5"SSD
OR
2.5"bracket
7mm
8-1. Remove the 2.5" Tray
Side 2.5" Tray
Install 2.5" hard drive
8-2. Install the 2.5" SSD 8-3.Mount the Drive to the Chassis 9. The drive mounting surface is 8 mm outside the motherboard,
and the drive has 33 mm of clearance above the motherboard.
Please determine whether the drive will interfere with motherboard
components based on these two conditions and the drive thickness.
Motherboard Component Limitations
33mm
8mm
Warranty terms & conditions
