www.silverstonetek.com
User manual
RM4A
4U rackmount server chassis with
enhanced liquid cooling compatibility
3.5" HDD screws
Motherboard /
2.5" SSD screws
Manual
A:Handle brackets
B:Handle bars
C:Handle bar bracket screws
Motherboard standoffPSU screws
(A)
(B)
(C)
Parts package component list
1-1. Remove 4 screws from expansion card retainer
Hard Drive and Expansion Card
Retainer Installation
1-2. Expansion card retainer position shift
(It is recommended to avoid the position of the expansion card connectors,
and make sure the length of the PSU will not interfere.)
Position 1
Position 3
Position 2
Position 4
1-3. Install 2 x 3.5" HDD on the expansion card retainer 1-4. Install 3 x 2.5" SSD on the expansion card retainer 1-5. Install 2.5" drives on 2.5" trays 1-6. Removing expansion card clip buckle
1
2
Press and push
Pull up
1-7. Adjust the position of the expansion card retainer according to the
required height of the interface card, then tighten the screw
loosen
tighten
2-1. Height limitation with expansion card clip buckle installed
Expansion card limitations
113mm
Graphics Card
2-2. Height limitation with expansion card clip buckle removed
139mm
Graphics Card
2-3. Height limitation with expansion card retainer removed
154mm
Graphics Card
3-1. CPU cooler height limitation with expansion card retainer is 137mm,
and 148mm without. CPU cooler is allowed to protrude the motherboard
by 15mm to avoid interference with the PSU. If hard drives are to be
installed on the expansion card retainer, further deduct the height of the
hard drives
Component restrictions
Maximum 137mm
Maximum 15mm
Maximum 148mm
3-2. When shifting positions of the expansion card retainer, the maximum
depth limitation for PSU is 255mm to avoid interference
255mm
power
supply
3-3. The maximum length limitation for graphics cards, front panel case
fans, and radiator is 424mm
Graphics card
Maximum424mm
3-4. If the 8th slot is to be used for expansion cards, please remove the
2.5" drive tray as appropriate
