User manual
Accessories Content
RM31-MINI
Install Hard Drive
1-1 Remove the drive tray. 1-2 Install 2 × 3.5" drives or 2 × 2.5" drives. 1-3 Install the drive tray into the chassis.
Power Supply InstallationPower Supply and Radiator
limitations
2-1 Power Supply Installation
Left and Right Handles Installation
3-1 Secure the handle assemblies to both sides of
the chassis.
x2
Motherboard
standoff
Motherboard
screws
Secure 2.5″
SSD screws
Secure 2.5″
SSD tray
screws
Secure 3.5″
HDD, power
supply screws
Handle bar Handle bar
bracket
screws
L-shaped
bracket
3U rackmount server chassis with
8 expansion slots & 360mm radiator support
55mm
166mm
Supports installation of PSU up to 166mm
Supports installation of front fans and radiator
up to 55mm
Install radiator
4-1 Remove Front Panel 4-2 Install 120 mm fan + radiator 4-3 Install Front Panel
Graphics Card Width Limitation
Expansion Card Width Limit: 115 mm
CPU Cooler Limitation
CPU Cooler Height Limit: 110 mm If no side tray is installed, the CPU cooler may extend up to 6 mm beyond the edge of the motherboard.
If a side tray with a 2.5" drive is installed, the CPU cooler must remain within 7 mm inside the edge of
the motherboard.
361mm
Radiator and Expansion Card
Limitations
397mm
Combined radiator
and expansion card
length: 361 mm
If the radiator length
exceeds 397 mm, the
fans must be
installed in the front
with the radiator
positioned behind.
115mm
Maximum
110mm
6mm
2.5"SSD
OR
2.5"bracket
7mm
Motherboard Component
Limitations
Install Hard Drive
5-1 Remove the 2.5" Tray 5-2 Install the 2.5" Drive 5-3 Mount the Drive to the Chassis The drive mounting surface is 8 mm outside the
motherboard, and the drive has 33 mm of
clearance above the motherboard.
Please determine whether the drive will interfere
with motherboard components based on these
two conditions and the drive thickness.
33mm
8mm
Motherboard
2.5
" Drive
