PREMIER HEAVY-DUTY STAPLE & BRAD NAIL GUN
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health and safety, local authority, & general workshop practice regulations are adhered to when using this staple/
nail gun.
9 Maintain the staple/nail gun in good condition, (use an authorised service agent).
9 Use this product in an adequate working area for its function, keep area clean, tidy, and free from unrelated materials. Ensure there is adequate
lighting.
WARNING! Always wear approved eye or face protection when operating the staple/nail gun.
9 Remove ill fitting clothing, ties, watches, rings, other loose jewellery, and tie back long hair.
9 Wear appropriate protective clothing.
9 Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT force this product to achieve a task it was not designed to perform.
8 DO NOT operate if any parts are damaged or missing. This may cause failure or possible injury.
8 DO NOT get the Stapler/Nailer wet or use in damp or wet locations.
8 DO NOT point at other persons or animals.
8 DO NOT operate if you are tired, under the influence of alcohol, drugs, or intoxicating medication.
9 When not in use store in a safe, dry, child proof area.
2. INTRODUCTION
2-in-1 staple and nail gun. Heavy-duty reinforced heat treated carbon steel handle with a PVC casing. Sliding magazine for easy
clearance of any blockages. Suitable for a wide range of applications. Supplied with a starter pack of 150 staples and nails.
3. SPECIFICATION
4. OPERATION
4.1. LOADING
4.1.1. Hold the stapler in one hand and point away from your body. Push in with
finger and thumb at the base of the stapler feed bar and withdraw it from
the stapler. Insert new staples or nails into the guidance track. See (fig.1)
for staple placement within the track. Reinsert the feed bar upwards to
retain it.
4.2. STAPLING
4.2.1. Prior to stapling, ensure that the stapler is correctly positioned and
the sole plate is in firm contact with the surfaced to be stapled. Firmly
depress the trigger until the gun fires. See (fig.2).
Refer to
instruction
manual
Wear eye
protection
Original Language Version
© Jack Sealey Limited
AK7067 Issue:1 21/11/24
MODEL NO: AK7067
Model No: AK7067
Consumable Parts: AK7067.1 & AK7067.2
Crown Size: 10.6mm
Nett Weight: 0.350kg
STAPLE EXIT PATH
fig.
2
Guidance
Track
Handle Trigger
Feed Bar
fig.
1
Original Language Version
© Jack Sealey Limited
4.3. HOW TO CLEAR BLOCKAGES
Remove the feed bar (fig.1) and any loose staples remaining in the guidance track. Clear any damaged staples away from the staple exit path.
Close the feed bar back into place.
4.4. STAPLE REMOVAL
4.4.1. Release the feed bar. Move the stapler onto it’s side, the staples will exit out from the guidance track. Close the feed bar after.
4.5. STORAGE
4.5.1. Store in a dry place out of the reach of children.
AK7067 Issue:1 21/11/24
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. If you require documentation for alternative versions, please email or call our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is Lifetime from purchase date, proof of which is required for any claim.
