WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
WARNING Notice before use
● Use water under 40℃ in order to remove dirt from the unit .
● Do not use it to clean arts and crafts, fibers and items not suitable for cleaning by water, and
surfaces easy to be hurt (like floor, table and so on) .
● Do not slant if with water in the tank to avoid wetting floor.
● Stop the machine and empty the dirty water tank if it reaches the full line.
● Make sure the detergent used is not bad for your washed items.
● The machine may stop when cleaning long hair carpet due to blocked air outlet Stop the
machine if big quantity of foam or dirty water comes out and empty the dirty water tank before
use it again.
● Do not use foam detergent.
● Please make sure the users need assistant (including children) are under supervision when they
use the machine.
● Do not use liquid like pesticides, hair dyes and lubricant .
● Do not use to pick up any flammable or combustible objects or cigarettes.
● Do not use to pick up any oil or hot air, or dry dust .
● Do not use it if the hose is broken, avoid bending, stampede and pulling violently of the hose.
● Do not block the air outlet to avoid influence on the heat dissipation.
● Stop use it in case of any unusual noise and smell.
● Do not disassemble, repair and change the machine’s structure by yourself.
● Do not use it under the scene of heavy wind or rain.
● Do not immerse in water or liquid to avoid fire or electric shock hazard.
● Do not use to pick up any dust with infectious danger.
● Do not use without dirty water tank in position.
● lf the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● This appliance can be used by children aged from 8 years and above and persons with
reducedphysical. sensory or mental capabilities or lack of experience and knowledge if they have
beengiven supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. children shall not play with the appliance. Cleaning and user maintenance shall
notbe made by children without supervision.
● This appliance may be normal used under 50Hz or 60Hz the frequency need not to be adjusted.
PRECAUTIONS TO SOME FAILURES
● This machine is mainly for wet using, do not use to pick up large quantity of dust.
● Dry the dirty water tank, clean water tank and inside of the hose if the temperature is
extremely low to avoid freezing.
● Take out foreign matters from the hose when blocked before use it again.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environmentor human health
from uncontrolled waste disposal, recycle it responsibly to promotethe sustainable reuse
of material resources. To return vour used device, please use the return and collection
systems or contact the retailer where the product waspurchased. They can take this
product for environmental safe recycling.
- 1 -
● Do not use it other than cleaning.
● This machine is for household use only.
● Do not close to fire or heating equipment.
● Stop working if the water-spray mouth is blocked.
● Stop working if any foreign matters are taken in.
● Empty the tanks if anything in block before use again.
● Do not slant or ride on the machine.
● Do not use it in the scope touchable for kids.
● Not for outdoor use.
● Do not continue to use when the suction hole is blocked.
CAUTION
USE THE POWER CORD AND PLUG PROPERLY
● Clean the plug from time to time.
● Plug in well when use it.
● Unplug the machine if the machine will not be used for a long time.
● Unplug the machine before maintenance, checking and moving.
● Do not plug or unplug the machine with wet hands.
● Keep the plug away from kids.
● Do not damage the power cord. Do not pull the plug violently when move the machine.
● Do not use the machine in case of damaged power cord or plug.
● Do not use overloaded socket.
● Do not use in case of any failures, cut the power and unplug the machine.
BELOW MATTERS ARE NOT ALLOWED TO BE PICKED UP
● Dry dust
● Big quantity of powder
● Big quantity of sand and stones
● Big quantity of rubbish
● Metal matters like needles, pins
● Big polybag and stockings
● Things easy to be dumped inside
- 2 -
KNOW-HOW OF THE MACHINE
1
8
9
10
11
12
13 14
2
3
4
5
7
6
1. Handle
2. Switch
3. Big brush
4. Clean water tank
5. Released button for brush
6. Brush handle
7. Hook for brush
8. Button for dirty water tank
9. Dirty water tank
10. Power cord
11. Power cord hook
12. Hose
13. Small brush
14. Big brush
COMPONENTS LIST：
- 3 -
PREPARATIONS BEFORE USE
Take the hose hook from the
handle, insert it into the
machine and screw it tightly.
1
Take out the clean water tank.
Notice: pull the clean water tank with
an angle of 30 degree to take it out.
2
Take out the sealing pad, fill the
clean tank and seal it by the
sealing pad.
3
Assemble the brush as you may
want.
5
Wrap the hose around the base
and insert the hook.
6
Put the clean water tank in.
Notice: lock the bottom part to the
machine, then put the clean water
tank in.
4
- 4 -
HOW TO USE
HOW TO CLEAN STUBBORN STAINS
Plug the power cord and press
ON/OFF button.
1
Press the water-spray button to
spray water.
2
Brush the unit back and forth to
clean stains.
3
Suction inlet
Press the brush in the stains
position to suck all dirty water.
4
Power it off after cleaning. Wrap
the hose around the base and
lock in the hook.
Notice: clean the dirty water tank
after every use to avoid unpleasant
smell
5
Open the water-in sealing pad,
fill the clean water tank.
1
Put detergent into the tank.
2
Please use big brush when
clean big surface cleaning to
save time.
6
Use fabric detergent to clean stubborn stains. Make the water and detergent with a certain proportion to
fill the tank to the full line mark, and then install the clean water tank to the machine
- 5 -
SPECIFICATIONS
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
QUESTIONS
Name
Item number
Voltage/Frequency
Rated power
Max vacuity
Capacity of clean water tank/
Dirty water tank
IP rating
Portable carpet cleaner
W05
220-240V~ 50/60Hz
450W
≥11 kPa
1080ML /
800ML
IPX4
Fault Possible Reasons Messures
No working
after turning on
● The plug is not well plugged
● The cord is damaged
Please read below table carefully before contacting the maintenance agency to avoid any unnecessary
losses.
No water comes out
or little water comes
out after pressing the
water-spray button
No suction or weak
suction power
Turn if off, plug in well, or consult the
service agent via hotline
● Spray water mouth is blocked
● The handle or the pump has been
damaged
Take out the brush, wash the spray
water mouth or consult the service
agent via hotline.
● The machine is not on
● The dirty water tank is full
● The hose is not in good status
● The wind-in sponge is blocked
Turn on the power.
Clean the dirty water tank to use it
again.
Check the hose to make sure it is in
well status.
Clean or change the sponge.
- 7 -
CLEAN THE CLEAN WATER TANK
Pour water out from the tank. Slant the machine after plug off
to dump all water.
Install that empty clean water
tank and press the water-spray
button to spray the rest water.
CLEAN THE DIRTY WATER TANK
Clean the dirty water tank before
it reaches to the full line mark.
The float inside will work to stop
sucking if it is full of dirty water.
Take out the dirty water tank,
open the tank cover, take out
the wind guide tube and float.
Float
Clean all parts.
Clean the clean water tank
Tubes Guided ribs Insert the
clean floating along the guided
ribs, then insert the high part of
wind guided tube into the high
part of the tube inside the tank,
and tighten the tank cover.
Install the dirty water tank to the
machine.
Guided Ribs
Tank Tubes
Clean the dirty water tank after every use to avoid unpleasant smell.
- 6 -
1 3
2
1 2 3
4 5
PORTABLE CARPET CLEANER
W05
USER’S MANUAL
Email: [email protected]
Our Portable Carpet Cleaner have a one-year warranty.
If you have any questions, pls contact us.
Read the instruction manual before using the machine. Save it well.
142*210MM 128G铜板纸
