Before using your new product, please read these instructions to prevent any damage.
USER GUIDE
4.5 cu.ft. Top Mount
Compact Fridge - SS
NS-CF45TMSS26L
www.insigniaproducts.com
2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Grounding requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Main components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Preparing to install your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Before using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Providing proper ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Reversing the door position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Removing the door
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Maintaining your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cleaning the interior of your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Changing the interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
T
your refrigerator for extended periods . . . . . . . . . . . . . . . . . . . . . .14
Moving your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
10
Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-CF45TMSS26L represents the state of the art in top mount compact
refrigerator design and is designed for reliable and trouble-free
performance.
Important Safety Instructions
WARNING
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this appliance near water.
6 Clean only with a damp cloth.
7 Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8 Do not install near any heat sources, such as radiators, heat registers, stoves, or
other apparatuses (including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A
grounding-type plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10 Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the appliance.
11 Do not attempt to modify or extend the power cord of this appliance.
12 Unplug this appliance during lightning storms or when it will not be used for
long periods of time.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that
dangerous voltage constituting a
risk of electric shock is present
within your compact refrigerator.
This symbol indicates that there
are important operating and
maintenance instructions in the
literature accompanying your
compact refrigerator.
4
NS-CF45TMSS26L
www.insigniaproducts.com
13 Make sure that the available AC power matches the voltage requirements of
this appliance.
14 Do not handle the plug with wet hands. This could result in an electric shock.
15 Unplug the power cord by holding the plug, never by pulling the cord.
16 Do not turn the appliance on or off by plugging or unplugging the power
cord.
17 Turn off the appliance before unplugging it.
18 Refer all servicing to qualified service personnel. Servicing is required when
the appliance has been damaged in any way, such as when the power-supply
cord or plug is damaged, when liquid has been spilled or objects have fallen
into the appliance, or when the appliance has been exposed to rain or
moisture, does not operate normally, or has been dropped.
19 To reduce the risk of fire or electric shock, do not expose this appliance to rain,
moisture, dripping, or splashing, and do not place objects filled with liquid on
top of it.
20 If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent, or a similarly qualified person in order to avoid a hazard.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in
electric shock, fire, or death.
1 WARNING–Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
2 WARNING–Do not touch the interior of the freezer
compartment with wet hands. This could result in frost bite.
3 WARNING–Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
4 WARNING–Do not damage the refrigerant circuit when handling, moving, or
using the refrigerator.
5 WARNING–Do not use electrical appliances inside the food storage
compartment of the refrigerator unless they are of the type recommended by
the manufacturer.
6 WARNING–DANGER—Never allow children to play with, operate, or crawl
inside the refrigerator.
7 Risk of child entrapment. Before you throw away your old refrigerator or
freezer:
1) Take off the doors
2) Leave the shelves in place so that children may not easily climb inside
8 Unplug the refrigerator before carrying out user maintenance on it.
WARNING
5
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
9 This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance. Cleaning and maintenance should not be performed by children
without supervision.
10 If a component part is damaged, it must be replaced by the manufacturer, its
service agent, or similar qualified persons in order to avoid a hazard.
11 Follow local regulations regarding disposal of the appliance due to flammable
refrigerant and gas. All refrigeration products contain refrigerants, which
under the guidelines of federal law must be removed before disposal. It is the
consumer's responsibility to comply with federal and local regulations when
disposing of this product.
12 This appliance is intended to be used in household and similar environments.
13 Do not store or use gasoline or any flammable liquids inside or in the vicinity
of this refrigerator.
14 Do not use extension cords or ungrounded (two prong) adapters with this
appliance. If the power cord is too short, have a qualified electrician install an
outlet near the appliance. Use of an extension cord can negatively affect the
refrigerator’s performance.
15 Do not store explosive substances, such as aerosol cans with a flammable
propellant, in this appliance
16 This appliance is intended to be used in household and similar applications
such as:
• Staff kitchen areas in shops, offices, and other working environments;
• Farm houses and by clients in hotels, motels, and other residential type
environments;
• Bed and breakfast type environments;
• Catering and similar non-retail applications.
17 Lamp replacement by professionals.
Grounding requirement
This appliance must be grounded. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be inserted into an outlet
that is properly installed and grounded.
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or service person if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly
grounded.
6
NS-CF45TMSS26L
www.insigniaproducts.com
Features
Package contents
•
4.5 cu.ft. Top Mount Compact Fridge
• User Guide
Main components
Note: To remove a refrigerator shelf, lift it up, then slide it out.
7
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
Dimensions
Preparing to install your refrigerator
Before using your refrigerator
• Remove the exterior and interior packaging.
• Let the refrigerator stand upright for approximately four hours before
connecting it to power. This reduces the possibility of a malfunction in the
cooling system from improper handling during transportation.
• Clean the interior surface with a damp, warm cloth.
Finding a suitable location
• This refrigerator is designed to be free standing only, and should not be
recessed or built-in.
refrigerator when it is fully loaded.
• Allow 5 in. (12.7 cm) of space between the back and sides of the refrigerator
and any surrounding walls. This allows for proper air ventilation. Adjust the
feet to keep the refrigerator level.
18.5
i
n
.
(
47.0
c
m
)
20.1
i
n
.
(
51.
0
c
m
)
46.9 in. (119.0 cm)
8
NS-CF45TMSS26L
www.insigniaproducts.com
• Locate the refrigerator away from direct sunlight and sources of heat (stove,
heater, radiator, and so on). Direct sunlight may affect the acrylic coating
and heat sources may increase electrical consumption. Ambient
temperature below 50°F (10°C) or above 85°F (29.4°C) will hinder the
performance of this refrigerator. This refrigerator can be placed in a garage
as long as the ambient temperature in the garage is between 50°F (10°C)
and 85°F (29.4°C). It is not designed for use outside.
• Avoid locating the refrigerator in moist areas.
• This refrigerator can be placed on carpet, but care should be taken not to
damage the carpet when moving the refrigerator.
Leveling your refrigerator
• It is very important for the refrigerator to be level in order to function
properly. If the refrigerator is not leveled during installation, the doors may
not close or seal properly, causing cooling, frost, or moisture problems.
• To level your refrigerator, you may either turn the leveling foot clockwise to
raise that side of the refrigerator or turn it counter-clockwise to lower that
side.
Providing proper ventilation
Place the refrigerator at least 5 in. (12.7 cm) from the wall to ensure proper airflow
to the compressor. Do not place the refrigerator near any heat sources, such as a
heater or stove, as this may put strain on the compressor.
Providing a proper power supply
Check your local power source. This refrigerator requires a 110V-120V, 60Hz power
supply.
Use a receptacle that accepts the grounding prong. The power cord is equipped
with a 3-prong (grounding) plug which goes into a standard 3-prong (grounding)
wall outlet to minimize the possibility of electric shock.
Note: Having someone push against the top of the refrigerator helps to take
some weight off the leveling foot, making it easier to adjust.
Notes:
• The refrigerator should always be plugged into its own individual electrical
outlet which has a voltage rating that matches the rating plate.
• Never unplug your refrigerator by pulling on the power cord. Always grip the
plug firmly and pull straight out from the outlet.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet Using a grounding adapter
9
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
Setting the thermostat
• Turn the temperature control knob to 3, the internal temperature
of the refrigerator becomes lower.
• Turn the temperature control knob to 1, the internal temperature
of the refrigerator becomes higher.
•
The number on the knob only represents the temperature level, but does not mean the
speciÿc temperature, the "O" means stop working.
NOTE:Recommended temperature setting is between "1" and "3".
10
NS-CF45TMSS26L
www.insigniaproducts.com
Defrost
Reversing the door position
Your refrigerator is built with a reversible door. Based on the location where you
plan to use your compact refrigerator, you may it more convenient to reverse
the position of the door, to have it open from right to left instead of left to right.
Before you begin
You will need: A 10 mm socket driver and a Phillips screw driver.
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that the refrigerator be tilted backwards. Rest the
refrigerator on something solid, such as a chair, just below the top panel.
• Do not lay the refrigerator complet
you do not damage the
coolant system.
CAUTION: To avoid injury to yourself or your property, we recommend that
someone assist you during the door reversal process.
•
• Remove the food from the refrigerator and place it properly to prevent food
from melting.
• Clear the drain pipe (to use soft materials to prevent damage to the liner),
Prepare the water containers for defrosting (pay attention to clean the
• You can also use the appropriate amount of hot water to speed up the defrost,
with a dry towel to dry the water after defrosting.
• After defrosting, put food back in cabinet, and power on the refrigerator.
avoiding
11
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
Removing the door
1)
2) Remove the hinge cover, then remove the upper hinge screws, upper hinge and hole cap
on the other side.
Right
12
NS-CF45TMSS26L
www.insigniaproducts.com
4) Remove the refrigerating door, remove the bottom hinge and adjustable foot of the other side.
5)
3)Remove the freezer door, the middle hinge, and the screw hole caps.
Install the adjusting foot on the right side, take out two limit blocks from the plastic bag in the
instruction manual and ÿx them to the left side of the lower end cover respectively with screws.
Remove the other side of the lower hinge from the instruction bag and install on the left side.
13
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
6)Place the refrigerating door from top to bottom, take out the gasket from the plastic bag in the
instructions and put it into the axle hole on the left side of the refrigerating door, as shown
in the picture. Fix the center hinge with screws and install
the studs.
7) Put the freezer door on the middle hinge, assemble the upper hinge on the other side,
fix the hinge cover on the upper hinge and fix hole cap on the other side.
14
NS-CF45TMSS26L
www.insigniaproducts.com
Maintaining your refrigerator
Your refrigerator is designed for year-round use with only minimal cleaning and
maintenance.
When you first receive it, wipe the case with a mild detergent and warm water,
then wipe dry with a dry cloth. Do this periodically to keep your refrigerator
looking new.
Cleaning the interior of your refrigerator
1 Turn off the refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Wash the inside with a damp, warm cloth.
4 Dry the interior and exterior with a soft cloth.
Changing the interior light
A
ny replacement or maintenance of the LED lamps is intended to be made by
the manufacturer, its service agent or similar qualified person.
Turning off your refrigerator for extended periods
1 Turn off the refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Clean the refrigerator.
4 Leave the door open slightly to avoid possible formation of condensation,
mold, or odor.
CAUTION: To prevent damage to the finish, do not use:
• Gasoline, benzine, thinner, or other similar solvents.
• Abrasive cleaners.
Note: It is recommended that you soak your cloth in a baking soda solution
before washing the interior. Mix one quart of warm water and two tablespoons
of baking soda.
CAUTION: Use extreme caution with children. The refrigerator should not be
accessible to child's play.
15
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
Moving your refrigerator
1 Turn off the refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Securely tape down all loose items inside of your refrigerator.
4 Tape the doors shut.
Tips on saving energy
• Place your refrigerator in the coolest area of the room, away from
heat-producing appliances or heating ducts, and out of direct sunlight.
• Let hot foods cool before placing them in the refrigerator. Overloading the
refrigerator forces the compressor to run longer. Foods that freeze too slowly
may lose quality or spoil.
• Wrap foods properly and wipe containers dry before placing them in the
refrigerator. This cuts down on frost build-up inside the refrigerator.
• Organize and label food to reduce door openings and extended searches.
Troubleshooting
Note: Make sure that your refrigerator stays in an upright position during
transportation.
CAUTION: Do not try to repair your refrigerator yourself. Doing so invalidates the
warranty.
PROBLEM SOLUTION
My refrigerator does not work. • Make sure that your refrigerator is securely
plugged into a working outlet.
• Make sure that your power source has the
correct voltage. Your refrigerator’s voltage rating
is on a label on the back of your refrigerator.
• Check the house fuse or circuit breaker box and
replace the fuse or reset the circuit breaker.
The refrigerator compartment
has a bad odor.
• Make sure that all food with a strong odor (like
onions) is wrapped or stored in airtight
packaging.
• Certain containers and wrapping materials (such
as paper, foil, or plastic) can cause odors. If you
think this might be the case, try using different
containers or a different brand of wrapping
material.
• Check for spoiled food and remove it.
• Clean the inside of your refrigerator. See
Maintaining your refrigerator on page 14.
16
NS-CF45TMSS26L
www.insigniaproducts.com
The refrigerator doors do not
close completely.
• Make sure that no food packages are in the way.
• Make sure that the door gaskets (seals) are clean.
See Maintaining your refrigerator on page 14.
• If the door gasket does not seal, try heating then
cooling the seal. You can use an electric hair
dryer to heat the seal.
• Make sure that your refrigerator is level. See
Leveling your refrigerator on page 8.
• Make sure that the top of your refrigerator is
tilted backward about 0.4" (10 mm) to 0.6"
(15 mm). See Leveling your refrigerator on
page 8.
The temperature is too hot. • You may have left the doors open too long or
opened them too frequently.
• Make sure that no obstacle is keeping the doors
from closing correctly.
• Adjust the refrigerator or freezer compartment
temperature. See
Setting the thermostat on
page 9.
• Your refrigerator may not have enough
clearance from walls or the ceiling. See Providing
proper ventilation on page 8.
The temperature is too cold. • Adjust the refrigerator or freezer compartment
temperature. See
Setting the thermostat on
page 9.
A layer of frost occurs in one
of the compartments.
• A layer of frost may occur on the compartment’s
interior walls if the freezer is opened frequently
or kept open too long.
• Make sure that the air outlets are not blocked by
food.
• Make sure that the doors are fully closed.
• To remove the frost, see
Defrosting your
refrigerator on page 10.
The refrigerator door is hard
to open.
• When you open the refrigerator door, warm air
rushes inside. When you close the door, the
warm air rushes to the condenser which causes a
vacuum. This causes the door to be hard to open
for about 10 to 15 seconds after closing.
• If the door is hard to open at other times, try
rubbing paraffin wax or petroleum jelly along
the edges of the entire gasket. Paraffin wax is
used for canning and is safe for use around food.
PROBLEM SOLUTION
17
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
The compressor runs for a
long time or turns on and off
frequently.
The compressor runs longer if:
• The room temperature is high.
• You just added a large amount of food. Wait for
the food to freeze, then check again.
• You open and close the door frequently.
• The door gasket is dirty. Clean the gasket. See
Maintaining your refrigerator on page 14.
• Your refrigerator has been disconnected for a
period of time. Wait for your refrigerator to cool
(about four hours) before adding food.
• You have the temperature set too low.
The light inside the
refrigerator does not turn on.
• Make sure that your refrigerator is plugged into
a working outlet.
• If a door stays open too long, your refrigerator
automatically turns off the light.
• Close then open the door again.
• Check to see if the light is damaged. If the light is
damaged, have it replaced by a qualified service
technician. See
Changing the interior light on
page 14.
The refrigerator makes
unusual noises or vibrations.
The following sounds are normal:
• Compressor running noises.
• Air movement noise from the small fan motor in
the freezer compartment or other
compartments.
• Gurgling sound similar to water boiling.
• Clicking noise before the compressor starts.
Other unusual noises or vibrations may occur:
• If you have items on the top of your refrigerator.
Remove the items.
• If your refrigerator is not level. See
Leveling your
refrigerator on page 8.
• If your refrigerator is touching walls. Move it
away from the walls.
• If the shelves or drawers are installed incorrectly.
The outside of the refrigerator
is hot.
Heat dissipation from the condenser may make the
outside feel hot. This is normal and happens if:
• The room temperature is high.
• You have too much food in your refrigerator.
• You open and close the doors excessively.
Water condenses on the
outside of the refrigerator.
• Condensation on the exterior surface and door
seal is normal when the room humidity is high.
• When you open the door, warm, moist outside
air meets the cold dry air inside your refrigerator.
This is normal.
PROBLEM SOLUTION
18
NS-CF45TMSS26L
www.insigniaproducts.com
Dimensions (W x D x H)
18.5 × 20.1 x 46.9 in (47.0 × 51.0 × 119.0 cm)
Power requirements 115 V~60 Hz
9A.0
Power consumption (annual) 329 kWh
Power cord length 5.4 ft. (1.65 m)
62.8 Ibs (28.5 kg)
Weight
Current
19
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY
Denitions:
The Distributor* of Insignia branded products warrants to you, the original purchaser of this
new Insignia-branded product (“Product”), that the Product shall be free of defects in the
original manufacturer of the material or workmanship for a period of one (1) year from the
date of your purchase of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United States or Canada
from a Best Buy branded retail store or online at
www.bestbuy.com or www.bestbuy.ca and
is packaged with this warranty statement.
How long does the coverage last?
Wh
at does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of
the Product is determined to be defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or
(2) replace the Product at no charge with new or rebuilt comparable products or parts.
Products and parts replaced under this warranty become the property of Insignia and are
not returned to you. If service of Products or parts are required after the Warranty Period
expires, you must pay all labor and parts charges. This warranty lasts as long as you own your
Insignia Product during the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or from a Best Buy online
website (www.bestbuy.com or www.bestbuy.ca), please take your original receipt and the
Product to any Best Buy store. Make sure that you place the Product in its original packaging
or packaging that provides the same amount of protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY or in Canada call
1-866-BESTBUY. Call agents may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy branded retail stores
or websites to the original purchaser of the product in the county where the original
purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
• Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such as power surges
• Accidental damage
• Misuse
• Abuse
• Negligence
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modiÿcation of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied for lengthy periods
(burn-in).
• Damage due to incorrect operation or maintenance
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product or
the date of delivery (if later than the date of purchase). Your purchase date is printed on the
receipt you received with the Product. In the event that Authorized Partner ceases to sell the
covered Insignia branded product, this warranty shall terminate for that product and there
shall be no repair or replacement of the Product.
20
NS-CF45TMSS26L
www.insigniaproducts.com
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA, AAA, C, etc.)
• Products where the factory applied serial number has been altered or removed
• Loss or Theft of this product or any part of the product
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly
illuminated) grouped in an area smaller than one tenth (1/10) of the display size or up to
five (5) pixel failures throughout the display. (Pixel based displays may contain a limited
number of pixels that may not function normally.)
• Failures or Damage caused by any contact including but not limited to liquids, gels or
pastes.
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY
FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT, INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER
EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL EXPRESS AND IMPLIED
WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE WARRANTY
PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contac
t Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its liated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Rich eld, MN 55423 U.S.A
©2025 Best Buy. All rights reserved.
21
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
22
NS-CF45TMSS26L
www.insigniaproducts.com
23
4.5 cu.ft. Top Mount Compact Fridge - SS
www.insigniaproducts.com
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada)
INSIGNIA is a trademark of Best Buy and its liated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Rich eld, MN 55423 U.S.A.
©2025 Best Buy. All rights reserved.
V1 ENGLISH
25-0052
