USB-A one-port charging
The USB-A port is suitable for smartphones,
smartwatches, and earbuds. It provides up to
12W of power when used alone.
Two-ports charging
When both ports are used together, they share
20W max (5V, 4A).
USING YOUR SURGE PROTECTOR
• Plug your wall tap into a wall outlet. You can also
mount your wall tap onto a wall outlet using the
screw hole.
• The Protected LED lights when surge protection is
working. If the indicator no longer lights, the surge
protector has protected your device from a power
surge. Replace your wall tap.
USB-C one-port charging
The USB-C port is more suitable for tablets and
smartphones. It provides up to 30W of power when
used alone.
Before using your new product, please read these instructions to prevent any damage.
QUICK SETUP GUIDE
5-Outlet Surge
Protector Wall Tap
NS-HXWT26
PACKAGE CONTENTS
• 5-outlet surge protector wall tap
• Quick Setup Guide
FEATURES
• Five wide-spaced AC outlets power multiple
devices at the same time
• One USB-C PD port (30W) and one USB-A port
(12W), or 20W (5V, 4A when you use two ports)
total when used together to charge your
smartphones, tablets, and more
• Surge protection guards your device against
unexpected power surges
• LED indicator lets you know when your devices are
protected
OVERVIEW
USB-A
USB-C
USB-C one-port (30W)
Fast charges mobile phones
USB-A one-port
(5V/2.4A, 12W)
Normal charging
Mounting screw hole
Protected
LED indicator
AC outlet
USB-C
USB-A
V1 ENGLISH 25-0153
LEGAL NOTICES
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to
operate the equipment.
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call
1-877-467-4289 (U.S. and Canada)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2025 Best Buy. All rights reserved.
SPECIFICATIONS
• Dimensions (H×W×L) (not including plug):
5 × 3.5 × 1.6 in. (12.6 × 8.9 × 4.1 cm)
• Load rating: 15 amps
• Line voltage: 120V AC ~ 60Hz
• Surge protection: 3 lines (L-N / L-G / N-G)
• Maximum surge current: 72,000 amps
• Maximum energy dissipation: 1,080 joules
• EMI/RFI noise ltering: Up to 40 dB
• Surge protector certication: UL-1449 certied
• USB output: Use One Port:
USB-C: PD 30W
DC 5V/3A, 9V/3A, 15V/2A, 20V/1.5A
(PPS) 5-11V/3A, 5-16V/2A, 30W MAX
USB-A: 5V/2.4A, 12W Max
Use Multi Ports:
Total 5V/4A (shared)
3A Max for USB-C and 2.4A Max for USB-A
TROUBLESHOOTING
• If your surge protector turns o and the LED
indicator is o, it means the surge protection
circuitry has reached the end of its service life and
the wall tap needs to be replaced.
• If the wall outlet which your surge protector plugs
into is loose, or does not hold the product weight
well, use the screw-mount option.
SAFETY INFORMATION/CAUTION
READ ALL INSTRUCTIONS BEFORE USING.
• RISK OF ELECTRIC SHOCK – Use only in dry locations and only indoors.
• DO NOT plug into another relocatable power tap or extension cord.
• DO NOT “daisy chain” surge protectors.
• DO NOT use with any aquarium equipment.
• DO NOT use if correctly grounded outlets are not available.
• This device features internal protection that will disconnect the surge
protective component at the end of its useful life and Auto Shutdown
this device. At this time, no output power will be provided to AC
outlets and DC ports and device needs to be replaced.
