��1000
Power Burst
Jump Starter & Air Pump
PRODUCT DIAGRAM
CONTROL BUTTONS
Pressure unit change/Flashlight control
Dial down adjustment
Power control/inflator start
Dial-up adjustment
Mode change
1. EC5 jump start connector
2. USB output
3. Multi information LED
4. TYPE C input
5. Inflator connection
6. LED flashlight
7. Control buttons
Product Specifications
Storage Temp: -20 - 60° C Product dimensions: 150 x 129 x 37mm
Charging port: Type-C Charging spec: DC5V/2A
USB output: DC5V/2A Charging time: ≤ 6 hours
LED Light: 1 LED Battery capacity: 8800mAh
Operating Temp: -10 - 45° C
Inflator Speed��Car tires up to 18 inch ~ 15 minutes (from empty to full�
Peak Current: 1000A
Inflator tube��240mm extension (Including air tap)
1
1
2
3
7
6
5
4
Product Content
Main unit x 1 Carrying bag x 1
AC Charger x 1 Car Charger x 1
USB Cable x 1 Inflator Tube x 1
User Manual x 1 Instruction Card x 1
Air Pump Operating Instructions
Using the Inflator Pump
Suitable Applications:
Most vehicles with inflatable wheels (exclude trucks that are> 5 tons), sports
equipment, inflatable swimming apparatus, and small air mattresses.
This product can be operated with manual or preset limits for automatic
inflation. Four different units of measure in pressure can be selected for
ease of operation. As a side benefit, this product can also be used as a
pressure gauge.
It comes with 4 preselect modes indicated as CAR, MOTOCYCLE, BICYCLE and
BASKETBALL features for a no-guess operation. Once you have selected the
mode, you can fine-tune the pressure to fit the applications. Once this is all set,
the automatic function will take over with no guesswork.
With an added LED, it is perfect for those hard-to-see areas when it is dark.
Jump Starter Cable x 1Nozzle Kit x 1
2
Car/Motorcycle/Electric Scooter/Bicycle
Press and lock the inflator quick-connect to the tire valve stem. Turn on the
main unit, and the LED will display the current tire pressure. Select either
manual or preset mode, then inflate to the desired pressure setting.
Inflatable ball/Air floatation equipment/Air mattress
Choose the right plastic inflator adaptor; clip and press into the quick
connect. Turn on the main unit, select manual or preset mode, then inflate.
Product offers 4 different units of pressure measurement:
(PSI) / (BAR) / (KPA) / (Kg/cm
2
)
Four modes of preset values
BAR
Power ON/OFF
Press power button for 3 seconds, it will turn on, LED will display onboard
battery capacity.
Basketball
0.6
Car
2.5
Bicycle
2.1
Motorcycle
2.2
3
To shut off unit, simply press power button for 3 seconds. If unit is ON and
there is no activity for more than 3 minutes, it will shut off automatically. To
turn back on, simply follow the power on procedures.
Mode Change
This unit has 4 preset modes to choose from. The 4 modes are “CAR”
“MOTORCYCLE” “BICYCLE” &“BASKETBALL”.
You can press once to toggle to right mode. A preset pressure value will
be selected but you can adjust it as you see fit.
Unit Change
This unit has 4 pressure units of measure for your convenience. They are:
“PSI” “BAR” “KPA”& “Kg/cm² ”. You can press once to toggle to right unit
of measure. Your choice of unit will reappear on the next power on.
Value Adjustment
All preset modes include a predetermined pressure value for your convenience.
However, if you need to fine-tune it, you can press the or for finer
adjustment. Pressing once will adjust 0.01 value once, holding it will quickly
adjust addtional 0.01 value. Waiting for 3 seconds will set value, or press to
set. Turning the pump on will automatically stop it at the preset point.
4
LED Flashlight
This unit has a built in LED flashlight to illuminate it. First you power
on the unit, then press for 3 seconds, and the LED will turn on.
Pressing again will turn it into S.O.S. flash mode. A sustained press will
turn off the LED.
Power Bank Function
This unit has a USB outlet 5V/2A to charge up your portable
electronics. It has an 8800mAh battery, and it will provide ample
charging
power to your electronics. To use this feature, all you need to do is
power on the unit.
JUMP STARTER OPERATION
The jump-start unit is suitable to diesel 5.0L gasoline or 3.0L diesel
engines. (A colder climate or degraded engine system will impact the
effectiveness for diesel period�)
When your car is disabled on the road, this jump starter will help you
to get back on the road without calling for heip.
Using high output Lithium battery technology, the battery will quickly
generate up to 1000A peak current to crank over your disabled engine.
In order to maximize safety, this unit comes with 8 protection
parameters.
h
5
charging
1. Short circuit 2. Reverse polarity 3. Over-charging 4. Excess current output
5. Excess temperature 6. Overload 7. Low voltage limits 8. Excess voltage limits
Note: Please make sure the unit has more than 30% of battery capacity remaining
Step 2
Clip the jump-start cable to the battery
terminal. RED TO RED and BLACK TO
BLACK. Make sure the alligator clip is
reasonably secure and target battery
post is free of any rust and oxidation.
Step 1
At this point, make sure the RED (+
POSITIVE) and BLACK (-NEGATIVE)are
attached correctly. Connect the other
cable connector to the jump-start
connection location. Turn the power
on for the unit.
Step 3
Start your car at once. If it fails to start,
retry in about 20 seconds and repeat
process. If your car fails to start after 4
attempts, please stop and call for help. If
the outside temperature is below freezing
point, you may try it up to 6 times.
Step 4
Once you successfully start your car, please
remove the alligator clips ASAP to prevent
damage to the unit.
Charging unit
Use the TYPE C input to charge the unit. Make sure the power source
is at least 5V/2A, if less, it will take longer to charge. With the correct
6
power source, it will
take around 6 hours to completely charge the unit.
The charging icon on the LED will blink and continue to show capacity until
it reaches 100% and shuts off automatically. TO MAKE SURE YOUR CHARGER
IS FULLY CHARGED, CHARGE IT FOR 12 HOURS BEFORE INITIAL USE.
Product Features
There are six patents for this product
1. Mini/lightweight/portable/easy storage, it is a necessity for a self-
driving tour & outdoor activities.
2. Multi-function in one product: pressure gauge + air pump + lighting +
power bank + jump starter
3. Safety and efficiency with a high-rate lithium polymer battery.
4. Eight features to guarantee safety
5. Can inflate up to 150PSI with super-powerful inflatable ability
6. High-precision tire pressure detection, accurate to 0.01BAR
7. Low battery alert function, to make sure your product always has
sufficient power
Caution
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS
PRODUCT. Failure to follow these safety instructions may result in an
ELECTRICAL SHOCK, EXPLOSION, or FIRE, which may lead to a SERIOUS
INJURY, DEATH, or PROPERTY DAMAGE.
ELETCTRICAL SHOCK. Product is an electrical device that can shock and cause
serious injury. Do not cut power cords. Do not submerge in water or get wet.
EXPLOSION. Unmonitored, incompatible, or damaged batteries can explode if
used with product. Do not leave product unattended while in use. Do not
7
EXPLOSIVE GASES. Working in the vicinity of a lead-acid is dangerous.
Batteries generate explosive gases during normal battery operation. To
reduce risk of battery explosion, follow all safety information instructions
and those published by the battery manufacturer and manufacturer of any
equipment intended to be used in the vicinity of battery. Review cautionary
markings on these products and on engine.
Accessories may present a choking hazard to children. Do not leave children
unattended with product or any accessory. The product is not a toy.
Never plug the air tube into any person or animal’s mouth/ear/noise/eye.
Using near any combustible or explosive liquid or gas place (such as gas
station) is forbidden.
The air tube will be really hot after inflation, watch your hand while
removing it.
Suggest waiting for 5-10 minutes between inflating each tire .
Do not plug in the charging cable for a long time, in case it over charges or
damages the product .
attempt to jump start a damaged or frozen battery. Use product only with
batteries of recommended voltage. Operate product in well ventilated areas.
FIRE. Product is an electrical device that emits heat and is capable of causing
burns. Do not cover product. Do not smoke or use any source of electrical
spark or fire when operating jump start . Keep product away from
combustible materials.
8
WARRANTY, REGISTRATION & TECHNICAL SUPPORT
PLEASE FILL OUT AND RETURN THE PRODUCT REGISTRATION CARD INCLUDED
WITH YOUR NEW ROYAL PRODUCT OR FILL OUT THE PRODUCT REGISTRATION
FORM ON THE ROYAL WEB PAGE AT: http:// www.royal.com.
BE SURE TO KEEP A COPY OF YOUR SALES RECEIPT!
STANDARD WARRANTY
ROYAL CONSUMER INFORMATION PRODUCTS, INC. ("Royal"), at 1011 U.S.
Highway 22 west, Suite 202 Bridgewater, NJ 08807 USA WARRANTS that your
NEW Product is free of defects of workmanship and materials. If there is a
defect or malfunction of this product, Royal will repair it free of charge as
follows:
PARTS: New or comparable rebuilt parts in exchange for
defective parts for ONE (1) YEAR from date of customer
purchase.
LABOR: Royal provides labor warranty for (90) DAYS from
date of end-user purchase. Product must be sent postage
prepaid and insured to Royal in accordance with the warranty
procedures outlined below. At completion of the repair, the
consumer will be responsible for the cost for any parts or
services no longer covered under the warranty.
This warranty does not apply to persons who purchased this product
second-hand or used.
This warranty does not include adjustments, parts and/or repairs required by
circumstances beyond the control of Royal, including but not limited to fire
or other casualty, accident, neglect, abuse, misuse, abnormal use, or battery
leakage damages.
THERE ARE NO OTHER EXPRESSED WARRANTIES EXCEPT AS STATED HEREIN.
AFTER THE PERIOD OF EXPRESSED WARRANTY SET FORTH HEREIN, THERE
ARE NO EXPRESSED OR IMPLIED WARRANTIES AND THOSE EXCLUDED
INCLUDE THOSE OF MERCHANTABILITY AND FITNESS FOR PARTICULAR
PURPOSE. Royal shall NOT be held liable for CONSEQUENTIAL DAMAGES
resulting from any failure, defect or malfunction of this product. Some States
do not allow limitations on how long an implied warranty lasts and some
9
States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations may not apply to you.
WARRANTY PROCEDURES
TO OBTAIN SERVICE UNDER THE TERMS OF THIS WARRANTY:
Please do the following:
1. Send a copy of your original sales receipt showing original purchase date,
along with your mailing and shipping addresses, the model name of the
product, and a note describing the nature of the problem to:
Royal Consumer Information Products, Inc.
Warranty Processing
50 Hilton Street
Easton,
PA 18042-7391 USA
Do Not Return the Product to This Address!
2. You will receive a return authorization number via U.S Mail within 7-12
business days from the date your return request is received if it is
determined that there is a basis for a replacement product. The return
authorization form you receive will list the return procedures, applicable
charges, if any, and the correct shipping address for the returned product.
PRODUCT SUPPORT HOTLINE:
For questions on use of this product or this warranty call
1-800-272-6229 (in the U.S. and Canada) or in Mexico call
01-800-849-4826, Monday through Friday during normal
business hours. You can also e-mail Royal at: hotline@royal.com
10
JS1000IM0420
1011 U.S. Highway 22 West
Suite 202
Bridgewater, NJ 08807
�������������
© Copyright
Royal Consumer Information Products, Inc.
2020, All Rights Reserved.
�����
®
�����������������������������������
������
Power Bust
Jump Starter & Air Pump
