Compressor Wine Cooler
FP10176US-BK
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US office: Fontana UK office: Ipswich AU office: Truganina
DE office: Hamburg
FR office: Saint Vigor d'Ymonville
PL office: Gdańsk
US:cs.us@costway.com
UK:cs.uk@costway.com
Before You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled
near to the area in which they will be placed in use, to avoid
moving the product unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product
away from babies and children as they potentially pose a serious
choking hazard.
Warning: Before connecting this wine cooler to a power
source, let it stand upright for approximately 24 hours.
Warning: To reduce the risk of fire, electrical shock, or injury
when using your appliance, follow these basic precautions:
·Before using the appliance, please read this user manual to ensure
that you gain the maximum benefit from it.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge ifthey have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
If the SUPPLY CORD is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
When positioning the appliance, ensure the supply cord is not trapped or
damaged.
Do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance.
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the drink storage compartments of
the appliance, unless they are of the type recommended by the
manufacturer.
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
1)
10)
11)
2)
3)
4)
5)
6)
7)
8)
9)
02 03
Before You Start
Please read all instructions carefully.
Retain instructions for future reference.
Separate and count all parts and hardware.
Read through each step carefully and follow the proper order.
We recommend that, where possible, all items are assembled
near to the area in which they will be placed in use, to avoid
moving the product unnecessarily once assembled.
Always place the product on a flat, steady and stable surface.
Keep all small parts and packaging materials for this product
away from babies and children as they potentially pose a serious
choking hazard.
Warning: Before connecting this wine cooler to a power
source, let it stand upright for approximately 24 hours.
Warning: To reduce the risk of fire, electrical shock, or injury
when using your appliance, follow these basic precautions:
·Before using the appliance, please read this user manual to ensure
that you gain the maximum benefit from it.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge ifthey have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
If the SUPPLY CORD is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
When positioning the appliance, ensure the supply cord is not trapped or
damaged.
Do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance.
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the drink storage compartments of
the appliance, unless they are of the type recommended by the
manufacturer.
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
1)
10)
11)
2)
3)
4)
5)
6)
7)
8)
9)
02 03
·Note: This appliance contains flammable refrigerant R600a and foaming
agent cyclopentane.
Please avoid contact fire when you transport and use it.
Please ask professional for servicing when the machine broke down.
Please send it to your local appointed disposal station when you discard it.
Save these instructions.
·WARNING: Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
·WARNING: Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
·WARNING: Do not damage the refrigerant circuit.
·WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
·WARNING: Risk of child entrapment. Before you throw away your old
refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily climb inside.
During using, service and disposal the appliance, please
pay attention to symbol similar as left side, which is
located on rear of appliance (rear panel or compressor)
and with yellow or orange color. It’s risk of fire warning
symbol. There are flammable materials in refrigerant
pipes and compressor. Please be far away fire source
during using, service and disposal.
1: Upper Hinge
2: Door Gasket
3: Shelves
4: Door Handle
5: Leveling Feet
6: Bottom Hinge
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
This appliance is intended to be used in household and similar
applications such as：
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
To avoid contamination of drink, please respect the following
instructions:
- Opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance.
- Regularly clean surfaces that can come in contact with drink and
accessible drainage systems.
- If the refrigerating appliance is left empty for long periods, switch off,
defrost, clean, dry, and leave the door open to prevent mould developing
within the appliance.
This appliance is designed to be free standing only, and should not be
recessed or built-in.
Place your appliance on a floor that is strong enough to support the
appliance when it is fully loaded. To level your appliance, adjust the
leveling feet at the bottom of the appliance.
Allow 50mm of space between the top, the back and sides of the appliance,
which allows theproper air circulation to cool the compressor and
condenser.
Locate the appliance away from direct sunlight and sources of heat
(stove, heater, radiator, etc.). Direct sunlight may affect the acrylic
coating and heat sources may increase electrical consumption. Extreme
cold ambient temperatures may also cause the unit not to perform
properly.
Avoid locating the appliance in moist areas.
Plug the unit into an exclusive, properly installed-grounded wall outlet.
Do not under any circumstances cut or remove the third (ground) prong
from the power cord. Any questions concerning power and/or grounding
should be directed toward a certified electrician.
After plugging the applianceinto a wall outlet, allow the appliance to cool
down for 2-3 hours before placing any items in the compartment.
INSTALLATION INSTRUCTIONS
PARTS AND FEATURES
12)
13)
14)
15)
04 05
·Note: This appliance contains flammable refrigerant R600a and foaming
agent cyclopentane.
Please avoid contact fire when you transport and use it.
Please ask professional for servicing when the machine broke down.
Please send it to your local appointed disposal station when you discard it.
Save these instructions.
·WARNING: Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
·WARNING: Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
·WARNING: Do not damage the refrigerant circuit.
·WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
·WARNING: Risk of child entrapment. Before you throw away your old
refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily climb inside.
During using, service and disposal the appliance, please
pay attention to symbol similar as left side, which is
located on rear of appliance (rear panel or compressor)
and with yellow or orange color. It’s risk of fire warning
symbol. There are flammable materials in refrigerant
pipes and compressor. Please be far away fire source
during using, service and disposal.
1: Upper Hinge
2: Door Gasket
3: Shelves
4: Door Handle
5: Leveling Feet
6: Bottom Hinge
Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
This appliance is intended to be used in household and similar
applications such as：
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
To avoid contamination of drink, please respect the following
instructions:
- Opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance.
- Regularly clean surfaces that can come in contact with drink and
accessible drainage systems.
- If the refrigerating appliance is left empty for long periods, switch off,
defrost, clean, dry, and leave the door open to prevent mould developing
within the appliance.
This appliance is designed to be free standing only, and should not be
recessed or built-in.
Place your appliance on a floor that is strong enough to support the
appliance when it is fully loaded. To level your appliance, adjust the
leveling feet at the bottom of the appliance.
Allow 50mm of space between the top, the back and sides of the appliance,
which allows theproper air circulation to cool the compressor and
condenser.
Locate the appliance away from direct sunlight and sources of heat
(stove, heater, radiator, etc.). Direct sunlight may affect the acrylic
coating and heat sources may increase electrical consumption. Extreme
cold ambient temperatures may also cause the unit not to perform
properly.
Avoid locating the appliance in moist areas.
Plug the unit into an exclusive, properly installed-grounded wall outlet.
Do not under any circumstances cut or remove the third (ground) prong
from the power cord. Any questions concerning power and/or grounding
should be directed toward a certified electrician.
After plugging the applianceinto a wall outlet, allow the appliance to cool
down for 2-3 hours before placing any items in the compartment.
INSTALLATION INSTRUCTIONS
PARTS AND FEATURES
12)
13)
14)
15)
04 05
Key Function
① Unlock key: long press for 2 seconds to unlock
② Light/CF key: short press to turn on or off the light; long press to switch
between Fahrenheit and Celsius
③ Add key: temperature setting
④ Minus key: temperature setting
Error code
LL: When the temperature measured by the temperature probe is lower than
0 °C /32 °F, "LL" is displayed, flashing, and the cooling is stopped.
Forced defrosting function
When the compressor works for 12 hours, the compressor will stop working
for 40 minutes.
Memory function
The control board is re-energized after each power-off, the temperature
setting value, Fahrenheit/Celsius state will be the same as before the
power-off, and the length of power-off time is not limited.
The refrigerator doesn’t work
If the product is not working properly, please check and handle according to
the following methods. If the situation can not be changed, please contact
the after-sales service center in time, and be sure to provide the model name
and product number in detail.
When the temperature probe is short-circuited or disconnected, the setting
temperature value is displayed, the compressor will work for 15 minutes and
stop for 18 minutes.
When the temperature measured by the temperature probe is higher than 37
°C /99 °F, the setting temperature value is displayed, the compressor will
work for 15 minutes and stopfor 18 minutes.
Automatic locking function
When all the key no operation for 20 seconds, the key will be locked
automatically. After locking, the plus and minus keys can not be operated.
The unlock key and light / CF key operate normally.
Auto light off function
When all the key no operation for 10 minutes, the lamp will turn off
automatically
Adjustable range
Minimum value: 5°C / 41°F
Maximum value: 18°C / 64°F
Display range
Temperature display range of control panel:0~37°C / 32~99°F
Display stability
In the Celsius state: When the temperature measured by the temperature
probe is within ± 1 °C of the set temperature, the temperature display will
display the set temperature value.
In theFahrenheit state: When the temperature measured by the temperature
probe is within ± 2 °F of the set temperature, the temperature display will
display the set temperature value.
Setting the Temperature Control
OPERATING YOUR UNIT
GENERAL FAULT DESCRIPTION
Is the power on?
Is the power supply voltage too low?
06 07
Key Function
① Unlock key: long press for 2 seconds to unlock
② Light/CF key: short press to turn on or off the light; long press to switch
between Fahrenheit and Celsius
③ Add key: temperature setting
④ Minus key: temperature setting
Error code
LL: When the temperature measured by the temperature probe is lower than
0 °C /32 °F, "LL" is displayed, flashing, and the cooling is stopped.
Forced defrosting function
When the compressor works for 12 hours, the compressor will stop working
for 40 minutes.
Memory function
The control board is re-energized after each power-off, the temperature
setting value, Fahrenheit/Celsius state will be the same as before the
power-off, and the length of power-off time is not limited.
The refrigerator doesn’t work
If the product is not working properly, please check and handle according to
the following methods. If the situation can not be changed, please contact
the after-sales service center in time, and be sure to provide the model name
and product number in detail.
When the temperature probe is short-circuited or disconnected, the setting
temperature value is displayed, the compressor will work for 15 minutes and
stop for 18 minutes.
When the temperature measured by the temperature probe is higher than 37
°C /99 °F, the setting temperature value is displayed, the compressor will
work for 15 minutes and stopfor 18 minutes.
Automatic locking function
When all the key no operation for 20 seconds, the key will be locked
automatically. After locking, the plus and minus keys can not be operated.
The unlock key and light / CF key operate normally.
Auto light off function
When all the key no operation for 10 minutes, the lamp will turn off
automatically
Adjustable range
Minimum value: 5°C / 41°F
Maximum value: 18°C / 64°F
Display range
Temperature display range of control panel:0~37°C / 32~99°F
Display stability
In the Celsius state: When the temperature measured by the temperature
probe is within ± 1 °C of the set temperature, the temperature display will
display the set temperature value.
In theFahrenheit state: When the temperature measured by the temperature
probe is within ± 2 °F of the set temperature, the temperature display will
display the set temperature value.
Setting the Temperature Control
OPERATING YOUR UNIT
GENERAL FAULT DESCRIPTION
Is the power on?
Is the power supply voltage too low?
06 07
Improper setting temperature, please
select the appropriate temperature.
The door is not closed tightly or
opened frequently, and the
opening time is too long.
Is the location exposed to direct
sunlight or too close to the
furnace and other heat sources?
Poor heat dissipation, please
check whether there is enough
cooling space around the
product.
It's noisy
The internal temperature is not low
WIRING DIAGRAM
Whether the ground is flat and
whether the product is placed stably.
Is the product in contact with
external objects or walls?
08 09
Improper setting temperature, please
select the appropriate temperature.
The door is not closed tightly or
opened frequently, and the
opening time is too long.
Is the location exposed to direct
sunlight or too close to the
furnace and other heat sources?
Poor heat dissipation, please
check whether there is enough
cooling space around the
product.
It's noisy
The internal temperature is not low
WIRING DIAGRAM
Whether the ground is flat and
whether the product is placed stably.
Is the product in contact with
external objects or walls?
08 09
Please give us a chance to make it right and do better !
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP !
Contact Us!
Do NOT return this item.
Compressor Wine Cooler
FP10176US-BK
USER’S MANUAL
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
US office: Fontana UK office: Ipswich AU office: Truganina
DE office: Hamburg
FR office: Saint Vigor d'Ymonville
PL office: Gdańsk
US:cs.us@costway.com
UK:cs.uk@costway.com
