MODEL: ACAP330
(Mon. to Sun. Any time)
DIGITAL
AIR C
OMPRE
SSOR
Any
product/re
turn issu
es,
pleas
e feel free
to conta
ct us direc
tly via
E-mail: [email protected]
1. Inspect unit before each use.
2. The metal compressor cylinder will heat up during operation. Do not touch
the cylinder head or fittings with bare hands during or immediately after use.
3. Only hold the unit by the carrying handle.
4. Do not over-inflate. Always confirm the tire pressure with a trusted tire
pressure gauge that features a built-in air bleeder valve.
5. Do not use the inflator when the vehicle is moving.
6. Do not leave the working inflator unattended.
7. Do not put the inflator on or near sources of direct heat or expose to
direct sunlight.
8. Do not operate the inflator in or around flammable environments.
9. Do not kink or block the air hose while the inflator is working.
10. Do not use the inflator if bent, broken, melted, burnt, wet or any of the
components are damaged.
11. Do not use the inflator on high pressure tires such as those used on
commercial vehicles, agricultural or specialist vehicles.
12. The inflator is not waterproof.
13. Make sure that the cables and hoses connected to the inflator will not
interfere safe operation of vehicles.
14. This inflator is not designed for continuous use. Operation over an
extended period of time will overheat the unit and damage the inflator. It
should not be used continuously for more than 15 minutes. After 15 minutes
of continuous use, turn it off and let it cool for at least 10 minutes before
resuming operation.
15. If the inflator is making an abnormal sound, or the temperature of the
unit is too high, turn the power off immediately and let it cool for at least 10
minutes before resuming operation.
16. The infiator contains no user serviceable parts. Do not open.
17. The compressor was permanently lubricated during assembly. Do not
add oil or any other lubricant.
SAFETY INSTRUCTION
1
ATTENTION
TECHNICAL SPECIFICATIONS
1. The air compressor can not be used on any truck or motor lorry.
2. The product only can be used on DC 12V power source and it can’t be
used directly on AC 110V, AC 220V, DC 24V, DC 36V.
3. Avoid over-inflating, never exceed the recommended pressure. Items
over inflated may burst and cause serious injury. Allow device to cool
for 10 minutes after 15 minutes of continuous operation.
4. The unit will become hot during use and we recommend to wear
protective gloves when operation. Use caution when touching the
unit. Only cautiously hold the unit by the carry handle and allow the
unit to cool enough before storing.
Property
Working voltage DC 12V
Rating power 180W
120 PSI
14 Amps
Min. Amp 8 Amps
Inflating speed 1.23 CFM
Power cord 3m
Air hose
LED
2
Fuse size
Maxim
um recomme
nded contin
uous operati
ng time
15 Min
utes
Specification
Maximum working pressure
Maximum Amp
250 LU
M
15A 30
mm glass
0.6m
FUNCTION DESCRIPTION
1. Digital Display
2. “-” Button (Decrease V alue)
3. “SET” Button (Unit Change)
4. “+” Button (Increase V alue)
5. LED Switch
6. On/Off Switch
7. LED Light
8. Valve Cover Storage
9. Air Hose
3
滚滚长江东逝水
HOW TO INFLATE CAR TIRE
Preset Value
Actual Tire Pressure
4
Step 1
Make sure the power swi
tch is at OFF position.
Start the engine.
Step 2
Plug the pow
er cord into the cigarette
lighter
socket of the vehicle
Step 3
Press “SET”
button to select tire press
ure
measurement
units fr
om PSI, KPA
, BAR.
Press
“+” or “-” butt
on to preset
tire pressure
.
The pr
eset tire pres
sure value c
an be read i
n the display
.
HOW TO INFLATE CAR TIRE
Press the switch backward to start air pump
and press the switch forward to start the light.
Step 4
Connect the air hose to the tire valve stem.
NOTE:
We recommend users turn on the pump before
connecting it to tire valve stems because this way
can prevent blowing the fuse.
Step 5
The compressor will automatically stop inflating
once the preset pressure is reached.
NOTE:
The air compressor display may have an error value
( +/- 1 psi ) but always consistent. If happened, users
can set 1 psi higher or lower than the actual tire
pressure.
5
6
HOW TO INFLATE CAR TIRE
To prevent blowing fuse, please turn on the pump before connecting it
to tire valve stems.
To prevent compressor damage: if compressor shuts off automatically,
allow to cool for 10 minutes before restarting. Compressor shuts off to
prevent overheating damage.
REPLACE THE FUSE
A
B
C
1. Unthread and remove the Bezel (A).
2. Slide the Fuse (B) out of the Lighter Adapter.
3. Insert a new Fuse.
4. Recombine the Bezel.
To rep
lace the fuse
located insid
e the Lighte
r Adapter, pl
ease follow t
hese
steps (
See Figure b
elow):
If the unit would not turn on or abruptly turn off during operation, check
the following:
a. Is the Lighter Adapter fully and securely inserted into the vehicles 12
volt power supply?
b. Has the fu
se inside the Lighter Ada
pter blown? If so, replace
the fuse.
For inflating sport balls like basketball, football, etc. The following two pictures shows
how to hoop up the nozzle to air chuck.
Note: Do not fully insert the ball needle into the air chuck to prevent the vent
hole of needle from being completely blocked.
Sport Balls Needle
Correct
Wrong
ATTACHMENTS
Bike Valve Adapter
Tapered Nozzle
7
TROUBLESHOOTING
Problem Possible Cause Solution
The inflator
does not
start.
The preset pressure
setting may be below
the actual pressure of
.
Adjust the preset pressure
setting to a higher pressure.
The power cord is not
plugged.
Plug the power cord into
a working power outlet.
The circuit breaker is
tripped.
The fuse in the 12 volt
hicle cord is
blown.
ve
8
the item you
are
inflating.
Reset the c
ircuit breaker.
Replace the
fuse.
