Sealey SWFE01 Welding Fume Extractor

WELDING/FUME EXTRACTOR

MODEL NO: SWFE01

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

1. SAFETY

9  Ensurethatanyfaultyitemisrepairedorisreplacedimmediatelybyaqualiedelectrician.

9  Ifthecableorplugisdamagedduringuse,switcho󰀨theelectricitysupplyandremovefromuse.

9  Ensurethatrepairsarecarriedoutbyaqualiedelectrician.

9  SealeyrecommendthatanRCD(ResidualCurrentDevice)isusedwithallelectricalproducts.

 Important:Ensurethatthevoltageratingontheappliancesuitsthepowersupplytobeusedandthattheplugisttedwiththe

correct fuse.

8 DO NOT pull or carry the appliance by the power cable.

8 DO NOT pull the plug from the socket by the cable.

1.2. GENERAL SAFETY

CAUTION: Read the instruction manual before using the machine.

9  Thismachineisintendedforcommercialuse,forexampleinhotels,schools,hospital,factories,shops,o󰀩ces,andrentalbusiness.

9  Theapplianceshallbedisconnectedfromitspowersourceduringserviceandwhenreplacingpartsand,ifthattheremovaloftheplug

 isforeseen,itshallbeclearlyindicatedthattheremovaloftheplughastobesuchthatanoperatorcancheckfromanyofthe

 pointstowhichhehasaccessthattheplugremainsremoved.

9 Any additional hoses or ducts can add pressure drop and shall be considered by the installation designer or the user.

 WARNING! Disconnect the extractor from the mains power and ensure the impeller is at a complete standstill before attempting to

 changeaccessories,serviceorperformanymaintenance.

9  Maintaintheextractoringoodcondition(useanauthorisedserviceagent).

9  Replaceorrepairdamagedparts.Userecommendedpartsonly.Non-authorisedpartsmaybedangerousandwillinvalidatethe 

8 DO NOT use the extractor for any purpose other than that for which it is designed. DO NOT pick up glass, metal or water.

8 DO NOT allow untrained persons to operate the extractor.

8 DO NOT get the unit wet or use in damp or wet locations or areas where there is condensation.

 WARNING! DO NOTuseextractorwherethereareammableliquids,solidsorgasessuchaspetrol,paintsolvents,wasteragsetc.

8 DO NOToperatetheextractorifanypartsaremissingordamagedasthismaycausefailureand/orpersonalinjury.

8 DO NOToperatetheextractorwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.

9  Whennotinuseswitchtheextractoro󰀨andisolatefromthepowersupply.Extractormustbestoredinalocationthatrestrictsitsuse

to skilled or instructed persons only.

2. INTRODUCTION

Adjustable1.5mextractionhosecanbealteredeasilyandholditsownposition.3Stagelteringprocessupto95%e󰀨ectiveremovingtoxic

3. SPECIFICATION

Model No: ................................................................SWFE01

Dimensions(excludingsuctionarm): ......560x430x430mm

Fan Type: .....................................................................Radial

Motor Type: ......................................................Brushless DC

Type of distribution system:.............................................. TN

Filter Medium: .....................................................Metal Mesh,

PrimaryFilter:madeofpolyesterbre,ltercotton

Noise Rating: ............................................................78dB(A)

NumberofFilterCartridges: .................................................3

NumberofPhases/Frequency: .....................1/AC230V~50Hz

Suction Arm: ..................................................................1.5m

Sound Pressure: ......................................................76dB(C)

SpeciedMax.AmbientOperatingTemp: ......................40°C

Short circuit current rating for each incoming power supply:

Nolter/220V/50HzInput:Incomingcurrent:3.8AMaxoperationcurrent:2.8A

Withlter/220V/50HzInput:Inputcurrent:3.8AOperationcurrent:1.2A

Full load current for each incoming supply:

Numbers refer to attached Part List

4.1.  Fitwheels(20)securewithsplitpin(13)andcastors(19).

4.2.  Fitextractionhoseassembly(22)withsixM5x12mmscrews.

4.3.  Fithandle(6)usingfourM8x30mmscrews.

5. CONTROLS

 A:Mainslead C:On/O󰀨switch

 B:Fuse  D:Fanspeed

6. OPERATION n

6.1. RESTRICTED USE

6.1.1. The use of the machine should be restricted to those trained in its use. Reduce the risks associated with welding using an extractor

6.3.  All3ltersmustbeinplaceduringoperation.

6.4.  Connecttomainssupply.PressOn/O󰀨switch(C).

6.5.  Thenozzleoftheextractionarmneedstobepointedattheareaofwelding,nottooclosesoastobedamagedbytheweldingprocess

but close enough to suck up the fumes to go through the extraction process.

6.6.  Setfanspeedasrequired(D).

6.7. BLOCKAGE

6.7.1. Theextractorcanbecomeblockedbysomethingbeingsuckedintotheextractorwhichblocksthearmornozzle,orthelters.Itcould

 becomecloggedbyfumeparticles.Inbothcasesswitcho󰀨andunplugthemachine,thenremoveblockagefromarmornozzleorin

 thecaseofcloggedlterscleanorifnecessary,replace.

7. MAINTENANCE.

7.5. Regular maintenance can ensure good equipment performance.

7.6. MAINTENANCE

7.6.1. Clean the metal mesh of the metal filter.

7.6.2. Replacefiltercottonofprimaryfilter(polyesterfibrefiltercotton).

7.6.3. Replacethewholesecondaryfilter(PP+PET).

fig.

1

7.6.4. Refer to fig.1.

7.6.4.1. Filter Inspection: Removethefrontcover,andthenremovethefilterholder.Thefiltersareinside,removethemforcleaningor 
