GENPOWER GENPINGPRAI45S Inverter Generator Portable 4kW User Manual

User Manual

[Revision 7.0 January 2024]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY

VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,

assembly, inclusions, specifications, description, and packaging.

The product is NOT supplied with engine oil, although traces of oil from the manufacturing process may be present. It is essential to add

adequat

e engine oil of the correct type to the engine before use. Failure to add engine oil will void the product warranty.

i45s Inverter Generator

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

• Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

• Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases, or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

• Keep clear of moving parts.

• Equipment may be a potential source of

electric shock or injury if misused.

• Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

• Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

• Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

• Work areas should be clean and well it.

• Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

• If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

• Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

• Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

• Do not use the equipment if tired or under

the influence of drugs, alcohol, or

medication.

• This equipment is not intended for use by

persons with reduced physical, sensory, or

mental capabilities.

General Fuel Safety

• Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

• Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

• Do NOT smoke near fuel or when

refuelling.

• Always shut off the engine before

refuelling.

• Do NOT refuel a hot engine.

• Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

• Always refuel in well ventilated areas.

• Always check for fuel leakage. If fuel

leakage is found, do not start, or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

• Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

• Use combustion engines OUTSIDE only,

and far away from windows, doors, and

vents.

General Equipment Use and Care

• The equipment is designed for domestic

use only.

• Handle the equipment safely and carefully.

• Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage, or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

• Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

• Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

• Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

• Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

• Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases, or liquids etc.

• The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

• Do not clean equipment with solvents,

flammable liquids, or harsh abrasives.

• For specific equipment safety use and care,

see Equipment Safety.

i45s Inverter Generator

General Electrical Safety

• Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

• Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

• When wiring electrically powered

equipment, follow all electrical and safety

codes.

• Always use a Residual Current Device

(RCD) (GFCI) / Earth Leakage Circuit

Breaker / Safety Switch when operating this

item (electrical items only).

• High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

• Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

• Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

• Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

• Do NOT use electrical equipment in wet

conditions or in damp locations.

• Do NOT use electrical cords to lift, move or

carry equipment.

• Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

• The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

• Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

• Do NOT attempt any maintenance or repair

work not described in this manual.

• After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories, or performing repair or

maintenance.

• Do NOT adjust while the equipment is

running.

• Perform service-related activities in suitable

conditions, such as a workshop.

• Replace worn, damaged or missing

warning/safety labels immediately.

Important Safety Reminders

DANGER!

• USING A GENERATOR INDOORS CAN KILL YOU IN MINUTES.

• GENERATOR EXHAUST CONTAINS CARBON MONOXIDE. THIS IS A POISON THAT YOU CANNOT SEE OR SMELL.

• NEVER USE INSIDE A HOME OR GARAGE.

WARNING!

• THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING CARBON MONOXIDE, WHICH IS KNOWN TO CAUSE CANCER AND

BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

Operator Safety

WARNING!

• Always perform an oil, fuel and air filter check before starting the engine.

• Properly clean and maintain the equipment.

• Operate the generator according to instructions for safe and dependable service.

• Before operating the generator, read the user guide carefully. Otherwise, personal injuries or equipment damage may result.

• Never run the generator in an enclosed area to avoid harm from exhaust emissions of a poisonous carbon monoxide gas.

• Pay attention to the warning labels. The engine exhaust system will become heated during operation and remain hot immediately after the engine

is stopped.

• Gasoline is a highly flammable and explosive liquid. Refuel in a well-ventilated area with the engine stopped.

• When refuelling the generator, keep it away from cigarettes, open flames, smoke and/or sparks.

• Use of gasoline with an ethanol content greater than 10% can damage the engine and fuel system and will void the manufacturer’s warranty.

• Place the generator at least 10 feet away from buildings or other equipment during operation.

• Run the generator on a level surface. Tilting the generator may result in fuel spills.

• Do not touch the spark plug while the engine is operating or shortly after the engine has been shut down.

• Know how to stop the generator quickly and understand operation of all the controls. Never permit anyone to operate the generator without

proper instructions.

• Keep children, pets, and machinery with rotating parts away during operation.

• Do not operate the generator in rain or snow.

• Do not allow any moisture to come in contact with the generator.

AC Safety

WARNING!

• Before connecting the generator to an electrical device or power cord:

• Make sure that everything is in proper working order. Faulty devices or power cords can lead to an electrical shock.

• Turn off the generator immediately if the device begins to operate abnormally. Then disconnect the device and investigate the problem.

• Keep away from other electric cables or wires.

• To prolong engine life, make sure that the combined load of your devices does not exceed the rated running wattage of the generator.

i45s Inverter Generator

• When an extension cable is required, be sure to use a tough rubber sheathed flexible cable (according to IEC245 or equivalent standards). The

maximum length of the extension cable: 196 feet (60 meters) for cable of 15.5 gauge (1.5mm2); 328 feet (100 meters) for cable of 13.25 gauge

(2.5mm2).

• Connections for standby power to a building’s electrical system must be done by a qualified electrician and must comply with all applicable

laws and electrical codes. Improper connections may cause serious injuries to electrical workers during a power outage, and when the utility

power is restored, the generator may explode or cause fires. The generator shall be connected through transfer equipment that switches all

conductors other than the equipment grounding conductor. The frame of the generator shall be connected to an approved grounding electrode.

• This unit is floating neutral. The generator (stator winding) is isolated from the frame and from the AC receptacle ground pin.

• Electrical devices that require a grounded receptacle pin connection will not function if the receptacle ground pin is not functional.

Maintenance Safety

WARNING!

• After any maintenance is performed, wash hands immediately using soap and clean water because repeated exposure to lubricant may cause

skin irritation.

• Do not clean the filter element with flammable liquids like gasoline because an explosion may occur.

• Turn off the engine and allow the generator to cool down before performing any maintenance. Failure to do so can cause severe personal injury

or death.

• Always wear safety glasses when cleaning the generator set with air.

• Do not clean the generator set with a pressure washer because it can damage the generator set.

• When working with batteries, ventilate the area, use safety glasses, do not smoke. Always disconnect the negative first and reconnect it last.

• Use rubber gloves when coming into contact with engine oil.

• Always stop the generator set before removing the oil filler cap.

• Only qualified maintenance personnel with knowledge of fuels, electricity, and machinery hazards should perform maintenance procedures.

• Refer to Maintenance Schedule

in this manual.

Other Safety Tips

WARNING!

• TOXIC FUMES HAZARD. Running engines give off carbon monoxide, an odourless poisonous gas that can cause nausea, fainting, or death. Do

not start engine indoors or in an enclosed area, even if the windows and doors are open.

• To avoid breathing in poisonous carbon monoxide from the exhaust gases, adequate ventilation should be provided, only operate the generator

outside and away from enclosed areas, windows, and doors.

• If the generator set is stored outdoors, check all the electrical components on the control panel before each use. Moisture can damage the

generator and can lead to an electric shock.

• Generators vibrate in normal use. During and after the use of the generator, inspect the generator as well as extension cords and power supply

cords connected to it for damage resulting from vibration. Have damaged items repaired or replaced as necessary. Do not use plugs or cords that

show signs of damage such as broken or cracked insulation or damaged blades.

• If you start to feel sick, dizzy, or weak after the generator has been running, move to fresh air RIGHT AWAY. See a doctor. You could have

carbon monoxide poisoning.

i45s Inverter Generator

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases, or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases, or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing, and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

i45s Inverter Generator

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp, or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

i45s Inverter Generator

Table of Contents

Safety ............................................................................................................................................................. 2

Safety Symbols ........................................................................................................................................................... 5

Parts Identification ....................................................................................................................................... 8

Components ............................................................................................................................................................... 8

Control Panel .............................................................................................................................................................. 9

Checklist ................................................................................................................................................................... 10

Pre-Operation Check .................................................................................................................................. 11

Adding Oil ................................................................................................................................................................. 11

Adding Fuel ............................................................................................................................................................... 12

Checking the Air Filter .............................................................................................................................................. 13

Starting the Engine ..................................................................................................................................... 14

Starting Your Generator ........................................................................................................................................... 14

Recoil Start ......................................................................................................................................................... 15

Carburettor Modification for High Altitude Operation ......................................................................................... 15

Generator Use ............................................................................................................................................. 16

Ready To Use, Overload, and Oil Alert Indicator ..................................................................................................... 16

DC Applications ........................................................................................................................................................ 16

Connecting the Charging Cable ......................................................................................................................... 17

Disconnecting the Charging Cable .................................................................................................................... 17

AC Applications ........................................................................................................................................................ 18

Stopping the Engine ................................................................................................................................... 19

Maintenance ................................................................................................................................................ 20

General Inspection Tips ............................................................................................................................................ 20

Maintenance Schedule ............................................................................................................................................. 20

Changing the Oil ....................................................................................................................................................... 21

Cleaning the Air Filter ............................................................................................................................................... 22

Spark Plug Maintenance .......................................................................................................................................... 23

Spark Arrester Maintenance ..................................................................................................................................... 24

Fuel Filter Maintenance ............................................................................................................................................ 24

Valve Clearance ....................................................................................................................................................... 25

Emission Control System ......................................................................................................................................... 25

Transportation and Storage ....................................................................................................................... 27

Draining the Fuel Tank ............................................................................................................................................. 27

Transporting the Generator ...................................................................................................................................... 27

Storage ..................................................................................................................................................................... 28

Troubleshooting ......................................................................................................................................... 29

Appendix ..................................................................................................................................................... 31

Specifications ............................................................................................................................................. 32

i45s Inverter Generator

Parts Identification

Components

Spare parts available

for purchase, scan QR

code below:

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Control Panel

1. Ground Terminal: The ground terminal is used to externally ground the generator.

WARNING! BEFORE USING THE GROUND TERMINAL CONSULT A QUALIFIED ELECTRICIAN,

ELECTRICAL INSPECTOR, OR LOCAL AGENCY HAVING JURISDICTION FOR LOCAL LAWS AND

CODES THAT APPLY TO THE INTENDED USE OF THE GENERATOR.

The ground terminal is connected to the non-current carrying metal parts (such as the fuel tank), the frame,

and the ground terminals of the AC outlets. Floating Neutral.

2. Power Outputs

3. Parallel Operation Inputs: A compatible Inverter Generator can be connected for additional power input.

4. USB Ports: Two-port 5V/2.1A USB outlet. Accepts Type A USB plugs.

5. Hour Meter: Display shows total run time. Use this to perform maintenance at the proper intervals according

to the Maintenance Schedule section of this manual.

6. Low Oil LED: The oil alert system is designed to prevent engine damage caused by an insufficient amount

of oil in the crankcase. Before the oil level in the crankcase reaches an unsafe limit, the oil alert system will

automatically shut down the engine (the battery power switch remains in the ON position). If the oil alert

system shuts down the engine, the low oil indicator light (red) will turn on. Check the engine oil level.

12

11

5

4

3

1

2

10

9

8

6

7

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

7. Overload LED: Indicates that the generator is overloaded. If the generator is overloaded (producing more

than running wattage) or a connected appliance has short-circuited, the output indicator light will turn off and

the overload indicator light will turn on.

8. Output Ready LED: Illuminates when the generator is operating normally. Indicates the generator is

producing electrical power at the receptacles.

9. Overload Reset Button: The generator inverter will automatically switch OFF all AC output to protect the

generator if overloaded or if there is a short circuit in a connected appliance.

10. Eco Mode ON/OFF: Turning Eco Mode to ON is recommended for minimizing fuel consumption. In this

mode the engine will dynamically meet the demand of the current electrical load and will automatically go

into an idle state if all electrical loads are disconnected.

Before connecting or removing a high load device to the generator, turn Eco Mode to OFF until that device

has reached running power.

When Eco Mode is OFF, the engine runs at full speed.

11. Power Switch: The two-way power switch starts and stops the unit. ON: Switch must be in this position to

recoil start. STOP: Stops the engine.

12. 12 Volt output

Checklist

Make sure your generator has everything listed below.

•

1x Inverter Generator

•

1x Spark Plug Wrench

•

1x Oil Funnel (not included)

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Pre-Operation Check

Set the generator on a level surface and the power switch to STOP.

Adding Oil

1. Unscrew the oil dipstick.

2. Fill with fresh oil up to the maximum fill level on the dipstick.

3. Check the oil level by reinserting the dipstick without rethreading it. Remove the dipstick and examine the oil

level. If the oil level is at or below the minimum oil level, continue filling the oil to the maximum oil level mark.

4. Reinsert the dipstick and tighten securely.

NOTE: SAE 10W-30 or 15W-30 is recommended for general use. Use of synthetic oil does not change

maintenance intervals. Oil Capacity: 20 fl. oz. / 0.6 L. DO NOT OVERFILL.

(Not included)

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Effective Viscosity Range of Engine Oils

NOTE:

•

Do not tilt the generator when adding engine oil. This could result in overfilling and damage to the engine.

•

Use high quality 4-stroke engine oil, certified to meet, or exceed API standard SG, SF, SAE ratings with

strong detergents. Using non-detergent or 2-stroke oil could shorten the engine’s working life.

•

Do not mix different engine oils.

•

Handle and store the engine oil with care, avoid getting dirt or dust into the engine oil.

•

Before the engine oil falls below the safety margin, the low oil alert system will automatically shut off the

engine. The low oil light will turn on.

•

To avoid the inconvenience of unexpected engine shutoff, check the oil level as often as possible.

Adding Fuel

DANGER! GASOLINE IS HIGHLY FLAMMABLE AND EXPLOSIVE UNDER CERTAIN CONDITIONS.

REFUEL IN A WELL-VENTILATED AREA WITH THE ENGINE STOPPED. DO NOT SMOKE OR

ALLOW OPEN FLAMES OR SPARKS IN THE AREA WHERE THE GENERATOR IS BEING REFUELED OR

WHERE GASOLINE IS STORED. DO NOT OVERFILL THE TANK. BE CAREFUL NOT TO SPILL FUEL

WHEN REFUELING. WIPE UP ANY SPILLED GASOLINE AND LET THE AREA DRY BEFORE STARTING

THE ENGINE. GASOLINE SUBSTITUTES SUCH AS GASOHOL ARE NOT RECOMMENDED. THEY MAY BE

HARMFUL TO THE FUEL SYSTEM COMPONENTS.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

NOTE:

•

Always place the generator on level ground and in a well-ventilated area when filling the fuel tank

•

Add fuel only to the red maximum fill ring on the fuel screen filter visible in the filler neck.

•

Use of gasoline with an ethanol content greater than 10% can damage the engine and the fuel system and

will void the manufacturer’s warranty.

•

Only use unleaded gasoline (Octane 85 or higher).

•

Never use stale or contaminated gasoline, or an oil/gasoline mixture.

•

Avoid getting dirt or water into the fuel tank.

•

Do not use a mixture of gasoline containing methanol. This will cause serious damage to the engine.

•

We recommend using air filter oil, this will help capture any stray particles of dirt or debris, this will increase

the longevity of the engine.

Checking the Air Filter

Examine the air filter before your first use. Check the Maintenance section for a complete cleaning guide.

1. Unscrew the air filter cover and remove the filter.

2. Clean the foam air filter with soap and water or solvent and squeeze dry (do not wring out).

3. Soak in clean engine oil.

4. Squeeze (do not wring) out all excess oil and reinstall. Replace the filter if it is damaged.

NOTE: Running the engine without the air filter or a dirty air filter will quickly degrade the engine.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Starting the Engine

DANGER! USING A GENERATOR INDOORS WILL KILL YOU IN MINUTES.

Generator exhaust contains high levels of carbon monoxide (CO), a poisonous gas you

cannot see or smell. If you can smell the generator exhaust you are breathing CO. Even if you cannot

smell the exhaust, you could be breathing CO.

NEVER use a generator inside a home, garage, crawlspace, or other partly enclosed area, deadly levels

of carbon monoxide can build up in these areas. Using a fan or opening windows and doors will NOT

supply enough fresh air.

ONLY use a generator outdoors and far away from open windows, doors, and vents. These openings can

pull in generator exhaust. Even when you use a generator correctly, CO may leak into the home.

ALWAYS use a CO alarm in your home.

If you start to feel sick, dizzy, or weak after the generator has been running, move to fresh air RIGHT

AWAY and seek medical attention. You could have carbon monoxide poisoning. Never run the generator

in an enclosed or even partially enclosed area where people may be present.

Starting Your Generator

WARNING! Before using the generator, consult a local electrician and local electrical codes to

determine grounding requirements for your intended use. This generator is floating neutral.

NOTE:

•

Ensure all connected appliances are turned off.

•

Return the starter grip slowly by hand, do not let it snap back.

•

For proper break-in procedure, do not exceed 50% of the rated running watts in the first five (5) hours of

operation. Vary the load occasionally to allow stator windings to heat and cool and help seat the piston rings.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Recoil Start

1. Open the fuel valve by turning the fuel knob to the ON position.

2. Turn the power switch to the ON position.

3. For a cold engine, move the choke lever to the START position. To restart a warm engine, move the choke

lever to the half-START position.

4. Pull the starter slowly until you feel it engage then pull quickly. Repeat until the generator starts.

5. When the engine warms up push the choke lever fully to the RUN position. The choke is used to provide the

proper air-fuel mixture when the engine is cold.

Carburettor Modification for High Altitude Operation

•

At high altitudes, the standard carburettor air-fuel mixture will be too rich. Fuel consumption will increase,

and performance will decrease. A very rich mixture will also foul the spark plug and cause hard starting.

•

If using the generator at high altitudes, change the main-nozzle or adjust the idling-screw of the carburettor.

If always operating the generator at altitudes above 3280 feet (1,000m), contact an authorized service centre

to have the carburettor modified.

•

Conversely, if the carburettor has been modified for high altitude operation, the air-fuel mixture will be too

lean for low altitude use. Operation at low altitude may cause the engine to overheat and result in serious

engine damage. In this case the carburettor needs to be returned to its original specifications.

•

Generator output power should be modified according to the altitude and ambient temperature.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Generator Use

WARNING!

•

Before using the generator, consult a local electrician and local electrical codes to determine

grounding requirements for your intended use. This generator is floating neutral.

•

Do not connect to the building’s electrical system. Doing so may result in electrical shocks and fire.

•

To prolong engine life, do not exceed the rated running wattage. Do not connect an extension to the

exhaust pipe.

•

When an extension cable is required, be sure to use a tough rubber sheathed flexible cable

(according to IEC245 or equivalent standards). The maximum length of the extension cable: 196 feet

(60 meters) for cable of 15.5 gauge (1.5mm2); 328 feet (100 meters) for cable of 13.25 gauge

(2.5mm2).

•

Keep away from other electric cables or wires.

Ready To Use, Overload, and Oil Alert Indicator

Light (Solid) Description

Green

Ready to Use Indicator

ON Indicates normal operation.

OFF Indicates a problem or unit is OFF.

Red

Overload Indicator

ON

Indicates overload or problem with connected

appliances, disconnect any appliances.

OFF Indicates normal operation.

Red

Low Oil Indicator

ON Indicates insufficient oil in the crankcase.

OFF Indicates normal operation.

DC Applications

The DC receptacle may be used for charging 12V batteries only. In DC operation, turn Eco Mode OFF.

NOTE:

•

The DC receptacle can be used while the AC power is in use. If used at the same time, be sure not to

exceed the total power for AC and DC. (AC: 3200W, DC: 8A)

•

Motor vehicles require more than their rated wattage when starting.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Connecting the Charging Cable

1. If connecting to a vehicle battery, disconnect the vehicle battery ground cable from the negative (-) battery

terminals.

2. Connect the DC outlet to the battery terminals using a DC charging cable (not included). Connect red lead to

positive (+) battery terminal and black lead to negative (-) battery terminal.

3. Turn Eco Mode OFF and start the generator.

NOTE: DO NOT start the vehicle engine when the generator is still connected to the battery, this will damage the

generator. System floating for DC output.

Disconnecting the Charging Cable

1. Stop the engine.

2. Disconnect the black lead from the negative (-) battery terminal, and the red lead from the positive (+) battery

terminal.

3. Reconnect the vehicle battery ground cable.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

AC Applications

1. Start engine and make sure output indicator light (READY TO USE) is on.

2. Confirm all electrical appliances are switched off, and connect the appliance plugs to the generator

receptacle.

3. Turn on the appliances.

4. Turn Eco Mode ON.

NOTE:

•

Confirm all electrical appliances are in good working condition before connecting them to the generator. If an

electrical appliance becomes abnormal, sluggish, or stops suddenly, shut off the generator engine

immediately, and disconnect the appliance.

•

Most appliances require more than their rated wattage upon start-up.

•

For continuous operation do not exceed the rated output of the generator.

•

The grounding system is not connected to the AC neutral wire.

•

Neutral floating for AC system.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Stopping the Engine

1. Switch off the connected electrical appliances and disconnect them.

2. Allow the generator to run with no load for a few minutes to stabilize the internal temperature. Turn the

power switch to the STOP position.

3. Turn the fuel valve to the OFF position.

NOTE: Never start or stop the generator with a load connected. Make sure the fuel switch is in the CLOSED

position when stopping, transporting, and storing the generator. To stop the engine in an emergency, turn the

power switch to STOP immediately.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Maintenance

Proper maintenance keeps your generator in the best operating condition by ensuring safe, economical, and

trouble-free operation. Only use genuine parts and recommended fluids to replace the worn components.

Improper maintenance may cause the generator to malfunction and can lead to serious injury.

General Inspection Tips

•

Look for fuel leaks around the fuel tank, fuel hose, and fuel valve. Close the fuel valve and repair leaks

immediately.

•

Look and listen for exhaust leaks while the engine is running. Have all the leaks repaired before continuing

operation.

•

Check for dirt and debris and clean as necessary.

•

Check the engine oil level and add oil as necessary.

Maintenance Schedule

Regular maintenance will improve performance and extend the service life of the generator. Maintain the

generator according to the maintenance schedule below.

NOTE: Service more frequently when used in dusty areas or adverse conditions. These items should be

serviced by an authorised service centre unless you have the proper tools and are mechanically proficient. Refer

to user guide for service procedures.

Before Each Use

1

Replace air filter if it cannot be

adequately cleaned.

2

Change oil after every 100 hours or

yearly, whichever comes first. Service

more frequently when operating under

heavy load or in high temperatures.

3

Recommend service to be performed

by authorised service dealer.

Check engine oil level

Inspect air filter

First 25 Hours or First Month

Change engine oil

Every 50 Hours or 6 Months

Check and clean air filter

1

Every 100 Hours or 12 Months

Change engine oil

2

Inspect/clean spark arrestor

Inspect/clean spark plug

Every 300 Hours

Replace spark plug

R

eplace air filter

Clean combustion chamber

3

Inspect/adjust valve clearance

3

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Changing the Oil

WARNING! Used motor oil can cause skin irritations if left in long-term contact with skin.

Thoroughly wash off used oil from hands as soon as possible with soap and water. Do not

dispose of used oil in drains or on soil. Local service shops provide environmentally friendly disposal

methods. Remove the spark plug boot from the spark plug before performing maintenance procedures

on the generator to avoid an accidental start-up.

Drain the oil rapidly and completely while the engine is still warm.

1. Place an oil collection pan under the oil drain bolt. Loosen the oil drain bolt then tip the generator and

continue to fully loosen the bolt.

2. Drain into the oil collection pan completely. Reinstall the oil drain bolt.

3. Refill the oil to the maximum level mark. Check the oil level by reinserting the dipstick without rethreading it.

Remove the dipstick and examine the oil level when the unit is on a flat surface.

4. Reinstall the oil dipstick and tighten it.

NOTE: Max oil capacity: 20 fl. oz / 0.6L. SAE 10W-30 or 15W-30 oil is recommended for general use. Use of

synthetic oil does not change maintenance intervals. DO NOT OVERFILL.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

NOTE:

•

Do not tilt the generator when adding engine oil. This could result in overfilling and damage to the engine.

•

Use high quality 4-stroke engine oil, certified to meet or exceed API standard SG, SF, SAE ratings with

strong detergents. Using non-detergent or 2-stroke oil could shorten the engine’s working life.

•

Do not mix different engine oils.

•

Handle and store the engine oil with care, avoid getting dirt or dust into the engine oil.

•

Before the engine oil falls below the safety margin, the low oil alert system will automatically shut off the

engine. The low oil light will turn on.

•

To avoid the inconvenience of unexpected engine shutoff, check the engine oil level as often as possible

Cleaning the Air Filter

WARNING! Using gasoline or other flammable solvents can cause a fire or explosion. Do not

operate this product without an air filter. A dirty air filter will restrict air flow into the carburetor.

Clean and maintain the air filter regularly, especially in dusty areas.

NOTE: Never run the generator without an air filter, doing so will quickly degrade the engine.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

1. Unscrew and remove the air filter cover.

2. Remove the foam filter.

3. If the foam element is dirty, clean it in warm soapy water, rinse, and allow it to dry thoroughly, or clean in

non-flammable solvent and allow to dry.

4. Dip the foam element in clean engine oil, then squeeze out all excess oil. The engine will smoke when

started if too much oil is left in the filter.

5. Wipe dirt from the air filter assembly and reinstall into the unit.

Spark Plug Maintenance

NOTE: Do NOT rinse spark plug in water. Follow guidelines and be careful not to overtighten the spark plug.

Recommended spark plug: F7RTC. Check the spark plug gap and clean the carbon deposits at the bottom of

the spark plug.

Tighten 3/8 TO 1/2 turn when installing a new spark plug.

Tighten 1/8 TO 1/4 turn when re-installing an old spark plug.

1. Make sure the engine has cooled down.

2. Remove the spark plug cap by pulling it away from the engine.

3. Remove the spark plug with the included spark plug wrench.

4. Visually inspect the spark plug. Replace with a new one if the insulation is cracked or chipped. Clean with a

wire brush if the spark plug is reused.

5. Measure the spark plug gap with a feeler gauge. The normal value is: 0.6-0.8mm (0.024- 0.032in). Adjust the

gap by carefully bending the electrode.

6. Carefully reinstall the spark plug by hand, to avoid cross-threading. A new spark plug should be tightened

3/8 to 1/2 turn with a wrench. A used spark plug should be tightened 1/8 to 1/4 turn with wrench.

7. Reinstall the spark plug cap.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

NOTE: The spark plug must be securely tightened, or it could cause the spark plug to heat up enough to

damage the engine. Never use a spark plug with an improper heat range.

Spark Arrester Maintenance

1. Make sure the muffler has cooled down.

2. Use a brush to remove carbon deposits from the spark arrester. If the spark arrester is worn down, replace it.

3. Use compressed air to clear remaining deposits.

NOTE: Failure to properly clean the spark arrester will reduce engine performance.

Fuel Filter Maintenance

WARNING! Gasoline is highly flammable and explosive under certain conditions. Refuel in a well-

ventilated area with the engine stopped. Do not smoke or allow open flames or sparks in the area

where the generator is being refueled or where gasoline is stored. Do not overfill the tank. Be careful not

to spill fuel when refueling. Wipe up any spilled gasoline and let the area dry before starting the engine.

1. Remove the fuel cap and filter.

2. Clean the filter with solvent.

3. Wipe the filter.

4. Reinsert the filter.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Valve Clearance

NOTE: Recommend service to be performed by authorized service dealer. Only check or adjust the valves when

the engine is cold. The gasket should be replaced if torn or damaged.

Valve Clearance:

•

Intake Valve 0.0031 - 0.0047 in. (0.08 - 0.12 mm)

•

Exhaust Valve 0.0051 - 0.0067 in (0.13 - 0.17 mm)

Torque: 106 inch-pound (12 N·m).

1. Remove the spark plug cap. Carefully remove the breather tube and the valve cover.

2. Identify the intake valve on the right and the exhaust valve on the left. Slowly pull the recoil handle to move

the valves until the intake rocker arms is fully down.

3. Adjust the exhaust rocker arm by inserting a feeler gauge between the rocker arm and the valve stem to

measure valve clearance.

4. If an adjustment is necessary, hold the rocker arm pivot and loosen the pivot adjusting nut.

5. Turn the rocker arm pivot to obtain the specified clearance. Hold the rocker arm pivot and re-tighten the pivot

adjusting nut to the specified torque.

6. Perform step 2 to 5 for the other valve.

7. Reinstall the breather tube, the valve cover, and the spark plug cap.

Emission Control System

Emission Source

Exhaust gas contains carbon monoxide, nitrogen oxides (NOx) and hydrocarbons. It is very important to control

the emissions of NOx and hydrocarbons as they are a major contributor to air pollution. Carbon monoxide is a

poisonous gas. The emission of fuel vapours is a source of pollution as well. The generator engine utilizes a

precise air-fuel ratio and emission control system to reduce the emissions of carbon monoxide, NOx,

hydrocarbons, and evaporative fuel emissions.

Regulation

Your engine has been designed to meet current Environmental Protection Agency (EPA) clean air standards.

The regulations dictate that the manufacturer provides operation and maintenance standards regarding the

emission control systems. Adherence to the following instruction will ensure your engine meets the emission

control standards.

Modification

Modification of the emission control system may lead to increased emissions. Modification is defined as the

following:

•

Disassembling or modifying the function or parts of the intake, fuel or exhaust system.

•

Modifying or destroying the speed governing function of the generator.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Engine faults that may affect emission

Any of the following faults must be repaired immediately. Consult with your authorized service centre for

diagnosis and repair:

•

Hard starting or shut down after starting.

•

Unstable idle speed.

•

Shut down or backfire after applying an electrical load.

•

Backfire or after fire.

•

Black smoke and/or excessive fuel consumption.

Replacement parts and accessories

The parts making up the emission control system in your product’s engine have been specifically approved and

certified by the regulatory agencies. You can trust that the replacement parts supplied by customer service have

been manufactured to the same production standard as the original parts. The use of replacement parts or

accessories which are not designed by – may negatively affect the engine emission performance. Therefore,

only use replacements parts and accessories from a qualified service centre to guarantee that the replacement

products will not adversely affect emission performance.

Replacement parts other than those from an authorised service centre will void the warranty.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Transportation and Storage

Draining the Fuel Tank

1. Turn OFF the engine. Remove the fuel cap and the debris screen underneath the fuel cap.

2. Empty the fuel tank using a siphon and an approved gasoline container.

3. Loosen the carburettor drain bolt to discharge all gasoline from inside of the carburettor.

NOTE: Do not use an electric pump to drain the fuel tank.

Transporting the Generator

•

Do not overfill the fuel tank (No residual fuel on the neck of tank).

•

Do not use the generator in the vehicle. The generator should ONLY be used while in a well-ventilated area.

•

Avoid exposing the generator to prolonged direct sunlight while in an enclosed vehicle. The high temperature

inside the vehicle could cause fuel to vaporize resulting in a possible explosion.

•

Drain the generator of fuel and oil before being transported on rough roads.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Storage

Gasoline can oxidize in as little as 30 days, causing gum and varnish to build up in fuel system components.

NOTE: Ensure that the storage area is free of excess humidity and dust. Do NOT store the generator near

appliances that produce heat.

Storage Duration Preparation Required

Less than 1 Month

No storage preparation required, simply store as is.

2 to 6 Months

Drain the old gas and completely fill the tank with fresh gas before storage. Drain the

carburetor float bowl. Add fuel stabilizer according to the manufacturer’s directions. Adding a

quality fuel stabilizer can keep gas fresh for up to a year.

6 Months or Longer



Drain off the gasoline from the fuel tank, and store in a suitable container. This will help

prevent deposits from forming in the fuel system.



Turn the fuel switch to OPEN and loosen the carburetor drain bolt. Take off the spark

plug cap and revolve the engine 3 or 4 times, by pulling the recoil handle, to fully

discharge the gasoline from the fuel lines.



Turn the fuel switch to CLOSED and tighten the drain bolt of the carburetor.



Change oil while engine is still warm from operation.



Remove the spark plug and pour a tablespoon of clean engine oil (10~20ml) into the

cylinder. Revolve the engine several times by pulling on the recoil start to distribute the

oil. Reinstall the spark plug. Pull the starter grip slowly until you feel resistance. At this

point, the piston is coming up on its compression stroke and both the intake and exhaust

valves are closed. This position helps to protect the engine from internal corrosion.

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Troubleshooting

If appliances do not operate:

DC receptacle without any electricity:

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

If the engine does not start:

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Appendix

•

The standard condition of rated power output:

•

Altitude: 0m

•

Ambient temperature: 77°F (25°C)

•

Relative humidity: 30%

Factor of Environment Correction:

Altitude Ambient Temperature (°C)

25°C 30°C 35°C 40°C 45°C

0 1 0.98 0.96 0.93 0.90

500 0.93 0.91 0.89 0.87 0.84

1000 0.87 0.85 0.82 0.80 0.78

2000 0.75 0.73 0.71 0.69 0.66

3000 0.64 0.62 0.60 0.58 0.56

4000 0.54 0.52 0.50 0.48 0.46

NOTE:



Relative humidity 60% correction factor C-0.01



Relative humidity 80% correction factor C -0.02



Relative humidity 90% correction factor C-0.03



Relative humidity 100% correction factor C-0.04

Example:



Rated power (PN) 2.8kVA generator (Altitude: 1000m) Ambient temperature: 35°C, Relative humidity: 80%



P = Pn*(C-0.02) = 2.8*(0.82-0.02) = 2.24kVA

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

i45s Inverter Generator

Specifications

Peak Output 4000W / 4.0kW

Continuous Rated Output

from the 240V outlets

3500W / 3.5kW

PLEASE NOTE: Continuous Rated Output is what power

this generator consistently and reliably provides. We

strongly recommend that you consider this figure when

determining whether this model suits your requirements.

Engine Type Single-Cylinder, 4-Stroke, Air-Cooled, OHV horizontal shaft

Displacement 212CC

Engine Output 5.85hp/3600rpm

Starting system Recoil

Fuel Type Regular Unleaded 95+RON

AC Outlets 2 x 240V 10A/15A

USB Outlets 2 x 5V (2.1A, 1.0A)

DC Output 12V -15A

Parallel Connection option Yes

Alternator Type Single Phase

Engine Oil Type SAE10W-30 (not included with purchase)

Fuel Tank Capacity 7L

Runtime 4 hrs @ 100% load, 8 hrs @ 50% load

Noise Level 81.6dB

Preferred Oil Type SAE 10W30

Oil Capacity 0.6

GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER GENPOWER

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.



Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.



The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business,

or employee, or financially affect the user, business, or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

ideas, diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,

without express permission or consent from the publisher.

GENPOWER GENPINGPRAI45S Inverter Generator Portable 4kW Peak 3.5kW Rated Ideal

Product's Documents

Product manual

Specifications

GENPOWER GENPINGPRAI45S Questions and Answers
