User Manual
[Revision 4.0 November 2023]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY
VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,
assembly, inclusions, specifications, description, and packaging.
The product is NOT supplied with engine oil, although traces of oil from the manufacturing process may be present. It is essential to add
adequat
e engine oil of the correct type to the engine before use. Failure to add engine oil will void the product warranty.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 2
Safety
Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or
equipment or property damage if not understood or followed. Safety messages have the following symbols:
You WILL be KILLED or
SERIOUSLY INJURED if you do
not follow instructions.
You CAN be KILLED or
SERIOUSLY INJURED if you do
not follow instructions.
You CAN be INJURED if you do
not follow instructions or equipment
damage may occur.
It is vital that you read and understand this
user manual before using the product,
including safety warnings, and any assembly
and operating instructions. Keep the manual
for future reference.
Safety precautions and recommendations
detailed here must be fully understood and
followed to reduce the risk of injury, fire,
explosion, electrical hazard, and/or property
damage.
Safety information presented here is generic
in nature – some advice may not be
applicable to every product. The term
"equipment" refers to the product, be it
electrical mains powered, battery powered or
combustion engine powered.
• Before Use - If you are not familiar with the
safe operation/handling of the equipment or
are in any way unsure of any aspect of
suitability or correct use for your
application, you should complete training
conducted by a person or organization
qualified in safe use and operation of this
equipment, including fuel/electrical handling
and safety.
• Do NOT operate the equipment in
flammable or explosive environments, such
as in the presence of flammable liquids,
gases, or dust. The equipment may create
sparks or heat that may ignite flammable
substances.
• Keep clear of moving parts.
• Equipment may be a potential source of
electric shock or injury if misused.
• Do NOT operate the equipment if it is
damaged, malfunctioning or is in an
excessively worn state.
• Do NOT allow others to use the equipment
unless they have read this manual and are
adequately trained.
• Keep packaging away from children - risk
of suffocation! Operators must use the
equipment correctly. When using the
equipment, consider conditions and pay
due care to persons and property.
General Work Area Safety
• Work areas should be clean and well it.
• Do not operate the equipment if
bystanders, animals etc are within
operating range of the equipment or the
general work area.
• If devices are provided for connecting dust
extraction / collection facilities, ensure
these are connected and used properly.
Dust collection can reduce dust-related
hazards.
General Personal Safety
• Wear appropriate protective equipment
when operating, servicing, or when in the
operating area of the equipment to help
protect from eye and ear injury, poisoning,
burns, cutting and crush injuries. Protective
equipment such as safety goggles,
respirators, non-slip safety footwear, hard
hat, hearing protection etc should be used
for appropriate equipment / conditions.
Other people nearby should also wear
appropriate personal protective equipment.
Do not wear loose clothing or jewellery,
which can be caught in moving parts. Keep
hair and clothing away from the equipment.
• Stay alert and use common sense when
operating the equipment. Do not over-
reach. Always maintain secure footing and
balance.
• Do not use the equipment if tired or under
the influence of drugs, alcohol, or
medication.
• This equipment is not intended for use by
persons with reduced physical, sensory, or
mental capabilities.
General Fuel Safety
• Petrol/fuel/gasoline is extremely flammable
– keep clear of naked flames or other
ignition sources.
• Do not spill fuel. If you spill fuel, wipe it off
the equipment immediately – if fuel gets on
your clothing, change clothing.
• Do NOT smoke near fuel or when
refuelling.
• Always shut off the engine before
refuelling.
• Do NOT refuel a hot engine.
• Open the fuel cap carefully to allow any
pressure build-up in the tank to release
slowly.
• Always refuel in well ventilated areas.
• Always check for fuel leakage. If fuel
leakage is found, do not start, or run the
engine until all leaks are fixed.
General Carbon-Monoxide Safety
• Using a combustion engine indoors CAN
KILL IN MINUTES. Engine exhaust
contains carbon-monoxide – a poison you
cannot smell or see.
• Use combustion engines OUTSIDE only,
and far away from windows, doors, and
vents.
General Equipment Use and Care
• The equipment is designed for domestic
use only.
• Handle the equipment safely and carefully.
• Before use, inspect the equipment for
misalignment or binding of moving parts,
loose components, damage, or any other
condition that may affect its operation. If
damaged, have the equipment repaired by
an authorised service centre or technician
before use.
• Prevent unintentional starting of the
equipment - ensure equipment and power
switches are in the OFF position before
connecting or moving equipment. Do not
carry equipment with hands or fingers
touching any controls. Remove any tools or
other items that are not a part of the
equipment from it before starting or
switching on.
• Do not force the equipment. Use the
correct equipment for your application.
Equipment will perform better and be safer
when used within its design and usage
parameters.
• Use the equipment and accessories etc. in
accordance with these instructions,
considering working conditions and the
work to be performed. Using the equipment
for operations different from those intended
could result in hazardous situations.
• Always keep equipment components
(engines, hoses, handles, controls, frames,
housings, guards etc) and accessories
(cutting tools, nozzles, bits etc) properly
maintained. Keep the equipment clean and,
where applicable, properly lubricated.
• Store the equipment out of reach of
children or untrained persons. To avoid
burns or fire hazards, let the equipment
cool completely before transporting or
storing. Never place or store the equipment
near flammable materials, combustible
gases, or liquids etc.
• The equipment is not weather-proof, and
should not be stored in direct sunlight, at
high ambient temperatures or locations that
are damp or humid.
• Do not clean equipment with solvents,
flammable liquids, or harsh abrasives.
• For specific equipment safety use and care,
see Equipment Safety.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 3
General Electrical Safety
• Inspect electrical equipment, extension
cords, power bars, and electrical fittings for
damage or wear before each use. Repair or
replace damaged equipment immediately.
• Ensure all power sources conform to
equipment voltage requirements and are
disconnected before connecting or
disconnecting equipment.
• When wiring electrically powered
equipment, follow all electrical and safety
codes.
• Always use a Residual Current Device
(RCD) (GFCI) / Earth Leakage Circuit
Breaker / Safety Switch when operating this
item (electrical items only).
• High voltage / high current power lines may
be present. Use extreme caution to avoid
contact or interference with power lines.
Electrical shock can be fatal.
General Electrical Safety
• Electrically grounded equipment must have
an approved cord and plug and be
connected to a grounded electrical outlet.
• Do NOT bypass the ON/OFF switch and
operate equipment by connecting and
disconnecting the electrical cord.
• Do NOT use equipment that has exposed
wiring, damaged switches, covers or
guards.
• Do NOT use electrical equipment in wet
conditions or in damp locations.
• Do NOT use electrical cords to lift, move or
carry equipment.
• Do NOT coil or knot electrical cords, and
ensure electrical cords are not trip hazards.
General Service Information
• The equipment must be serviced or
repaired at authorised service centres by
qualified personnel only.
• Replacement parts must be original
equipment manufacturer (OEM) to ensure
equipment safety is maintained.
• Do NOT attempt any maintenance or repair
work not described in this manual.
• After use, the equipment and components
may still be hot – allow the equipment to
cool and disconnect spark plugs and/or
electrical power sources and/or batteries
from it before adjusting, changing
accessories, or performing repair or
maintenance.
• Do NOT adjust while the equipment is
running.
• Perform service-related activities in suitable
conditions, such as a workshop.
• Replace worn, damaged or missing
warning/safety labels immediately.
INVERTER GENERATOR SAFETY
• WARNING: Operating, servicing, and maintaining this equipment can expose you to chemicals including engine exhaust, carbon monoxide,
phthalates, and lead, which are known to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing
exhaust, and wear gloves or wash your hands frequently when servicing this equipment.
• DISCLAIMER: All information, illustrations, and specifications in this manual were in effect at the time of publishing. The illustrations used in
this manual are intended as representative reference views only. We reserve the right to make any specification or design change without
notice.
• DANGER! Read this manual before using or performing maintenance on this product. Failure to follow the instructions and safety precautions
in this manual can result in serious injury or death.
• SAVE THESE INSTRUCTIONS.
• This product is designed and rated for continuous operation at ambient temperatures up to 104°F (40°C). If needed, this product can be
operated at temperatures ranging from 5°F (15°C)–122°F (50°C) for short periods. If the product is exposed to temperatures outside of this
range during storage, it should be brought back within this range before operation. This product must always be operated outdoors in a well-
ventilated area and away from doors, windows, and other vents.
• Maximum wattage and current are subject to and limited by such factors as fuel BTU content, ambient temperature, altitude, engine conditions,
etc. Maximum power decreases about 3.5% for each 1,000 feet above sea level and will also decrease about 1% for each 10°F (6°C) above
60°F (16°C) ambient temperature.
CORRECT USAGE
Example location to reduce risk of carbon monoxide poisoning:
• ONLY use outside and downwind, far away from windows, doors, and vents.
• Direct exhaust away from occupied spaces
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 4
INCORRECT USAGE
DO NOT operate in any of the following locations:
• Near any door, window, or vent
• Garage
• Basement
• Crawl Space
• Living Area
• Attic
• Entry Way
• Porch
• Mudroom
CARBON MONOXIDE WARNINGS
• NOTICE: Install battery-powered carbon monoxide detectors or plug-in carbon monoxide detectors with battery back-up in living areas.
• DANGER! Using a generator indoors CAN KILL YOU IN MINUTES. Generator exhaust contains carbon monoxide. This is a poison you cannot
see or smell.
• NEVER use inside a home or garage, EVEN IF doors and windows are open.
• Only use OUTSIDE and far away from windows, doors, and vents.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 5
FIRE AND ELECTROCUTION HAZARDS
• DANGER! Fire and electrocution hazard. DO NOT connect to a building’s electrical system unless the generator and transfer switch have been
properly installed and the electrical output has been verified by a qualified electrician. The connection must isolate the generator power from
utility power and must comply with all applicable laws and electrical codes.
• DANGER! Electrocution hazard. Never use the generator in a location that is wet or damp. Never expose the generator to rain, snow, water
spray, or standing water while in use. Protect the generator from all hazardous weather conditions. Moisture or ice can cause a short circuit or
other malfunction in the electrical circuit.
GENERAL SAFETY PRECAUTIONS
• Never use the generator to power medical support equipment.
• DO NOT operate the generator when you are tired or under the influence of drugs, alcohol, or medication.
• DO NOT use generator with electrical cords which are worn, frayed, bare, or otherwise damaged.
• All electrical tools and appliances operated from this generator must be properly grounded by use of a third wire or be double insulated.
• When this generator is used to supply a building wiring system the generator must be installed by a qualified electrician and connected to a
transfer switch as a separately derived system in accordance with local regulations.
• If you begin to feel sick, dizzy, or weak while using the generator, move to fresh air IMMEDIATELY. See a doctor, as you can have carbon
monoxide poisoning.
• Only use OUTSIDE and far away from windows, doors, and vents. Your specific home and/or wind conditions may require additional distance.
• While operating and storing, keep at least five feet of clearance on all sides of the generator, including overhead. Allow the generator to cool a
minimum of 30 minutes before storage. Heat created by the muffler and exhaust gases could be hot enough to cause serious burns and/or
ignite combustible objects.
• DO NOT touch the muffler or engine. They are very HOT and will cause severe burns. DO NOT put body parts or any flammable or
combustible materials in the direct path of the exhaust.
• Always remove any tools or other service equipment used during maintenance away from the generator before operating.
• Avoid skin contact with engine oil or petrol. Wear protective clothing and equipment. Wash all exposed skin with soap and water.
• A transfer switch must be installed by a licensed electrician approved by the authority having jurisdiction. The installation must comply with all
applicable laws and electrical codes.
FUEL SAFETY
• Store fuel in a container approved for petrol.
• DO NOT smoke when filling the generator with petrol.
• DO NOT allow the generator’s gas tank to overflow when filling.
• Shut down the engine and allow it to cool for five minutes before adding petrol or oil to the generator.
• Never remove the fuel cap when the generator is running. Shut off the engine and allow the unit to cool at least five minutes. Remove the fuel
cap slowly to release pressure, keep fuel from escaping around the cap, and to avoid the heat from the muffler igniting fuel vapours. Tighten
the fuel cap securely after refuelling.
• Wipe spilled fuel from the unit.
• Never attempt to burn off spilled fuel.
• Never overfill the fuel tank. Leave room for fuel to expand. Overfilling the fuel tank can result in a sudden overflow of petrol and result in spilled
petrol coming in contact with HOT surfaces.
• Spilled fuel can ignite. If fuel is spilled on the generator, wipe up any spills immediately. Dispose of rag properly. Allow area of spilled fuel to
dry before operating the generator.
• Wear eye protection while refuelling.
• Never use petrol as a cleaning agent.
• Store any containers containing petrol in a well-ventilated area, away from any combustibles or source of ignition.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 6
PETROL AND PETROL VAPOUR (GAS)
• DANGER! Fire and explosion hazard. Petrol is highly explosive and flammable and can cause severe burns or death.
• In case of a gas fire, DO NOT attempt to extinguish the flame if the fuel valve is in the gas position. Introducing an extinguisher to a generator
with an open fuel valve could create an explosion hazard.
• Gas has a distinctive odour; this will help detect potential leaks quickly.
• Gas vapours can cause a fire if ignited.
• Petrol is a skin irritant and needs to be cleaned up immediately if it comes in contact with the skin.
WHEN STARTING THE GENERATOR
• Make sure that the fuel cap, air filter, spark plug, fuel lines, and exhaust system are properly in place.
• If you spill any petrol on the tank, allow it to fully evaporate before operating.
• Make sure the generator is on a flat surface before operating.
WHEN TRANSPORTING OR SERVICING THE GENERATOR
• Disconnect the spark plug wire to prevent accidental starting.
WHEN STORING THE GENERATOR
• Store away from sparks, open flames, pilot lights, heat, and other sources of ignition.
• DO NOT store gas near furnaces, water heaters, or any other appliances that produce heat or have automatic ignitions.
CO SENSOR
• The CO Sensor monitors for the accumulation of poisonous carbon monoxide gas around the generator when the engine is running. If
increasing levels of CO gas are detected, the CO Sensor automatically shuts down the engine.
• The CO Sensor will also detect the accumulation of carbon monoxide from other fuel burning sources used in the area of operation. For
example, if the exhaust of fuel burning tools is pointed at a CO Sensor-equipped generator, a shut-off may be initiated due to rising CO levels.
This is not an error. Hazardous carbon monoxide has been detected. Move and redirect any additional fuel burning sources to dissipate carbon
monoxide away from personnel and occupied buildings.
• NOTE: Remote start-equipped generators must be restarted with the START/STOP button on the control panel after an automatic shut-down
occurs.
• Generators are intended to be used outdoors, far from occupied buildings and the exhaust pointed away from personnel and buildings. If
misused and operated in a location that results in the accumulation of CO, like in a partially enclosed area, the CO Sensor shuts off the engine,
notifies the user with a RED indicator light, and directs the user to read the Action Label for steps to take. The CO Sensor DOES NOT replace
carbon monoxide alarms. Install battery-powered carbon monoxide alarm(s) in your home.
• WARNING! Automatic shutoff accompanied with a flashing RED light in the CO Sensor portion of the control panel is an indication that the
generator was improperly located. If you start to feel sick, dizzy, weak, or carbon monoxide detectors in your home indicate an alarm, get to
fresh air immediately. Call emergency services. You may have carbon monoxide poisoning.
CO SENSOR INDICATOR LIGHTS
RED
• Carbon monoxide accumulated around the generator. After shut-off, the RED indicator light in the CO Sensor area of the control panel will
flash to provide notification that the generator was shutoff due to an accumulating CO hazard. The RED light will flash for at least five minutes
after a CO shut-off.
• Move the generator to an open, outdoor area far away from occupied spaces with exhaust pointed away. Once relocated to a safe area, the
generator can be restarted. Introduce fresh air and ventilate the area where the generator had shut down.
YELLOW
• A CO sensor system fault occurred. When a system fault occurs, the generator is automatically shut down and the YELLOW indicator light in
the CO auto-shutoff area of the control panel will flash to provide notification that a fault has occurred. The YELLOW light will flash for at least
five minutes after a fault. The generator can be re-started but may continue to shutoff. A CO sensor fault can only be diagnosed and repaired
by an authorised service centre.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 7
Safety Symbols
The product may have safety warning labels attached to it, explained below. Understand the symbols on your
product and their meanings. If any stickers become unreadable, unattached etc., replace them.
Flammable Material Hazard
Flammable liquids, gases, or
substances etc may present.
Avoid ignition sources and open
flames. Danger of fire.
Read User Manual
Read and fully understand
product safety warnings,
operation, procedures etc before
using the product.
Use Hand Protection
Wear appropriate hand protection
and take due care as the product
or use of the product may present
hand hazards.
Carbon-Monoxide Hazard
Do not use the product in
confined areas or without
adequate ventilation. Carbon-
monoxide poisoning can be fatal.
Electrocution / Electrical Shock
Hazard
High voltage or high current
electricity may be present or
required by the product. Take
due care when handling electrical
products, cables, plugs and
leads. Electrical shock can be
fatal.
Toxic Fumes / Dust Hazard
Using the product or by-products
from use may produce fumes,
smoke or particles that could be
harmful if inhaled. Wear
appropriate breathing protection
and have adequate ventilation.
Explosive Material Hazard
Combustible liquids, gases, or
substances etc may be present.
Avoid ignition sources and open
flames. Danger of explosion.
Cutting / Amputation Hazard
The product may have blades,
edges or mechanical devices that
can cause severe cut injury to
fingers, limbs etc. Take due care
when handling and using the
product.
Crush Hazard
The product may have blades,
edges or mechanical devices that
can cause severe crush injury to
fingers, limbs etc. Take due care
when handling and using the
product.
Single Operator Only
The product must be operated by
a single person only. More than
one person operating the product
may introduce additional hazards.
Use Face Protection
Wear appropriate full-face
protection and take due care as
the product or use of the product
may present face and eye
hazards.
Use Foot Protection
Wear appropriate foot protection
and take due care as the product
or use of the product may present
foot hazards.
Use Eye / Ear / Head Protection
Wear appropriate eye and / or
ear and / or head protection and
take due care as the product or
use of the product may present
eye, hearing, and head hazards.
Running Hazard
Do not run on or near the product
as doing so may present a fall
hazard.
Diving Hazard
Do not dive into the product as
doing so may present a neck /
head injury hazard.
Adult Supervision Required
Always supervise children and
other users of a product to
prevent drowning or injury.
Skin Penetration / Puncture
Hazard
The product may produce
pressure, emit liquids or objects
that can cause severe injury to
fingers, limbs, blood etc. Take
due care when handling and
using the product.
Hot Surface Hazard
Be aware that the product may
produce high temperatures and
hot surfaces that can cause burn
injuries.
Flying Debris Hazard
Be aware that the product or use
of the product may present
hazards produced by flying
debris. Wear appropriate clothing
and protective devices.
Moving Parts Hazard
Be aware that the product
contains or uses mechanical
devices that move or rotate.
Always wait for moving parts to
stop fully before handling the
product, adjusting, maintenance
etc.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 8
Carbon-Monoxide Hazard
Do not use the product in
confined areas or without
adequate ventilation. Carbon-
monoxide poisoning can be fatal.
Pull Hazard
Be aware that the product
contains or uses mechanical
devices that can pull in objects
and can cause severe injury to
fingers, limbs etc. Take due care
when handling and using the
product.
Slope / Fall Injury Hazard
Be aware that using the product
on sloping surfaces or in slippery
conditions may present additional
dangers from falls and contact
with blades, moving parts, hot
surfaces etc.
"Slam Dunk" Warning
Do NOT attempt "slam dunk"
manoeuvres as this may result in
severe injury due to falling,
product breakage or collapse etc.
Electrocution / Electrical Shock
Hazard - Outdoor
High voltage or high current
electricity may be present or
required by the product. Do NOT
use in rain, damp, or wet
conditions. Electrical shock can
be fatal.
Electrocution / Electrical Shock
Hazard - Disconnect
High voltage or high current
electricity may be present or
required by the product. Always
disconnect the product from the
electrical supply before handling
the product, adjusting,
maintenance etc.
Power Line Electrocution
Hazard
High voltage / high current power
lines may be present. Use
extreme caution to avoid contact
or interference with power lines.
Electrical shock can be fatal.
"Kick-Back" Hazard
High level of "kick-back" hazard
that can cause the machine to
suddenly rotate towards operator.
Kick-back injury can be fatal.
Winch Operator Position
Hazard
Do NOT stand between winch
and load. Do NOT use winch to
move people.
Winch Lift Hazard
Do NOT LIFT load vertically. Use
machine to PULL only.
Cable Hazard
Ensure that load bearing cable is
not kinked or knotted.
Winch Cable Hazard
Ensure that there is a minimum
number of cable coils on
winching mechanism.
Winch Hook Hazard
Carry hook to load – do NOT
throw or run.
Flash / Blinding Hazard
Wear appropriate eye protection
for welding. Direct exposure to
weld arcs may cause permanent
eye injury.
Laser Hazard
Laser may be in use – do NOT
look directly at laser or allow
others to.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 9
Table of Contents
Safety ............................................................................................................................................................. 2
Safety Symbols ........................................................................................................................................................... 7
Parts Identification ..................................................................................................................................... 11
Control Panel Components ...................................................................................................................................... 11
Generator Components ............................................................................................................................................ 12
Spare Parts ............................................................................................................................................................... 13
Assembly ..................................................................................................................................................... 14
Initial Oil Fill .............................................................................................................................................................. 14
Fuel ........................................................................................................................................................................... 15
Operation ..................................................................................................................................................... 17
Generator Location ................................................................................................................................................... 17
Grounding ................................................................................................................................................................. 17
High Altitude Operation ............................................................................................................................................ 18
Break-In Period ......................................................................................................................................................... 18
Frequency of Use ..................................................................................................................................................... 18
Before Starting the Generator .................................................................................................................................. 18
Starting the Engine ................................................................................................................................................... 19
Stopping the Engine ................................................................................................................................................. 20
Eco Mode .................................................................................................................................................................. 20
AC Circuit Breakers .................................................................................................................................................. 20
Overload Reset ......................................................................................................................................................... 20
Generator Capacity ................................................................................................................................................... 21
Power Management.................................................................................................................................................. 21
Extension Cords ....................................................................................................................................................... 22
Parallel Operation ..................................................................................................................................................... 23
Transporting .............................................................................................................................................................. 24
Maintenance ................................................................................................................................................ 25
Maintenance Schedule ............................................................................................................................................. 25
Engine Service Cover ............................................................................................................................................... 25
Air Filter Maintenance ............................................................................................................................................... 26
Engine Oil Level Check ............................................................................................................................................ 27
Engine Oil Change .................................................................................................................................................... 28
Spark Plug Maintenance .......................................................................................................................................... 29
Spark Arrestor Service ............................................................................................................................................. 30
Storage ..................................................................................................................................................................... 30
Short Term Storage .................................................................................................................................................. 31
Long Term Storage ................................................................................................................................................... 31
Draining the Float Bowl ............................................................................................................................................ 31
Draining the Fuel Tank ............................................................................................................................................. 32
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 10
Valve Clearance ....................................................................................................................................................... 32
Troubleshooting ......................................................................................................................................... 34
Specifications ............................................................................................................................................. 35
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 11
Parts Identification
Control Panel Components
1. Power Outputs
2. Ground Terminal: The ground terminal is used to externally ground the generator.
3. USB Ports: Two-port 5V/2.1A USB outlet. Accepts Type A USB plugs.
4. Eco Mode ON/OFF: Eco mode minimises fuel consumption and noise by adjusting the engine RPM to the
minimum required for the current load.
5. Low Oil LED: Indicates low oil level. When the oil level in the crankcase falls below the safe operating limit,
the low oil level indicator will illuminate, and the generator will automatically shut off the engine.
6. Overload LED: Indicates that the generator is overloaded.
3
2
1
4
5
6
7
8
9
10
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 12
7. Output Ready LED: Illuminates when the generator is operating normally. Indicates the generator is
producing electrical power at the receptacles.
8. Overload Reset Button: The generator inverter will automatically switch OFF all AC output to protect the
generator if overloaded or if there is a short circuit in a connected appliance.
9. Engine/Fuel Switch: Used to turn fuel valve to the Run, Choke, or OFF position.
10. Parallel Operation Inputs: A compatible Inverter Generator can be connected for additional power input.
Generator Components
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 13
Spare Parts
Spare parts available for purchase, scan QR codes below:
QR Code SKU
GENINVGPRA6MR
GENINVGPRA6MB
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 14
Assembly
Initial Oil Fill
NOTICE: THIS GENERATOR HAS BEEN SHIPPED WITHOUT OIL. DO NOT ATTEMPT TO CRANK
OR START ENGINE BEFORE IT HAS BEEN PROPERLY SERVICED WITH RECOMMENDED OIL.
FAILURE TO ADD ENGINE OIL BEFORE STARTING WILL RESULT IN SERIOUS ENGINE DAMAGE.
NOTICE: Use of 2-stroke/cycle oil or other unapproved oil types can cause severe engine damage that is not
covered under warranty. The included, recommended oil type for typical use is 10W-30 engine oil. If running the
generator in extreme temperatures, refer to the following chart:
1. On a level surface, remove the engine service cover and oil dipstick.
2. Using the supplied funnel and oil, add oil into the engine.
NOTE: As residual oil from the factory may remain in the engine, add the oil incrementally near the end of
the bottle to prevent overfilling the engine. See Engine Oil Level Check in the Maintenance section.
3. Replace the oil dipstick and hand-tighten.
4. Replace the engine service cover.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 15
Fuel
WARNING! Fire and explosion hazard. Never use a petrol container, petrol tank, or any other fuel
item that is broken, cut, torn or damaged. DANGER! Fire and explosion hazard. DO NOT overfill
fuel tank. Fill only to the red fill ring located in the in-tank fuel screen filter. Overfilling may cause fuel to spill onto
engine causing a fire or explosion hazard. DANGER! Fire and explosion hazard. Never refuel the generator
while the engine is running. Always turn the engine off and allow the generator to cool for two minutes before
refuelling. NOTICE: DO NOT use E15 or E85 fuel in this product. Engine or equipment damage caused by
stale fuel or the use of unapproved fuels (such as E15 or E85 ethanol blends) is not covered by warranty. Only
use unleaded petrol containing up to 10% ethanol.
Fuel Requirements
•
CLEAN, FRESH, unleaded petrol, 87–93 octane.
•
Up to 10% ethanol (gasohol) is acceptable (where available; non-ethanol fuel is recommended).
•
DO NOT use E85 or E15.
•
DO NOT use a gas oil mix.
•
DO NOT modify the engine to run on alternate fuels.
•
DO NOT fuel indoors.
•
DO NOT create a spark or flame while fuelling.
Using Fuel Stabiliser
Adding a fuel stabiliser (not included) extends the usable life of fuel and helps prevent deposits from forming that
can clog the fuel system. Follow the manufacturer’s instructions for use.
Always mix the correct amount of fuel stabiliser to petrol in an approved petrol container before fuelling the
generator. Run the generator for five minutes to allow the stabiliser to treat the entire fuel system.
Filling the Fuel Tank
1. Turn the generator OFF and allow to cool for a minimum of two minutes before fuelling.
2. Place the generator on level ground in a well-ventilated area.
3. Clean the area around fuel cap and remove the cap slowly.
NOTICE: Only fill the tank from an approved petrol container. Make sure the petrol container is internally
clean and in good condition to prevent fuel system contamination.
4. Slowly add the recommended fuel. DO NOT overfill. Fill only to the red maximum fill ring on the fuel screen
filter visible in the filler neck.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 16
5. Install the fuel cap securely.
NOTICE: Fuel can damage paint and plastic. Use caution when filling the fuel tank. Damage caused by
spilled fuel is not covered under warranty. Clean the fuel screen filter of debris before and after each
fuelling. Remove the fuel screen filter by slightly compressing it while removing it from the fuel tank.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 17
Operation
Generator Location
Read and understand all safety information before starting the generator. DANGER! USING A
GENERATOR INDOORS CAN KILL YOU IN MINUTES. GENERATOR EXHAUST CONTAINS
CARBON MONOXIDE. THIS IS A POISON YOU CANNOT SEE OR SMELL. NEVER use inside a home or
garage, EVEN IF doors and windows are open. Only use OUTSIDE and far away from windows, doors, and
vents. NEVER operate the generator inside any building, including garages, basements, crawlspaces, sheds,
enclosure, or compartment, including the generator compartment of a recreational vehicle. DANGER!
Electrocution hazard. Never use the generator in a location that is wet or damp. Never expose the generator to
rain, snow, water spray, or standing water while in use. Protect the generator from all hazardous weather
conditions. Moisture or ice can cause a short circuit or other malfunction in the electrical circuit. Using a
generator or electrical appliance in wet conditions, such as rain or snow, or near a pool or sprinkler system, or
when your hands are wet, could result in electrocution. DANGER! Fire hazard. Only operate the generator on a
solid, level surface. Operating the generator on a surface with loose material such as sand or grass clippings
can cause debris to be ingested by the generator that could block cooling vents or the air intake system. Allow
the generator to cool for 30 minutes before transport or storage.
The generator should be on a flat, level surface at all times (Even while not in operation). The generator must
have at least 5 ft. (1.5 m) of clearance from all combustible material.
DO NOT operate the generator in the back of a SUV, camper, trailer, truck bed (regular, flat, or otherwise),
under stairs, next to walls or buildings, or in any other location that will not allow for adequate cooling of the
generator and/or the muffler. DO NOT contain generators during operation.
DANGER! Asphyxiation hazard. Place the generator in a well-ventilated area. DO NOT place
the generator near vents or intakes where exhaust fumes could be drawn into occupied or
confined spaces. Carefully consider wind and air currents when positioning generator.
Grounding
WARNING! Shock hazard. Failure to properly ground the generator can result in electric shock.
The generator neutral is floating. The generator ground terminal is connected to the frame of the generator, the
metal non-current-carrying parts of the generator, and the ground terminals of each receptacle. The generator
(stator winding) is isolated from the frame and from the AC receptacle ground pin. Electrical devices that require
a grounded receptacle pin connection may not function properly.
If this generator will be used only with cord and plug equipment connected to the receptacles mounted on the
generator, National Electric Code does not require that the unit be grounded. However, other methods of using
the generator may require grounding to reduce the risk of shock or electrocution.
NOTICE: Only use grounded 3-prong extension cords, tools, and appliances, or double-insulated tools
and appliances.
Before using the ground terminal, consult a qualified electrician, electrical inspector, or local agency having
jurisdiction for local codes or ordinances that apply to the intended use of the generator.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 18
High Altitude Operation
Engine power is reduced the higher you operate above sea level. Output will be reduced approximately 3.5% for
every 1000 feet of increased altitude from sea level.
High altitude adjustment is required for operation at altitudes over 5,000 ft. (1524 m). Operation without this
adjustment will cause decreased performance, increased fuel consumption, and increased emissions. Operation
of the engine at altitudes below 2,000 ft. (762 m) with the high-altitude kit is not recommended.
NOTICE: Do not operate the generator at altitudes below 2,000 ft. (762 m) with the high-altitude kit
installed. Engine damage may occur.
Break-In Period
For proper break-in, DO NOT exceed 50% of the rated running watts (1500 watts) during the first five hours of
operation.
Vary the load occasionally to allow stator windings to heat and cool and help seat the piston rings.
Frequency of Use
If the generator will be used on an infrequent or intermittent basis (more than one month before next use), refer
to the Storage section of this manual for information regarding fuel deterioration.
Before Starting the Generator
Verify that:
•
The generator is placed in a safe, appropriate location.
•
The generator is on a dry, flat, and level surface.
•
The engine is filled with oil.
•
Petrol is in the fuel tank.
•
All loads are disconnected.
•
The ECO switch is in the OFF position.
DANGER! Fire and explosion hazard. DO NOT move or tip the generator during operation.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 19
Starting the Engine
1. Turn the engine/fuel switch to the Choke position.
NOTE: The generator can be started from the Run position if warm from operation.
2. Firmly grasp and pull the recoil handle slowly until you feel increased resistance, then pull rapidly.
3. After the engine starts, turn the fuel switch to the RUN position.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 20
Stopping the Engine
1. Turn OFF and unplug all connected electrical loads. Never start or stop the generator with electrical devices
plugged in or turned on.
2. Let the generator run with no load for several minutes to stabilise internal temperatures of the engine and
generator.
3. Turn the engine/fuel switch to the OFF position.
4. Allow the engine to cool, then turn the fuel cap vent to the OFF position.
NOTE: If there is an emergency and the inverter must be stopped quickly, immediately move the fuel switch
to the OFF position.
Eco Mode
NOTICE: Always start the generator with ECO MODE OFF. Allow the engine speed to
stabilise and the OUTPUT READY LED to illuminate before switching ECO MODE ON.
•
ECO MODE minimizes fuel consumption and noise by adjusting the engine RPM to the minimum
required for the current load.
•
Turn ECO MODE ON when powering small appliances with continuous loads such as a computer or electric
light.
•
Turn ECO MODE OFF when powering large surge loads such as an air conditioner or electric pump.
•
To turn on ECO MODE, verify that the OUTPUT READY LED is illuminated green, then push the switch to
the ON position. If no load is present, the generator RPM will drop to idle speed. The generator will detect
loads as they are applied and increase engine RPM.
•
To run the generator at maximum power and RPM, push the ECO MODE switch to the OFF position.
AC Circuit Breakers
The circuit breakers will automatically switch OFF if there is a short
circuit, a significant overload of the generator at a receptacle.
If the AC circuit breaker switches OFF automatically, check that the
appliance is working correctly, and it does not exceed the rated load
capacity of the circuit before resetting the circuit breaker.
Overload Reset
The generator will automatically switch OFF all AC output to protect the generator if overloaded or if there is a
short circuit in a connected appliance. However, the engine will continue to run. Marginal overloading that
temporarily illuminates the OVERLOAD LED may shorten the service life of the generator.
OVERLOAD on the control panel will illuminate red and the green OUTPUT READY will be OFF.
To restore AC output:
1. Turn OFF and unplug all connected electrical loads.
2. Push the RESET button on the control panel until the OVERLOAD LED goes OFF and the OUTPUT READY
LED is illuminated.
3. Reset the circuit breakers if OFF.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 21
4. Verify that the intended running and peak loads DO NOT exceed the generator’s capacity.
5. Reconnect electrical loads sequentially, allowing the generator to stabilise after each load is connected.
Generator Capacity
NOTICE! DO NOT overload the generator’s capacity. Exceeding the generator’s wattage/amperage
capacity can damage the generator and/or electrical devices connected to it.
Make sure the generator can supply enough continuous (running) and surge (starting) watts for the items you
will power at the same time.
The total power requirements (Volts x Amps = Watts) of all appliances connected must be considered. Appliance
and power tool manufacturers usually list rating information near the model or serial number.
To determine power requirements:
1. Select the items you will power at the same time.
2. Total the continuous (running) watts of these items. This is the amount of power the generator must produce
to keep the items running. See the wattage reference chart on the next page.
3. Estimate how many surge (starting) watts you will need. Surge wattage is the short burst of power needed to
start electric motor-driven tools or appliances such as a circular saw or refrigerator. Because not all motors
start at the same time, total surge watts can be estimated by adding only the item(s) with the highest
additional surge watts to the total rated watts from step 2.
Tool or Appliance
Running
Watts
Starting
Watts *
TV (Tube Type) 300 0
RV Refrigerator 180 600
Radio 200 0
Light (75 Watts) 300
0
Coffee Maker 600 0
1580
T
otal
Running
Watts*
600
Highest
Starting
Watts*
Total Running Watts 1580
Highest Starting Watts +
600
Total Starting Watts Needed 2180
* Wattages listed are approximate. Verify actual wattage.
Power Management
To prolong the life of the generator and attached devices, use care when adding electrical loads to the
generator. There should be nothing connected to the generator outlets before starting the engine. The correct
and safe way to manage generator power is to sequentially add loads as follows:
1. With nothing connected to the generator, start the engine as described in this manual.
2. Plug in and turn on the first load, preferably the largest load you have.
3. Permit the generator output to stabilise (engine runs smoothly and attached device operates properly).
4. Plug in and turn on the next load.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 22
5. Again, permit the generator to stabilise.
6. Repeat steps 4 and 5 for each additional load.
Wattage Reference
Tool or Appliance
Estimated
Running
Watts *
Estimated
Starting
Watts *
Incandescent Lights
(4 Quantity x 75 Watts)
300 0
TV (Tube Type) 300 0
Sump Pump (1/3 HP) 800
1300
Refrigerator or Freezer 700 2200
Well Pump (1/3 HP) 1000
2000
Radio 200 0
Drill (3/8”, 4 amps) 440
600
Circular Saw
(Heavy Duty, 7-1/4”)
1400 2300
Mitre Saw (10”) 1800
1800
Table Saw (10”) 2000 2000
* Wattages listed are approximate. Verify actual wattage.
Extension Cords
WARNING! Asphyxiation hazard. Extension cords running directly into the home increase the
risk of carbon monoxide poisoning through any openings. If an extension cord running directly
into your home is used to power indoor items, there is a risk of carbon monoxide poisoning to people inside the
home. Always use battery-powered carbon monoxide detector (s) that meet your local safety standards when
running the generator. Regularly check the detector (s) battery. When operating the generator with extension
cords, make sure the generator is located in an open, outdoor area, at least 20 ft. (6 m.) from occupied spaces
with exhaust pointed away. Fire and electrocution hazard. Never use worn or damaged extension cords.
Damaged or overloaded extension cords could overheat, arc, and burn resulting in death or serious injury.
Before connecting an AC appliance or power cord to the generator:
•
Use grounded 3-prong extension cords, tools, and appliances, or double-insulated tools and appliances.
•
Make sure the tool or appliance is in good working order. Faulty appliances or power cords can create a
potential for electric shock.
•
Make sure the electrical rating of the tool or appliance does not exceed the rated power of the generator or
the receptacle being used.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 23
Extension Cord Sizing
Only use grounded 3-prong extension cords marked for outdoor use that are rated for the electrical load.
Parallel Operation
WARNING! Fire and electrocution hazard. Never connect or disconnect the parallel cord leads
when a generator is running. CAUTION! Correct connection of the left and right cables is very
important when the generators are used with a transfer switch to supply power to a building. To avoid serious
personal injury or damage to electrical devices, including the generators, do not try to power an electrical system
in a building without using an approved transfer switch. NOTICE: Connecting to a generator that is not
compatible can cause a low voltage output that can damage tools and appliances powered by the generator.
Parallel operation gives you the ability to link to another compatible SV6000 Inverter Generator with a separate
parallel cord for combined running and peak power output. A parallel cord (purchased separately from the
supplier) is also compatible.
NOTE: Compatible generators without parallel ports can be operated in parallel with a receptacle-
mounted parallel cable (purchased separately from the supplier). DO NOT use ECO MODE during
parallel operation if powering large surge loads such as an air conditioner or electric pump. Engine rpm may not
adjust quickly enough to provide the voltage requirements of large surge loads, causing damage to the devices
or the generators.
1. On both generators, make sure the engine/fuel switch and the ECO MODE switch are in the OFF position.
2. Connect two parallel cable leads to the parallel outlets on the first generator, then connect the opposite cable
leads to the other generator’s parallel outlets.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 24
NOTE: If powering devices directly from the generators (not connected to a building’s transfer switch), you
do not need to match the left/right cables to the generator’s parallel outlets.
3. Start one of the generators and wait until the OUTPUT READY LED illuminates.
4. Start the second generator and wait until the OUTPUT READY LED illuminates before connecting a load.
5. Connect additional loads as described in Power Management section.
6. Unplug all loads before stopping the generators.
Transporting
•
Allow the generator to cool a minimum of 30 minutes before transporting.
•
Replace all protective covers on the generator control panel.
•
Only use the generator’s fixed handle to lift the unit or attach any load restraints such as ropes or tie-down
straps. DO NOT attempt to lift or secure the generator by holding onto any of its other components.
•
Keep the unit level during transport to minimize the possibility of fuel leakage or, if possible, drain the fuel or
run the engine until the fuel tank is empty before transport.
•
Use the extendable handle for one-person, hand transport. To deploy the handle, push on the handle locking
button and pull on the handle until it’s fully extended. To stow it, push on the locking button and push on the
handle until it’s fully retracted. Only extend or retract the handle while the generator is OFF, stationary, and
resting on a horizontal surface. DO NOT use the extendable handle to lift the generator entirely off the
ground, tow it, or up-end it.
CAUTION! Fire hazard. DO NOT fully up-end the generator. Fuel or oil can leak
and damage to the generator may occur.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 25
Maintenance
Maintenance Schedule
Regular maintenance will improve performance and extend the service life of the generator. Follow the hourly or
calendar intervals, whichever occurs first. More frequent service is required when operating in adverse
conditions as noted below.
Before Each Use Check engine oil
After First 25 Hours or First Month Check engine oil
After 50 Hours or Every 6 Months
Change engine oil
1
Clean air filter
2
After 100 Hours or Every 6 Months
Inspect/clean spark arrestor
Inspect/clean spark plug
Inspect/adjust valve clearance
3
After 300 Hours or Every Year
Replace spark plug
Replace air filter
1
Change oil every month when operating under heavy load or in high temperatures.
2
Clean more often under dirty or dusty conditions. Replace air filter if it cannot be adequately cleaned.
3
Recommend service to be performed by an authorised service centre.
Engine Service Cover
Remove the engine service cover to access the air filter and carburettor. Remove the cover screws then
carefully pull the cover out with both hands.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 26
Air Filter Maintenance
WARNING! Fire hazard. Never use petrol or other flammable solvents to clean the air filter. Use
only household detergent soap to clean the air filter.
The air filter must be cleaned after every 50 hours of use or six months (frequency should be increased if the
generator is operated in a dusty environment).
1. Place the generator on a level surface and allow the engine to cool for several minutes.
2. Remove the engine service cover.
3. Remove the screw securing the air cleaner cover and remove the cover.
NOTE: The air filter element is oil soaked. Use an appropriate cleaning container. Avoid skin contact
with engine oil. Wear protective clothing and equipment. Wash all exposed skin with soap and water.
4. Remove the foam air filter from the air cleaner housing and wash it by submerging the element in a solution
of household detergent soap and warm water. Slowly squeeze the foam to thoroughly clean.
NOTE: DO NOT twist or tear the foam air filter element during cleaning or drying. Only apply slow but
firm squeezing action.
5. Rinse the air filter element by submerging it in fresh water and applying a slow squeezing action. Allow the
filter to dry thoroughly.
NOTE: DO NOT pollute. Follow your local guidelines or other governmental agencies for proper disposal
of hazardous materials. Consult local authorities or reclamation facilities.
6. Dip the foam air filter in clean engine oil then squeeze out all excess oil. The engine will smoke when started
if too much oil is left in the filter.
7. Install the foam air filter in the housing and reinstall the air cleaner cover.
8. Install the engine service panel.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 27
Engine Oil Level Check
CAUTION! Avoid skin contact with engine oil. Wear protective clothing and equipment. Wash all
exposed skin with soap and water. NOTICE: Always use the specified engine oil. Failure to use the
specified engine oil can cause accelerated wear and/or shorten the life of the engine.
Change the oil more frequently when using the generator in dusty conditions or in extremely hot weather.
Ambient air temperature will affect engine oil performance. Change the type of engine oil used based on weather
conditions.
Check the engine oil level before each use or every 8 hours of operation.
1. Place the generator on a level surface and allow the engine to cool for several minutes.
2. Remove the oil access cover.
3. With a damp rag, clean around the oil dipstick.
4. Remove the oil dipstick and wipe the dipstick clean.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 28
5. Insert the dipstick into the filler neck without screwing it in. Remove the dipstick and verify that the oil level is
within safe operating range.
6. If low, add recommended engine oil incrementally and recheck until the level is between the L and H marks
on the dipstick. DO NOT overfill. If over the full mark on dipstick, drain the oil to reduce oil level to the full
mark on dipstick.
7. Replace the oil dipstick and hand-tighten.
8. Install the access cover.
Engine Oil Change
WARNING! Accidental start-up. Remove the spark plug boot from the spark plug when working on the
generator.
When using the generator under extreme, dirty, dusty conditions or in extremely hot weather, change the oil
more frequently. Change the oil while the engine is still warm from operation.
1. Place the generator on a level surface and allow the engine to cool for several minutes.
NOTE: Placing the generator on a raised surface slightly above the oil pan will facilitate draining.
2. Remove the oil access cover and spark plug cover. Disconnect the spark plug boot from the spark plug and
place the wire where it cannot contact the spark plug.
3. With a damp rag, clean around the oil dipstick. Remove the dipstick and wipe clean.
4. Place an oil pan (or suitable container) under the oil fill/drain hole.
5. Tilt the generator to drain the oil.
6. Slowly pour oil into the oil fill opening until oil the level is between the L and H marks on the dipstick. Stop
frequently to check the oil level. DO NOT overfill.
Maximum oil capacity: 0.53 US qt (0.5 L)
7. Replace the dipstick and hand-tighten.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 29
8. Connect the spark plug wire and install the oil access cover.
NOTICE: DO NOT pollute. Follow your local guidelines or other governmental agencies for proper
disposal of hazardous materials. Consult local authorities or reclamation facilities.
Spark Plug Maintenance
Inspect and clean the spark plug after every 100 hours of use or six months. Replace the spark plug after 300
hours of use or every year.
1. Place the generator on a level surface and allow the engine to cool.
2. Remove the spark plug cover.
3. Remove the spark plug boot by firmly pulling the spark boot directly away from the engine.
4. Clean the area around the spark plug.
5. Remove the spark plug with the included spark plug socket wrench.
NOTICE: Never apply any side load or move the spark plug laterally when removing the spark plug.
6. Inspect the spark plug. Replace if electrodes are pitted, burned, or the insulator is cracked. Only use a
recommended replacement plug.
7. Measure the spark plug electrode gap with a wire-type feeler gauge. If necessary, correct the gap by
carefully bending the side electrode.
Spark plug gap: 0.024 - 0.032 in. (0.60 - 0.80 mm)
8. Carefully install the spark plug finger tight, then tighten as additional 3/8 to 1/2 turn with the spark plug
wrench.
9. Install the spark plug boot and engine service cover.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 30
Spark Arrestor Service
Allow the muffler to cool completely before servicing the spark arrestor. Check and clean the spark arrestor after
every 100 hours of use or six months. Failure to clean the spark arrestor will result in degraded engine
performance.
1. Place the generator on a level surface.
2. Remove the cover screws and the muffler cover. Use a screw driver to remove the spark arrestor.
3. Carefully remove the carbon deposits from the spark arrestor screen with a wire brush. The spark arrestor
must be free of breaks and tears. Replace the spark arrestor if damaged.
4. Reinstall the spark arrestor and muffler cover.
Storage
Proper storage preparation is required for trouble-free operation and generator longevity.
NOTICE: Petrol stored for as little as 30 days can deteriorate, causing gum, varnish, and corrosive build-
up in fuel lines, fuel passages and the engine. This corrosive build-up restricts the flow of fuel, which can
prevent the engine from starting after a prolonged storage period. The use of fuel stabilizer significantly
increases the storage life of petrol. Full-time use of fuel stabilizer is recommended. Follow the manufacturer’s
instructions for use.
Storage Time Recommended Procedure
Less than 1 month No service required.
2 to 6 months Fill with fresh petrol and add petrol stabiliser. Drain the carburettor float bowl.
6 months or longer Drain the fuel tank and carburettor float bowl.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 31
Short Term Storage
•
Allow the generator to cool a minimum of 30 minutes before storage.
•
Replace all protective covers on the generator control panel.
•
Wipe the generator with a moist cloth. Clean any debris from the air inlets on the front of the unit and muffler
cooling vents.
•
Store the generator in a well-ventilated, dry location away from sparks, open flames, pilot lights, heat, and
other sources of ignition such as areas with a spark producing electric motor or where power tools are
operated.
•
DO NOT store the generator or petrol near furnaces, water heaters, or any other appliances that produce
heat or have automatic ignitions.
•
With the engine and exhaust system cool and all surfaces dry, cover the generator to keep out dust. DO
NOT use a plastic sheet as a dust cover. Non-porous materials trap moisture and promote rust and
corrosion.
Long Term Storage
Even properly stabilised fuel can leave residue and cause corrosion if left long term. If storing the generator for
two to six months, drain the float bowl to prevent gum and varnish build-up in the carburettor.
Draining the Float Bowl
1. Turn the fuel tank valve to the OFF position.
2. Locate the drain screw on the bottom of the carburettor float bowl.
3. Place an appropriate petrol container under the drain screw to catch the drained fuel.
4. Loosen the float bowl drain screw and allow the fuel to drain. Tighten the float bowl drain screw.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 32
Draining the Fuel Tank
If storing the generator for longer than six months, drain the fuel tank to prevent fuel separation, deterioration,
and deposits in the fuel system.
1. Unscrew the fuel tank cap. Remove the fuel screen filter.
2. Using a commercially available petrol hand pump (not included), siphon the petrol from the fuel tank into an
approved petrol container. DO NOT use an electric pump.
3. Reinstall the fuel screen filter and the fuel tank cap.
4. Start the generator and allow it to run until the generator engine stops.
5. Remove the spark plug.
6. Put a teaspoon of engine oil into the cylinder and pull the recoil handle until resistance is felt. At this position,
the piston is coming up on its compression stroke and both valves are closed. Storing the engine in this
position will help prevent internal corrosion. Return the recoil handle gently.
7. Reinstall the spark plug. Leave the spark plug boot disconnected to prevent accidental starting.
8. Install the engine service cover.
Valve Clearance
NOTICE: Checking and adjusting valve clearance must be done when the engine is cold.
1. Remove the rocker arm cover and carefully remove the gasket. If the gasket is torn or damaged, it must be
replaced.
2. Remove the spark plug so the engine can be rotated more easily.
3. Rotate the engine to top dead centre (TDC) by pulling the recoil handle slowly. Looking through the spark
plug hole, the piston should be at the top (both valves are closed).
4. Both the rocker arms should be loose at TDC on the compression stroke. If they are not, rotate the engine
360°.
5. Insert a feeler gauge between the rocker arm and the valve stem to measure valve clearance.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 33
Intake Valve Exhaust Valve
Valve Clearance
0.0031 – 0.0047 in.
(0.08 – 0.12 mm)
0.0051 – 0.0067 in.
(0.13 – 0.17 mm)
Torque
8–12 N • m 8–12 N • m
6. If an adjustment is necessary, hold the rocker arm pivot and loosen the pivot adjusting nut.
7. Turn the rocker arm pivot to obtain the specified clearance. Hold the rocker arm pivot and re-tighten the pivot
adjusting nut to the specified torque.
Torque: 106 inch-pound (12 N • m)
8. Perform this procedure for the other valve.
9. Install the gasket, rocker arm cover, and spark plug.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 34
Troubleshooting
PROBLEM POSSIBLE CAUSE CORRECTION
Engine will not start
Out of fuel. Refuel.
Bad fuel, generator stored without
treating or draining petrol, or refuelled
with bad petrol.
Drain the fuel tank. Refuel with fresh petrol.
Dirty air filter. C
lean the air filter.
Low engine oil level stopped generator.
If low oil LED illuminated, turn battery switch to
the OFF position. Add engine oil.
Spark plug wet with fuel (flooded engine).
W
ait five minutes. Turn battery switch to
the OFF position. Pull recoil handle rapidly
several times. If the generator does not start,
remove spark plug, and dry.
Spark plug faulty, fouled, or improperly
gapped.
Gap or replace the spark plug. Reinstall.
Fuel filter restricted, fuel system
m
alfunction, fuel pump failure, ignition
malfunction, valves stuck, etc.
Contact an authorised service centre or
qualified technician.
Choke partially open or closed due to
weak or disconnected battery.
Manually set the choke. See Maintenance
section.
CO sensor removed or modified. R
eturn to original configuration.
Engine starts, then
shuts down
Out of fuel. Refuel.
Incorrect engine oil level. Check engine oil level.
Dirty air filter. Clean the air filter.
Contaminated fuel. D
rain the fuel tank. Refuel with fresh petrol.
Defective low oil level switch.
Contact an authorised service centre or
qualified technician.
CO sensor activated or system fault
oc
curred.
Relocate generator / Contact an authorised
service centre or qualified technician.
Engine lacks power
Air filter restricted. Clean or replace air filter.
Bad fuel, generator stored without
treating or draining petrol, or refuelled
with bad petrol.
Drain the fuel tank. Refuel with fresh petrol.
Fuel filter restricted, fuel system
malfunction, fuel pump failure, ignition
malfunction, valves stuck, etc.
Contact an authorised service centre or
qualified technician.
Engine runs rough or
bogs when load
applied
Dirty air filter. Clean the air filter.
Generator overloaded. Unplug some devices.
Faulty power tool or appl
iance.
Replace or repair tool or appliance. Stop and
restart the engine.
Fuel filter restricted, fuel system
malfunction, fuel pump failure, ignition
malfunction, valves stuck, etc.
Contact an authorised service centre or
qualified technician.
background
SV6000 Inverter Generator
E&OE © 2023 GenPower 35
PROBLEM POSSIBLE CAUSE CORRECTION
No power at AC
r
eceptacles
OUTPUT READY LED is OFF and
OVERLOAD LED is ON.
Check AC load. Stop and restart engine.
Check the air inlet. Stop and restart the engine.
AC circuit breaker/s tripped. Check AC loads and reset circuit breaker/s.
Faulty power tool or appliance.
R
eplace or repair tool or appliance. Stop and
restart the engine.
Faulty generator.
Contact an authorised service centre or
qualified technician.
Specifications
Max Output 3500W (Starting watts)
Continuous Rated Output
3200W / 3.2kW
Note: Continuous Rated Output is what power this generator consistently and reliably
provides. We strongly recommend that you consider this figure when determining
whether this model suits your requirements.
AC Outlet 240V
DC Outlet 2x USB
Fuel Tank Capacity 5L
Engine Type 4-stroke Petrol Engine
Fuel Type Regular unleaded (Min 95 RON)
Engine Oil Type 10W-30 non-synthetic engine oil (not included with purchase)
Runtime 3 hrs @ 100% load, 6 hrs @ 50% load
Noise Level 71dB (50% load)
Parallel Outlet 2
Ignition System TCI
Warranty 3 Years
Terms of 3 Month
Satisfaction Guarantee
The duration of the Satisfaction Guarantee is calculated from the date of delivery.
A maximum of one product may be returned.
A Satisfaction Guarantee covers the amount paid for the product less the original
shipping price for the product, and less the return freight cost.
The product must be packed in a manner suitable for return freight.
background
Some experts believe that the incorrect or prolonged use of almost any
product may cause serious injury or death. To help reduce your risk of
serious injury or death, refer to the information below. For more information,
see www.datastreamserver.com/safety
Consult all documentation, packaging,
and product labelling before use. Note
that some products feature
documentation available online. It is
recommended to print and retain the
documentation.
Before each use, check the product for
loose/broken/damaged/missing parts,
wear, or leaks (if applicable). Never use a
product with
loose/broken/damaged/missing parts,
wear, or leaks.
Products must be inspected and serviced
(if applicable) by a qualified technician
every 6 months. This is based on
average residential use by persons of
average size and strength, and on a
property of average metropolitan size.
Use beyond these recommendations may
require more frequent
inspections/servicing.
Ensure that all users of the product have
completed a suitable industry recognised
training course before being allowed
access to the product.
The product has been supplied by a general merchandise
retailer that may not be familiar with your specific
application or description of application. Be sure to attain
third-party approval from a qualified specialist for your
application before use, regardless of any assurances from
the retailer or its representatives.
This product is not intended for use where fail-safe
operation is required. As with any product (for example,
automobile, computer, toaster), there is the possibility of
technical issues that may require the repair or
replacement of parts, or the product itself. If the possibility
of such failure and the associated time it may take to
rectify could in any way inconvenience the user, business,
or employee, or financially affect the user, business, or
employee, then the product is not suitable for your
requirements. This product is not intended for use where
incorrect operation or a failure of any kind, including but
not limited to, a condition requiring product return,
replacement, parts replacement, or service by a
technician may cause financial loss, loss of employee
time or an inconvenience requiring compensation.
If this product has been purchased in error when
considering the information presented here, contact the
retailer directly for details of their returns policy, if
required.
©2023 GenPower. All rights reserved. No part of this document, including descriptive content, concepts,
ideas, diagrams, or images may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying, scanning, or recording, or any information storage and retrieval system,
without express permission or consent from the publisher.

Specifications

Indexed Terms: Inverter Generator

GENPOWER GENINVGPRA6MB Questions and Answers

Find answers or ask new question.
See other models: SINE2500W PURESINE2500W PURESINE2000W TNFSTDGPRA3C0 GENPSTGN3C0A
Questions and Answers
