Door View Cam
Charge the provided battery.
= Charged
= Charging
Grab your Wi-Fi password.
You’ll need it later to set up your Door View Cam.
Write it down below so it’s handy when you need it:
Clean up any paint.
If your peephole was painted
over, you may have to remove
the excess in order to unscrew it
(if not, skip ahead).
Check for paint on or around
your peephole, both indoors
and outdoors.
Use the toothed edge of the
Door View Key to carefully
remove paint covering the
edges or slots.
Remove the indoor half.
On the indoor side, place the flat
edge of the Door View Key into the
slots on your peephole and rotate
counter-clockwise to unscrew it.
Once it’s loose enough, you can use
your fingers to finish unscrewing it
and remove it completely.
You may have to secure the outdoor side
of the peephole while unscrewing the
indoor portion to keep it from spinning.
Download the Ring app.
The Ring app walks you through setting up
and managing your Door View Cam.
Download it on your iOS or Android device.
First, fully charge the battery.
Find it in the Door View Kit tray,
along with the adapter and
tightening nut.
Plug it into a USB power source
using the provided orange cable
(located underneath your
Door View Key).
The battery is fully charged
when just one LED is lit.
Remove the outdoor half.
With the indoor side removed,
the outdoor portion should
slide right out.
In the event that it doesn’t,
check again for paint or other
obstructions around the lens.
If this isn’t your forever home,
consider storing the peephole
in a safe place in case you have
to re-install it one day.
Place the outdoor assembly.
From the front side of your door, insert
the tube through the hole until your
Door View Cam is flush with the door.
Now it’s time to continue setup on the
inside part of your door.
54
Remove the rear cover.
Grasp the thin edge of the indoor assembly body, and pinch the cover
at the indentations.
Pull the body and cover apart. Set the cover aside for now.
You might need the included adapter.
It’s used to support larger door view holes. Let’s find out if it’ll fit yours...
Remove the adapter from the Door View Kit tray. From the indoor side
of your door, place the adapter over the tube and cable, then slide it
towards the hole.
If it DOES NOT slide in easily,
don’t force it through.
You won’t need the adapter.
If it DOES slide in easily,
insert the adapter until the
rim is flush with your door.
You may have to hold the outdoor
assembly in place while inserting the
adapter to keep it from falling out;
if you’ve got a wide door, grab a partner.
76
Place the indoor assembly.
Next, carefully slide the indoor assembly
onto the tube until it’s flush with your
door, making sure the outdoor assembly
isn’t pushed out the other side.
Remove the connector cable.
Once again, you may have to hold the
outdoor assembly in place to keep it from
falling out while placing the indoor assembly.
Join the indoor and outdoor assemblies.
With the cable out of the way, place the tightening nut from the
Door View Kit tray over the tube and into the hole.
Using either your fingers or the Door View Key, twist clockwise and
tighten firmly to make sure your Door View Cam doesn’t rotate freely.
Once secure, check the outdoor assembly. It may shift slightly while
tightening, so make sure it’s level.
Grasp either side of the exposed tab, and delicately draw it out of the
tube until there’s no more slack left.
We tucked it into the tube for safe travels,
but now it’s time to take it out.
98
Plug in the connector.
Gently pull the cable taut, then
firmly press the connector into
the port on the indoor assembly,
ensuring it is inserted.
Secure the cable.
Guide the tab with the arrow into the channel, and slide it down to
secure the remaining slack in the cable.
Insert the battery.
Slide the charged battery into the bottom of
your Door View Cam until it clicks into place
(don’t put the cover back on just yet).
Complete setup in the Ring app.
In the Ring app, select Set Up a Device and
follow the in-app instructions.
Once setup is complete, place the cover back
on your Door View Cam.
11
