LADDER ROOF RACK CLAMPS
MODEL NO: SLC2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
I
MP
PO
R
RTA
TA
NT:
PLEA
S
E READ THE
S
E IN
S
TRU
C
TI
O
N
S
C
AREFULLY. N
O
TE THE
S
AFE
O
PERATI
O
NAL RE
Q
UIREMENT
S
, WARNIN
GS
&
C
AUTI
O
N
S
. U
S
E
TH
HE
P
PR
O
ODU
C
T
CO
RRE
C
TLY AND WITH
C
ARE F
O
R THE P
U
RP
OS
E F
O
R WHI
C
H IT I
S
INTENDED. FAIL
U
RE T
O
D
O
SO
MAY
C
A
US
E DAMA
G
E AND
/O
R
PE
ER
S
SON
N
AL IN
JU
RY AND WILL INVALIDATE THE WARRANTY. KEEP TH
ESE
IN
STR
UCT
ION
S S
AFE
FO
R F
U
T
U
RE
USE
.
1. SAFETY
WARNING! Due to the variety in the design of vehicles and roof bars/racks, it is the users responsibility to ensure that the ladder
rack clamps are fi tted and attached correctly.
DO NOT use the ladder rack clamps if any parts are damaged or missing, as this may cause failure and/or possible personal injury.
Maintain the ladder rack clamps in good condition.
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
Familiarise yourself with the applications and limitations of the ladder rack clamps, as well as all potential hazards.
DO NOT use the ladder rack clamps for any purpose other than that for which it is designed.
Always use the ladder rack clamps in pairs. One at the front and one at the rear.
During use frequently check that the ladder rack clamps and ladder are secure.
DO NOT over tighten the ladder rack clamps. This may cause damage to the roof bar/rack or the clamps.
Use only to clamp ladders.
WARNING! Remove any loose objects from the ladder prior to clamping to the roof bar/rack.
WARNING! Ensure that neither the ladder rack clamps or the ladder project beyond the maximum profi le of the vehicle.
WARNING! When a ladder is clamped to the roof bars/rack, the characteristics of the vehicle will change. Driving techniques
should be altered to allow for this. Reduce speeds and allow longer braking distances.
Check that the ladder is secure and stable prior to transit.
WARNING! The security and safety of the load carried is the responsibility of the vehicle driver.
WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations
that may occur. It must be understood by the operator that common sense and caution are factors which cannot
be built into this product, but must be applied by the operator.
2. INTRODUCTION
Universal fi tment for roof racks providing a safe and easy way to secure ladders. Yellow phosphate fi nish for added corrosion resistance.
Suitable for trades where ladders need to be transported safely for on site applications. Supplied with two heavy-duty iron padlocks for
security. Made in the UK.
3. SPECIFICATION
Model No: ..................................................................... SLC2
Maximum width: ......................................................... 365mm
4. CONTENTS
SLC2 Issue 2 (H,F) 08/11/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
ITEM DESCRIPTION QTY
1 Roof bar hooks 1
2 Clamp bar 1
3 Ladder stop 2
4 Washer 1
5 Lock bar 1
6 Thread protector 1
7 Padlock (not shown) 1
5. ASSEMBLY
5.1. CLAMP ASSEMBLY
5.1.1. Remove the thread protector (#6) from the roof hook bar (#1).
5.1.2. Place the clamp bar (#2), pre-fi tted with ladder stops (#3), over the roof bar hook.
5.1.3. Fit the washer (#4) over the roof bar hook and onto the ladder stop.
5.1.4. Thread the lock bar (#5) onto the roof bar hook.
5.1.5. Replace the thread protector.
6. SECURING LADDER TO RACK
6.1. Inspect the roof bars/rack to ensure they are fi tted and assembled correctly to the manufactures instructions and are in a safe,
usable condition.
6.2. Load the ladder onto the roof bars/rack. Seek the assistance of another person for heavier or longer ladders.
6.3. Position the ladder on the roof bars/rack evenly ensuring that there is not excessive overhang.
6.4. If a long ladder is carried it should be secured to the front and rear of the vehicle. Any rear overhang should have a visible warning
indicator.
6.5. Pass the roof bar hook through the ladder and under one of the roof rack bars (fi g 1).
6.6. Screw down the lock bar onto the clamp bar (fi g 2).
DO NOT over tighten.
NOTE: Ensure that the ladder is located between the ladder stops.
6.7. When the ladder is secure pass the padlock through the lock down bar and the clamp bar locking them in place (fi g 3).
7. MAINTENANCE
7.1. Periodically grease the hook bar thread.
SLC2 Issue 2 (H,F) 08/11/21
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
fi g.1
fi g.2
fi g.3
Parts support is available for this product. To obtain a parts listing and/or diagram, please log on to
www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
