5 PANEL MOBILE STORAGE RACK
MODEL NO: MK76.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Only use on firm, level, unobstructed surfaces which are capable of supporting the stand and body panels.
8 DO NOT overload.
9 Always load evenly with the centre of gravity of the load as near the centre as possible.
9 Apply the brakes before commencing work.
8 DO NOT stand/ride on the rack, or allow others to do so.
9 Replace or repair damaged parts. Use only recommended parts. Unauthorised parts may be dangerous and will invalidate the warranty.
WARNING! Failure to comply with these instructions may result in loss of load, damage to the rack or other property and/or personal
injury.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
and situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
2. INTRODUCTION
Suitableforwindscreens,sheetmetals,bonnetsanddoorsaswellasotherlargeitems.Storeuptovepanelswithamax.capacity
of 150kg. Rack includes 12 foam-cushioned support arms to protect the items held within it. Fitted with four castors, two with brakes,
formaximummanoeuvrabilityandsafepositioning.
3. SPECIFICATION
Model No................ ........................MK76
Width............................................700mm
Height...........................................635mm
Arm Length...................................630mm
Max.Capacity.................................150kg
4. ASSEMBLY
Assemble panel stand according to the diagram overleaf.
MK76.V2 Issue 1 07/11/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear
protective
gloves
Wear
protective
footwear
MK76.V2 Issue 1 07/11/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
Number Description Quantity
1 Base tube (Long) 2
2 Base tube (Short) 2
3 Support arm 12
4 4”PPCastor 4
5 Handle with buckle 12
6 T Bracket clamp 8
7 BoltM8x50mm 16
8 Washer M8 16
9 Nut M8 16
