LADDER STABILISER
MODEL NO: LAD001
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
Original Language Version
© Jack Sealey Limited
1. SAFETY
WARNING! Ensure Health and Safety, local authority, and general workshop practice regulations are adhered to when using this
equipment.
9 Familiarise yourself with the application and limitations of the ladder Stabilizer, as well as the potential hazards.
9 Maintain the equipment in good condition.
9 Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
WARNING! When viewed from the front, the top of the ladder section(s) must always be directly above the base.
Place ladder at an angle of 65° to 70° - foot of ladder 1 metre from wall for each 3 metres up - for stability.
Wherepossible,lashtopofladdertoaxturetopreventslipping.
WARNING! Never over-reach when on the ladder.
9 Keep children and unauthorised persons away from the working area.
8 DO NOT use the ladder Stabilizer for any purpose other than that for which it is designed.
8 DO NOT use the equipment if any parts are damaged or missing as this may cause failure and/or personal injury.
8 DO NOT allow children to climb the ladder.
8 DO NOTusetheequipmentwhenyouaretiredorundertheinuenceofalcohol,drugsorintoxicatingmedication.
9 When not in use store in a safe, dry, childproof area.
9 Ensure strap is securly tightened around the lower rung of the ladder.
2. INTRODUCTION
Safeandeasywaytostabiliseyourladderonevenorunevensurfaces.Yellowphosphatenishforaddedcorrosionresistance.
Suitablefortradeswhereladdersneedtobeusedforonsiteapplications.Featuresheavy-dutymetalfeetttedwithnon-sliprubber
pads for added grip and four eyelets for pegging to ground (pegs not included). Tray is adjustable for angle and includes an integral tie
down to secure ladder. Increases ladder footprint from 26cm² to 3097cm². Made in the UK.
3. SPECIFICATION
Model No: ..........................................................LAD001
LadderTray(WxD): .................................500x125mm
OverallSize(WxDxH): ................605x515x112mm
4. CONTENTS
Main fram:........................1
Feet:................................4
Nuts:................................4
5. ASSEMBLY
5.1. STABILIZER ASSEMBLY
5.1.1. The stabilizer will come mostly assembled apart from the four feet. Screw the nuts onto the feet then screw the feet into the threaded
insertsoneachcorner(g.1).
5.2. USINGTHESTABILIZER
5.3. Locatethestabilizeronsolidevenorunevenground,thestabilizerusesaraisingtraytocounterunevenground,g.2.Ensurethat
the stabilizer is the correct way around to achieve this (the tray raises away from the slope).
5.3.1. The stabilizer has back to front adjustment within the feet, loosen the nut and screw in or out to the required height then tighten nut
5.3.2. Removethe‘R’clipfromthelockingpin,withdrawthelockingpinfromtheadjusterbracket(g.2a).
5.3.3. Lift the tray so that the ladder can be placed on a level surface (a spirit level can be used but by eye should be accurate enough),
move the adjuster bracket through its arc of movement to align the holes in the tray with ones in the bracket, when the holes line up
insert the pin and secure with ‘R’ clip.
5.3.4. Place the ladder in the tray and secure the strap around the lower rung of the ladder. Wrap the strap round the rung, pass it through
thegripandpulltight,asshowning.2.
NOTE You may also use pegs to secure the stabilizer to the ground to prevent slipping (pegs not supplied).
LAD001 Issue: 2 05/07/23
g.1
g.2
© Jack Sealey Limited
Original Language Version
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENTPROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
REGISTER YOUR
PURCHASE HERE
6. MAINTENANCE
6.1. Periodically check that all nuts are tight and secure but DO NOT over-tighten.
6.2. Check that the rubber feet on the Stabilizer are in good condition and are not worn, replace if necessary.
LAD001 Issue: 2 05/07/23
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
