4-WAY TRADE ALUMINIUM ADJUSTABLE
HEIGHT TELESCOPIC LADDER EN 131
MODEL NO: AFPL3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL
REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE
PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY
AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL LADDER SAFETY
WARNING! Risk of fall from ladder. Refer to the instruction manual/booklet before use.
9 Inspect the ladder after delivery. Before every use, visually check the ladder is not damaged and is
safe to use. DO NOT use a damaged ladder
9 Maximum total load is 150kg
8 DO NOT use the ladder on an unlevel or unrm base.
8 DO NOT overreach.
8 DO NOT erect ladder on contaminated ground.
9 Maximum number of users - 1
8 DO NOT ascend or descend unless you are facing the ladder.
9 Keep a secure grip on the ladder when ascending and descending. Maintain a handhold whilst working
from a ladder or take additional safety precautions if you cannot.
8 Avoid work that imposes a sideways load on ladders, such as side-on drilling through solid materials.
8 DO NOT carry equipment which is heavy or dicult to handle while using a ladder.
8 DO NOT wear unsuitable footwear when climbing a ladder.
8 DO NOT use the ladder if you are not t enough. Certain medical conditions or medication, alcohol or
drug abuse could make ladder use unsafe.
8 DO NOT spend long periods on a ladder without regular breaks (tiredness is a risk).
9 Prevent damage of the ladder when transporting e.g. by fastening and, ensure they are suitably placed
to prevent damage.
9 Ensure the ladder is suitable for the task.
8 DO NOT use the ladder if contaminated, e.g. with wet paint, mud, oil or snow.
8 DO NOT use the ladder outside in adverse weather conditions, such as strong wind.
9 For professional use a risk assessment shall be carried out respecting the legislation in the country of use.
9 When positioning the ladder take into account risk of collision with the ladder e.g. from pedestrians,
vehicles or doors. Secure doors (not re exits) and windows where possible in the work area.
WARNING! ELECTRICAL HAZARDS
9 Identify any electrical risks in the work area, such as overhead lines or other exposed electrical
equipment and DO NOT use the ladder where electrical risks occur.
9 Use non-conductive ladders for unavoidable live electrical work.
8 DO NOT use the ladder as a bridge.
8 DO NOT modify the ladder design.
8 DO NOT move a ladder while standing on it.
9 For outdoor use, caution to the wind.
9 This ladder is suitable for domestic and professional use.
1.2. LEANING LADDERS
9 Leaning ladders with rungs shall be used at the correct angle.
9 Leaning ladders with steps shall be used that the steps are in a horizontal position.
9 Ladders used for access to a higher level shall be extended at least 1 m above the landing point and
secured, if necessary.
9 Only use the ladder in the direction as indicated, only if necessary due to design of ladder.
8 DO NOT lean the ladder against unsuitable surfaces.
9 Ladder shall never be moved from the top.
8 DO NOT stand on the top three steps/rungs of a leaning ladder.
1.3. STANDING LADDERS
8 DO NOT step o the side of standing ladder onto another surface.
9 Open the ladder fully before use.
9 Use the ladder with restraint devices engaged only
9 Standing ladders shall not be used as a leaning ladder unless it is designed to do so.
8 DO NOT stand on the top two steps/rungs of a standing ladder without a platform and a hand/knee rail.
9 Any horizontal surface which looks like a platform on a standing ladder that is not designed for standing on
(e.g. a plastic work tray shall be clearly indicated on that surface, (only if necessary due to design of ladder).
1.4. EXTENDING LADDERS
9 Locking devices shall be checked and be fully secured before use if not operated automatically.
9 The loose end of the rope shall be tied to the ladder (only if necessary due to design of ladder).
AFPL3 Issue 2 (H,3,F) 02/10/23
Original Language Version
© Jack Sealey Limited
2. INTRODUCTION
EN 131 Certied 4-way, 4-section, aluminium ladder. Can be used as a straight ladder, step ladder, oset ladder and extension ladder.
Fitted with two robust auto-latching locking hinges for multi-positioning. Features extendable legs providing increased climbing height.
3. SPECIFICATION
Model No: ............................................................AFPL3
Extension Ladder Height Min/Max: .......... 2720/4550mm
Folded Depth: .....................................................190mm
Folded Height: ...................................................1405mm
Maximum Capacity: ...............................................150kg
Oset Ladder Height Min/Max: ................. 1400/2000mm
Step Ladder Height Min/Max: ................... 1320/2200mm
Treads: ........................................................................16
Width: ..................................................................600mm
4. OPERATION
WARNING! Ensure all hinges and locks are fully engaged into their locking positions before using the ladder.
4.1. STRAIGHT / EXTENSION LADDER
IMPORTANT: Always position the ladder at an angle of between 65° and 75° to the ground (see safety instructions above).
4.1.1. Fold out the two sections of the ladder until the sprung hinge locks lock into their rst position (step ladder), push in the two hinge locks
(Fig.1) and carry on folding out the two sections of the ladder until it is aligned straight and ensure the hinge locks lock out into their
second position.
4.1.2. To extend the ladder, pull the spring loaded locking arms outward (Fig.2) and adjust the ladder length as required. Ensure the locking
arms lock into position.
4.1.3. Carefully manoeuvre the ladder into place, ensuring the correct angle and positioning for maximum stability.
4.2. STEP LADDER
4.2.1. Fold out the two sections of the ladder until the sprung hinge locks lock into their rst position (the two sections are approx. 45° apart).
4.2.2. If required, extend one side of the ladder at a time by pulling the spring loaded locking arms outward (Fig.2) and adjust the ladder
length as required. Ensure the locking arms lock into position and that both sides are extended equally.
4.3. OFFSET LADDER
4.3.1. Set up the ladder as a step ladder rst, but then extend one side of the ladder by one or two rungs more than the other side, depending
on the height of the steps that the ladder will be placed on.
4.3.2. The shorter side of the ladder MUST always be placed on the step, and the longer side placed on the ground.
FIG.1 FIG.2
5. MAINTENANCE
5.1. Repairs and maintenance shall be carried out by a competent person and be in accordance with the producer’s instructions.
NOTE: a competent person is someone who has the skills to carry out repairs or maintenance, e.g. by a training by the manufacturer.
5.2. For repairs and replacement of parts, e.g. feet, if necessary contact the producer or distributor.
5.3. Ladders should be stored in accordance with the producer’s instructions.
5.4. Ladders made of or using thermoplastic, thermosetting plastic and reinforced plastic materials should be stored out of direct sunlight.
5.5. Ladders made of wood should be stored in a dry place and shall not be coated with opaque and vapour-tight paints.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
