MOTORCYCLE PORTABLE FOLDING WORKBENCH
360KG
MODEL NO: MCW360.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Ensure safety strap is securely fitted before moving workbench.
9 Select a work area suitable for the workbench and keep the area clean, tidy and free from unrelated materials. Ensure there is adequate
lighting.
9 Stand the workbench on a stable surface strong enough to take the weight of the workbench and the motorcycle.
9 Ensure that the motorcycle is secure and stable before beginning to work on it.
9 The maximum motorcycle weight is 360kg. DO NOT exceed this rated capacity.
9 Maintain the workbench in good condition.
9 Replace or repair damaged parts. Use recommended parts only, unauthorised parts may be dangerous and will invalidate the
warranty.
9 Remove ill fitting clothing, remove ties, watches, rings and other loose jewellery and contain long hair.
9 Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT attempt to ride a motorcycle up onto the workbench.
2. INTRODUCTION
Lightweight, folding design with wheels make this workbench mobile
and allows compact storage where workshop space is limited. With
a working height of 455mm, it is ideal for servicing/maintenance.
Additionally the loading ramp doubles as a convenient workshop stool.
Suitable for professional workshops, mobile mechanics, enthusiasts,
track days or as a display table in showrooms.
3. SPECIFICATION
Model No: ..........................................................MCW360.V2
Maximum Load Capacity: ............................................. 360kg
Maximum Height: ....................................................... 455mm
Platform Width/Length: ....................................600 x 2200mm
Ramp Width/Length: .......................................300 x 1340mm
Folded Dimensions (L x W x D): ............ 1100 x 600 x 150mm
4. OPERATION
4.1. WORKBENCH AND RAMP
4.1.1. Wheel workbench to its desired location.
4.1.2. With assistance lay the workbench on the ground, undo the
safetystrapandopenthetwohalvesoutat.Themiddleleg
will deploy itself.
4.1.3. Remove the R clip from the pin on the middle of the leg brace.
Removethepin,seeg.1.
4.1.4. Fold out the leg perpendicular to the workbench and secure
thelegbraceusingthepinandRclip,seeg.2.
4.1.5. Repeat operations 4.3. and 4.4. for the other leg.
4.1.6. With assistance, turn the workbench the right way up.
Note: Take care that the loading ramp does not swing out
whilst the workbench is being turned the right way up.
4.1.7. Fold the loading ramp down.
4.2. WORKSHOP STOOL
4.8.1. Remove the R clips and pins which hold the loading ramp to
theworkbench,seeg.3.
4.8.2. Turn the loading ramp over and remove the R clip and pin to let
the legs unfold. Turn the right way up.
MCW360.V2 Issue 1 08/10/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
g.2
g.1
Pin position for
folded leg
Pin position for
leg brace
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
MCW360.V2 Issue 1 08/10/21
Original Language Version
© Jack Sealey Limited
g.3
Loading ramp pins
