FOLDING BUMPER / PANEL STAND
MODEL NO: MK54.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Familiarise yourself with the application, limitations and hazards of the panel stand.
9 Maintain the panel stand in good condition (use authorised replacement parts).
9 Keep the panel stand clean for best and safest performance.
9 Locate the panel stand in a suitable work area.
WARNING! Use the panel stand on level and solid ground, preferably concrete.
8 DO NOT overload the panel stand. Safe working load 140kg.
8 DO NOT climb on the panel stand.
8 DO NOT use the panel stand for any purpose other than for which it is designed.
8 DO NOT use the panel stand if any parts are damaged or missing as this may cause failure and/or personal injury.
9 Keep the work area clean, uncluttered and ensure that there is adequate lighting.
9 Keep children and unauthorised persons away from the work area.
WARNING! The warnings, cautions and instructions discussed in this manual cannot cover all possible conditions and situations that
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
2. INTRODUCTION
Ideal for storage of bumpers prior to preparation and spraying. Adjustable stand width with extendable arms makes this unit suitable for holding
various types and styles of bumpers. Folds away for easy storage whilst not in use.
3. SPECIFICATIONS
Model No: ................................................................ MK54.V3
Arms Closed: .............................................................700mm
Arms Fully Extended: ..............................................2000mm
Folded Height: .......................................................... 1130mm
4. ASSEMBLY
Parts assembly are as per parts diagram attached.
MK54.V3 Issue 1 07/11/22
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
MK54.V3 Issue 1 07/11/22
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
