Jet-USA PRWELC450USAACAB 1800PSI Electric High Pressure User Manual

1 | Page

IMPORTANT: Please read all safety

warnings and all instructions. Failure

to follow the warnings and instructions

may result in electric shock, fire and/or

serious injury. Please read and

understand this manual prior to using

your Pressure Washer. Save this

operating manual for future reference.

User Manual

[Revision 8.0 December 2023]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY

VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance,

assembly, inclusions, specifications, description, and packaging.

2 | Page

Specifications

Know your product

1. Pressure cleaner

2. Water supply hose

3. Water connection

4. Water inlet

5. High pressure tube

6. Water outlet (backside)

7. Spray gun

8. Power supply

9. on/off switch

* No. 2, 3, 8 are not included

Model

RX450

Working pressure

1600PSI (110bar)

Allowable pressure

2900PIS(200bar)

Working flow rate

5 l/min

Max. flow rate

6.25 l/min

Max. pressure water

l

0.4MPa(4 bar)

Motor Capacity

1400W

Power Supply Voltage

240V~50Hz

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

3 | Page

Contents

Specifications .......................................................................................................................................... 2

Know your product ................................................................................................................................. 2

Introduction ............................................................................................................................................ 4

Assembly ................................................................................................................................................. 4

Operation ................................................................................................................................................ 4

Adjusting fan pattern ...................................................................................................................... 4

Angle to the cleaning surface.......................................................................................................... 4

How to avoid damaging surfaces .................................................................................................... 5

Turbo nozzle .................................................................................................................................... 5

Detergents ...................................................................................................................................... 5

Surface preparation ........................................................................................................................ 5

Initial High Pressure Rinse ............................................................................................................... 6

Detergent Application ..................................................................................................................... 6

Final Rinse ....................................................................................................................................... 6

Shut down ....................................................................................................................................... 6

Storage ............................................................................................................................................ 7

Maintenance ........................................................................................................................................... 7

Nozzle cleaning instructions ........................................................................................................... 7

Hose Care ........................................................................................................................................ 7

Spare parts .............................................................................................................................................. 8

Disposal / Recycling ................................................................................................................................ 8

Troubleshooting ...................................................................................................................................... 9

Warranty ............................................................................................................................................... 10

Description of symbols .......................................................................................................................... 11

Electrical safety ..................................................................................................................................... 11

General power tool safety warnings ..................................................................................................... 11

Electrical safety ............................................................................................................................. 11

Personal safety .............................................................................................................................. 11

Power tool use and care ............................................................................................................... 12

Service ........................................................................................................................................... 12

No

tice: Automatic ON/OFF ........................................................................................................... 12

Portable washer safety warnings .......................................................................................................... 12

Australian Distributor............................................................................................................................ 13

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

4 | Page

Introduction

Congratulations on purchasing your Pressure Washer. We aim to provide quality tools at an

affordable price. We hope you will enjoy using this tool for many years. Your RX450 Portable

Washer has been designed for cars, bikes, boats and other outdoor equipment or garden

patios, green houses etc.

Assembly

You will need a standard screw driver.

1. Insert cable hook hold into the machine (figure 1a)

2. Align holes on the bottom of the pressure cleaner as shown and tighten the 2 screws

(figure 1b)

Figure 1a Figure 1b

Operation

PLEASE NOTE: Using long extension leads can result in

reduced power in some cases.

Adjusting fan pattern

The angle of spray coming out of the lance may be adjusted

on some lances by rotating the nozzle. This will vary the

spray pattern from approximately a 0° narrow high impact

stream to a 60° wide fan spray (Figure2)

A narrow stream has high impact force on the cleaning

surface and results in maximum deep cleaning in a

concentrated area. However, this narrow high impact spray

must be used cautiously, as it may damage some surfaces

(figure 3)

A wide fan pattern will distribute the impact of the water over

a larger area, resulting in excellent cleaning action with a

reduced risk of surface damage, Large surface areas can be

cleaned more quickly using a wide fan pattern (figure 4)

Angle to the cleaning surface

When spraying water against a surface, maximum impact is

generated when the water strikes the surface “head on.”

However, this type of impact tends to cause dirt particles to

imbed in the surface, thereby preventing the desired cleaning

action.

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

5 | Page

The optimum angle for spraying water against a cleaning surface if 45 degrees.

Spraying water against a surface at this angle provides for the most beneficial impact force

combined with efficient removal of debris from the surface.

Distance from cleaning surface

Another factor that determines the impact force of the water is the distance from the spray

nozzle to the cleaning surface. The impact force of the water is increased as the nozzle is

moved closer to the surface.

How to avoid damaging surfaces

Damage to cleaning surfaces occurs because the impact force of the water exceeds the

durability of the surface. The impact force can be varied by controlling the three previously

noted items. Never use a narrow high impact stream or a turbo/rotary nozzle on a surface

that is susceptible to damage. Avoid spraying windows with a narrow high impact stream or

turbo nozzle as this may cause breakage.

The recommended way to avoid damaging surfaces is as follows:

- Before triggering the gun, adjust the nozzle to a wide fan pattern.

- Place the nozzle approximately 4-5 feet from and 45 degrees to the cleaning surface,

and trigger the gun.

- Vary the fan pattern spray angle and the distance to the cleaning surface until optimum

cleaning efficiency is achieved without damaging the surface.

Turbo nozzle

(NOT INCLUDED WITH ALL MODELS)

A turbo nozzle, sometimes referred to as a rotary nozzle, is a very effective tool that can

significantly reduce cleaning time. The turbo nozzle combines the power of a narrow high

impact stream and the efficiency of a 25 degree fan pattern. This swirls the narrow high

impact stream into a cone shape that cleans a larger area.

CAUTION: Since a turbo nozzle uses a narrow high impact stream, only use it in

applications where the cleaning surface cannot be damaged by narrow high impact spray.

Additionally, the turbo nozzle is NOT adjustable and cannot be used to apply detergent.

Detergents

The use of detergents can dramatically reduce cleaning time and assist in the removal of

difficult stains. Some detergents have been customized for pressure washer use on specific

cleaning tasks. These detergents are approximately as thick as water. The use of thicker

detergents, such as dish soap, will clog the chemical injection system and prevent the

application of the detergent. The cleaning power of detergents comes from applying them to

a surface and giving the chemicals time to break down the dirt and grime. Detergents work

best when applied at low pressure. The combination of chemical action and high pressure

rinsing is very effective. On vertical surfaces, apply the detergent starting at the bottom and

work your way upward. This will prevent the detergent from sliding down and causing

streaks. High pressure rinsing should also progress from the bottom to top. On particularly

tough stains, it may be necessary to use a brush in combination with detergents and high

pressure rinsing.

The following cleaning procedure will help you to organize your cleaning task, and ensure

that you achieve the most beneficial results in the shortest amount of time. Remember to

use the spraying/cleaning techniques previously listed.

Surface preparation

Before starting a pressure wash cleaning job, it is important to prepare the surface that is to

be cleaned. This is done by cleaning the area of furniture, and making sure that all windows

and doors are closed tight. In addition, you should make sure that all plants and trees

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

6 | Page

adjacent to the cleaning area are protected by a drop cloth. This will ensure that your plants

won’t be sprayed by the detergents.

Initial High Pressure Rinse

The next step is to spray the cleaning surface with water to clear off any dirt or grime that

may have collected on the surface. This will allow your detergent to attack the deep down

dirt that has worked its way into the cleaning surface. Before triggering the gun, adjust the

nozzle to a wide fan pattern and slowly adjust to the desired spray pattern. This will help you

avoid applying too much concentrated spray to the surface which could cause damage.

Detergent Application

USE THE INSTRUCTIONS APPROPRIATE FOR MODEL PURCHASED

NOTE: Use only detergents formulated for pressure washes.

NOTE: Test detergent in an inconspicuous area before use.

For Units with Detergent Applicator Included

Follow manufacturer’s label directions for mixing correct

concentrations of detergent to water ratio through the

pressure washer is approximately 5.4% (1 to 19).

1. Unscrew to top of detergent applicator and fill

applicator with detergent.

2. Replace top on applicator.

3. Remove lance from gun.

4. Attach detergent applicator to gun. (See Figure 8)

5. Apply detergent so it thoroughly covers cleaning

surface. Apply from bottom to top to prevent detergent

from sliding down and streaking.

6. Allow detergent to remain on the surface for a few minutes. This is a good time to use a

brush to lightly scrub heavily soiled areas. Never allow detergent to dry on the cleaning

surface.

7. Remove detergent applicator from gun and replace with the lance, or remove applicator

from end of lance.

8. Rinse detergent from surface.

NOTE: Flush detergent applicator with clear water following each use.

Final Rinse

Start final rinse at bottom and work upward. Make sure you thoroughly rinse the surface and

that all detergent has been removed.

Shut down

1. Be sure all detergent is flushed from system.

2. Turn off motor.

3. Turn off water supply.

4. After motor and water supply are turned off, trigger gun to depressurize system.

CAUTION: NEVER turn water supply off before turning motor off. Serious damage could

occur to the pump and/ or motor.

WARNING! NEVER disconnect high pressure discharge hose from machine while system

is pressurized. To depressurize, turn motor off, turn water supply off and squeeze gun

trigger times.

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

7 | Page

Storage

Do not store pressure washer outdoors or where it might freeze.

Tips for extending the life of your pressure washer;

- Never operate unit without water.

- Pressure washer is not meant to pump hot water. Never connect to hot water supply –

this will significantly reduce life of the pump.

- Using detergent other than others brand may cause damage to pump components (O-

rings, etc.).This also applies to chemicals such as bleach, dish soap, etc.

- Never operate unit for more than one (1) minute without spraying water. Resulting heat

build-up will damage pump.

- Before adjusting nozzles pressure (high-to-low or low-to-high) release trigger. Failure to do

so will reduce life of O-rings in lance.

Maintenance

Nozzle cleaning instructions

A clogged or partially clogged nozzle can cause a significant reduction of water coming out

of the nozzle and cause the unit to pulsate while spraying.

To clean out the nozzle:

1. Turn off and unplug unit.

2. Turn off water supply. Relieve any pressure trapped in

the hose by squeezing trigger 2-3 times.

3. Separate lance from gun.

4. Rotate nozzle to the narrow stream setting. This

opens up the fan blades.

5. Using included tip cleaner, or an unfolded paper clip, insert wire into the nozzle hole and

move back and forth until debris is dislodged. (See Figure 5.)

6. Remove additional debris by back-flushing water through the nozzle. To do this, place

end of a garden hose (with water running ) to end of nozzle for 30-60 seconds.

Hose Care

- To extend your hose life, you’ll want to drain the hose after use. Don’t rely on the nozzle

to cut the water when you are done. If you do, the water pressure builds up inside the

hose and can burst it. The better procedure for the hose upkeep is to turn off the water at

the spigot and allow the hose to drain.

- Another way to keep your hose in good shape for longer is to avoid dragging it by the

spray trigger assembly. This weakens the coupler connection and causes leaks.

- Also, don’t just leave it in a pile when you are finished with it. Using the included hose

reel prevents kinks that create tears.

- Finally, there is the issue of storing a hose over winter. If you live in a cold winter region,

you’ll want to bring the hose into the garage (or somewhere inside) to prevent freezing.

Drain the entire hose first, then coil it on a hose reel and carry it inside.

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

8 | Page

Spare parts

Need Parts? If you require spare parts please visit http://www.edisons.com.au, look up your

product and simply select the “Need Parts” button.

OR

Scan QR code below:

Can’t find what you need? If you are unable to find the parts you need please contact us

by email [email protected] and one of our professional customer service reps will be

in touch with you as soon as they can or call us on (02) 8667 7874 Mon - Fri, 11am - 7pm

AEST.

Disposal / Recycling

Power tools that are no longer

usable should not be disposed

of with household waste but in

an environmentally friendly

way. Please recycle where

facilities exist. Check with your

local council authority for

recycling advice.

Recycling packaging reduces

the need for landfill and raw

materials. Reuse of recycled

material decreases pollution

in the environment. Please

recycle packaging where

facilities exist. Check with

your local council authority

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

9 | Page

Troubleshooting

Symptom

Possible cause(s)

Corrective Action(s)

No detergent suction –

units with tanks

1. Lance nozzle is not in

low pressure.

2. High pressure

extension hose is too

long.

3. Injector clogged on

pump.

1. Slide lance nozzle

into low pressure

position (see page 13)

2. Remove high

pressure extension

hose or use high

pressure hose shorter

than 25 feet.

3. Contact the distributor

No detergent suction –

units with attachable

applicators

1. Detergent applicator is

clogged

1. Clean applicator with

warm water.

2. Replace the

applicator.

Unit begins to smoke

1. Overheated,

overloaded or damaged

motor.

1. Turn off and call the

dealer.

Pressure washer does

not start up

1. Unit is pressurised.

2. Plug is not well

connected or electrical

socket is faulty.

3. Extension cord is too

long or wire size too

small.

4. Main voltage supply is

too low.

5. Thermal safety switch

has tripped.

1. Squeeze trigger on

gun.

2. Check plug, socket

and fuse.

3. Remove extension

cord.

4. Check that main

supply voltage age is

adequate.

5. Switch off motor unit

and allow motor to

cook down.

Pump does not reach

necessary pressure

1. Water inlet filter is

clogged

2. Pump is sucking air

from hose connections

3. Nozzle is worn or not

correct

4. Unloader is clogged or

Worn

5. Valves is clogged or

worn

1. Clean the water inlet

filter.

2. Check that

connections and

locking ring are

properly tightened.

3. Call the dealer.

4. Call the dealer.

5. Call the dealer.

Fluctuating Pressure

1. Pump is sucking in air.

2. Clogged nozzle.

3. Valves dirty, worn or

stuck.

4. Water Seals worn.

1. Check that the hoses

and connections are

tight.

2. Clean with tip

cleaner(see page 8)

3. Call the dealer

4. Call the sealer

Motor stops suddenly

1. Extension cord is too

long or wire size too

small.

2. Thermal safety switch

has tripped due to

overheating.

1. Remove extension

cord (see page 4)

2. Check that main

supply corresponds to

specifications.

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

10 | Page

Warranty

Mills International Trading Pty Ltd offers a 12 month warranty on all products used for private

household use from the date of purchase. In line with most major machinery brands, the use of

products for commercial purposes qualifies the purchaser to a 3 month warranty period.

Naturally the warranty cover does not extend to damage caused by normal wear and tear, accidents,

misuse, lack of maintenance, neglect, natural disaster, or other external causes; to damage caused

by operating the equipment in a manner outside that described in the instructions. The warranty is

considered void if the item has been modified, altered or tampered with by a person (or persons) not

authorised by Mills International Trading Pty Ltd to provide service (not including standard periodic

maintenance).

Consumable components (and accessories) such as carry bags, batteries, hoses, grinding discs,

belts, cables, wheels, blades etc. are not covered by warranty. We do however stock many of these

replacement parts for purchase.

Dead on Arrival -

Many of our items are technical in nature. While there is always a small chance of an item missing

parts, being "dead on arrival" or working only for a short time, keep in mind that we cover all our items

with a comprehensive warranty - simply get in touch with our customer service team and they can

easily resolve any issue. In the rare case where this occurs, please keep in mind that photos will be

required to be emailed to allow confirmation and resolution of the issue. Your item may also need to

be returned and inspected prior to any resolution being provided. The outcome of the inspection

should take no longer than 8 business days from the date the item is received by our service

department (times may vary). Mills International Trading Pty Ltd may provide details allowing return of

the item at no cost to the customer (check 'Returning Items' for more info).

General Repairs –

Until the nature of any fault is determined, the resolution Mills International Trading Pty Ltd can offer

may vary. Please keep in mind that photos will be required to be emailed to allow confirmation and

resolution of the issue. Where necessary, the item may need to be returned to determine fault/issue.

Once the fault/issue is clarified, Mills International Trading Pty Ltd may fit replacement parts or offer

replacement parts to the customer. Other alternatives may be offered to the satisfaction of both

parties. While many spare parts are stocked in Australia, we may need to order certain parts from the

supplier on your behalf. While specially ordered parts generally arrive within around 15 days, a small

number of difficult to order parts may require up to 8 weeks to arrive.

In the above 2 instances, Mills International Trading Pty Ltd may not accept the warranty claim in

cases where the buyer has contributed to the failure, or been misleading in their description of their

issues. Where freight costs were incurred by Mills International Trading Pty Ltd to return your item for

inspection, reimbursement to Mills International Trading Pty Ltd may be required prior to releasing the

goods. The item is also to be returned to the buyer at the buyer’s expense. Freight cost not to exceed

original freight cost. Where item was purchased with free postage, freight costs are to be set at 20%

of the item cost. Payment to be made to Mills International Trading Pty Ltd within 14 days of being

notified of warranty rejection. Storage fees to apply beyond 7 days at 5% of the original product cost

until the credit expires..

Where money is owed to Mills International Trading Pty Ltd for repairs and/or postage, Mills

International Trading Pty Ltd is entitled to hold onto the item until payment is made.

**Ensure you read the Returning Items info below prior to returning any product**

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You

are entitled to a replacement or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced

if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

11 | Page

Description of symbols

To help recognise this information please observe the following symbols;

Danger

Caution

Warning

Note

Electricity Risk

Machine not suitable for

connection to the potable

Double Insulated

Electrical safety

WARNING! When using mains-powered equipment, basic safety precautions, including the

following, should always be followed to reduce risk of fire, electric shock, personal injury and material

damage.

The term “power tool" in all of the warnings refers to your mains-operated (corded) power tool or

battery-operated (cordless) power tool.

General power tool safety warnings

WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or serious injury.

Work area safety

a)

Keep work area clean and well lit. Cluttered or dark areas invite accidents.

b)

Do not operate power tools in explosive atmospheres, such as in the presence of flammable

liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.

c)

Keep children and bystanders away while operating a power tool. Distractions can cause

you to lose control.

Electrical safety

a)

Power tool plugs must match the outlet. Never modify the plug in any way.

b)

Do not use any adapter plugs with earthed (grounded) power tools.

c)

Unmodified plugs and matching outlets will reduce risk of electric shock.

d)

Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and

refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

e)

Do not expose power tools to rain or wet conditions. Water entering a power tool will increase

the risk of electric shock.

f)

Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords

increase the risk of electric shock.

g)

When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a

cord suitable for outdoor use reduces the risk of electric shock.

h)

If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)

protected supply. Use of an RCD reduces the risk of electric shock. Always use a Residual

Current Device (RCD) (GFCI) / Earth Leakage Circuit Breaker / Safety Switch when operating

this item (electrical items only).

Personal safety

a)

Stay alert, watch what you are doing and use common sense when operating a power tool. Do

not use a power tool while you are tired or under the influence of drugs, alcohol or medication.

A moment of inattention while operating power tools may result in serious personal injury.

b)

Use personal protective equipment. Always wear eye protection. Protective equipment such as

dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate

conditions will reduce personal injuries.

c)

Prevent unintentional starting. Ensure the switch is in the off-position before connecting to

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

12 | Page

power source and/or battery pack, picking up or carrying the tool. Carrying power tools with

your finger on the switch or energising power tools that have the switch on invites accidents.

d)

Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may result in personal injury.

e)

Do not overreach. Keep proper footing and balance at all times. This enables better control of

the power tool in unexpected situations.

f)

Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves

away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.

g)

If devices are provided for the connection of dust extraction and collection facilities, ensure

these are connected and properly used. Use of dust collection can reduce dust-related hazards.

Power tool use and care

a)

Do not force the power tool. Use the correct power tool for your application. The correct power

tool will do the job better and safer at the rate for which it was designed.

b)

Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be

controlled with the switch is dangerous and must be repaired.

c)

Disconnect the plug from the power source and/or the battery pack from the power tool before

making any adjustments, changing accessories, or storing power tools. Such preventive safety

measures reduce the risk of starting the power tool accidentally.

d)

Store idle power tools out of the reach of children and do not allow persons unfamiliar with the

power tool or these instructions to operate the power tool. Power tools are dangerous in the

hands of untrained users.

e)

Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and

any other condition that may affect the power tool's operation. If damaged, have the power tool

repaired before use. Many accidents are caused by poorly maintained power tools.

f)

Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

g)

Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking

into account the working conditions and the work to be performed. Use of the power tool for

operations different from those intended could result in a hazardous situation.

Service

Have your power tool serviced by a qualified repair person using only identical replacement

parts. This will ensure that the safety of the power tool is maintained.

Notice: Automatic ON/OFF

The motor on this pressure washer does not run continuously. It only runs when the trigger of

the spray gun is squeezed. After following the startup procedures in this manual, turn the

pressure washer ON and squeeze the trigger for activation. See “Operating Instruction” section

in this manual for further details.

WARNING! The electrical supply connection shall be made by a qualified person and comply with

IEC 60364-1. The electric supply to this machine should include either a residual current device that

will interrupt the supply if the leakage current to earth exceeds 30 mA for 30 ms or a device that will

prove the earth circuit.

WARNING! The operating method to be followed in the event of accident (e.g. contact with

detergents: rinse with an abundance of clean water) or breakdown to prevent unsafe situations.

WARNING! The motor of this pressure washer will NOT run unless the trigger is squeezed.

Portable washer safety warnings

This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible for their

safety.

WARNING! This product is not intended for pumping water in a home domestic

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

13 | Page

application. Do not use it for corrosive, abrasive, explosive or dangerous liquids. Fluids

other than water will damage the water pump and/or create a fire hazard.

WARNING! High pressure jets can be dangerous if subject to misuse. The jet

must not be directed at persons, live electrical equipment or the appliance itself.

WARNING! Do not use the appliance within range of persons unless they wear protective

clothing.

Disconnect from the power supply before carrying out user maintenance. High pressure cleaners

shall not be used by children or untrained personnel.

To ensure appliance safety, use only original spare parts from the manufacturer or approved by

the manufacturer.

WARNING! High pressure hoses, fittings and couplings are important for the safety of the

appliance. Use only hoses, fittings and couplings recommended by the manufacturer.

Do not use the appliance if a supply cord or important parts of the appliance are damaged, e.g.

safety devices, high pressure hoses, trigger gun.

If an extension cord is used, the plug and socket must be of watertight construction.

WARNING! This appliance must be attended during operation.

Australian Distributor

Mills International Trading

Unit 2, 2 Costello Place Seven Hills NSW 2147

(02) 8667 7874 Mon - Fri, 11am - 7pm AEST

Email: [email protected]

JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA JET USA

14 | Page

Some experts believe that the incorrect or prolonged use of almost

any product may cause serious injury or death. To help reduce your

risk of serious injury or death, refer to the information below. For

more information, see www.datastreamserver.com/safety



Consult all documentation, packaging,

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.



Before each use, check the product for

loose/broken/damaged/missing parts,

wear, or leaks (if applicable). Never use

a product with

loose/broken/damaged/missing parts,

wear, or leaks.



Products must be inspected and

serviced (if applicable) by a qualified

technician every 6 months. This is

based on average residential use by

persons of average size and strength,

and on a property of average

metropolitan size. Use beyond these

recommendations may require more

frequent inspections/servicing.



Ensure that all users of the product

have completed a suitable industry

recognised training course before being

allowed access to the product.



The product has been supplied by a general

merchandise retailer that may not be familiar with your

specific application or description of application. Be

sure to attain third-party approval from a qualified

specialist for your application before use, regardless of

any assurances from the retailer or its representatives.



This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility

of technical issues that may require the repair or

replacement of parts, or the product itself. If the

possibility of such failure and the associated time it may

take to rectify could in any way inconvenience the user,

business, or employee, or financially affect the user,

business, or employee, then the product is not suitable

for your requirements. This product is not intended for

use where incorrect operation or a failure of any kind,

including but not limited to, a condition requiring product

return, replacement, parts replacement, or service by a

technician may cause financial loss, loss of employee

time or an inconvenience requiring compensation.



If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.

concepts, ideas, diagrams, or images may be reproduced or transmitted in any form or by

any means, electronic or mechanical, including photocopying, scanning, or recording, or any

information storage and retrieval system, without express permission or consent from the

publisher.

Jet-USA PRWELC450USAACAB 1800PSI Electric High Pressure Washer- RX450

Product's Documents

Product manual

Specifications

Jet-USA PRWELC450USAACAB Questions and Answers
