3 EN
Content
Proper use ____________________________3
Safety notes __________________________4
Product contents and device overview ______7
Before fi rst use ______________________
Charging the rechargeable battery _________8
Operation ____________________________9
Cleaning and storage ___________________ 10
Tr ouble shooti ng ________________________ 11
Technical data _________________________ 11
Disposal______________________________ 12
Proper use
• This device is intended for vacuum cleaning dry surfaces.
• Do not in any case vacuum up the following:
– smouldering ashes, cigarette butts, matches etc.,
– fl ammable or ignitable materials,
– very fi ne dust (e.g. cement dust), ash or toner,
– pointy, hard objects such as larger glass shards,
– liquids or wet dirt.
• The device is intended for domestic, not commercial use.
Explanation of symbols
Safety instructions:
Please read these care-
fully and comply with
them in order to prevent
personal injury and dam-
age to property.
Energy effi ciency class V
Protection class II
May only be used in-
doors!
Polarity of the barrel
plug
Supplementary informa-
tion
Read the instruction befo-
re use!
V
Dear customer,
We are delighted that you have decided on this battery-operated handheld vacuum
cleaner.
Before using the device for the fi rst time, please carefully read through the instruc-
tions and store them for future reference. These instructions are to accompany the
device when passed on to others.
The manufacturer and importer assume no liability in the event the data in these
instructions have not been observed!
Please note: The illustrations in these instructions may vary slightly from the real
device.
09847_DE-EN-FR-NL_A5_V3.indb 1309847_DE-EN-FR-NL_A5_V3.indb 13 09.06.2016 08:06:1909.06.2016 08:06:19
8
EN 4
• Only use the device as described in this instruction manual. Any other use is deemed
improper.
• Defects arising due to improper handling, damage or attempts at repair are excluded
from the warranty. This also applies to normal wear and tear.
Safety notes
■
This device may be used by children aged 8 and over and by
people with reduced physical, sensory or mental abilities or a
lack of experience and/or knowledge if they are supervised or
have received instruction on how to use the device safely and
have understood the dangers resulting from this.
■
Children may not play with the device.
■
Cleaning and user maintenance may not be carried out by chil-
dren.
■
Children younger than 8 years of age and animals must be kept
away from the device and the connecting cable!
■
Children must be supervised to guarantee that they do not play
with and/or injure themselves on the device.
■
Only use and store the device out of the reach of children and
animals. Improper use may result in injury and electrical shock.
The mains cable must also be kept out of the reach of children
and animals.
■
The device must always be disconnected from the mains power
when it is left unattended and before assembling, disassembling
or cleaning the device.
■
Only charge the rechargeable battery with the enclosed mains
adapter and the charging station. Do not charge any devices
other than the handheld vacuum cleaner. with the the enclosed
mains adapter and the charging station.
■
Never immerse the device, mains cable or plug in water or other
liquids and ensure that they cannot fall into water or become wet.
■
If the device, the connecting cable or the plug of the device is
damaged, it must be replaced by the manufacturer or customer
service department or a similarly qualifi ed person (e.g. specialist
workshop) in order to avoid any hazards.
09847_DE-EN-FR-NL_A5_V3.indb 1409847_DE-EN-FR-NL_A5_V3.indb 14 09.06.2016 08:06:2009.06.2016 08:06:20
5 EN
Risks of injury
■ Keep children and animals away from the device and packaging material. There is a
danger of injury and suffocation!
■ Do not use the device if it is damaged.
■ During use, keep the nozzles away from body parts and pets. They could be caught
in the vacuum cleaner. If the vacuum cleaner attaches itself when vacuuming, turn it
off immediately with the On/Off switch.
Risk of electric shock and fi re
■ Only connect the mains adapter to a properly installed socket with protective earth con-
tacts. The socket must also be easily accessible after connecting so that the mains
connection can be quickly disconnected. The mains voltage must correspond to the
technical data of the device. Only use proper extension cords, whose technical data
correspond to those of the device or mains adapter.
■ If the device falls in water, immediately disconnect the power supply. Do not attempt
to pull the device out of the water when it is connected to the mains supply!
■ Never touch the device, the mains cord and the mains adapter with wet hands when
these components are connected to the mains supply.
■ Turn the device off and pull the mains adapter out of the socket
■ if you stop working with it,
■ before a storm,
■ if an error or fault occurs during operation,
■ if foreign objects penetrate the device.
■ Do not use the device if it is still connected to the mains adapter or to the power
source.
■ Always pull on the mains adapter and never on the mains cord.
■ Only use the device in enclosed areas.
■ Do not use the device in rooms containing easily fl ammable dust or toxic and explo-
sive vapours.
■ Do not operate the device in very moist environment or in the vicinity of fl ammable
material.
■ For your own safety, always check the device for damages prior to using it. Only use
the device if the device, the rechargeable battery, mains cord and the plug do not
exhibit any damages!
Danger from Rechargeable Batteries
■ Rechargeable batteries can be deadly if swallowed. Seek medical attention immedi-
ately if a battery has been swallowed.
■ Before inserting the battery pack, check whether the contacts are clean and clean
them if necessary.
■ Use only the battery type specifi ed in the technical data.
■ If the battery has leaked, do not allow your skin, eyes and mucous membranes to
come into contact with the battery acid. If you touch battery acid, rinse the affected
09847_DE-EN-FR-NL_A5_V3.indb 1509847_DE-EN-FR-NL_A5_V3.indb 15 09.06.2016 08:06:2009.06.2016 08:06:20
EN 6
sites with abundant fresh water immediately and contact a doctor as soon as pos-
sible.
■ Remove a leaking battery from the device immediately. Clean the contacts before
inserting a new battery.
■ The battery must not be taken apart, thrown into a fi re, immersed in liquids or short-
circuited.
Avoiding damage to materials, property and the device
■ Always place the device on a dry, level, fi rm and heat resistant surface.
■ Lay the cable of the mains adapter so that it does not pose a tripping hazard.
■ Make sure that the mains cord does not get pinched, kinked or laid over sharp edges
and does not come into contact with hot surfaces.
■ Maintain adequate distance to heat sources such as stoves or ovens to prevent da-
mage to the device. Do not place any open fl ames, e.g. burning candles, in the direct
vicinity of the device, cord, rechargeable battery and mains adapter.
■ Do not allow the device to fall and do not subject it to strong percussions.
■ Do not pull or carry the device by the cord of the mains adapter.
■ Do not subject the device to extreme temperatures, severe changes in temperature,
moisture, wetness or direct sunlight.
■ Do not use any corrosive or abrasive cleaning agents to clean the device. They
could damage the surface.
■ Only use the device if it has been completely and correctly assembled! The dust bin
and fi lter must be in place. The fi lters may not be damaged!
■ Do not insert anything in the openings / nozzles of the device and make sure that
they are not plugged.
■ Empty the dust bin after every use. The fi lters must also be cleaned regularly to
prevent the motor from being overloaded.
■ Only use the accessories recommended by the manufacturer.
09847_DE-EN-FR-NL_A5_V3.indb 1609847_DE-EN-FR-NL_A5_V3.indb 16 09.06.2016 08:06:2009.06.2016 08:06:20
EN 8
Brush nozzle
Use the brush nozzle for all objects, furniture, lamps, win-
dow sills, profi le strips and skirting boards with uneven
surfaces as well as delicate objects like picture frames,
lamp shades, keyboards, books etc.
Before fi rst use
ATTENTION!
■ Keep children and animals away from the packaging material. Danger of suffocation
exists!
1. Unpack all parts, remove the foils and transport guards and make sure that the product
contents are complete (see chapter “Product contents and device overview”) and
check for any damages from transport. If you identify damages to the components,
do not use them (!), instead contact our customer service centre.
2. Charge the rechargeable battery (see chapter “Charging the rechargeable battery”).
Charging the rechargeable battery
ATTENTION!
■ Pull the mains adapter out of the socket if you do not use it for a prolonged period of time.
■ Completely charge the rechargeable battery before fi rst use for maximum
charge. Charging takes approx. 4 to 5 hours.
■ If the rechargeable batter y is completely depleted after use, it will take approx.
4 to 5 hours to recharge the rechargeable battery.
1. Remove the rechargeable battery from the device:
Push
the latch on the rechargeable battery (see photo) and re-
move it.
2. Insert the rechargeable battery into the charging station.
3. First connect the barrel connector of the mains adapter to
the connector jack on the charging station and then to a
properly installed, easily accessible socket.
4. The green and the red control light on the charging sta-
tion will be illuminated. The rechargeable battery will be
charged.
5. Let the rechargeable battery of the device charge for ap-
prox. 4 to 5 hours in order to reach the maximum charge.
If only the green control light is still illuminated, the rechar-
geable battery has been fully charged.
09847_DE-EN-FR-NL_A5_V3.indb 1809847_DE-EN-FR-NL_A5_V3.indb 18 09.06.2016 08:06:2209.06.2016 08:06:22
9 EN
6. First disconnect the mains adapter from the mains supply and then the barrel con-
nector from the charging station.
7. Remove the rechargeable battery from the charging station and insert it in the de-
vice again.
Operation
ATTENTION!
■ During use, never hold the nozzles near body parts and do not reach into them. The
device could attach itself to them and you could be injured. If the vacuum cleaner
attaches itself to the fl oor, turn it off immediately.
■ Keep the nozzles away from animals during use. Do not attempt to vacuum off ani-
mals with the device. The device could attach itself to them and you could be injured.
If the vacuum cleaner attaches itself to the fl oor, turn it off immediately.
■ Make sure that there are no large, pointy objects on the area to be cleaned.
■ Do not in any case vacuum up the following:
– smouldering ashes, cigarette butts, matches etc.,
– fl ammable or ignitable materials,
– very fi ne dust (e.g. cement dust), ash or toner,
– pointy, hard objects such as larger glass shards,
– liquids and wet dirt.
■ Empty and clean the dust bin after every use (see chapter “Cleaning and storage”).
■ Do not use the device when it is connected to the mains adapter.
1. Stick the nozzle adapter on the suction opening.
2. If desired, attach the extension tube to the nozzle adapter.
3. Attach the desired nozzle to the extension tube.
The nozzles can also be attached to the nozzle adapter directly without attaching
the extension tube between them.
4. Switch the device on. This can be done in one of two ways:
– by gently holding the On / Off switch down. The device will switch off when you let
it go.
– by fi rmly pushing the On / Off switch once and then releasing it. If you would like to
switch the device back off, push the On / Off switch again
5. The device will immediately start to vacuum clean.
6. Run the device over the area to be cleaned.
7. Turn the device off.
8. If you would like to remove the nozzles, simply pull them off the nozzle adapter or
off of the extension tubes.
09847_DE-EN-FR-NL_A5_V3.indb 1909847_DE-EN-FR-NL_A5_V3.indb 19 09.06.2016 08:06:2309.06.2016 08:06:23
EN 10
Cleaning and storage
ATTENTION!
■ Ensure that the device has been deactivated before you clean it!
■ Never immerse the device, the mains adapter, the rechargeable battery or the cable
in water or other liquids.
■ The device may not be connected with the mains adapter when cleaning the dust
bin.
■ Never use soap or other cleaners to clean the dust and HEPA fi lter. Otherwise this
would damage the fi lters.
■ The fi lters are not suitable for the washing machine, dishwasher or dryer! Only air
dry the fi lters and do not in any case use a hair dryer.
■ Only put the device back together once all parts are completely dry!
■ Do not use any corrosive or abrasive cleaners to clean the housing. They could
damage the surface. If needed, clean the housing with a damp, soft cloth.
Emptying the dust bin and cleaning the fi lters
1. Take the dust bin off of the device by turning it approx. one quarter revolution coun-
terclockwise and pulling it out.
2. Push the release button on the dust bin and empty the dust bin over a waste bin.
3. Pull the fi lters out of the dust bin: Turn the dust fi lter
approx. one quarter turn counterclockwise and remove
both fi lters. Tap out the fi lters over a waste bin.
4. If necessary, clean the dust bin and the fi lters with clean, lukewarm water.
5. Allow all parts to dry completely before assembling them.
ATTENTION: Do not in any case insert the fi lters if they are still moist. Reverse
the steps to assemble them. Make sure that the catches on the dust bin are inserted
into the corresponding recesses on the main unit. Otherwise, the dust bin will not
correctly lock into the device.
6. Store the device and accessories in a dry area out of the sun that is not accessible
to children and animals.
If you do not want to use the device for a prolonged period, remove the rechar-
geable battery to stay on the safe side (see section “Removing the rechargeable
battery”).
09847_DE-EN-FR-NL_A5_V3.indb 2009847_DE-EN-FR-NL_A5_V3.indb 20 09.06.2016 08:06:2409.06.2016 08:06:24
11 EN
Troubleshooting
If the device is not working properly, please check whether you are able to rectify the
problem yourself fi rst.
Do not attempt to repair a defective device yourself!
Problem Possible cause/solution
The device only operates
slowly or doesn’t start.
• Is the rechargeable battery empty? Charge it.
The suction power is weak.
• Is the waste tank full? Empty the bin.
• Is the fi lter heavily laden with dirt? Clean it.
• Is the suction opening plugged?
Turn off the device and remove the blockage.
• It is also possible that some particles remain caught
in the carpet fl oor or that they are too large/too
heavy for the device to vacuum up. Simply remove
the debris by hand.
The device emits dust
when vacuuming.
• Check whether the dust bin and fi lters have been
properly inserted and if necessary, correct their
seating.
The control light doesn’t
illuminate when the device
is connected to the mains
supply.
• Is the mains adapter properly connected with the
socket and the barrel connector with the connector
jack on the device?
• Is the socket defective? Try another socket.
• Check the fuse for your mains connection.
09847_DE-EN-FR-NL_A5_V3.indb 2109847_DE-EN-FR-NL_A5_V3.indb 21 09.06.2016 08:06:2409.06.2016 08:06:24
EN 12
Disposal
The packaging material is recyclable. Dispose of the packaging in an environ-
mentally-friendly manner and make it available to the collection service for re-
cyclable materials.
Dispose of the article in an environmentally friendly manner. It should not be
disposed of in the normal household waste. Please dispose of it at a recycling
centre for used electrical and electronic devices. You can obtain more informa-
tion from your local authorities.
Rechargeable batteries and batteries must be removed and disposed of sepa-
rately before disposing of the device. To protect the environment, batteries and
rechargeable batteries may not be disposed of together with normal household
waste. Instead they must be turned in at appropriate collection points. Please
also observe applicable statutory provisions regulating the disposal of batteries.
Removing the rechargeable battery
ATTENTION!
■ Do not open the rechargeable battery; there is a risk of a short circuit; irritating va-
pours or corrosive liquids may also be emitted.
■ Do not expose the rechargeable battery to intense sunlight, heat or fi re; there is a
risk of explosion.
This device has a rechargeable battery; it must be removed before disposing of
the old device.
1. The rechargeable battery is located on the bottom of the
main unit.
2. Push the latch on the rechargeable battery (see photo)
and remove it.
3. Dispose of the rechargeable battery in an environmen-
tally-friendly manner (collection points or vendors).
All rights reserved.
09847_DE-EN-FR-NL_A5_V3.indb 2209847_DE-EN-FR-NL_A5_V3.indb 22 09.06.2016 08:06:2409.06.2016 08:06:24
09847_DE-EN-FR-NL_A5_V3.indb 4309847_DE-EN-FR-NL_A5_V3.indb 43 09.06.2016 08:06:3609.06.2016 08:06:36
09847_DE-EN-FR-NL_A5_V3.indb 4409847_DE-EN-FR-NL_A5_V3.indb 44 09.06.2016 08:06:3609.06.2016 08:06:36
