4-SHELF EXTRA-WIDE GALVANIZED STEEL
FLOOR CABINET
MODEL NO: GSC110385.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this cabinet.
9 Locate cabinet in a suitable work area.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use cabinet on level and solid ground, preferably concrete.
9 Keep the cabinet clean and tidy in accordance with good workshop practice.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT use the cabinet for any purpose other than that for which it is designed.
8 DO NOT use the cabinet outdoors.
8 DO NOT place the cabinet in a damp or wet location or an area where there is condensation.
8 DO NOT clean the cabinet with any solvents which may damage the surfaces or the protective coating.
8 DO NOT move the cabinet when there are items placed inside.
8 DO NOT step on the shelves.
8 DO NOT overload the cabinet.
2. INTRODUCTION
Floor standing galvanized steel cabinet with lockable double doors. Fitted with four adjustable shelves and base storage. Supplied
with four keys. Ideal for factory, workshop or home use. Features two rear wiring grommets allowing power tool batteries and other
devicestobechargedwhilstinstorage.Floorcabinetissuppliedat-packedandwillneedsomeassembly.
3. SPECIFICATION
Model No ...................................................... GSC110385.V3
Overall Size (W x D x H) ..................... 1100 x 400 x 1830mm
Shelf Size (W x D x H) ............................1095 x 370 x 20mm
Shelves ................................................................................ 4
4. ASSEMBLY
4.1. Unpacktheunitandconrmthatallthepartslisted(g.1).
4.2. Assemble the unit on a solid level surface.
4.3. The assistance of a second person will be required.
4.4. Toassembletheunityouwillrequirearubbermalletandacross-headscrewdriver.
4.5. Wherepracticalxunittoawallforextrastrengthanddurability.
GSC110385.V3 Issue 1 19/03/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear protective
gloves
NOTE: It is advisable to have at least two people (wearing gloves) working together to assemble this unit.
Step 1 - g.2
Layrearpanel(g.1.2)onoorandoerupsidepanels(g1.3,g.1.4)totherelevantsides.NOTE the side panels are handed.
Using only the lower two holes in the side panels, screw them in place to the rear panel.
DO NOTxtheupperscrewholesatthisstage.SeeStep3.
Step 2 - g.3
Standtheassemblyuprightandoerupthedoorfrontsection(g.1.1)totintothecutoutsinthesidepanels.Thiswillrequire
at least two people to support the structure whilst assembling this stage.
Step 3 - g.4
Placeoorsection(g.1.6)insitueandpressdownrmlytoengageit
with the other panels. Note the location of the cutouts to avoid the door
frame central support.
Original Language Version
© Jack Sealey Limited
GSC110385.V3 Issue 1 19/03/21
1 2 3 4
5
6 7
g.1
Item
no.
Description Qty. Part no.
1 Doors 1
2 Rear Panel 1
3 Side (LH) 1
4 Side (RH) 1
5 Base 1
6 Top 1
7 Shelf 4
g.2
g.4
DO NOT xscrewstoupper
holes at this stage
g.3
Original Language Version
© Jack Sealey Limited
Step 4 - g.4, g.5
Placeroofpanel(g.1.5)insitueandscrewinplaceusingthreeholesintherearedgeofthepanel.Useaatbladedscrewdriverto
deformthe‘H’slotsuchthatitengageswiththeslotinthefrontpanel(g.X.).
Step 5
Arrange shelf supports to suit your requirements. See parts list for description.
GSC110385.V3 Issue 1 19/03/21
g.5
g.4
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on technical@sealey.co.uk or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
