2.
3.
312x302x172mm
70m/ s
1450W
750W
Operate
indicator
Power
indicator
196mm
18mm
3mm
2
36
m
m
23
6m
m
217mm
120cm
113cm
130cm
120cm
140cm
150cm
134cm
160cm
141cm
170cm
148cm
180cm
155cm
127cm
Aim the holes of baseplate and t he plastic
screw anchors, mount it on the wall by 4
self tapping screws.
Drill holes
4
2
17
m
m
1
9
6
m
m
1
8
m
m
3
m
m
2
3
6
mm
Grounding
device
AK2901
Power plug
AC120V~
IPX1
This product is intended for installation by a qualified service
person.
Place with temp erature below - 10℃ or over 40℃
Plug into 120V outlet to
test before installing
Please contact Awoco
customer service for any
issue or replacement parts
at 888-412-3428 or
sales@awoco.com
AK2901-V1.1
Maintenan ce
Clean with a soft dry cloth or towel.
Please use neutral detergent, don’t use
organic solvents, acid or alkali toilet clean,
nor cleaning brush, etc.
Don’t use chemical detergent to clean the
sensing area
Main machine
about 54 inches
If the counter top or obstacles below the machine, the minimum distance should
be 16 inches to avoid reflection to mis-sense.
Note: ADA requires the bottom of the hand dryer must fall between a height of
38 inches to 48 inches off the floor.
Environment saving, no need of paper towels.
Quick dry 7-10 seconds with high speed air flow.
Solid built with stainless steel shell, ease of maintenance.
Overtime protection stops the unit after 45 seconds to avoid overheated.
Air temperature at 68-104°F, mostly at 99°F.
Built-in HEPA air filters filter 99.97% of bacteria from the moist restroom air.
Refer to the installation location, according to
the screw hole position, drill four mm holes
and put the plastic screw anchors into the holes.
1. Remove the shell, open the air inlet cover,
pull the air filter out by the hand.
Ribbed plastic anchor
5x25mm self tapping screw
Power
Current
12A
Circuit
board
Motion
sensor
Air outlet
Air inlet cover
Remove the shell
Mount the machine
8
