30” Tower Fan
version A - 05 - 2021
PFT28A2BWW
PFT28A2BBB
midea.com
USER MANUAL
en
PFT28A2BWW
PFT28A2BBB
Warning Notice: Before using
this product, please read this
manual carefully and keep it for
future reference. For additional
support, please call customer
service at 1-866-646-4332.
The design and specifications are
subject to change without prior
notice for product improvement.
Consult with your dealer or
the manufacturer for details.
version A - 04 - 2021 (PREVIEW01)
Page 2
Read This Manual
Inside you’ll find many helpful hints on how to use and maintain your
appliance properly. Just a little preventive care on your part can save you
a great deal of time and money over the life of your appliance. You’ll find
many answers to common problems in the troubleshooting tips - you should
be able to fix most of them quickly before calling service. These instructions
may not cover every possible condition of use, so attention to safety details
is required when operating and maintaining this product.
SAFETY PRECAUTIONS
OWNER’S MANUAL
To prevent injury to the user or other people and property damage, the
instructions shown here must be followed. Incorrect operation due to
ignoring of instructions may cause harm or damage. The different levels of
risk is shown by the following indications.
WARNING
This symbol indicates a hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
This symbol indicates a hazardous situation, which, if
not avoided, could result in minor or moderate injury.
This symbol addresses practices not related to
physical injury.
NOTICE
SAFETY PRECAUTIONS ......................................................................................... 2
IMPORTANT INSTRUCTIONS ................................................................................ 3
PARTS AND FEATURES ....................................................................................... 4
PARTS ASSEMBLY .................................................................................................. 4
OPERATION INSTRUCTIONS ................................................................................ 5
CLEANING AND STORAGE .................................................................................. 6
USER SERVICING INSTRUCTIONS ..................................................................... 6
SERVICE AND SUPPORT ....................................................................................... 7
ONE (1) YEAR LIMITED WARRANTY .................................................................. 8
Page 3
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons,
including the following:
1. To Reduce The Risk of Fire or Electric Shock, Do Not Use This Fan With
Any Solid-State Speed Control Device, other than the one supplied.
2. This product is intended for household use ONLY and not for commercial,
industrial or outdoor use.
3. If the supply cord is damaged, it must be replaced by the manufacturer its
service agent or a similarily qualified person in order to avoid a hazard.
4. This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do
not attempt to defeat this safety feature.
5. Close supervision is necessary when any appliance is used by or near
children.
6. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Arrange cord away from traffic area and
where it will not be tripped over.
7. This product employs overload protection (fuse). A blown fuse indicates
an overload or short-circuit situation. If the fuse blows, unplug the product
from the outlet. Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and check the product.
If the replacement fuse blows, a short-circuit may be present and the
product should be discarded or returned to an authorized service facility
for examination and/or repair.
a) Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
b) Avoid contact with moving fan parts.
8. To avoid overturning, be sure the fan is on a stable surface when operating it.
9. To reduce the risk of electric shock, DO NOT use the fan by a window.
10. Place the fan on a dry level surface.
NOTICE
Please read and save these important safety instructions!
Page 4
PARTS AND FEATURES
PARTS ASSEMBLY
NOTICE
All the pictures in this manual are for explanation purpose only. Any
discrepancy between the real object and the illustration in the drawing
shall be subject to the real subject.
(1) Tower Fan
(5) Power cord
(2) (3) Support Base
(4) Base Clip
1. Pull power cord (5) out slightly.
2. Assemble the front and rear base components (2) and (3) to form a
round base plate assembly.
3. Install the base plate assembly (2+3) to the bottom of the body (1) with
power cord retaining clip on the back side of the fan body. Attach using
base clip (4).
4. Slide the power cord under the clip on the rear base plate (2).
NOTICE
Please place the machine on the package foam or other soft surfaces
and invert it to avoid scratch mark when install the base.
Page 5
a. Control features:
1. Timer
2. Body oscillating switch
3. Speed switch
b. Instructions:
1. Plug the power cord into a wall outlet.
2. The air flow can be angled to the left
or right by pushing the button of body
oscillating switch (2). If you want to stop
angling, push it again.
3. Automatic 120-minute timer. Turn the knob
of the timer (1) to the desired time the
fan will stop when the time is done. The
longest timer setting is 120 minutes. If the
timer is not in use, set the timer to “
0
“.
4. Speed is controlled by pushing speed
switch (3) on the top of the body. There
are 4 positions:
0 - Off; 1 - Low; 2 - Medium; 3 - High
OPERATION INSTRUCTIONS
0
4080
120
1
2
3
0123
Page 6
CLEANING AND STORAGE
• Ensure the fan is turned off and unplugged.
• Use only a soft cloth to gently wipe the outer surfaces of the fan clean.
• To clean between the grills and fan blade area, we recommend using a
pipe cleaner, flexible dust wand, vacuum cleaner or compressed air to
gently remove the dust.
• To clean the rear grill use a soft dry cloth.
• DO NOT immerse the fan in water and never allow water to drip into the
motor housing.
• DO NOT use gasoline, paint thinner or other chemicals to clean the fan.
• For storage, you may leave the fan assembled and covered to protect it
from dust. Store the fan in a cool, dry place.
USER SERVICING INSTRUCTIONS
1. Grasp plug and remove from the
receptacle or other outlet device. Do not
unplug by pulling on cord.
2. Open fuse cover. Slide open fuse access
cover on top of attachment plug towards
blades.
3. Remove fuse carefully. Insert the tip of your tool into fuse slot (close with the
terminal), then pry the fuse gradually and slowly, but not overexert. If you
feel tight, you can try it at several times and pry the fuse little by little. When
one side of the fuse has been pryzed, then you can get the fuse out entirely.
4. Risk of fire. Replace fuse only with 2.5 Amp, 125 Volt fuse.
5. Close fuse cover. Slide closed the fuse access cover on top of attachment plug.
6. To Reduce the Risk of fire, do not replace attachment plug. Contains a safety
device (fuse) that should not be removed. Discard product if the attached
plug is damaged.
NOTICE
When you replace the fuse, please don’t operate suddenly or overexert,
or else the product will be damage or cause accident.
Page 7
SERVICE AND SUPPORT
In the event of a warranty claim or if service is required for this product,
please contact us at the following:
Toll Free: 1-866-646-4332
For questions or comments, please write to:
Midea America Corp
759 Bloomfield Ave., # 386
West Caldwell, NJ 07006-6701
Email: customersupport@pelonis.com
For your records, staple your sales receipt to this manual and record the
following:
DATE OF PURCHASE: _____________________________________________
PLACE OF PURCHASE: ____________________________________________
(STAPLE SALES RECEIPT HERE)
NOTE: PROOF OF PURCHASE IS REQUIRED FOR ALL
WARRANTY CLAIMS
PRINTED IN CHINA
Page 8
ONE (1) YEAR LIMITED WARRANTY
Please read all the instructions before attempting to use this product.
Midea America Corporation warrants as limited herein to the original purchaser of
retail that each new Fan, shall be free of defects in material and workmanship for a
period of one (1) year from the date of original purchase. This one (1) year warranty is
limited to the Motor and Electric Element.
In the event of malfunctions or failure of your Fan, simply deliver or send the Fan,
postage prepaid along with PROOF OF PURCHASE, within the warranty period of one
(1) year, to Midea America Corporation. Midea America Corporation reserves the right
to inspect the claimed defective part or parts to determine if the defect or malfunction
complaint is covered by this warranty. Midea America Corporation shall, within sixty
(60) days after receipt of the product, at its option, repair and/or replace the defective
part or parts free of charge. This warranty shall only cover defects arising from normal
usage. Midea America Corporation assumes no responsability whatsoever if the Fan
should fail during the warranty period by reason of:
• Misuse, negligence, physical damage or accidents.
• Lack of maintenance (see instructions for proper maintenance).
• Repair by any unauthorized party during the warranty period.
• Damage caused by connection to an improper input voltage (see specification label
on your Fan).
Midea America Corporation makes no further warranties or representations, express
or implied except those contained herein. No representative or dealer is authorized
to assume any other liability regarding tha Fan. The duration of the implied warranty
granted under State law, including warranties of merchantability and fitness for
particular purpose are limited in duration should the duration of the express warranty
grant it hereunder. Midea America Corporation shall in no event be liable for direct,
indirect, special or consequential damages.
Some states do not allow limitations on how long an implied warranty lasts, and/or the
above limitations or exclusion may not apply to you. This warranty gives you specific
legal rights and you may have other rights which vary from state to state.
