40" TOWER FAN
MODEL: PSF40T2ABB
SKU# 6211463
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
OWNER’S MANUAL
1
CAUTION
WARNING
1. To reduce the risk of fire or electric shock, do not use this fan with any solid
state speed control device.
2. This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to the fit in a polarized
outlet only one way. If plug does not fit fully in the outlet, reverse plug. If it
still does not fit, contact a qualified electrician. Do not attempt to modify this
safety feature.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities,or lack of experience and
knowledge, unless they have been supervised or instructed related to
use of the appliance by a person responsible for their safety.
4. Do not leave the fan running unattended.
Read Rules for Safe Operation and Instructions Carefully.
IMPORTANT SAFETY INSTRUCTIONS
1．The rules about cord and plug as below:
(1) This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing instructions (follow
product marking for proper fuse rating) and check the products. If the
replacement fuse blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for examination and/
or repair.
(2) Do not operate any fan with a damaged cord or plug. Discard fan or return to
an authorized service facility for examination and/or repair.
(3) Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
2. Fan should be used under rated voltage.
3. Connect power after the fan is fully assembled.
4. Never insert fingers, pencils, or any other object through the guard when fan is
running.
5. Unplug from outlet when not in use, when moving fan from one location to
another, before putting on, or taking off parts, and before cleaning.
6. Be sure fan is on a stable surface when operating to avoid overturning.
7. DO NOT use fan in window. Moisture may create electrical hazard.
RULES FOR SAFE OPERATION
READ AND SAVE THESE INSTRUCTIONS
5. Unplug or disconnect the appliance from the power supply before servicing.
2
PART FIGURE
Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between
the real object and the illustration in the drawing shall be subject to the real subject.
1. Body
2. Rear base
3. Front base
4. Plastic nut
5. Power cord
1
3
4
2
5
ASSEMBLY INSTRUCTIONS
1. Take out the fan body and the spare parts from the box. Put the front base
onto rear base and join them together. (See Fig. 1)
2. Unlock the plastic nut from the fan body.
3. Pass the power cord through the flute, then insert the fan body into the base.
(See Fig. 2)
4. Fix the fan body on the base with the plastic nut. (See Fig. 3)
Fig.1 Fig.2
flute
flute
Fig.3
plastic nut
3
OPERATION INSTRUCTION
I. Control Panel (Fig.4)
1. “ ” ON/OFF KEY
Press this key to switch on/switch off the fan.
2. “ ” SPEED KEY
When the fan started, press this key repeated, the fan will work with “1-2-3” circula-
tory.
3. “ ” OSC/LOUVER KEY
After the fan has started, press this key to select oscillation mode. The lights on the
display can indicate fan oscillation mode.
4. “ ” MODE KEY
Press this key to select mode. The sequence is normal, natural, and sleep when
this key being touched repeatedly or continuously. The light indicate mode state.
5. “ ” TIMING KEY
Press this timer key repeatedly to set the time for air delivery. Increase in incre-
ments up to "1-2-3-4-5-6-7-8-9-10-11-12-13-14-15" hours.
Fig.4
4
b. BATTERY WARNING AS BELOW
1. Do not dispose of batteries in fire, batteries may explode or leak.
2. Do not mix old and new batteries.
3. Do not mix alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium) batteries.
c. REMOTE CONTROLLER OPERATION
Point the remote controller at the receptor on body of the fan and press the
desired button. The remote controller will work at distances of up to roughly
16.4 feet and the angle of 30 degree included between right and left from the
receptor. The batteries must be removed from the remote controller before it is
scrapped and that they are disposed of safely.
d. OVERHEAT PROTECTION OF THE MOTOR
The windings of the motor have a thermal-fuse that burns out and the fan
switches off and temperature of the motor is no longer going up so that plastic
parts of the fan don’t subject to deformation so far so to be burned by the
overheat if the motor is overheat for any unexpected reason.
II.Remote Control (Fig.5)
a. BATTERIES
(battery not included in the packaging)
1. Slide the battery compartment Cover.
2. Insert the batteries, and make sure that the batteries are placed as shown in
the Fig.6.
3. Slide back the battery cover.
NOTES: Use manganese or alkaline batteries of type "AAA". Do not use
rechargeable batteries.
POWER
TIMER
MODE
OSCILLATION
FAN SPEED
Fig.5
Fig.6
Remote control
AAA Battery, 1.5V
Battery cover
5
USER SERVICING INSTRUCTIONS
CLEANING
1. Grasp plug and remove from the receptacle or
other outlet device. Do not unplug by pulling on
cord.
2. Open fuse cover. Slide open fuse access cover
on top of attachment plug towards blades.
3. Remove fuse carefully. Push the fuse from the
other side to remove fuse.
4. Risk of fire. Replace fuse only with 2.5 Amp,
125 Volt fuse (provided with product.)
5. Close fuse cover. Slide closed the fuse access
cover on top of attachment plug.
6. Risk of fire. Do not replace attachment plug.
Contains a safety device (fuse) that should not
be removed. Discard product if the attachment
plug is damaged.
1. When you replace the fuse, please don’t operate suddenly or overexert, or else
the product will be damage or cause accident.
2. Confirm positioning is correct to avoid any complexity when operating.
NOTE:
1. Be sure to unplug the power cord from the outlet before cleaning.
2. Plastic parts should be cleaned with mild soap and damp cloth or sponge.
Thoroughly remove soap lm with clean water. Do not use any abrasive
detergent or solvents to avoid scratching the sufrace. Do not use of the
following as a cleaner: gasoline, thinner, bending.
3. Be sure not to get water or other liquid enter the inside of the motor.
4. Dry all parts completely before plugging into socket.
6
Midea America Corporation
Customer Care Center
5 Sylvan Way, Suite 100
Parsippany, NJ 07054
7
• Please read all instructions before attempting to use this product.
• Please retum the Warranty Registration card within fifteen(15)days from the
date of purchasing this product.
PELONIS warrants as limited herein to the original purchaser of retail that each
new Pelonis fan, shall be free of defects in material and workmanship for a
period of one(1)year from the date of original purchase. This one(1)year
warranty is limited to the motor and electric control circuit board.
In the event of malfunctions or failure of your Pelonis fan, simply deliver or send
the fan,postage prepaid along with PROOF OF PURCHASE,within the warranty
period of one(1)year,to PELONIS. PELONIS reserves the right to inspect the
claimed defective part or parts to determine if the defect or malfunction
complaint is covered by this warranty. PELONIS shall,within sixty(60)days after
receipt of the product, at its option, repair and/or replace the defective part or
parts free of charge. This warranty shall only cover defects arising from normal
usage. PELONIS assumes no responsibility whatsoever if the fan should fail
during the warranty period by reason of:
• Misuse,negligence,physical damage or accidents.
• Lack of maintenance(see instructions for proper maintenance).
• Repair by any unauthorized party during the warranty period.
• Damage caused by connection to an improper input voltage(see specifica-
tion label on your fan).
PELONIS makes no further warranties or representations,express or implied
except those contained herein.No representative or dealer is authorized to
assume any other liability regarding the fan. The duration of the implied warran-
ty granted under State law,including warranties of merchantability and fitness
for particular purpose are limited in duration should the duration of the express
warranty grant it hereunder. PELONIS shall in no event be liable for direct,
indirect, special or consequential damages.
Some states do not allow limitations on how long an implied warranty lasts,
and/or the above limitations or exclusion may not apply to you. This warranty
gives you specific legal rights and you may have other rights which vary from
state to state.
