Fast, easy setup!
1. After installation
Press the button on the timing
pad for the amount of time you
wish your lights to be powered
ON. The blue LED will activate.
NOTE: This will now be the
default time if the function
button or door is pressed.
2. Set new time
Select a new time or press
the currently selected time
again to deactivate.
3. Using the timer as
a switch
If no time has been selected,
pressing the function button
or door will allow the timer to
act as a light switch. The blue
indicator light below the
function button shows
whether the controlled light
is currently ON or OFF.
4. ON/OFF door activation
Pressing the door turns lights
ON for the countdown time
previously selected. Pressing
the door again will override
the program and turn
lights OFF.
RISK OF ELECTRIC SHOCK
• SHUT OFF POWER AT FUSE BOX OR CIRCUIT
BREAKER BEFORE INSTALLATION
• DO NOT USE IN WET LOCATIONS
• USE INDOORS ONLY
RISK OF FIRE
• DO NOT USE TO CONTROL APPLIANCES THAT
CONTAIN HEATING ELEMENTS (COOKING
APPLIANCES, HEATERS, IRONS, ETC.)
• DO NOT EXCEED ELECTRICAL RATINGS
• USE COPPER WIRE ONLY WITH THIS DEVICE
• DO NOT USE TO CONTROL RECEPTACLES
WARNING
In-Wall Digital
40953 VERSION 01 10/15/18
Specifications:
120VAC 60Hz
15A General/Resistive
1200W Tungsten
1200VA Ballast
1/2HP
Works with dimmable
LED and CFL bulbs.
Function
Button
MADE IN CHINA/HECHO EN CHINA
Distributed by Jasco Products Company LLC,
10 E. Memorial Rd., Oklahoma City, OK 73114.
This Jasco product comes with a 1-year limited warranty.
Visit www.byjasco.com for warranty details.
Questions? Contact us at 1-800-654-8483
between 7:00AM—8:00PM CST.
