TheenergyefficiencyofthisENERGY
STARcertifiedmodelismeasuredbased
onaratiobetweenthemodel’sCADRfor
smokeandtheelectricalenergyit
consumes,orCADR/Watt.
T810 USER MANUAL
AIR PURIFIER
• The product warranty is printed on the back of this guide. This product is manufactured for use
only in USA / CANADA This product is suitable for 120 V only.
WHERE TO USE
12~18 in
12~18 in
12~18 in
12~18 in
Allow 12 ~ 18 in. of space between TVs, radios, , humidifiers, and
other electronics
It can cause malfunction due to electromagnetic interference and
humidified water.
Place indoors away from direct sunlight
Direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
Flimsy or slanted surfaces may result in abnormal noise and
vibrations.
Allow 12 ~ 18 in. from walls
For maximum air flow.
FRONT BACK
PACKAGE CONTENTS
Smart Sensor
Air Outlet Vent
Handle
Power Plug
Control Panel
Front Panel
Unit
360º All-in-One
True HEPA Filter
User
Manual
FRONT
PACKAGE CONTENTS
BACK
Control Panel
Air Outlet Vent
Handle
Smart Sensor
Power Plug
User
Manual
360º All-in-One
True HEPA Filter
Unit
Front Panel
MODEL PART DIAGRAM
4-STAGE
AIR PURIFICATION
Air Purification means it
removes inanimate particles
Activated Carbon Filter
Fine Mesh Pre-Filter
True HEPA Filter
PlasmaWave Technology
Technology
Activated Carbon Filter
True HEPA Filter
Fine Mesh Pre-Filter
02
05
13
03 03
01
06
07
04
09
08
14
10 11 12
15
01. Filter Life / Filter Reset Button
• A quick press will show the remaining filter life:
indicated on the front display (F99 ~ F00).
• A long press of 10 seconds will reset the filter life indicator.
- Use when replacing the filters.
- Filter Reset Button can be used when the power is turned off.
- The filter life will be reset to 100%.
02. Light Mode Button
Use the light button to set the desired display brightness. The
display brightness cycles in the order of 100% 70% 30%
OFF. Other features remain unchanged.
03. Fan Speed Indicator Buttons
Indicates the current fan speed.
• Use the Fan Speed arrow buttons to set the desired fan
speed. Fan speeds cycle over in this sequence:
Auto, Low, Mdium, High, Turbo.
04. Auto
Mode Button
The unit will default to Auto with PlasmaWave
®
enabled when
first powered on.
• Auto Mode automatically adjusts fan speeds according to
your indoor air quality. The fan speed will adjust to low when
air quality is good, medium when fair, and to high when poor.
05. Power Button
Turnstheunitonoroff.Duringthefirst30secondsofpower,theAir
Quality Indicator will cycle through Blue, Green, Amber and Red colors.
• SmartSensortakesapproximately30secondstodetectthe
air quality in the environment before normal operation begins.
06. Light Sensor
Detects the amount of ambient light in the environment. When
in Auto Mode, the light sensor detects when to put the unit into
Sleep Mode.
07. Wi-Fi / Pairing Button
• A quick press will turn Wi-Fi on/off.
• A long press of 3 seconds will activate pairing mode.
• A Wi-Fi indicator will display on the front while Wi-Fi is active.
CONTROL PANEL
08. Air Quality Indicator
Color coded LED light indicates one of four levels of Air Quality:
Red (poor), Amber (fair), Green (average) and Blue (good).
09. PlasmaWave
®
Button
Enables or disables PlasmaWave
®
When the unit is running, you may hear a chirping or
buzzing sound. The sound is from particles passing through
PlasmaWave
®
, it is normal and does not signify product failure.
Press the PlasmaWave
®
Technology button when the unit is on
to enable or disable this feature.
10. Mode Indicator
Indicates whether Auto & Fan Speed Mode is enabled or disabled.
Low Medium High
Turbo
11. Sleep Mode Indicator
Indicates whether Sleep Mode is enabled or disabled.
12. Wi-Fi Indicator
Indicates whether Wi-Fi Mode is enabled or disabled.
13. PlasmaWave
®
Indicator
Indicates whether PlasmaWave
®
is enabled or disabled.
14. Filter Replacement Indicator
LED light indicates when it is time to change the filter.
15. Ultrafine Dust Density Indicator
• The LED Ultrafine Dust Density Indicator displays the quality
of air in your environment.
When the unit senses an air quality change, it automatically
adjusts the LED Indicator to display the respective air quality.
• LED Numeric Smart Sensor displays air quality measures
fine particles down to 2.5 microns.
INITIAL OPERATION
1. Turn the product upside down.
2. Grab the handle at the bottom of the
product, turn counter-clockwise, and pull
out the filter cover.
3. Remove the protective vinyl from the filter
installed inside the product.
4. Install the filter top side down into the
bottom of unit until it is fully inserted. The
top of the filter shows the opening and the
bottom of the filter is solid.
5. After installing the filter, turn the handle
clockwise to close the filter cover.
6. Return the product to an upright position
and resume normal operation.
BOTTOM
When to Replace Filters
Filter Indi cator Light When to Ser vice When to Replac e
360º All-in-One
True HEPA Filter
Check Filter
Clean once every 14 days
Lasts Approx. 12 months
• When the Check Filter indicator LED is on, it is time to replace the All-in-One True HEPA Filter.
• Intervals between filter replacement may vary depending on environment.
MAINTENANCE
R
1712-0118-00
FILTER
REPLACING FILTERS
Resetting Filter Life:
After replacing the 360º All-in-One True HEPA Filter, use a small object such as
aWhiletheunitison,holdtheFilterResetButtonforatleast5secondsuntilyou
hear the beep. After the beep, the Filter Replacement Indicator will disappear.
The numerical pollution level value displayed may differ from the information provided by
official institutions depending on the indoor environment or the location of the product.
BLUE GREEN ORA NGE RED
0 ~ 35 36 ~ 55 56 ~ 150
150 ~ or higher
*PM2.5
GuidetoFineDustConcentration(Unit:μg/m
3
)
CLEANING CARE
Cleaning the Filters:
Clean with a vacuum or a soft brush.
• Only clean the Pre-Filter.
• This filter CAN NOT be washed.
• Intervals between filter cleaning may vary
depending on the air quality.
Cleaning the Exterior & Interior:
Wipe with a soft damp cloth using room temperature
water. Afterwards, wipe it down with a clean dry cloth.
After turning the product upside down, remove the
filter cover and clean the interior with a vacuum
cleaner.
• For optimal performance, clean every 14 days.
N O T I C E
• When cleaning the unit, always unplug the power cord
first and then wait until the unit has cooled down.
• Never disassemble, repair, or modify this unit yourself.
• Do not use flammable sprays or liquid detergents.
• Do not allow children to clean or maintain the unit.
• Before cleaning or maintaining, ensure unit is unplugged.
• Do not use benzene, alcohol, or other volatile fluids,
which may cause damage or discoloration.
How to disassemble and clean the smart sensor cover
1. Please use your finger to detach the cover of the
dust sensor.
2. Clean the lens and suction port of the dust sensor
with a cotton swab, and then use a dry cotton
swab to clean the dust sensor.
(Cleaning frequency: Once every two months)
3. Close the cover of the dust sensor until you hear
a clicking sound.
N O T I C E
• Do not clean the sensor with volatile substances such
as water, alcohol, or acetone.
If not cleaned regularly, the performance of the dust
sensor may deteriorate.
UNIT SPECIFICATIONS
Model Name T810 Dimensions
11.3 in(W) x 11.3 in(D) x 20.4 in(H)
Power Voltage
AC 120 V / 60 Hz
Weight 10.2lbs
Power Rate 45W
Replacement
Filter
R
Verifie d Room Size 410sq.ft.
The exterior, design, and product specifications may be changed without prior notice to improve product performance.
Contact Winix for product related inquiries and customer service
• Dedicated Call Center: (877) 699-4649
• Website: www.winixamerica.com
To expedite service, please specify the model name and number, the nature of the problem, your contact
information, and your address.
Do not pull on the power cord when
unplugging the unit.
Do not tie or knot the power cord when unit
is in operation.
SAFETY AND CAUTIONS
Before operating this equipment, carefully read and
follow these safety cautions.
Ensure filters are inserted before running unit.
Running the unit without filters may shorten the
lifespan of the unit and cause electric shock or
injury.
Be sure foreign objects are NOT inserted into the
vents on the unit.
Objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit
with wet hands.
The high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become
blocked.
Blockage may lead to increased internal
temperatures, causing product failure and
deformation.
Do not use the unit as a step stool or place heavy
objects on it.
Personal injury may occur or product failure and
deformation.
When turning the product upside down, install the
filter with care in the direction that the bottom
(blocked) side of the filter is visible from the top.
If the filter direction is not installed properly, it may
cause product damage and user injury.
W A R N I N G
Follow these instructions to reduce the risk of
serious injury or death and to reduce risk of
damaging the unit.
• If the power cord is damaged, it must be replaced
with a special cord. Assembly available from the
manufacturer or its service agent.
• This appliance is not intended for use by
a person (including children) with reduced
physical sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• This unit is not intended to be used to preserve
documents or in art conservation.
If the unit becomes submerged in water,
unplug it and contact customer service.
Do not unplug or move the unit while in
operation.
Do not plug additional appliances into the
same outlet or power supply.
Do not touch the plug with wet hands.
Unplug the unit when not in operation for
extended periods of time.
Do not place around heating elements.
Do not use around mist or fumes from
industrial oil or around large quantities of
metallic dust.
The cord can become damaged by forcefully
bending, pulling, twisting, bundling, pinching
or placing heavy objects on it.
Do not install in any sort of motor or
transport vehicle (trucks, boats, ships,
etc.).
Do not place in an area with excessive
amounts of noxious gases.
Do not place near any flammable materials
(aerosols, fuel, gases, etc.).
Do not have the unit facing into wind or
drafts.
Do not place below any electrical outlet.
Do not place in excessively humid areas
where the unit may become wet.
To reduce the risk of fire or electric shock,
do not use this fan with any solid-state
speed control device.
Do not place unit closer than 12 inches
from the wall during operation. It may
cause condensation on the wall and the
surrounding area.
After winter product delivery/installation
and initial operation, there may be
condensation inside the sensor due to
indoor/outdoor temperature differences,
which can temporarily result in a display
of5μg/m
3
dust concentration and blue
maintenance of cleanliness.
Please use it with confidence as it will
disappear after running for about 1-2 hours
during initial operation.
The minimum value of dust concentration
displayedontheproductis5μg/m
3
.
SAFETY INSTRUCTIONS
Thank you for purchasing a Winix air purifier. This product is for household use only.
• Do not repair or modify the unit. All repairs
should be completed by a qualified technician.
• The plug for this unit is polarized with one blade
wider than the other. Do not force the plug into
an electrical outlet. Do not alter the plug in
any way. If the plug does not fit into the outlet,
reverse the plug. If it still does not fit, contact a
qualified technician to install a proper outlet.
• Do not use if the power cord or plug is damaged
or the connection to the wall outlet is loose.
• Use AC 120 V only.
• Do not damage, break, forcefully bend, pull, twist,
bundle, coat, pinch, or place heavy objects on
the power cord.
• Periodically remove dust from the power plug.
This will reduce the risk of shock due to humidity
build up.
• Remove the power plug from the outlet before
cleaning the unit. When removing the power
plug, grasp by holding the plug itself, never hold
by the cord.
• If the power plug is damaged, it must be replaced
by the manufacturer or a qualified technician.
• Remove the power plug from the outlet when not
in use.
• Do not handle the power plug with wet hands.
• Do not operate the unit when using indoor
smoke-generating insecticides.
• Do not clean unit with benzene or paint thinner.
Do not spray insecticides on the unit.
• Do not use the unit where it is humid or where
the unit may become wet, such as the bathroom.
• Do not insert fingers or foreign objects into air
intake or outlet.
• Do not use the unit near flammable gases. Do
not use near cigarettes, incense, or other spark-
creating items.
• Unit will not remove carbon monoxide emitted
from heating appliances or other sources.
IMPORTANT CAUTIONS FOR USING YOUR AIR PURIFIER
WARNING:
Follow the instructions in this manual to reduce the risk of electric shock, short circuit, and/or fire.
IMPORTANT PRECAUTIONS FOR USING YOUR AIR PURIFIER
• Do not block the intake or outlet vents.
• Do not use near hot objects, such as a stove.
• Do not use where the unit may come into contact with steam.
• Do not use the unit on its side.
• Keep away from products that generate oily residue, such as a deep fryer.
• Do not use detergent to clean the unit.
• Do not operate without a filter.
• Do not wash and reuse the 360º All-in-One True HEPA Filter.
• Hold the handle on the back of the unit to transport.
• Do not hold by the front panel.
• Do not stick any small objects in the air outlet vents or fan.
LIMITED WARRANTY
The terms of the limited warranty are as follows.
1. This product is manufactured under stringent
quality control and inspections.
2. The limited warranty will be voided if product
failure is a result of negligence or misuse by
the consumer.
3. A proof of purchase must be presented upon
claiming a limited warranty.
4. Store the proof of purchase in a safe place or
register your product on winixamerica.com to
upload your proof of purchase.
5. This limited warranty is valid only in the USA
and Canada.
* for more information visit
https://winixamerica.com/terms-and-conditions/
Product Na me
Air Purifier
Model Name
T810
Purc hase Date
Warranty Period
Two (2) Years
Place o f Purchase
Place o f Purchase
tel.
Customer
Address
Name
Tel.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or on experienced radio / TV technician for help.
This device contains license-exempt transmitter(s) / receiver(s) that comply with Innovation, Science
and Economic Development Canada's license-exempt RSS(s). Operation is subject to the following
two conditions:
• This device may not cause interference.
• This device must accept any interference, including interference that may cause undesired operation
of the device.
In French: L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
• L’appareil ne doit pas produire de brouillage;
• L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
2610-0339-00 Rev.00
