Strength, durability, and performance are at the center of
the newly refined Crossover 2.0 by Wascomat small chassis
front load stacked dryer. Built with professional grade
components and loaded with powerful features, Crossover
combines innovative technology, energy eciency, and proven
Wascomat reliability for optimal results every time.
KEY FEATURES
• Commercial grade construction
• Extra large load drum — 22+ pound capacity
• 7.0 cu. ft. drum
• Drum supported by five roller bearings for long life
• Fast drying
• Axial airflow ensures the shortest drying time
• Easy to clean, heavy duty lint screen
• Extra large door opening for easy loading and unloading
• Large capacity can handle oversized loads with ease
• Coin and card payment compatibility
• Space-saving design
• Easy to install
• Stacking kit available
THE POWER OF
TRUE COMMERCIAL
CROSSOVER 2.0
AVAILABLE IN GAS OR ELECTRIC
MODEL No. (GAS): Metered (Coin) / Card Ready
DLHF0817G / DLHF0817GDC
MODEL No. (ELECTRIC):Metered (Coin) / Card Ready
DLHF0817E / DLHF0817EDC
STACKED DRYER MODELS
STACKED DRYER
COIN/CARD & OPL
STACKED DRYER
SPEC SHEET
COIN/CARD & OPL
STACKED DRYER
The highly ecient axial
airflow system and tight
construction results in
extremely low energy usage
and faster dry times.
AXIAL AIRFLOW
Innovative support rollers
improve drum stability,
ensure quiet operation,
and extend the life of the
machine.
ROLLER SUPPORTED TUMBLER
MODEL NO. GAS
Metered (Coin) / Card-ready
DLHF0817G / DLHF0817GDC
MODEL NO. ELECTRIC
Metered (Coin) / Card-ready
DLHF0817E / DLHF0817EDC
MOTOR
1/3 HP
ELECTRICAL RATING
(GAS MODEL)
120 V/60 Hz / 1-phase
ELECTRICAL RATING
(ELECTRIC MODEL)
208 or 240V (heating)/120V (motor
and controls) / 60hz / 1-phase
BREAKER FUSE
REQUIREMENTS (GAS HEAT)
15A
BREAKER FUSE
REQUIREMENTS
(ELECTRIC HEAT)
30A
CYLINDER VOLUME
7.0 cu ft (200 liters)
CYLINDER DIAMETER
26 in (660 mm)
CYLINDER DEPTH
22 in (559 mm)
CAPACITY (DRY WEIGHT)
22 lbs (10 kg)
AIRFLOW
170 cfm
GAS HEATING
18,000 BTU/hr
ELECTRIC HEATING
5.0 kW
GAS CONNECTION
3/8 in MNPT
TUMBLING SPEED
50 rpm
EXHAUST CONNECTION
4 in diameter
APPROX. NET WEIGHT
158 lbs (71.7 kg)
APPROX. SHIPPING WEIGHT
173 lbs (78.5 kg)
CROSSOVER 2.0 Stacked Dryer Specs
Refer installation and servicing to qualified, licensed personnel. Always read Installation
and Operating Manuals and consult local codes before installation. Protect machines with
properly rated circuit breakers ONLY. Warranty void if not properly installed.
Preliminary specifications: Specifications subject to change without notice. Laundrylux
assumes no responsibility for errors or omissions in this information.
Money boxes and coin meter sold separately.
CROSSOVER 2.0 Stacked Dryer Specs at a Glance
DRY CAPACITY
22 lb / 10 kg
CYLINDER VOLUME
7.0 cu ft / 200 liters
A. OVERALL HEIGHT
85 in (2235 mm)
B. HEIGHT TO CENTER OF DOOR N/A
C. HEIGHT TO BOTTOM OF DOOR N/A
D. OVERALL WIDTH
27 in (686 mm)
E. OVERALL DEPTH
29 in (737 mm)
F. DEPTH W/ DOOR OPEN 90
º
N/A
.
.
.
.
.
.
.
.
.
.
.
CROSSOVER 2.0
SPEC SHEET
Crossover 2.0 dryers are
easily programmable with
promotional vend pricing
at specified times and days.
Multiple promotion events
can be programmed at one
time using the built-in real
time clock.
TIME-OF-DAY PROMO PRICING
