Rinnai RPC41NC 4.1Kw Cooling Only Portable Air Conditioner

Operation & Installation Manual - Transcript

• Page 1: Portable Room Air Conditioner Operation amp Installation Manual Models REFRIGERANT R290 RPC41NC
• Page 2 - English - : Rinnai 2 Portable Room AC OIM For continued safety of this appliance it must be installed and maintained in accordance with the manufacturers instructions Before proceeding with the operation of your new Rinnai Portable Room Air Conditioner please read this manual thoroughly and gain a full understanding of the requirements features and operation of your new appliance REFRIGERANT R290
• Page 3 - English - : Rinnai 3 Portable Room AC OIM TABLE OF CONTENTS Safety amp Important Information 4 Specications 10 Introduction 10 Specications  10 AirConditionerBasics 11 Appliance Components  11 Operation 12 Control Panel 12 Basic Operation  12 Basic Operation Control Panel  12 Cool 12 Dry 13 Fan 13 Other Operation 13 Timer 13 RemoteControl 14 Remote Control Overview 14 Basic Operation Remote Controller  14 Button Descriptions amp Operation  14 Remote Control Batteries  15 CareampMaintenance 16 General Maintenance 16 Cleaning the Air Filter 16 Save a Service Call 17 When to Call for Service 17 Installation 18 Location 18 Duct Assembly  18 Window Installations  19 Condensate Drainage  20 Internal Condensate Tank  20 Fixed Condensate Drainage Hose  20 Warranty 21 Contacts 28
• Page 4 - English - : Rinnai 4 Portable Room AC OIM WARNING READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE Alwayscomplywiththefollowingprecautionstoavoiddangeroussituationsandtoensure optimumperformance Failure to carefully read and follow all instructions in this manual can result in equipment malfunctionpropertydamagepersonalinjuryandordeath DANGERIndicatesanimminentlyhazardoussituationwhichifnotavoidedwillresultin personalinjuryordeath WARNINGSIndicatesapotentiallyhazardoussituationwhichifnotavoidedcouldresultin personalinjuryordeath CAUTIONSIndicatesapotentiallyhazardoussituationwhich ifnotavoidedcouldresult inminorormoderateinjuryordamagetotheapplianceItmayalsobeusedtoalertagainst unsafepractices WARNING The appliance is tted with an Australian exible cord and plug intended for connection to an Australian 10 Amp socket outlet It is not suitable for connection in other countries or alternative power supplies Ensure that the voltage and frequency of the power supply correspond to the ratings on the dataplate of the appliance This appliance is not intended for use by persons including children with reduced physical sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety Young children should be supervised to ensure they do not play with the appliance DO NOT allow children or persons with reduced physical sensory or mental capabilities to sleep directly in front of this appliance DO NOT allow children to post articles into the louvres of the appliance DO NOT use power boards or double adaptors with this appliance DO NOT coil or bundle the electric cord to reduce its length as overheating of the cord may occur which could result in a re hazard The exible cord and plug must not be modied If the cord or plug are damaged they must be replaced by Rinnai or a Rinnai appointed service agent DO NOT cover or place articles on or against any parts of this appliance to avoid overheating DO NOT sit on this appliance DO NOT use this appliance in the immediate surroundings of a bath a shower or a swimming pool DO NOT move this appliance whilst it is turned on DO NOT unplug the appliance by pulling on the exible cord DO NOT handle any parts of this appliance including the plug and exible cord with wet or damp hands DO NOT immerse the appliance exible cord and plug in water or any other liquid DO NOT place containers of any liquid or wax on top of this appliance Turn o the appliance and unplug from the power socket outlet when not in use DO NOT use in areas where ammable liquids are stored This appliance is suitable for indoor use only Never dismantle the appliance Tampering with electrical connections and components is highly dangerous and may cause appliance malfunction property damage personal injury andor death SAFETY amp IMPORTANT INFORMATION
• Page 5 - English - : Rinnai 5 Portable Room AC OIM WARNING WARNINGINFORMATIONREGARDINGAPPLIANCESWITHR290REFRIGERANTGAS Thoroughly read all of the warnings Thisappliancecontainsupto270gofR290refrigerantgas This appliance uses R290 refrigerant which is class 3 ammability and must be handled by a refrigeration mechanic with appropriate Australian refrigerant handling licence Theappliancemustbeinstalledusedandstoredinaventilatedareathatisgreaterthan13m When cleaning the appliance do not use any tools other than those recommended by the manufacturing company DO NOT use means to accelerate the defrosting process or to clean other than those recommended by the manufacturer The appliance must be placed in an area without any continuous sources of ignition for example open ames gas or electrical appliances in operation DO NOT puncture and DO NOT burn Refrigerant gases can be odourless If the appliance is installed operated or stored in a nonventilated area the room must be designed to prevent the accumulation of refrigerant leaks resulting in a risk of re or explosion due to ignition of the refrigerant caused by electric heaters stoves or other sources of ignition Compliance with national gas regulations shall be observed Keep ventilation openings clear of obstruction A warning that the appliance shall be stored in a wellventilated area where the room size corresponds to the room area as specied for operation Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certicate from an industryaccredited assessment authority which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specication Servicing shall only be performed as recommended by the equipment manufacturer Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of ammable refrigerants The appliance MUST BE stored in such a way as to prevent mechanical failure Repairs must be performed based on the recommendations from the manufacturing company Maintenance and repairs that require the assistance of other qualied personnel must be performed under the supervision of an individual specied in the use of ammable refrigerants IMPORTANT MANDATORY INSPECTION PRIOR TO INSTALLATION Immediately report any damage or discrepancies to the Supplier of the appliance This appliance was inspected and tested at the time of manufacture and packaging and released for transportation without known damage Upon receipt inspect the exterior for evidence of rough handling in shipment Ensure that the appliance is labelled correctly for the gas and electrical supply andor other services it is intended to be connected to For safety and warranty purposes appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances Installation of damaged or incorrect appliances may contravene local government regulations Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances NOTE A NOTE ON ILLUSTRATIONS The illustrations used in this manual are for explanatory purposes only and the shape of your indoor unit may vary slightly from that which is shown in this manual SAFETY amp IMPORTANT INFORMATION
• Page 6 - English - : Rinnai 6 Portable Room AC OIM WARNING EXPLANATION OF SYMBOLS DISPLAYED ON THE UNIT WARNINGRiskofreammablematerialIftherefrigerantisleakedtogetherwithan externalignitionsourcethereisapossibilityofignition ReadtheOPERATINGINSTRUCTIONScarefullybeforeoperation Service personnel are required to carefully read the OPERATING INSTRUCTIONS and INSTALLATIONMANUALbeforeoperation Further information is available in the OPERATING INSTRUCTIONS INSTALLATION MANUALandthelike 1 Transportofequipmentcontainingammablerefrigerants See transport regulations 2 Markingofequipmentusingsigns See local regulations 3 Disposalofequipmentusingammablerefrigerants See national regulations 4 Storageofequipmentappliances The storage of equipment should be in accordance with the manufacturers instructions 5 Storageofpackedunsoldequipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge The maximum number of pieces of equipment permitted to be stored together will be determined by local regulations General work area All maintenance sta and others working in the local area shall be instructed on the nature of work being carried out Work in conned spaces shall be avoided The area around the workspace shall be sectioned o Ensure that the conditions within the area have been made safe by control of ammable material 6 Informationonservicing 1 Checks to the area Prior to beginning work on systems containing ammable refrigerants safety checks are necessary to ensure that the risk of ignition is minimised For repair to the refrigerating system the following precautions shall be complied with prior to conducting work on the system 2 Work procedure Work shall be undertaken under a controlled procedure so as to minimise the risk of a ammable gas or vapour being present while the work is being performed 3 General work area All maintenance sta and others working in the local area shall be instructed on the nature of work being carried out Work in conned spaces shall be avoided The area around the workspace shall be sectioned o Ensure that the conditions within the area have been made safe by control of ammable material 4 Checking for presence of refrigerant The area shall be checked with an appropriate refrigerant detector prior to and during work to ensure the technician is aware of potentially ammable atmospheres Ensure that the leak detection equipment being used is suitable for use with ammable refrigerants ie nonsparking adequately sealed or intrinsically safe 5 Presence of re extinguisher If any hot work is to be conducted on the refrigeration equipment or any associated parts appropriate re extinguishing equipment shall be available to hand Have a dry powder or CO re extinguisher adjacent to the charging area SAFETY amp IMPORTANT INFORMATION
• Page 7 - English - : Rinnai 7 Portable Room AC OIM 6 No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained ammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of re or explosion All possible ignition sources including cigarette smoking should be kept suciently far away from the site of installation repairing removing and disposal during which ammable refrigerant can possibly be released to the surrounding space Prior to work taking place the area around the equipment is to be surveyed to make sure that there are no ammable hazards or ignition risks No Smoking signs shall be displayed 7 Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work A degree of ventilation shall continue during the period that the work is carried out The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere 8 Checks to the refrigeration equipment Where electrical components are being changed they shall be t for the purpose and to the correct specication At all times the manufacturers maintenance and service guidelines shall be followed If in doubt consult the manufacturers technical department for assistance The following checks shall be applied to installations using ammable refrigerants The charge size is in accordance with the room size within which the refrigerant containing parts are installed The ventilation machinery and outlets are operating adequately and are not obstructed If an indirect refrigerating circuit is being used the secondary circuit shall be checked for the presence of refrigerant Marking to the equipment continues to be visible and legible Markings and signs that are illegible shall be corrected Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components unless the components are constructed of materials which are inherently resistant to being corroded or are suitably protected against being so corroded 9 Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures If a fault exists that could compromise safety then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with If the fault cannot be corrected immediately but it is necessary to continue operation an adequate temporary solution shall be used This shall be reported to the owner of the equipment so all parties are advised Initial safety checks shall include That capacitors are discharged this shall be done in a safe manner to avoid possibility of sparking That there no live electrical components and wiring are exposed while charging recovering or purging the system That there is continuity of earth bonding 7 Repairstosealedcomponents 1 During repairs to sealed components all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers etc If it is absolutely necessary to have an electrical supply to equipment during servicing then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation 2 Particular attention shall be paid to the following to ensure that by working on electrical components the casing is not altered in such a way that the level of protection is aected This shall include damage to cables excessive number of connections terminals not made to original specication damage to seals incorrect tting of glands etc Ensure that apparatus is mounted securely Ensure that seals or sealing materials have not degraded such that they no longer serve the purpose of preventing the ingress of ammable atmospheres Replacement parts shall be in accordance with the manufacturers specications NOTE The use of silicon sealant may inhibit the eectiveness of some types of leak detection equipment Intrinsically safe components do not have to be isolated prior to working on them SAFETY amp IMPORTANT INFORMATION
• Page 8 - English - : Rinnai 8 Portable Room AC OIM 8 Repairtointrinsicallysafecomponents Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use Intrinsically safe components are the only types that can be worked on while live in the presence of a ammable atmosphere The test apparatus shall be at the correct rating Replace components only with parts specied by the manufacturer Other parts may result in the ignition of refrigerant in the atmosphere from a leak 9 Cabling Check that cabling will not be subject to wear corrosion excessive pressure vibration sharp edges or any other adverse environmental eects The check shall also take into account the eects of aging or continual vibration from sources such as compressors or fans 10 Detectionofammablerefrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks A halide torch or any other detector using a naked ame shall not be used 11 Leakdetectionmethods The following leak detection methods are deemed acceptable for systems containing ammable refrigerants Electronic leak detectors shall be used to detect ammable refrigerants but the sensitivity may not be adequate or may need recalibration Detection equipment shall be calibrated in a refrigerantfree area Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed and the appropriate percentage of gas 25 maximum is conrmed Leak detection uids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipework If a leak is suspected all naked ames shall be removed extinguished If a leakage of refrigerant is found which requires brazing all of the refrigerant shall be recovered from the system or isolated by means of shut o valves in a part of the system remote from the leak Oxygen free nitrogen OFN shall then be purged through the system both before and during the brazing process 12 Removalandevacuation When breaking into the refrigerant circuit to make repairs or for any other purpose conventional procedures shall be used However it is important that best practice is followed since ammability is a consideration The following procedure shall be adhered to Remove refrigerant Purge the circuit with inert gas Evacuate Purge again with inert gas Open the circuit by cutting or brazing The refrigerant charge shall be recovered into the correct recovery cylinders The system shall be ushed with OFN to render the unit safe This process may need to be repeated several times Compressed air or oxygen shall not be used for this task Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to ll until the working pressure is achieved then venting to atmosphere and nally pulling down to a vacuum This process shall be repeated until no refrigerant is within the system When the nal OFN charge is used the system shall be vented down to atmospheric pressure to enable work to take place This operation is absolutely vital if brazing operations on the pipework are to take place Ensure that the outlet for the vacuum pump is not close to any ignition sources and there is ventilation available 13 Chargingprocedures In addition to conventional charging procedures the following requirements shall be followed Ensure that contamination of dierent refrigerants does not occur when using charging equipment Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them Cylinders shall be kept upright Ensure that the refrigeration system is earthed prior to charging the system with refrigerant Label the system when charging is complete if not already Extreme care shall be taken not to overll the refrigeration system Prior to recharging the system it shall be pressure tested with OFN The system shall be leak tested on completion of charging but prior to commissioning A follow up leak test shall be carried out prior to leaving the site SAFETY amp IMPORTANT INFORMATION
• Page 9 - English - : Rinnai 9 Portable Room AC OIM 14 Decommissioning Before carrying out this procedure it is essential that the technician is completely familiar with the equipment and all its detail It is recommended good practice that all refrigerants are recovered safely Prior to the task being carried out an oil and refrigerant sample shall be taken in case analysis is required prior to reuse of reclaimed refrigerant It is essential that electrical power is available before the task is commenced a Become familiar with the equipment and its operation b Isolate system electrically c Before attempting the procedure ensure that Mechanical handling equipment is available if required for handling refrigerant cylinders All personal protective equipment is available and being used correctly The recovery process is supervised at all times by a competent person Recovery equipment and cylinders conform to the appropriate standards d Pump down refrigerant system if possible e If a vacuum is not possible make a manifold so that refrigerant can be removed from various parts of the system f Make sure that cylinder is situated on the scales before recovery takes place g Start the recovery machine and operate in accordance with manufacturers instructions h Do not overll cylinders No more than 80 volume liquid charge i Do not exceed the maximum working pressure of the cylinder even temporarily j When the cylinders have been lled correctly and the process completed make sure that the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed o k Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked 15 Labelling Equipment shall be labelled stating that it has been decommissioned and emptied of refrigerant The label shall be dated and signed Ensure that there are labels on the equipment stating the equipment contains ammable refrigerant 16 Recovery When removing refrigerant from a system either for servicing or decommissioning it is recommended good practice that all refrigerants are removed safely When transferring refrigerant into cylinders ensure that only appropriate refrigerant recovery cylinders are employed Ensure that the correct number of cylinders for holding the total system charge is available All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant ie special cylinders for the recovery of refrigerant Cylinders shall be complete with pressure relief valve and associated shuto valves in good working order Empty recovery cylinders are evacuated and if possible cooled before recovery occurs The recovery equipment shall be in good working order with a set of instructions concerning the equipment that is at hand and shall be suitable for the recovery of ammable refrigerants In addition a set of calibrated weighing scales shall be available and in good working order Hoses shall be complete with leakfree disconnect couplings and in good condition Before using the recovery machine check that it is in satisfactory working order has been properly maintained and that any associated electrical components are sealed to prevent ignition in the event of a refrigerant release Consult manufacturer if in doubt The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery cylinder and the relevant Waste Transfer Note arranged Do not mix refrigerants in recovery units and especially not in cylinders If compressors or compressor oils are to be removed ensure that they have been evacuated to an acceptable level to make certain that ammable refrigerant does not remain within the lubricant The evacuation process shall be carried out prior to returning the compressor to the suppliers Only electric heating to the compressor body shall be employed to accelerate this process When oil is drained from a system it shall be carried out safely SAFETY amp IMPORTANT INFORMATION
• Page 10 - English - : Rinnai 10 Portable Room AC OIM INTRODUCTION This portable air conditioner can alter the room temperature and humidity It has multiple functions of cooling dehumidifying drying and fan ventilation and can be moved from room to room and transported from building to building easily The air conditioner can maintain set room indoor air temperatures between 18C and 32C The set room temperature is displayed on the remote control and in the control panel on the unit This does not mean that the air conditioner will necessarily reduce the actual room temperature to the set room temperature Do not place the air conditioner or plastic window slider in direct sunlight Close all curtains in the room being cooled For maximum cooling COOLING MODE set the temperature at 18C and the fan at HIGH After approximately 3 minutes the compressor will turn on and cooled air will come out of the front air outlet Warm air will also come out of the rear outlet and into the exhaust hose In COOLING MODE the air conditioner will not cool unless the set temperature is below the existing room temperature In COOLING MODE once the existing room temperature reaches the set temperature the fan continues operating and the compressor switches on and o to maintain the set temperature within the room For maximum cooling output keep the exhaust hose as short and as straight as possible Minimise bends which can reduce the maximum cooling capacity of the air conditioner Elevate the air conditioner if necessary Make sure the air intake and outlet grills are unobstructed Clean the lters at least once every two weeks SPECIFICATIONS MODEL RPC41NC Power Supply VHz 220240 50 Input Power W 1520 Dimensions Net H x W x D mm 745 x 450 x 396 Dimensions Packing H x W x D 880 x 499 x 459 Weight kg 34 Nominal Cooling Capacity kW 41 Rated Input Current A 85 Rated Input Power kW 165 Refrigerant Type R290 Refrigerant Volume g 270 Sound Power Level dBA 65 SPECIFICATIONS
• Page 11 - English - : Rinnai 11 Portable Room AC OIM APPLIANCE COMPONENTS 1 Control panel 2 Carry handles 3 Swivel casters x4 4 Cool air outlet 5 Remote control receiver 6 Room air intake lter located behind grill 7 Exhaust outlet 8 Lower air intake lter located behind grill 9 Power cable 10 Plug xer 11 Drain outlet 1 12 Drain tray outlet 13 Duct to appliance adaptor 14 Exhaust duct 15 Window exhaust duct window adaptor 16 Window slider kit 17 Remote Control 18 Condensate drain hose 13 14 15 AIR CONDITIONER BASICS
• Page 12 - English - : Rinnai 12 Portable Room AC OIM CONTROL PANEL 1 Timer Button 2 Fan Speed Button 3 Decrease Button 4 Display Screen 5 Increase Button 6 MODE Button 7 ONOFF Button 8 Sleep Indicator 9 Mode Indicator 10 Fan Speed Indicator 11 Timer Indicator IMPORTANT Before operating this appliance ensure that the location installation and condensation requirementshavebeenmetrefertoinstallationinstructionsstartingonpage19fordetails Forthebestcoolingresultsensurethattheltersarecleanreferpage17fordetails BASIC OPERATION When the appliance is plugged and the power point is turned on the appliance is on standby mode There are three basic operational modes available these are COOL chilled air operation FAN fan only operation and DRY chilled and dehumidied operation BASIC OPERATION CONTROL PANEL COOL 1 Press the ONOFF 7 button 2 Press the Mode Selection button 6 until the COOL mode indicator is illuminated 3 Use DecreaseIncreaser buttons 35 to select the desired temperature 18C to 32C 4 Use fan speed button 2 to select the desired fan speed HIGH MED LOW or AUTO 5 Press the ONOFF button 7 to stop operation 1 2 3 54 6 7 OPERATION
• Page 13 - English - : Rinnai 13 Portable Room AC OIM DRY 1 Press the ONOFF 7 button 2 Press the Mode Selection button 6 until the DRY mode indicator is illuminated 3 Press the ONOFF button 7 NOTE FanspeedisonAutowhenDRYmode FAN 1 Press the ONOFF button 7 2 Press the Mode Selection button 6 until the FAN mode indicator is illuminated 3 Use fan speed buttons 2 to select the desired fan speed HIGH MED or LOW The screen display as high speed as medium speed as low speed NOTE AUTOfanspeedisnotavailableonFANmode 4 Press the ONOFF button 7 NOTE Themostrecentbasicoperationalsettingsarestoredintheappliancesmemory If the appliance is not disconnected from the mains power supply then these setting will be availablethenexttimetheapplianceisturnedonviatheONOFFbutton OTHER OPERATION TIMER With the appliance quotOFFquot press the quotTIMERquot button 1 once to active Delay On Timer Press quotTIMERquot button 1 to set the desired time period 124 hours Wait until the timer indicator is light With the appliance quotONquot press the quotTIMERquot button 1 once to active Delay O Timer Press quotTIMERquot button 1 to set the desired time period Wait until the timer indicator is light When a timer is set pressing the quotTIMERquot button 7 will cancel any timer settings NOTE Onlyonemodeofoperationisavailableatanytime OPERATION
• Page 14 - English - : Rinnai 14 Portable Room AC OIM NOTE BeforeproceedingwiththeoperationofyournewRinnaiPortableRoomAirConditionerRemote Controller please read these instructions thoroughly and gain a full understanding of the requirementsfeaturesandoperationofyournewRemoteController REMOTE CONTROL OVERVIEW ONOFF Button Fan Speed Button Increase button Mode button Decrease button Swing button Timer button Sleep button Unit switch button Turbo button Not Applicable COOL symbol SLEEP symbol DRY symbol Timer ON symbol FAN symbol Timer OFF symbol HEAT symbol Not Applicable Fan speed symbol SMART symbol Turbo symbol Not Applicable SWING symbol Child lock symbol BASIC OPERATION REMOTE CONTROLLER The Rinnai Remote Controller allows for convenient operation of the appliance within a 7 metre range NOTE A conrmation beep sounds to conrm that a successfulcontrollerinputhasbeenreceivedbythe appliance BUTTON DESCRIPTIONS amp OPERATION 1 quotONOFFquot Button Press quotONOFFquot button to turn quotONquot or quotOFFquot the Air Conditioner 2 quotFAN SPEEDquot Button Press quotFAN SPEEDquot to set the fan speed LOW MEDIUM HIGH or AUTO 3 quot quot and quot quot Button to adjust temperature or time Press and to regulate the temperature the unit is 1C and set the time the unit is 05h The temperature ranges from 18 to 32 and the time ranges from 05h to 24h 4 MODE selection button Selects the operation mode COOL FAN DRY and SMART Auto NOTE SMARTAuto ThismodeoperatesonFanmodewhentheroomtemperatureisbelow23Candoperateson Coolmodewhentheroomtemperatureisabove23C Display on the control panel REMOTE CONTROL
• Page 15 - English - : Rinnai 15 Portable Room AC OIM 5 quotSWINGquot Button Press quotSWINGquot button to turn quotONquot or quotOFFquot the swing function 6 quotTIMERquot Button Delay on Timer With the appliance quotOFFquot press the quotTIMERquot button twice digits and a blinking and quothquot are shown on the LCD screen Press or to set the desired time period the available time range is in 12 hour increments from 05 to 24 hours Press the quotTIMERquot button again to lock in the setting DelayoTimer With the appliance quotONquot press the quotTIMERquot button once digits and a blinking and quothquot are shown on the LCD screen Press or set the desired time period the available time range is in 12 hour increments from 05 to 24 hours Press the quotTIMERquot button again to lock in the setting When a timer is set pressing the quotTIMERquot button 7 will cancel any timer settings 7 SLEEP Button The SLEEP function allows the set temperature to increase and decrease over an 8 hour period at preset time intervals to maintain your comfort while saving energy a In operating mode press SLEEP to enter the 8hour intelligent sleep mode After 8 hours the air conditioner will be o b the fan speed is low when sleep mode c In sleep mode press SLEEP again to exit the sleep mode NOTE SleepmodeisnotavailableinDRYandFANonlymode button Press this button to switch temperature unit 9 Turbo button Not applicable for this mode 10 Child lock Press or button simultaneously for 3 seconds to active he childlock function REMOTE CONTROL BATTERIES Insert batteries before using the remote control The battery type used is AAA 15 V 1 Remove the battery cover at the rear of the remote control 2 Insert the new batteries and make sure that the and terminals of the batteries are installed correctly 3 Reattach the battery cover NOTE IftheLCDscreenoftheremotecontrolstartstofadeorfailstotransmitreplacethebatteries REMOTE CONTROL
• Page 16 - English - : Rinnai 16 Portable Room AC OIM GENERAL MAINTENANCE It is recommended that after each cooling season the exterior panels and display of the appliance are cleaned with a soft damp cloth Air lters should be checked and cleaned every week during periods of heavy use For intermittent use this can be extended to 2 to 3 weeks CAUTION ALWAYSturnothepowerbeforeyouperformany maintenance DO NOTusesolventsalcoholorharshcleanerson thisapplianceorthelters NEVER use water that is hotter than 40C when you clean the lters It may cause deformation or discolouration CLEANING THE AIR FILTER There are two air lters in this appliance as shown in the gure on the right Before removing the grills ensure the power cord is disconnected from the power supply 1 Remove the grills To remove the Room Air Intake Grill pull down on the top tab and unfasten the grill To remove the Lower Air Intake Grill unfasten the grill 2 Unfasten the lters from each of the grills Clean the lters with a vacuum cleaner or with warm water If dirt is dicult to remove wash the lter in lukewarm water with a mild detergent 3 Ensuring that the lters are dry before replacing then clip the lters back into the grill covers 4 Reattach the grills To reattach the Room Air Intake Grill ensure that all the tabs are properly seated and that the grill is securely clipped back into place To reattach the Lower Air Intake Grill ensure that all the tabs are properly seated and that the grill is securely clipped back into place The power may now be reconnected NOTE Failuretocleantheltersregularlycancauseexcessivecondensationtoformandreducethe applianceseciency IfyouneedreplacementlterspleasecontactRinnai CARE amp MAINTENANCE
• Page 17 - English - : Rinnai 17 Portable Room AC OIM SAVE A SERVICE CALL SYMPTOM POSSIBLE CAUSES POSSIBLE SOLUTIONS Appliance will not operate Not plugged into power Plug into power Power switch OFF Switch power ON Timer Function set Wait or reset timer function Power to appliance but it will not start After switching o the appliance there may be a 3 minute delay before it may be restarted Wait 3 minutes Room temperature is lower than the set temperature Adjust the set temperature to be lower than the room temperature FT appears on the display Drain the water from the drain outlets Error code PF Sensor issue Contact Rinnai Error code FT Safety tank full Follow the instructions for Condensate drainage below The air conditioner does not generate enough cool air The air intake lters are blocked Clean air lters The set temperature is too high Adjust the set temperature to a lower temperature Drafts from open windows and doors Close windows and doors in the area you want to be cooled Other heat sources in the room Remove or turn o heat sources Cooling space too big Operate the appliance within the required cooling capacity Too noisy or vibrating Operating surface not level Move the appliance to level a operating surface Splashing sound High level of condensate being generated This is normal This appliance has a pump that evaporates some condensate through the exhaust duct WHEN TO CALL FOR SERVICE SYMPTOM CAUSE There is a burning smell and a strange sound coming from the unit When operated if a circuit breaker safety ground is thrown or a fuse is blown Turn o the air conditioner and contact Rinnai CARE amp MAINTENANCE
• Page 18 - English - : LOCATION This portable air conditioner must be installed on a at and dry surface A minimum clearance of 500mm from walls or other appliances is required as well as easy access to a power point GPO The air outlets and the ducting system must not be obstructed IMPORTANT Theapplianceisttedwithaexiblecord220 240V50Hz10A Themaximumductextensionis15mintotal Bothfactorsaretobetakenintoaccountwhen determiningthelocationthattheappliancewill beoperatedin DUCT ASSEMBLY 1 Place the Duct to Unit Adaptor 13 over the Exhaust Outlet 7 push it downwards to ensure it engages the Exhaust Outlet tabs 2 Screw one end of the Exhaust Duct 14 into the Duct to Unit Adaptor 13 3 On the other end of the Exhaust Duct 15 x the Window Exhaust Duct Adaptor 16 500mm 500mm 500mm 500mm 13 14 15 INSTALLATION Rinnai 18 Portable Room AC OIM
• Page 19 - English - : WINDOW INSTALLATIONS IMPORTANT DONOToverextendtheexhaustduct Overextensionoftheexhaustductcanleadtokinking Kinkedductingcausesairowrestrictionsandlowerstheeciencyoftheappliance Keepingtheexhaustductasshortaspossibleavoidsthisissue The window kit has been designed to t most standard vertical and horizontal window applications There may be some cases where you may need to modify some aspects of this installation procedure for certain window types Minimum and maximum horizontal vertical window opening dimensions 1 Once a suitable window has been chosen t the Adjustable Slider Kit 16 into the window areas and x the length of the kit using the supplied slide lock nut and bolt Foam seal Insert window exhaust duct adaptor here Slide lock nut and bolt Horizontal Window Installation A Minimum 520mm A Maximum 1000mm Vertical Window Installation Window Installation kit A A INSTALLATION Rinnai 19 Portable Room AC OIM
• Page 20 - English - : CONDENSATE DRAINAGE NOTE CondensateproducedbythisapplianceisNOTpotabledisposeofviawasteoutletorallowto evaporate INTERNAL CONDENSATE TANK During operation the appliance may produce small amounts of condensate The appliance has an inbuilt condensate tank If both drain outlets 11 and 12 are plugged then this tank may reach capacity If this happens the appliance will stop operation and the condensate full code will be shown on the control panel display and the condensate tank will need to be drained before operation can be resumed To do this 1 Place shallow tray such as an oven baking tray or similar with at least a 1 litre volume under Drain Tray Outlet 12 2 Remove the plug from Drain Tray Outlet 12 and drain out the condensate water once the condensate is drained replace the plug the appliance will now be able to then resume operation FIXED CONDENSATE DRAINAGE HOSE As an alternative to using the appliances internal condensate tank a condensate drain hose 18 may de tted Option 1 External Drain Tray with drain outlet 11 plugged t the condensate drain hose 18 to drain outlet 12 and drain the condensate into a drain tray Option 2 Existing Waste Outlet with drain outlets 12 plugged t the condensate drain hose 18 to drain outlet 11 and drain the condensate into a drain tray or waste outlet NOTE ThepointtowhichthecondensateistobedrainedMUST BElowerthanthedrainageoutletpoint Whenusingadraintrayoptionensurethatthecapacityofthetrayisgreaterthanthatofthe condensatebeingproduced Drain cap Drain cap Drain cap Shallow baking tray INSTALLATION Rinnai 20 Portable Room AC OIM
• Page 21 - English - : TERMS OF WARRANTY AUSTRALIA Rinnai Australia Pty Ltd ABN 74 005 138 769 100 Atlantic Drive Keysborough VIC 3173 NOTICE TO CONSUMERS UNDER AUSTRALIAN CONSUMER LAW Our goods and services come with guarantees that cannot be excluded under the Australian Consumer Law For a major failure with a good you are entitled to a replacement or refund and compensation for any other reasonable foreseeable loss or damage If the failure does not amount to a major failure and if the goods fail to be of acceptable quality you are also entitled to have the goods repaired or replaced For a major failure with the service you are entitled to cancel your service contract with us and obtain a refund for the unused portion or to compensation for its reduced value You are also entitled to be compensated for any other reasonably foreseeable loss or damage If the failure does not amount to a major failure you are entitled to have problems with the service rectied in a reasonable time and if this is not done to cancel your contract and obtain a refund for the unused portion of the contract The benets provided by this Warranty are in addition to any other rights and remedies available to a consumer under the Australian Consumer Law and any other law which may apply to the goods and or services 1 DEFINITIONS The terms listed below shall have the following meanings 1 Authorised Service Representative means an independent service contractor authorised by Rinnai or Rinnai service personnel 2 Rinnai means Rinnai Australia Pty Ltd ABN 74 005 138 769 and any related company 3 Certicates of Compliance means certicates issued by licensed personnel including plumbers refrigeration mechanics electricians or other relevant tradespeople to certify that any prescribed works comply with applicable regulatory requirements 4 Certicates of Occupancy means certicates issued by the local government authority or similar organisation which certies that a home can be occupied 5 InstallationSite means the site at which the Product is originally installed 6 NormalBusinessHours means 830am to 500pm Monday to Friday excluding public holidays 7 OperatingInstallation Instructions means the user manual or other documentation which provides detailed instructions on the proper operation and maintenance of the Product 8 Other Applications means any Product used for purposes other than Residential amp Light Commercial Applications Other Applications may include but are not limited to factory ITServer room telephone exchange processing area eg bakery kitchen warehouse swimming pool agricultural facilities such as a nursery Any Product which has been installed for whatever purpose as a retrot component to an existing system will also be classed as being part of an Other Application regardless of the purpose of use of the existing system into which such product has been installed 9 Purchaser means the end user of the Product the person named as owner in the Warranty certicate the holder of the Proof of Purchase or the holder of a property transfer document where the Product is included as part of the chattels 10 Product means the equipment purchased by the Purchaser and described in Section 2 of this document 11 ProofofPurchase means a Tax Invoice or Receipt in respect of the Product In the case of new constructions a Certicate of Occupancy or a Certicate of Compliance that details the date of installation or commissioning will suce 12 Qualied Installer means the qualied installation contractor who is responsible for performing the installation work in the manner prescribed by local and statutory regulations including compliance with any relevant and to Rinnai specications including Australian Standards 13 ResidentialampLightCommercialApplications means any Product for use in residential or light commercial applications where a the Product is solely used for the purpose of human comfort and b the ambient temperature of the space the Product is intended to heat or cool is inuenced solely or primarily by natural exterior weather conditions rather than by manmade or mechanical heat sources Examples of Residential amp Light Commercial Applications include homes oces hotels apartments nursing homes hospitals health care premises shopping centres and retail stores WARRANTY Rinnai 21 Portable Room AC OIM
• Page 22 - English - : 2 TERMS OF WARRANTY 21 Subject to the Terms of Warranty set out in this document eective from the date of purchase by the Purchaser the Product is warranted to be free from defects in materials amp factory workmanship for the period set out in table below Residential and Light Commercial PRODUCT GROUPS PARTS LABOUR Evaporative Coolers amp Ducted Gas Heaters excluding Compact Classic Series 5 Years Extended 4 Years Option 5 Years Extended 4 Years Option Ducted Gas Heaters Compact Classic Series 3 Years 3 Years Refrigerated Airconditioning Products 5 Years 5 Years Ducted Gas Heaters Heat Exchangers and Burners Evaporative Coolers Structural components only 10 Years NA Portable Air conditioning 2 Years NA WiFi Devices 1 Year 1 Year Other Applications All Product Groups 2 Years 1 Year After Market Spare Parts 1 Year NA Extended Warranty Option Up to 4 year extended warranty in addition to the standard warranty period listed above applies on selected products when you opt in to the Rinnai Service Advantage program This program has terms and conditions including the requirement for scheduled servicing of the product by Rinnai To participate in the program you must register your product online at wwwrinnaicomau supportresources warrantyregistration within the rst 12 months of the product being installed 22 Rinnai will determine in its sole discretion which classication the Product ts into and the corresponding Warranty that shall apply 23 An Authorised Service Representative will repair or replace at its option the Product or any part of the Product that its examination shows to be defective The repair or replacement shall be performed during Normal Business Hours by an Authorised Service Representative Repair by persons other than an Authorised Service Representatives may void the Warranty 24 Alternatively to clause 23 above Rinnai can at its discretion elect to pay you an amount equivalent to the cost of repairing or replacing the Product 25 If Rinnai provides you with either the replacement costs or replacement product ownership of the original Product shall immediately transfer to Rinnai 26 Rinnai is responsible for reasonable costs associated with legitimate warranty claims including callout of an Authorised Service Representative to inspect the Product Rinnai is not responsible for a costs for tradespeople engaged by you that are not Rinnai Authorised Service Representatives b any costs including call out costs for a Rinnai Authorised Service Representatives associated with a Product which is determined upon inspection not to be covered by this warranty 27 Rinnai will reimburse any reasonable costs associated with making a legitimate warranty claim against Rinnai which are not otherwise specied above 28 The Warranty of the Product requires that in addition to all other conditions the Purchaser conducts regular andor preventative maintenance as may be specied by the OperatingInstallation Instructions or otherwise directed by Rinnai and required by the level of usage and the usage environment including the use of correct and uncontaminated refrigerants and lubricants Refrigeration plumbing and electrical works must be undertaken by licensed personnel 29 Where a Product or failed component is replaced under warranty the time remaining on the original Product warranty period will continue to apply and the replacement product or part will be subject to the original warranty period only WARRANTY Rinnai 22 Portable Room AC OIM
• Page 23 - English - : 3 CONDITIONS OF WARRANTY 31 The Purchaser may only obtain the benet of the Warranty if the Purchaser a maintains and has the Product serviced in accordance with the instructions set out in the service section of the relevant Service or Owners Manual b complies with clause 7 Purchasers Responsibilities on page 24 c noties Rinnai within 30 days of a defect occurring or in the case of a latent defect becoming apparent that a claim is being made under this Warranty and d provides in support of the claim made under this Warranty a Proof of Purchase 32 This document and any statutory consumer guarantees represents the only Warranty given by Rinnai in respect of the Product No other person or organisation is authorised to oer any alternative warranty on behalf of Rinnai 33 If the date of purchase cannot be established to Rinnais satisfaction the date shall be deemed to be 2 months after the date of manufacture or the date of sale by Rinnai whichever is the latter 34 This warranty applies to Products which are manufactured on or after the date of publication of this warranty but before the next date of publication of this warranty 4 EXCLUSIONS 41 This Warranty does NOT cover a damage problems or failure resulting from improper operation andor inadequate maintenance by the Purchaser refer Purchasers Responsibilities section below b damage problems or failure resulting from improper or faulty installation The Product must be installed by a Qualied Installer in accordance with applicable regulations Where applicable Certicates of Compliance must be obtained by the purchaser from the Qualied Installer and presented to the Authorised Service Representative c damage problems or failure caused by factors external to the Product including but not limited to faulty or poor external electrical wiring incorrect or faulty power supply voltage uctuations over voltage transients or electromagnetic interference inadequate or faulty gas drainage services or water services including water pressure and nonpotable water d damage problems or failure caused by acts of God re wind lightning ood storm hail storm fallout vandalism earthquake war civil insurrection misuse abuse negligence accident pests animals pets vermin insects spidersbugs or entry of foreign objects or matter into the Product such as dirt debris soot or moisture e damage problems or failure caused by environmental conditions including but not limited to excessive moisture salt or other corrosive substances or atmospheric conditions f Product which has been installed in a portable or mobile building structure or application including but not limited to a caravan boat or trailer g Product which has been reinstalled at a location other than the original site h any consumable item supplied with the Product including but not limited to an air lter battery fan belt igniter or cooler pad i installation of thirdparty components that may be attached to the Product These include but are not limited to control wiring ducting return air lters grille register diuser zone motors controls thermostats pipe work and fabricated or added components These items remain solely the responsibility of the Qualied Installer j installations where electricselectronics may be subjected to moisturechemicals eg swimming pools or nurseries k any repair which is needed as a result of an accident misuse abuse or negligence l Product that is utilised in an environment indoor and outdoor outside its specied operating range and m fair wear and tear to the Product n Onsite labour warranty on portable nonxed installation Products In respect of such Products the Purchaser must return the Product to the supplier for repair or replacement WARRANTY Rinnai 23 Portable Room AC OIM
• Page 24 - English - : 5 LIMITATIONS 51 Third parties are often involved in providing advice to consumers about the climate control solutions best suited to the consumers needs Any advice or recommendations given by such parties including advice about Product tness for purpose and overall system design sizing and application are not the responsibility of Rinnai This includes but is not limited to the heat load calculations airow and system balancing 52 This Warranty does not apply to any Product installed at an Installation Site which is outside Australia 53 Except where inconsistent with the purchasers statutory rights and the rights given by this Warranty all liabilities of Rinnai for any direct special indirect or consequential loss or damage any damage or expense for personal injury or any loss or destruction of property arising directly or indirectly from the use or inability to use the Product or any of its parts andor servicing the Product are expressly excluded 6 TRAVEL TRANSPORT amp ACCESS COSTS 61 The Purchaser must pay freight charges intransit insurance expenses and travelling costs for repairs replacements under this Warranty that are required to be performed 50km from the nearest Rinnai branch or Authorised Service Representative 62 Subject to clause 63 Rinnai will pay freight charges intransit insurance expenses and travelling costs for repairsreplacements that are required to be performed less than 50km from the nearest Rinnai branch or Authorised Service Representative subject to the following a Rinnai will arrange for such repairsreplacements and make any payment directly to the third party to provide the freight intransit insurance or travel services or b if Rinnai considers appropriate it will authorise the Purchaser in writing to pay for the relevant freight charges intransit insurance expenses or travelling costs and then upon provision by the Purchaser to Rinnai of a tax invoice showing those costs have been incurred reimburse the Purchaser for such costs which are within the terms of the authorisation If the Purchaser pays for the relevant freight charges intransit insurance expenses or travelling costs without written authorisation from Rinnai Rinnai will not reimburse the Purchaser for such costs 63 The Purchaser must pay all costs and expenses in respect of a any service call out fee if the Product is not accessible for service b making the Product accessible for service for example restricted access or working at heights or the labour cost for an additional person due to OHS requirements c providing a safe working environment for installation service maintenance or repair of the Product d any surcharge applicable in respect of supplying replacement parts outside Normal Business Hours and e any other costs and expenses in relation to claiming the Warranty that is not covered by clause 62 7 PURCHASERS RESPONSIBILITIES 71 The Purchaser must operate and maintain the Product in accordance with the Operating Instructions and service maintenance schedule including conducting an appropriate number of services to the unit during the Warranty period based on usage and the usage environment including but not limited to a regularly cleaning the air lters and replacing them where necessary b replacing expired batteries or other consumables as required c ensuring that the condensate drain is kept clean and clear of obstructions HOW TO MAKE A WARRANTY CLAIM If you wish to make a warranty claim in respect of any Portable Product please return it to the place of purchase or if that is not possible contact Rinnai to enquire about alternative arrangements If you wish to make a warranty claim in respect of any xed Product please contact Rinnai on the details set out below to make arrangements for an Authorised Service Representative to inspect the product As per clause 26 of the Terms and Conditions of Warranty purchasers are responsible for the costs of any repair andor call out fee where on inspection the alleged defect is found by Rinnais Authorised Service Representative not to be covered by this warranty or any statutory consumer guarantee applicable to the Product The Terms and Conditions of Warranty contain important information about your rights and obligations under this warranty Please read them fully and carefully before making a claim WARRANTY Rinnai 24 Portable Room AC OIM
• Page 25: NOTES Rinnai 25 Portable Room AC OIM
• Page 26: NOTES Rinnai 26 Portable Room AC OIM
• Page 27: NOTES Rinnai 27 Portable Room AC OIM
• Page 28 - English - : Rinnai 28 Portable Room AC NC Series OIM Issue 1 August 2020 CONTACTS Rinnai Australia Pty Ltd ABN 74 005 138 769 AU45204 100 Atlantic Drive Keysborough Victoria 3173 PO Box 460 Braeside Victoria 3195 Tel 03 9271 6625 Fax 03 9271 6622 National Help Line Tel 1300 555 545 Fax 1300 555 655 Monday to Friday 800 am to 500 pm EST Cost of a local call higher from mobile or public phones For further information visit wwwrinnaicomau or email enquiryrinnaicomau Rinnai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your Rinnai appliance If your appliance requires service please call our National Help Line Rinnai recommends that this appliance be serviced every 2 years With our policy of continuous improvement we reserve the right to change or discontinue at any time specifications or designs without notice
