DEC 2015
USER MANUAL
POLO ‘C’ SERIES CONVECTION
PANEL HEATERS
The POLO “C” Series range of convection panel heaters consists of eight models – four with a digital timer
and four without a digital timer:
POLO Model CT
(with digital timer)
POLO Model C
(without digital
timer)
Watts Amps Length
(mm)
Height
(mm)
Thickness
(mm)
Weight
(kg –
approx)
CT100 C100 1000 4.2 545 452 75 6.5
CT150 C150 1500 6.3 700 452 75 8
CT200 C200 2000 8.3 890 452 75 10
CT240 C240 2400 10.0 1035 452 75 12
IMPORTANT SAFETY ADVICE
(1) The wall bracket supplied with the heater must be used to attach the heater to a wall.
(2) To locate the heater in a bathroom (ie containing a bath or shower) the heater must be located so
that the controls cannot be operated by a person in the bath or shower. The heater must be located
at least 600mm from a shower screen or bath surround. If in doubt, the services of a qualied
electrician or licensed electrical contractor must be used to determine a suitable location in a
bathroom.
(3) Do not use outdoors – indoor use only.
(4) Do not locate the heater immediately below a xed socket outlet.
(5) The heater may be installed in front of a xed socket outlet concealing the power lead and plug.
(6) Do not cover the heater or place material or garments on the heater.
(7) Do not obstruct the front nned air outlet of the heater or obstruct the air circulation around the
heater by curtains or pushing furniture up against it. This could cause overheating and a re risk.
(8) The heater carries the warning “Do not cover” indicating that in order to avoid overheating, do
not cover the heater.
(9) If used with the included castors, do not use this heater in the immediate surroundings of a bath, a
shower or a swimming pool.
(10) If the supply cord is damaged, it MUST be replaced by the manufacturer’s service agent or
similarly qualied person to avoid a hazard.
(11) When using models CT240/C240 – 2400 watts, do not share the power supply with other
appliances. Do not connect to multiple power outlets on extension leads.
(12) If any abnormal noise ever comes from the heater or control panel, switch off and contact Polo
immediately for advice.
(13) WARNING – THE SURFACES OF THIS HEATER CAN BE HOT ESPECIALLY THE FRONT
GRILL AND THE TOP OF THE HEATER
Momentarily contact with any part of the heater should not cause injury.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they don’t play with the appliance
Page 1
