OPERATOR’S MANUAL
80V BRUSHLESS HEDGE
TRIMMER
267-1543
HTB406
To Reduce The Risk Of Injury, User Must Read
CAUTION
And Understand Operator’s Manual. Save These Instructions For
Future Reference.
2200094ME
TABLE OF CONTENTS
Safety Symbols ........................................................................................................... Page 2
Safety Instructions ...................................................................................................... Page 3
Overview ..................................................................................................................... Page 7
Assembly .................................................................................................................... Page 8
Operation .................................................................................................................... Page 9
Maintenance / Troubleshooting ................................................................................. Page 10
Exploded view ........................................................................................................... Page 11
Notes ........................................................................................................................ Page 12
Warranty ...................................................................................................................Page 14
Page 2
SAFETY SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better
and safer.
Symbol Name Designation / Explanation
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
Wet Conditions Alert Do not expose to rain or use in damp locations.
Read The Operator’s Manual
To reduce the risk of injury user must read and
understand operator’s manual before using
this product.
Safety Alert Precautions that involve your safety.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Eye Protection
Always wear eye protection with side shields
marked to comply with ANSI Z87.1 when
operating this equipment.
Ricochet
Thrown objects can ricochet and result in
personal injury or property damage.
Sharp Blade Keep hands away from sharp, moving blades.
Gloves Wear non-slip, heavy duty gloves.
Keep Bystanders Away Keep all bystanders at least 50 ft. (15m) away.
Impeller Blades
Rotating impeller blades can cause severe
injury.
Page 3
SAFETY INSTRUCTIONS
The purpose of safety symbols is to attract our attention to possible dangers. The safety
symbols, and the explanations with them, deserve your careful attention and understanding.
The symbol warnings do not by themselves eliminate any danger. The instructions and
warnings they give are no substitutes for propper accident prevention measures.
Failure to obey this safety warning CAN result in death or serious
injury to yourself or to others. Always follow the safety precautions to reduce the risk of
re, electric shock and personal injury.
WARNING
Failure to obey this safety warning MAY result in personal injury
to yourself or others or property damage. Always follow the safety precautions to
reduce the risk of re, electric shock and personal injury.
CAUTION
Failure to obey this warning WILL result in death or serious injury
to yourself or to others. Always follow the safety precautions to reduce the risk of fire,
electric shock and personal injury.
DANGER
Be sure to read and understand all safety insructions in this
manual, including all safety alert symbols such as “DANGER”, “WARNING” and
“CAUTION”, before using this power tool. Failure to follow all instructions listed below
may result in electric shock, re and/or serious personal injury.
WARNING
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May be used
in conjuntion with other symbols or pictographs
Page 4
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS
BEFORE USING (THIS POWER
TOOL)
WARNING
Read and
understand all instructions before using
this product. Failure to follow all
instructions listed below may result in
electric shock, re, and/or serious
personal injury. When using an electrical
appliance, basic precautions should
always be followed, including the
following:
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
• Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
ELECTRICAL SAFETY
• A battery-operated tool with integral
batteries or a separate battery pack must
be recharged only with the specified
charger for the battery. A charger that may
be suitable for one type of battery may
create a risk of re when used with another
battery.
• Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
• Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
• Use a battery-operated tool only with
specified battery pack. Use of any other
batteries may create a risk of re.
• If operating a power tool in a damp location
is unavoidable, use a residual current
device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment
of inattention while operating power tools
may result in serious personal injury.
• Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for
appropriate conditions will reduce personal
injuries.
• Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on
the switch or energising power tools that
have the switch on invites accidents.
• Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part
of the power tool may result in personal
injury.
• Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
• Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught
in moving parts.
• If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of these devices can reduce
dust-related hazards.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the
correct power tool for your application. The
correct power tool will do the job better and
safer at the rate for which it was designed.
• Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
• Disconnect the battery pack from the
Page 5
power tool before making any adjustments,
changing accessories, or storing power
tools. Such preventive safety measures
reduce the risk of starting the power tool
accidentally.
• Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
• Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
• Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
• Use the power tool, accessories and
tool bits etc., in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
BATTERY TOOL USE AND CARE
• Ensure the switch is in the off position
before inserting battery pack. Inserting the
battery pack into power tools that have the
switch on invites accidents.
• Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of re when used with another
battery pack.
• Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury
and re.
• When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws, or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a re.
• Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
SAFETY INSTRUCTIONS
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
• Use only Masterforce Batteries: BAB726
and other BAB series.
• Use only Masterforce Charger: CAB809
and other CAB series.
SERVICE
• Have your power tool serviced by a
qualied repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
HEDGE TRIMMER SAFETY
WARNINGS
• Use both hands when operating the hedge
trimmer. Using one hand could cause loss
of control and result in serious personal
injury.
• Keep all parts of the body away from the
cutter blade. Do not remove cut material
or hold material to be cut when blades are
moving. Make sure the switch is off when
clearing jammed material. Blades coast
after turn off. A moment of inattention while
operating the hedge trimmer may result in
serious personal injury.
• Carry the hedge trimmer by the handle with
the cutter blade stopped. Proper handling
of the hedge trimmer will reduce possible
personal injury from the cutter blades.
• Hold the power tool by insulated gripping
surfaces only, because the cutter blade
may contact hidden wiring. Cutter blades
contacting a “live” wire may make exposed
metal parts of the power tool “live” and
could give the operator an electric shock.
• DANGER – Keep hands away from blade.
Contact with blade will result in serious
personal injury.
• Keep cable away from cutting area. During
operation the cable may be hidden in
shrubs and can be accidentally cut by the
blade.
• Always store idle power tools indoors.
When not in use, power tools should be
stored indoors in a dry place, out of reach
of children.
Page 6
WARNING
Only use with
handle and guard properly assembled to
hedge trimmer. The use of the hedge
trimmer without the proper guard or
handle provided may result in serious
personal injury.
PROPOSITION 65
This product contains a chemical known to
the state of California to cause cancer, birth
defects or other reproductive harm. Some dust
created by power sanding, sawing, grinding,
drilling, and other construction activities
contains chemicals known to cause cancer,
birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement
and other masonry products;
• Arsenic and chromium from chemically
treated lumber.
Your risk of exposure to these chemicals
varies depending on how often you do this
type of work. To reduce your exposure to these
chemicals, work in a well-ventilated area, and
work with approved safety equipment, such as
dust masks that are specially designed to lter
out microscopic particles.
CHILD SAFETY
Tragic accidents can occur if the operator is
not aware of the presence of children.
• Keep children out of the working
area and under the watchful care of a
responsible adult.
• Do not allow children under the age
of 14 to operate this blower. Children
who are 14 years of age and older must
read and understand the operating
instructions and safety rules in this
manual and must be trained and
supervised by a parent.
• Stay alert, and turn the blower off if a
child or any other person enters the
working area.
• Use extreme care when approaching
blind corners, doorways, shrubs, trees,
or other objects that may obscure your
SAFETY INSTRUCTIONS
view of a child who may run into the
path of the blower.
SAVE THESE INSTRUCTIONS
Page 7
OVERVIEW
SPECIFICATIONS
Type Cordless, battery operated
Motor 80V Brushless
Blade Length 24" (61 cm)
Cutting Capacity 3/4" (18 mm)
No Load Speed 3400 (±10%) SPM
Weight (Without Battery) 8.37 lbs.
Battery pack
SPECIFICATIONS
Guard
Auxiliary handle
Battery
release
button
Blade
Rotation lever
Trigger
Safety lock
button
Page 8
ASSEMBLY
UNPACKING
This product requires assembly.
• Carefully remove the product and any
accessories from the box. Make sure that
all items listed in the package contents
section are included.
• Inspect the product carefully to make sure
no breakage or damage occurred during
shipping.
• Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the product.
• If any parts are damaged or missing, please
call 1-844-MSTR4CE (844-678-7423) for
assistance.
THE BATTERY PACK
WARNING
Follow these instruc-
tions in order to avoid injury and to reduce the
risk of electric shock or re:
• Replace the battery pack or the charger
immediately if the battery case or charger
cord is damaged.
• Verify that the switch is in the OFF position
before inserting or removing the battery
pack.
• Verify that the battery pack is removed
and the switch is in the OFF position
before inspecting, adjusting, or performing
maintenance on any part of the blower.
To install the battery pack
1. Align the tongue of the battery pack with
the cavity in the handle housing.
2. Insert the battery into the battery opening
until the battery release button locks into
place.
3. Grasp the rear handle rmly.
4. Push the battery pack into the handle until
both sides lock. The latch button will click
when locked into place.
5. Do not use force when inserting the battery
pack. It should slide into place and click.
To remove the battery pack
1. Press and hold the battery release button
with rm grip.
2. Grasp the rear handle rmly. Pull the
battery pack out of the handle.
FIG. 1
Battery pack
Battery release button
Rear handle
Page 9
START / STOP THE BLOWER
To start
1. Press and hold the safety lock button.
2. Squeeze the trigger to start the machine.
3. Release the trigger to decrease the speed.
4. Release the lock-out button. The hedge
trimmer will stay on as long as the trigger
switch is engaged.
To stop
1. Release the trigger to stop the machine.
IMPORTANT: If the hedge trimmer is
accidentally dropped, the hedge trimmer will
turn OFF and the blade will coast to a stop
after several seconds. The hedge trimmer will
then be locked OFF again.
FIG. 5
Safety lock button
Auxiliary
handle
Trigger
ROTATE THE REAR HANDLE
1. Place the hedge trimmer on a flat and even
surface.
2. Make sure that you released the trigger.
3. Pull the rotation lever and begin turning the
rear handle. Release the rotation lever and
turn the handle 90 degrees to either side
until it clicks into place and the lever locks
in.
4. To turn the handle back to center, pull the
rotation lever again, turn the handle slightly,
release the rotation lever and continue
turning the handle until it locks into place.
FIG. 6
Rotation lever
OPERATION TIPS
• Do not push the machine through heavy
shrubbery. This can cause the blade
blockage. If the blades blocks,
1. stop the machine.
2. remove the battery pack.
3. remove the blockage.
• Do not try to cut too large stems or twigs.
• Wear the gloves when you cut.
• Cut the new growth with a wide sweeping
action so that the stems are put directly into
the blade.
• You can use a string to adjust the height of
the hedge.
• Stretch a piece of string along the hedge
at this height.
• Cut the hedge immediately above this
string.
• Cut the side of a hedge until it will be
narrower at the top. More of the hedge
will come into view in that way.
OPERATION
Page 10
MAINTENANCE
CLEAN THE MACHINE
• Clear the unwanted material out of the air
vent with a vacuum cleaner.
• Do not spray the air vent or put the air vent
in solvents.
• Clean the housing and the plastic
components with a moist and soft cloth.
CAUTION
Do not let brake
uids, gasoline, petroleum-based
materials touch the plastic parts.
Chemicals can cause damage to the
plastic, and make the plastic
unserviceable.
CAUTION
Do not use strong
solvents or detergents on the plastic
housing or components.
CAUTION
Remove the
battery pack from the machine before
maintenance.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Motor fails to start
when trigger switch is
depressed.
Battery is not secure. To secure the battery pack, make sure the
latches on the top of the battery pack snap into
place.
Battery is not charged. Charge the battery pack according to the
instructions included in the battery charger
manual.
Motor runs, but cutting
blades do not move.
Hedger damaged.
Do not use hedge
trimmer.
Call for technical service.
Hedge trimmer
smokes during
operation.
Hedger damaged.
Do not use hedge
trimmer.
Call for technical service.
Motor hums, blades
do not move.
Debris or other may
be jamming the
blades.
Remove battery, clear debris blockage from
blades.
LUBRICATE THE BLADE
To increase the efciency and life of the
blades, lubricate them carefully after each
work session:
• Put the machine on a at and smooth surface.
• Use a soft cloth to clean the blades and a
brush to remove more dirt.
• Use a light layer of oil to lubricate the
blades along the top edge of the blade.
STORE THE MACHINE
• Clean the machine before storage.
• Make sure that the motor is not hot when
you store the machine.
• Make sure that the machine does not have
loose or damaged parts. If it is necessary,
do these steps/instructions:
1. Replace the damaged parts.
2. Tighten the bolts.
3. Speak to a person of an approved
service center.
• Store the machine in a dry area.
• Make sure that children cannot come near
the machine.
EXPLODED VIEW
No. Part No. Qty Description
1 RB341011652 1 Auxiliary handle assembly
2 RB34110897V 1 Guard
Page 11
Page 12
NOTES
Page 13
NOTES
Page 14
SAVE YOUR RECEIPTS
THIS WARRANTY IS VOID WITHOUT THEM
80V BRUSHLESS HEDGE TRIMMER
WARRANTY
4-YEAR LIMITED WARRANTY
This MASTERFORCE™ brand power tool carries our famous No Hassle 4-Year Limited
Warranty to the original purchaser. If, during normal use, this MASTERFORCE™ power
tool breaks or fails due to a defect in material or workmanship within four (4) years from
the date of original purchase, simply bring the tool with the original sales receipt back
to your nearest MENARDS
®
retail store. At its discretion, MASTERFORCE™ agrees
to have the tool or any defective part(s) repaired or replaced with the same or similar
MAST
ERFORCE™ product or part free of charge, within the stated warranty period,
when returned by the original purchaser with original sales receipt. Not withstanding the
foregoing, this limited warranty does not cover any damage that has resulted from abuse
or misuse of the Merchandise. This warranty: (1) excludes expendable parts including
but not limited to blades, brushes, belts, bits, light bulbs, and/or batteries; (2) shall be
void if this tool is used for commercial and/or rental purposes; and (3) does not cover any
losses, injuries to persons/proper
ty or costs. This warranty does give you specific legal
rights and you may have other rights, which vary from state to state. Be careful, tools
are dangerous if improperly used or maintained. Seller’s employees are not qualified
to advise you on the use of this merchandise. Any oral representation(s) made will not
be binding on seller or its employees. The rights under this limited warranty are to the
original purchaser of the merchandise and may not be transferred to any subsequent
owner. This limited warranty is in lieu of all warranties, e
xpressed or implied including
warranties or merchantability and fitness for a particular purpose. Seller shall not be
liable for any special, incidental, or consequential damages. The sole exclusive remedy
against the seller will be for the replacement of any defects as provided herein, as long
as the seller is willing or able to replace this product or is willing to refund the purchase
price as provided above. For insurance purposes seller is not allowed to demonstrate
any of these power tools for you.
For questions / comments, technical assistance or repair parts -
Please
call toll free at: 1-844-678-7423 (M-F 8am - 6pm)
© 2019 Menard, Inc., Eau Claire, WI 54703 12/2019
