267-1530
OPERATOR’S MANUAL
CAUTION:
To Reduce the Risk of Injury, User Must
Read and Understand the Operator’s Manual. Save These
Instructions For Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374 (M-F 8:30am-5:00pm EST).
Cordless Hedge Trimmer
TABLE OF CONTENTS
Safety Symbols ......................................................... Page 2
Safety Instructions ...................................................... Page 3
Overview/Specifications ................................................. Page 8
Assembly ............................................................. Page 9
Operation ............................................................ Page 10
Maintenance .......................................................... Page 13
Troubleshooting ....................................................... Page 14
Warranty .............................................................Page 18
Page 2
SAFETY SYMBOLS
Some of these following symbols may be used on this tool. Please study them and learn
their meaning. Proper interpretation of these symbols will allow you to operate the tool bet-
ter and more safely.
Symbol
Name
Designation / Explanation
V Volts Voltage
A Amps Current
n
0
No-load Speed Rotational speed at no load
SPM Strokes per Minute Stroke speed, at no load
�
or d.c.
Direct Current Type of characteristic of current
WARNING:
To ensure safety and reliability, all repairs should be performed by a
qualied service technician.
Page 3
SAFETY INSTRUCTIONS
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols, and the explanations with them, deserve your careful attention and understand-
ing. The symbol warnings do not, by themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident prevention measures.
WARNING:
Be sure to read and understand all safety instructions in this manual,
including all safety alert symbols such as “DANGER”, “WARNING” and “CAUTION” before
using this tool. Failure to follow all instructions listed below may result in electric shock,
re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
DANGER:
Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING:
Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation, which, if not avoided, could
result in minor or moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
SAVE THESE INSTRUCTIONS!
Page 4
SAFETY INSTRUCTIONS
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING:
Read all safety
warnings, instructions, illustrations and
specications provided with this power
tool. Failure to follow all instructions listed
below may result in electric shock, fire and/
or serious injury.
SAVE ALL WARNINGS AND
INSTRUCTIONS FOR FUTURE
REFERENCE.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
WORK AREA SAFETY
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
3. Keep children and bystanders away
while operating a power tool. Distractions
can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the
outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of
electric shock.
2. Avoid body contact with earthed
or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
4. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
5. When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
6. If operating a power tool in a damp
location is unavoidable, use a ground fault
circuit interrupter (GFCI) protected supply.
Use of an GFCI reduces the risk of electric
shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing
and use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the inuence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
2. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-skid
safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have
the switch on invites accidents.
4. Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
Page 5
SAFETY INSTRUCTIONS
5. Do not overreach. Keep proper footing
and balance at all times. This enables better
control of the power tool in unexpected
situations.
6. Dress properly. Do not wear loose
clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught
in moving parts.
7. If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of dust
collection can reduce dust-related hazards.
8. Do not let familiarity gained from
frequent use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the
correct power tool for your application. The
correct power tool will do the job better and
safer at the rate for which it was designed.
2. Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
3. Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
4. Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
5. Maintain power tools and accessories.
Check for misalignment or binding of
moving parts, breakage of parts and
any other condition that may affect the
power tool’s operation. If damaged, have
the power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
7. Use the power tool, accessories
and tool bits etc. in accordance with
these instructions, taking into account
the working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
8. Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do
not allow for safe handling and control of the
tool in unexpected situations.
BATTERY TOOL USE AND CARE
1. Recharge only with the charger
specied by the manufacturer. A charger
that is suitable for one type of battery pack
may create a risk of fire when used with
another battery pack.
2. Use power tools only with specically
designated battery packs. Use of any other
battery packs may create a risk of injury and
fire.
3. When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects, that can make
a connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
4. Under abusive conditions, liquid may
be ejected from the battery; avoid contact.
If contact accidentally occurs, ush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
5. Do not use a battery pack or tool that
is damaged or modied. Damaged or
modified batteries may exhibit unpredictable
behaviour resulting in fire, explosion or risk
Page 6
SAFETY INSTRUCTIONS
of injury.
6. Do not expose a battery pack or tool
to re or excessive temperature. Exposure
to fire or temperature above 100 °C (212 °F)
may cause explosion.
7. Follow all charging instructions and
do not charge the battery pack or tool
outside the temperature range specied
in the instructions. Charging improperly or
at temperatures outside the specified range
may damage the battery and increase the
risk of fire.
SERVICE
1. Have your power tool serviced by a
qualied repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
2. Never service damaged battery packs.
Service of battery packs should only
be performed by the manufacturer or
authorized service providers.
HEDGE TRIMMER SAFETY
WARNINGS
1. Keep all parts of the body away from
the blade. Do not remove cut material or
hold material to be cut when blades are
moving. Blades continue to move after the
switch is turned off. A moment of inattention
while operating the hedge trimmer may
result in serious personal injury.
2. Carry the hedge trimmer by the handle
with the blade stopped and taking care
not to operate any power switch. Proper
carrying of the hedge trimmer will decrease
the risk of inadvertent starting and resultant
personal injury from the blades.
3. When transporting or storing the hedge
trimmer, always t the blade cover. Proper
handling of the hedge trimmer will decrease
the risk of personal injury from the blades.
4. When clearing jammed material or
servicing the unit, make sure all power
switches are off and the power cord is
disconnected. Unexpected actuation of
the hedge trimmer while clearing jammed
material or servicing may result in serious
personal injury.
5. Hold the hedge trimmer by insulated
gripping surfaces only, because the blade
may contact hidden wiring or its own cord.
Blades contacting a “live” wire may make
exposed metal parts of the hedge trimmer
“live” and could give the operator an electric
shock.
6. Keep all power cords and cables away
from cutting area. Power cords or cables
may be hidden in hedges or bushes and can
be accidentally cut by the blade.
7. Do not use the hedge trimmer in bad
weather conditions, especially when there
is a risk of lightning. This decreases the risk
of being struck by lightning.
IMPORTANT SAFETY INSTRUC-
TIONS
1. To reduce the risk of electric shock or
damage to the chargers and batteries, use
only with the MASTERFORCE® battery
packs and chargers listed.
Battery pack Charger
252-8029 (1.5Ah)
252-8030 (2.5Ah)
252-8031 (2.0Ah)
252-8034 (4.0Ah)
252-8035 (5.0Ah)
252-8025,
252-8036,
252-8037,
252-8044
2. Do not grasp the exposed cutting blades
or cutting edges when picking up or holding
the hedge trimmer.
3. Do not use on a ladder, rooftop, tree, or
other unstable support. Stable footing on a
solid surface enables better control of the
hedge trimmer in unexpected situations.
4. Never allow children to operate the
hedge trimmer.
5. Trim only in daylight or in good artificial
light.
Page 7
SAFETY INSTRUCTIONS
6. Do not wash with a hose; avoid getting
water in motor and electrical connections.
7. Do not incinerate the appliance even if
it is severely damaged. The batteries can
explode in a fire.
DANGER:
People with electronic
devices, such as pacemakers, should
consult their physician(s) before using this
product. Operation of electrical equipment
in close proximity to a heart pacemaker
could cause interference or failure of the
pacemaker.
WARNING:
• Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals
known to the state of California to cause
cancer, birth defects, or other reproductive
harm. Some examples of these chemicals
are:
–Lead from lead-based paints
–Crystalline silica from bricks, cement, and
other masonry products
–Arsenic and chromium from chemically-
treated lumber
• Your risk from these exposures varies,
depending upon how often you do this type
of work. To reduce your exposure to these
chemicals:
–Work in a well-ventilated area.
–Work with approved safety equipment,
such as dust masks that are specially
designed to lter out microscopic particles.
–Avoid prolonged contact with dust from
power sanding, sawing, grinding, drilling,
and other construction activities. Wear
protective clothing and wash exposed
areas with soap and water. Allowing dust
to get into your mouth or eyes or to lie
on the skin may promote absorption of
harmful chemicals.
SAVE THESE INSTRUCTIONS!
Page 8
OVERVIEW
SPECIFICATIONS
Rated Voltage 20 V d.c.
No-load Speed 2600 SPM
Cutting Blade Length 22 in.
Cutting Width 9/16 in.
Blades
Blade Cover
Rear Switch Trigger
Guard
Front Switch
Trigger
Lock-off Button
Page 9
WARNING:
If any part is broken or
missing, DO NOT attach the battery pack
or operate the tool until the broken or
missing part is replaced. Failure to do so
could result in possible serious injury.
WARNING:
Do not attempt to
modify this tool or create accessories not
recommended for use with this tool. Any
such alteration or modication is misuse
and could result in a hazardous condition
leading to possible serious injury.
WARNING:
Your tool should never
be connected to the battery pack when you
are assembling parts, making adjustments,
installing or removing blades, cleaning, or
when it is not in use. Disconnecting the
tool will prevent accidental starting, which
could cause serious personal injury.
ASSEMBLY
CONTENTS
Cordless hedge trimmer and instruction
manual.
UNPACKING
1. Carefully remove the tool and any
accessories from the carton. Make sure
that all items listed in the packing list are
included.
2. Inspect the tool carefully to make sure
that no breakage or damage occurred
during shipping.
3. Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the tool.
Page 10
TO ATTACH/DETACH BATTERY
PACK (FIG. 1)
TO ATTACH BATTERY PACK
1. Align the raised rib on the battery pack
with the grooves on the bottom of the
tool, then slide the battery pack onto the
tool.
2. Ensure that the battery-release button
on the battery pack snap into place and
the battery pack is secured to the tool
before beginning operation.
FIG. 1
Battery-release
Button
Attach
Detach
NOTICE: When placing the battery pack
on the tool, be sure that the raised rib on
the battery pack aligns with the groove on
the tool and the latches snap into place
properly. Improper assembly of the bat-
tery pack can cause damage to internal
components.
TO DETACH BATTERY PACK
1. Press the battery-release button to
release the battery pack.
2. Pull rearward on the battery pack to
remove it from the tool.
TO REMOVE/INSTALL THE
BLADE COVER (FIG. 2)
FIG. 2
Blade Cover
WARNING:
• Always wear gloves when removing or
installing the blade cover. Be careful of the
blade and protect your hands from being
injured by the blade.
• Always remove the battery pack from the
product when you are assembling parts,
making adjustments, cleaning, or when the
product is not in use.
1. The hedge trimmer is shipped with the
blade cover installed. Before use, slide
the blade cover off along the blade ridge
and remove it.
2. After using and before storing or
transporting the hedge trimmer, clean
the blade and insert the blade into the
blade cover; cover the entire length of
the blade and make sure that the open
side is facing upward.
OPERATION
Page 11
OPERATION
TO START/STOP THE HEDGE
TRIMMER (FIG. 3)
FIG. 3
Lock-off
Button
Rear Switch
Trigger
Front Switch
Trigger
Before starting the hedge trimmer
• Make sure that you have a secure and
balanced footing.
• Stand upright and hold the hedge trimmer
in a relaxed position.
• Remove the blade cover.
• Make sure that the cutting blade is not
touching the ground or any other objects.
• Hold the unit with both hands: one hand
on the rear handle and one hand on the front
handle.
TO START THE HEDGE TRIMMER
1. Install the battery pack.
2. Depress and hold the front switch
trigger with one hand.
3. Press and hold the lock-off button with
the thumb of your other hand, then
squeeze the rear switch trigger with
your fingers to start the hedge trimmer.
Release the lock-off button and continue to
squeeze the trigger for continued operation.
TO STOP THE HEDGE TRIMMER
Move the hedge trimmer away from the
cutting area and release either of the two
switch triggers to stop the hedge trimmer.
WARNING:
Always remove the
battery pack from the hedge trimmer dur-
ing work breaks and after nishing work.
USING THE HEDGE TRIMMER
WARNING:
• If any parts are missing, damaged or
broken, do not operate your trimmer until
they have been replaced. Failure to do so
could result in possibly serious personal
injury.
• To prevent serious personal injury, always
use both the front handle and the rear
handle to hold the hedge trimmer during
operation. Keep hands away from blades.
Do not attempt to remove cut material or
hold material to be cut when the blades are
moving. Make sure that the blades have
stopped completely, and that the battery
pack is removed before clearing jammed
material from the blades. Do not grasp the
exposed cutting blades or cutting edges
when picking up or holding the unit.
• Clear the area to be cut before each
use. Remove all objects, such as cords,
lights, wire, or string, that could become
entangled in the cutting blade and create
a risk of serious personal injury.
• If the blade jams on any electrical cord
or line, DO NOT TOUCH THE BLADE! IT
CAN BECOME ELECTRICALLY LIVE AND
VERY DANGEROUS. Continue to hold
the hedge trimmer by the insulated rear
handle or lay it down and away from you
in a safe manner. Disconnect the electrical
service to the damaged line or cord before
Page 12
attempting to free the blade from the line
or cord. Failure to heed this warning will
result in serious personal injury or possible
death.
TIPS FOR BEST TRIMMING RE-
SULTS
• Before starting the hedge trimmer,
maintain proper footing and balance and do
not overreach. Wear safety goggles, non-
skid footwear and rubber gloves. Hold the
unit with both hands, with the cutting blade
directed away from you.
• Do not trim too much at one time. This can
cause the blades to bind and slow, reducing
the cutting efficiency.
• Do not force the hedge trimmer through
heavy shrubbery. This can cause the blades
to bind and slow down. If the blades slow
down, slow the pace of your work.
• When trimming new growth, use a wide,
sweeping action so that the stems are fed
directly into the cutting blade. Older growth
will have thicker stems and will be trimmed
most easily by using a sawing motion.
• Always cut stems or twigs that are less
than 9/16 in. thick. Use a non-powered hand
saw or pruning saw to trim larger stems.
TOP CUTTING (FIG. 4A)
FIG. 4a
Use a wide, sweeping motion. A slight
downward tilt of the cutting blades in the
direction of motion provides the best cutting
results. If desired, you can use a string to
help guide you as you cut the hedge level.
Trim the hedge just above this guide line.
SIDE CUTTING (FIG. 4B)
FIG. 4b
When trimming the sides of the hedge,
begin at the bottom and cut upward. Trim
the side of a hedge so that the hedge will
be slightly narrower at the top. This shape
will expose more of the hedge to sunlight,
resulting in more uniform growth.
OPERATION
Page 13
MAINTENANCE
WARNING:
When servicing, use
only identical replacement parts. Use of
any other parts may create a hazard or
cause product damage.
WARNING:
To avoid serious
personal injury, always remove the battery
pack from the product when cleaning or
performing any maintenance.
CLEANING
• For safe and proper operation, always
keep the tool and its ventilation slots clean.
Always use only a soft, dry cloth or brush
to remove debris from the air vents and
cutting blade. To remove pitch and other
sticky residue on the cutting blade, spray
the blades with resin solvent, then wipe the
surface with a dry cloth; never use water to
clean the blade.
• Avoid using solvents when cleaning plastic
parts. Use only a dry, clean cloth to remove
dirt, dust, oil, grease, etc.
LUBRICATION
• For best operation and longer blade life,
lubricate the hedge trimmer blade with
lightweight machine oil before and after
each use.
• Lay the hedge trimmer on a flat surface.
Apply some lightweight machine oil along
the edge of the top blade.
• If the hedge trimmer will be used for an
extended period, it is advisable to stop,
remove the battery, and oil the blade during
use.
WARNING:
Do not oil the blade
while the hedge trimmer is running.
STORAGE
Clean the tool and lubricate the blade
thoroughly before storing it. Store the hedge
trimmer indoors, in a dry, well-ventilated
area, locked-up or up high, and out of
the reach of children. Keep it away from
corrosive agents, such as garden chemicals
and de-icing salts.
Page 14
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Hedge trimmer
dose not work.
The battery pack is not
properly attached to the
hedge trimmer.
Attach the battery pack to the hedge
trimmer.
The battery pack is
depleted.
Charge the battery pack.
The front and rear switch
triggers are not depressed
simultaneously.
Press the lock-off button first and then
press the front and rear switch triggers
simultaneously.
The blade is jammed. Remove the battery pack from the tool,
remove the obstruction carefully, then
reinsert the battery and restart the tool.
Excessive
vibration or noise.
Dry or corroded blades. Lubricate the blades.
Blades or blade support
is bent.
Replace with a new blade or support.
Bent or damaged teeth. Replace with a new blade.
Loose blade bolts. Tighten the blade bolts.
Page 15
NOTES
Page 16
NOTES
Page 17
NOTES
Page 18
SAVE YOUR RECEIPTS
THIS WARRANTY IS VOID WITHOUT THEM
Cordless Hedge Trimmer
WARRANTY
90-DAY MONEY BACK GUARANTEE:
This MASTERFORCE
TM
brand power tool carries our 90-DAY Money Back
Guarantee. If you are not completely satisfied with your MASTERFORCE
TM
brand
power tool for any reason within ninety (90) days from the date of purchase, return
the tool with your original receipt to any MENARDS® retail store, and we will provide
you a refund – no questions asked.
3-YEAR LIMITED WARRANTY:
This MASTERFORCE
TM
brand power tool carries our famous No Hassle 3-Year Limited
Warranty to the original purchaser. If, during normal use, this MASTERFORC
TM
power
tool breaks or fails due to a defect in material or workmanship within three (3) years
from the date of original purchase, simply bring this tool with the original sales receipt
back to your nearest MENARDS® retail store. At its discretion, MASTERFORCE
TM
agrees to have the tool or any defective part(s) repaired or replaced with the same or
similar MASTERFORCE
TM
product or part free of charge, within the stated warranty
period, when returned by the original purchaser with original sales receipt. Not
withstanding the foregoing, this limited warranty does not cover any damage that
has resulted from abuse or misuse of the Merchandise. This warranty: (1) excludes
expendable parts including but not limited to blades, brushes, belts, bits, light bulbs,
and/or batteries; (2) shall be void if this tool is used for commercial and/or rental
purposes; and (3) does not cover any losses, injuries to persons/property or costs. This
warranty does give you specific legal rights and you may have other rights, which vary
from state to state. Be careful, tools are dangerous if improperly used or maintained.
Seller’s employees are not qualified to advise you on the use of this Merchandise.
Any oral representation(s) made will not be binding on seller or its employees. The
rights under this limited warranty are to the original purchaser of the Merchandise
and may not be transferred to any subsequent owner. This limited warranty is in lieu
of all warranties, expressed or implied including warranties or merchantability and
fitness for a particular purpose. Seller shall not be liable for any special, incidental, or
consequential damages. The sole exclusive remedy against the seller will be for the
replacement of any defects as provided herein, as long as the seller is willing or able
to replace this product or is willing to refund the purchase price as provided above.
For insurance purposes, seller is not allowed to demonstrate any of these power tools
for you.
For questions / comments, technical assistance or repair parts –
Please call toll free: 1-866-917-4374 (M-F 8:30am – 5:00pm EST).
11/2018
© 2018 Menard, Inc., Eau Claire, WI 54703
