User Manual BISSELL® 22889 ICONpet™ Cordless Vacuum

BISSELL® 22889 ICONpet™ Cordless Vacuum - Use Manual - Use Guide PDF.
Documents: Go to download!
  • Owner's manual - (English)



User Manual Cordless Vacuum

What’s in the Box?

Standard accessories may vary by model. To identify what should be included with your purchase, please refer to the “Carton Contents” list located on the underside of the insert inside the carton.

Hand Vacuum Assembly

Extension Wand

Motorized Floor Cleaning Foot

Battery Charger

Wall Storage & Charging Station

Lighted Crevice Tool & Dusting Brush

Motorized TurboBrush® Tool

Getting to Know Your Vacuum

For additional support videos and information about your vacuum, visit BISSELL.com/support.

Product View

  1. Hand Vacuum Assembly
  2. Power Button
  3. Cleaning Mode Button
  4. Tank Release Button
  5. Dirt Tank
  6. Hand Vacuum Release Button
  7. Extension Wand
  8. Foot Release Button
  9. Tangle-Free Brush Roll
  10. Motorized Floor Cleaning Foot
  11. LED Headlights
  12. Charging Port
  13. Post-Motor Filter
  14. Foot Hose

Assembly

Go to BISSELL.com/support for assembly videos.

  1. Connect the Extension Wand to Motorized Floor Cleaning Foot. You’ll hear a “click” when they’re connected.
  2. Connect the Hand Vacuum Assembly to the Extension Wand. You’ll hear a “click” when they’re connected.
  3. Make sure to charge your stick vacuum before first use. Refer to page 6, “Charging the Battery” for instructions.

Installing the Wall Storage & Charging Station

Go to BISSELL.com/support for more tips and video instructions on installing the Wall Storage & Charging Station.

  1. Open the Wall Storage & Charging Station, use the bubble level to ensure it level and insert two screws to secure to wall. In order to charge the machine, ensure the Wall Storage & Charging Station is mounted near a wall outlet.
  2. Insert the tool holders into the side of the Wall Storage & Charging Station. To install the charging cord, remove the power cord clip from the Wall Storage & Charging Station. Insert the charging cord and secure it with the charging cord clip.
  3. Plug the power adapter into the wall and place the machine on the Wall Storage & Charging Station for charging. Refer to page 6, “Charging the Battery” for instructions.

Charging the Battery

Go to BISSELL.com/support for additional how-to videos.

Before first use, make sure to fully charge your stick vacuum for 4 hours to get a full charge. To charge the battery you can plug the charger directly into the Hand Vacuum Assembly or into the Wall Storage & Charging Station.

Charging with the Hand Vacuum

  1. Plug the battery charger into the wall.
  2. Plug the charger into the charging port on the back side of the hand vacuum.
  3. Let the hand vacuum charge for 4 hours or until all three sections of the battery charge icon are illuminated.

Charging with the Wall Storage & Charging Station

  1. Follow instructions on page 5 for installing the Wall Storage & Charging Station. Once installed, hang the machine onto the station.
  2. Let the vacuum charge for 4 hours or until all three sections of the battery charge icon are illuminated.

Using the Vacuum

Looking for more guidance? Go to BISSELL.com/support for tips and 24-7 support while cleaning

ICONpet Cordless can be used as a stick vacuum, hand vacuum or for extended reach with hand vacuum + wand.

  1. Press the Power Button to begin cleaning and to turn OFF the machine when finished cleaning.
  2. Press the Cleaning Mode Button to toggle between the three settings:
    • ••• Recommended for maximum suction. It’s the most powerful setting which is great for cleaning carpets, however has the shortest run time. This is the default suction mode when the vacuum is turned ON.
    • •• Recommended for everyday cleaning. It’s great for hard floors, low pile carpets and area rugs. It balances power and run time.
      • • Recommended for the longest run time. It’s great for hard floors and offers the quietest sound.

Attaching Tools for Hand Vac Use

Go to BISSELL.com/support for additional how-to videos.

Clean stairs or furniture easily with the tools provided. Pair your desired tool with the hand vacuum or extension wand. Go to BISSELL.com/support for tips on above floor cleaning tools.

  1. To use as as hand vacuum, press the release button to disconnect it from the extension wand.
  2. Attach your chosen tool.
  3. Use the tool to clean furniture, stairs or other surfaces in your home.

WARNING Do not use your vacuum until you are familiar with all instructions and operating procedures.

Emptying the Dirt Tank

More of a video person? Go to BISSELL.com/support for additional how-to videos.

  1. Turn OFF your machine. Remove the Dirt Tank from the hand vacuum by sliding the latch on the front of the tank.
  2. Grab the top of the tank and pull up. This will activate a wiping feature to remove debris from the mesh filter screen.
  3. Fully remove the separator from the tank and tap the mesh screen on the side of the trash bin.
  4. Dump dirt from the tank into the trash bin.
  5. Slide the separator back into the tank, ensuring the notch is seated into the tank correctly.
  6. Put the whole tank into the hand vacuum by guiding the notched out area on the bottom of the tank onto the hook on the hand vacuum. Push into place.

Removing the Brush Roll

Go to BISSELL.com/support for a full list of maintenance and troubleshooting support.

  1. Turn the machine OFF and press the Foot Release Button to disconnect the Motorized Floor Cleaning Foot from the Extension Wand.
  2. With a flathead screwdriver or coin, twist the slot on the side of the foot clockwise and pull the Brush Roll out.
  3. To replace, push the Brush Roll back in the chamber and twist counter-clockwise with a tool or coin to lock in place.

WARNING » Before using your vacuum, make sure that the Dirt Tank is in locked position and that all filters, both pre and post-filters, are in place. DO NOT operate your vacuum without these filters.

Cleaning & Replacing the Filters

Go to BISSELL.com/support for tips on maintaining and replacing your vacuum filters.

Pre-Motor Filters

For best cleaning performance, always clean your pre-motor filter after each use.

  1. To clean the pre-motor filter, turn OFF machine and remove Dirt Tank from the hand vacuum.
  2. Pull filter from the top of the tank. Remove the filter from the filter frame housing. Tap the filter against the side of a trash bin to remove dust and debris.
  3. To clean, rinse under warm water and squeeze to remove dirt. Lay out for 24 hours, until completely dry. Make sure to replace your filter into the frame with the tag side down (touching the frame) before using your machine.

Post-Motor Filter

  1. To clean your post-motor filter, turn OFF machine and press the latch on the back of the hand vacuum.
  2. Remove the post-motor filter from the vacuum.
  3. The pleated filter may NOT be washed. If dust/debris accumulates, gently tap the filter on a trash bin. Place the filter back into the vacuum and replace the filter cover.

WARNING

  • Do not use your vacuum until you are familiar with all instructions and operating procedures.
  • Before using your vacuum, make sure that the Dirt Tank is in locked position and that all filters, both pre and post-filters, are in place. DO NOT operate your vacuum without these filters.

Disposing of the Batteries

Go to BISSELL.com/support for additional support and how-to videos.

  1. Run the battery out. Make sure the unit is disconnected from the charger and turned OFF and the hand vacuum is disconnected from the extension wand.
  2. Remove five screws from the back of the unit.
  3. Pull the bottom cover off of the back of the unit.
  4. Disconnect and remove entire battery assembly by unplugging the two sockets from the vacuum.
  5. Properly discard remainder of product.

NOTE: Keep Battery Pack together – DO NOT separate individual batteries. For specific disposal instructions of batteries, please contact the RBRC (Rechargeable Battery Recycling Corporation) at 1-800-822-8837 or visit www.call2recycle.org.

NOTICE Disconnecting the battery will destroy the appliance and invalidate the warranty.

WARNING This product contains lithium-ion rechargeable batteries. According to Federal and state regulations, removal and proper disposal of lithium-ion batteries is required. For removal of the batteries in your ICONpet Cordless, see instructions on this page.

Troubleshooting

For a comprehensive walkthrough of your product and support visit BISSELL.com/support.

This guide has everything you need to get ready for first use, including setting up, using and maintaining your machine, but online you’ll find additional resources like tips and troubleshooting, videos, product registration, parts, and more.

Problem, Possible & Cause Remedies

  1. Vacuum won’t pick up dirt
    • Filters are dirty.
      • Remove and rinse Pre-Motor Filters. Allow enough time for them to dry properly before reinserting. Remove and dust off post-motor filter.
    • There is a clog in the vacuum.
      • Remove the foot and extension wand from the hand vacuum. Check for debris buildup or clogs in each of these sections. Clear any debris or clogs before reassembling.
    • Dirt Tank is not seated correctly.
      • Remove the tank and reseat properly.
  2. Dirt is escaping from the vacuum
    • Dirt Tank is full.
      • Empty the tank.
    • Filters are missing or dirty.
      • Check to see if the Pre-Motor & Post Motor Filters are in place and clean, if necessary.
    • There is a clog in the vacuum.
      • Remove the foot and extension wand from the hand vacuum. Check for debris buildup or clogs in each of these sections. Clear any debris or clogs before reassembling.
  3. Vacuum won’t charge
    • Wrong charger is being used.
      • Use only the charger that comes with the machine.
    • Charger is not plugged into the machine properly.
      • Remove the charger and reinstall into the hand vacuum.

Errors

  1. Cause: Suction motor fault.
    • Remedy: Contact Consumer Care.
  2. Cause: Brush roll stall.
    • Remedy: Turn machine OFF. Check and clean the brush roll of any clogs. Brush roll can be removed for thorough cleaning (page 8). Turn machine ON.
  3. Cause: Battery issue.
    • Remedy: Contact Consumer Care.
  4. Air flow issue.
    • Remedy: Turn machine OFF. Check and clean filters. Check and clean the machine of clogs. If this doesn’t solve the problem, contact Consumer Care.

Warranty: 2-Year limited warranty, may vary by state. Visit BISSELL.com/support or call 1-800-237-7691 for complete warranty information.
