Use Manual Samsung HW-Q800T/XY - 3.1.2ch Soundbar 2020

Samsung HW-Q800T/XY - 3.1.2ch Soundbar 2020 - Use Manual - Use Guide PDF.
Documents: Go to donwload!
  • Owner's manual - (English)

User manual Sound Bar for Samsung HW-Q800T/XY

Table of contents

  • Checking the Components
  • Product Overview
  • Front Panel / Top Panel of the Soundbar
  • Bottom Panel of the Soundbar
  • Using the Soundbar Remote Control
  • Using the Tap Sound
  • Installing the Wall Mount
  • Installation Precautions
  • Wallmount Components
  • Installing the Soundbar above a TV Stand
  • Component
  • Software Update
  • Auto Update
  • USB Update
  • Initialisation
  • Troubleshooting
  • Licence
  • Open Source Licence Notice
  • Important Notes About Service
  • Specifications andGuide
  • Specifications


  • For more information about the power supply and power consumption, refer to the label attached to the product.
  • To purchase additional components or optional cables, contact a Samsung Service Centre or Samsung Customer Care.
  • For more information about the wallmount or rubber-foot.
  • Design, specifications, and App screen are subject to change without prior notice.
  • The appearance of the accessories may differ slightly from the illustrations above.

Sound Control

When pressed, the setting items such as TREBLE, BASS, SYNC, CENTER LEVEL, FRONT TOP LEVEL, and VIRTUAL ON/OFF are displayed in sequence. The desired item can be adjusted using the Up/Down buttons.

  • To control the volume of the treble or bass sound, select TREBLE or BASS in Sound
  • Settings, and then adjust the volume between -6~+6 by using the Up/Down buttons.
  • Press and hold the (Sound Control) button for about 5 seconds to adjust the sound for each frequency band. 150Hz, 300Hz, 600Hz, 1.2kHz, 2.5kHz, 5kHz, and kHz are selectable using the Left/Right buttons and each can be adjusted to a setting between -6 to +6 using the Up/Down buttons.
  • Make sure the Sound mode is set to “STANDARD”.)
  • To control the volume of the each speaker select CENTER LEVEL, or FRONT TOP LEVEL in Sound Settings, and then adjust the volume between -6~+6 by using the
  • Up/Down buttons. If the video on the TV and audio from the Soundbar are not synchronised, select SYNC in Sound Control, and then set the audio delay between 0~300 millisecond
