Samsung HW-Q900T/XU Q900t 7.1.2ch Cinematic Soundbar User Manual

HW-Q900T

FULL MANUAL

Imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at www.samsung.com/register

ENG - 2

SAFETY INFORMATION

SAFETY WARNINGS

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE THE COVER (OR BACK).

NO USER-SERVICEABLE PARTS ARE INSIDE.

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

Refer to the table below for an explanation of

symbols which may be on your Samsung product.

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

This symbol indicates that high voltage

is present inside. It is dangerous to

make any kind of contact with any

internal part of this product.

This symbol indicates that this product

has included important literature

concerning operation and maintenance.

Class II product : This symbol indicates

that it does not require a safety

connection to electrical earth (ground).

If this symbol is not present on a

product with a power cord, the product

MUST have a reliable connection to

protective earth (ground).

AC voltage : This symbol indicates that

the rated voltage marked with the

symbol is AC voltage.

DC voltage : This symbol indicates that

the rated voltage marked with the

symbol is DC voltage.

Caution, Consult instructions for use :

This symbol instructs the user to

consult the user manual for further

safety related information.

WARNING

• To reduce the risk of re or electric shock, do

not expose this appliance to rain or moisture.

CAUTION

• TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

• This apparatus shall always be connected to a

AC outlet with a protective grounding

connection.

• To disconnect the apparatus from the mains,

the plug must be pulled out from the mains

socket, therefore the mains plug shall be

readily operable.

• Do not expose this apparatus to dripping or

splashing. Do not put objects lled with

liquids, such as vases on the apparatus.

• To turn this apparatus off completely, you

must pull the power plug out of the wall

socket. Consequently, the power plug must

be easily and readily accessible at all times.

Wiring the Main Power Supply

Plug (UK Only)

IMPORTANT NOTICE

The mains lead on this equipment is supplied with

a moulded plug incorporating a fuse. The value of

the fuse is indicated on the pin face of the plug

and if it requires replacing, a fuse approved to

BS1362 of the same rating must be used.

Never use the plug with the fuse cover removed.

If the cover is detachable and a replacement is

required, it must be of the same colour as the fuse

tted in the plug. Replacement covers are

available from your dealer. If the tted plug is not

suitable for the power points in your house or the

cable is not long enough to reach a power point,

you should obtain a suitable safety approved

extension lead or consult your dealer for assistance.

ENG - 3

However, if there is no alternative to cutting off the

plug, remove the fuse and then safely dispose of

the plug. Do not connect the plug to a mains

socket as there is a risk of shock hazard from the

bared exible cord. Never attempt to insert bare

wires directly into a mains socket. A plug and fuse

must be used at all times.

IMPORTANT

The wires in the mains lead are coloured in

accordance with the following code:– BLUE =

NEUTRAL BROWN = LIVE As these colours may not

correspond to the coloured markings identifying

the terminals in your plug, proceed as follows:– The

wire coloured BLUE must be connected to the

terminal marked with the letter N or coloured

BLUE or BLACK. The wire coloured BROWN must

be connected to the terminal marked with the

letter L or coloured BROWN or RED.

WARNING : DO NOT CONNECT EITHER WIRE TO

THE EARTH TERMINAL WHICH IS MARKED WITH

THE LETTER E OR BY THE EARTH SYMBOL ,

OR COLOURED GREEN OR GREEN AND YELLOW.

PRECAUTIONS

1. Ensure that the AC power supply in your

house complies with the power

requirements listed on the identication

sticker located on the bottom of your

product. Install your product horizontally, on

a suitable base (furniture), with enough

space around it for ventilation (7~10 cm).

Make sure the ventilation slots are not

covered. Do not place the unit on ampliers

or other equipment which may become hot.

This unit is designed for continuous use. To

fully turn off the unit, disconnect the AC plug

from the wall outlet. Unplug the unit if you

intend to leave it unused for a long period of

time.

2. During thunderstorms, disconnect the AC

plug from the wall outlet. Voltage peaks due

to lightning could damage the unit.

3. Do not expose the unit to direct sunlight or

other heat sources. This could lead to

overheating and cause the unit to

malfunction.

4. Protect the product from moisture (i.e.

vases), and excess heat (e.g. a replace) or

equipment creating strong magnetic or

electric elds. Unplug the power cable from

the AC wall socket if the unit malfunctions.

Your product is not intended for industrial

use. It is for personal use only. Condensation

may occur if your product has been stored in

cold temperatures. If transporting the unit

during the winter, wait approximately

2 hours until the unit has reached room

temperature before using.

5. The battery used with this product contains

chemicals that are harmful to the

environment. Do not dispose of the battery

in the general household trash. Do not

expose the battery to excess heat, direct

sunlight, or re. Do not short circuit,

disassemble, or overheat the battery.

Danger of explosion if the battery is replaced

incorrectly. Replace only with the same or

equivalent type.

ENG - 4

Fabric cleaning

Remove any dirt or stain on the product surface

immediately.

Removing and cleaning can be less effective for

some substances or if left for a prolonged time.

CAUTION

• Use a vacuum cleaner or an adhesive lint

roller to remove dust, handprints, and the

likes.

– Some cleaning brushes may damage the

product, depending on the materials they

contain.

– Towels and cleaning clothes may leave

lint or dirt on the product.

• Do not use a nail or other tools to scratch the

dirt off. It may damage the fabric.

• To remove oil or liquid stains, use a clean

white cloth moist with water. If the stain

persists, wipe it with a mixture of water and

neutral detergent (such as dishwashing

soaps) and a cloth.

– A non-neutral detergent or cleaner may

cause discolouration or fabric damage.

– After cleaning, use a dry cloth or

hairdryer to dry the area.

– Do not use excessive force to avoid

discolouration or fabric damage.

ENG - 5

CONTENTS

01 Checking the Components 7

02 Product Overview 8

Top Panel of the Soundbar ------------------------- 8

Bottom Panel of the Soundbar ------------------------- 9

03 Using the Soundbar Remote Control 10

Inserting Batteries before using the Remote Control (AA batteries X 2) ------------------------- 10

How to Use the Remote Control

-------------------------

Using the Hidden Buttons (Buttons with more than one function)

-------------------------

Output specications for the different sound effect modes

-------------------------

Adjusting the Soundbar volume with a TV remote control ------------------------- 14

04 Connecting the Soundbar 15

Connecting the power and units

-------------------------

– Manually connecting the Subwoofer

-------------------------

– LED Indicator Lights on the Rear of Subwoofer

-------------------------

Connecting an SWA-9000S (Sold Separately) to your Soundbar

-------------------------

05 Using a wired connection to the TV 21

Method 1. Connecting with HDMI

-------------------------

– Connecting the TV that supports HDMI ARC (Audio Return Channel)

-------------------------

Method 2. Connecting using an Optical Cable

-------------------------

06 Using a wireless connection to the TV 24

Connecting via Bluetooth

-------------------------

07 Connecting an External Device 26

Method 1. Connecting using an HDMI Cable (Capable of Dolby Atmos

decoding and playback)

-------------------------

Method 2. Connecting using an Optical Cable

-------------------------

ENG - 6

08 Connecting a Mobile Device 28

Method 1. Connecting via Bluetooth

-------------------------

Method 2. Connecting via Wi-Fi (Wireless Network)

-------------------------

Conguring Amazon Alexa

-------------------------

Using the Tap Sound

-------------------------

09 Installing the Wall Mount 35

Installation Precautions

-------------------------

Wallmount Components

-------------------------

10 Installing the Soundbar above a TV Stand 37

Component

-------------------------

11 Software Update 38

Auto Update

-------------------------

USB Update

-------------------------

Initialisation

-------------------------

12 Troubleshooting 40

13 Licence 42

14 Open Source Licence Notice 43

15 Important Notes About Service 43

16 SpecicationsandGuide 44

Specications

-------------------------

ENG - 7

01 CHECKING THE COMPONENTS

VOL WOOFER

SOUNDBAR

SOUND

MODE

PAIR

Soundbar Main Unit Soundbar Remote Control /

Batteries

Subwoofer

x 2

(M4 x L10)

x 2

Power Cord (Subwoofer, Soundbar) Screw

x 2

Wall Mount Guide Holder-Screw Bracket-Wall Mount

x 4

Rubber-Foot

• For more information about the power supply and power consumption, refer to the label attached

to the product. (Label: Bottom of the Soundbar Main Unit)

• To purchase additional components or optional cables, contact a Samsung Service Centre or

Samsung Customer Care.

• For more information about the wallmount or rubber-foot, see pages 35~37.

• Design, specications, and App screen are subject to change without prior notice.

• The appearance of the accessories may differ slightly from the illustrations above.

ENG - 8

02 PRODUCT OVERVIEW

Top Panel of the Soundbar

Position the product

so that the

SAMSUNG logo is

located on the top.

󱂓

󱂔

󱂖

󱂕

󱂓

(Multi Function) Button

• In standby mode, press the (Multi Function) button to turn on the Soundbar.

• Press the (Multi Function) button to change the input source.

• Press the (Multi Function) button for 3 seconds to call Alexa. Say with the button pressed to

enable voice recognition.

󱂔

Display

Displays the product’s status and current mode.

D.IN  HDMI 1  HDMI 2  Wi-Fi  BT

󱂕

(Mic On/Off) Button

Press the button to turn the microphone on or off.

󱂖

(Volume) Button

Adjusts the volume.

• When you plug in the AC cord, the power button will begin working in 4 to 6 seconds.

• When you turn on this unit, there will be a 4 to 5 second delay before it produces sound.

• If you hear sounds from both the TV and Soundbar, go to the Settings menu for the TV audio and

change the TV speaker to External Speaker.

ENG - 9

Bottom Panel of the Soundbar

ID SET

HDMI IN 1

HDMI IN 2

POWER

NETWORK

SERVICE

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

ID SET

(WOOFER/REAR)

POWER

ID SET

NETWORK

SERVICE

ID SET

(WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

󱂖

ID SET

HDMI IN 1

HDMI IN 2

POWER

NETWORK

SERVICE

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

ID SET

(WOOFER/REAR)

POWER

ID SET

NETWORK

SERVICE

ID SET

(WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

󱂔

󱂕

ID SET

HDMI IN 1

HDMI IN 2

POWER

NETWORK

SERVICE

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

ID SET

(WOOFER/REAR)

POWER

ID SET

NETWORK

SERVICE

ID SET

(WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

󱂓

ID SET

HDMI IN 1

HDMI IN 2

POWER

NETWORK

SERVICE

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

ID SET

(WOOFER/REAR)

POWER

ID SET

NETWORK

SERVICE

ID SET

(WOOFER/REAR)

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

󱂙

󱂘

󱂗

󱂓

POWER

Connect the Soundbar's AC power cable. (See page 15)

󱂔

ID SET (WOOFER/REAR)

Press to connect the Soundbar to surround speakers and a subwoofer wirelessly. (The surround speaker is

sold separately.)

󱂕

NETWORK

Press to connect to a wireless network (Wi-Fi) via the SmartThings app.

󱂖

SERVICE

Connect a USB storage device to upgrade the product's software.

󱂗

DIGITAL AUDIO IN (OPTICAL)

Connect to the digital (optical) output of an external device. (See page 27)

󱂘

HDMI 1 / HDMI 2

Inputs digital video and audio signals simultaneously using an HDMI cable.

Connect to the HDMI output of an external device. (See page 26)

󱂙

HDMI TO TV (eARC/ARC)

Connect to the HDMI jack on a TV. (See page 21)

• When disconnecting the power cord from a wall outlet, pull the plug. Do not pull the cable.

• Do not connect this unit or other components to an AC outlet until all connections between

components are complete.

ENG - 10

03 USING THE SOUNDBAR REMOTE

CONTROL

Inserting Batteries before using the Remote Control (AA batteries X 2)

Slide the back cover in the direction of the arrow

until it is completely removed. Insert 2 AA batteries

(1.5V) oriented so that their polarity is correct. Slide

the back cover back into position.

How to Use the Remote Control

VOL WOOFER

SOUNDBAR

SOUND

MODE

PAIR

󱂓

󱂔

󱂕

󱂖

󱂗

󱂙

󱂘

󱂚

󱂜

󱂛

󱂓

Power

VOL WOOFER

SOUND

MODE

PAIR

Turns the Soundbar on and off.

• Auto Power Down Function

The unit turns off automatically in the

following situations:

– In D.IN / HDMI 1 / HDMI 2 / Wi-Fi / BT

mode if there is no audio signal for 18

minutes.

󱂔

VOL WOOFER

SOUND

MODE

PAIR

Source

Press to select a source connected to the

Soundbar.

󱂕

Mute

VOL WOOFER

SOUND

MODE

PAIR

Press the (Mute) button to mute the

sound.

Press it again to unmute the sound.

ENG - 11

󱂖

SOUND MODE

VOL WOOFER

SOUND

MODE

PAIR

You can select the desired sound mode by choosing STANDARD, SURROUND, GAME

PRO, or ADAPTIVE SOUND.

• STANDARD

Outputs the original sound.

• SURROUND SOUND

Provides a wider sound eld than standard.

• GAME PRO

Provides stereoscopic sound to immerse you in the action while gaming.

• ADAPTIVE SOUND

Analyzes the content in real time and automatically provides the optimal sound eld

based on the characteristics of the content.

󱂗

VOL WOOFER

SOUND

MODE

PAIR

Bluetooth

PAIR

Switch the Soundbar to Bluetooth pairing mode. Press the button and wait for the “BT

PAIRING” screen to connect to a new Bluetooth device.

󱂘

Play / Pause

VOL WOOFER

SOUND

MODE

PAIR

You can also play or pause music by pressing the button.

󱂙

VOL WOOFER

SOUND

MODE

PAIR

Up/Down/

Left/Right

Press the indicated areas to select Up/Down/Left/Right.

Press Up/Down/Left/Right on the button to select or set functions.

• Music Skip

Press the Right button to select the next music le. Press the Left button to select

the previous music le.

• ID SET

Use this option when the Subwoofer or Surround Speakers are not connected or need

reconnection.

While powered off, press and hold the Up button for 5 seconds to perform ID SET.

(See page 16.)

ENG - 12

󱂚

Sound Control

VOL WOOFER

SOUND

MODE

PAIR

When pressed, the setting items such as TREBLE, BASS, SYNC, CENTER LEVEL, SIDE

LEVEL, FRONT TOP LEVEL, REAR LEVEL, REAR TOP LEVEL, and VIRTUAL ON/OFF are

displayed in sequence. The desired item can be adjusted using the Up/Down buttons.

– To control the volume of the treble or bass sound, select TREBLE or BASS in Sound

Settings, and then adjust the volume between -6~+6 by using the Up/Down buttons.

– Press and hold the (Sound Control) button for about 5 seconds to adjust the

sound for each frequency band. 150Hz, 300Hz, 600Hz, 1.2kHz, 2.5kHz, 5kHz, and

10kHz are selectable using the Left/Right buttons and each can be adjusted to a

setting between -6 to +6 using the Up/Down buttons.

(Make sure the Sound mode is set to “STANDARD”.)

– To control the volume of the each speaker select CENTER LEVEL, SIDE LEVEL, or

FRONT TOP LEVEL in Sound Settings, and then adjust the volume between -6~+6 by

using the Up/Down buttons.

– If the video on the TV and audio from the Soundbar are not synchronised, select

SYNC in Sound Control, and then set the audio delay between 0~300 milliseconds by

using the Up/Down buttons.

– SYNC is only supported for some functions.

– If Surround Speakers are connected, select REAR LEVEL or REAR TOP LEVEL and

then use the Up/Down buttons to adjust the volume within a -6 to +6 range.

– The VIRTUAL Speaker function can be turned ON/OFF by using the Up/Down

buttons.

󱂛

VOL WOOFER

SOUND

MODE

PAIR

WOOFER

(BASS) LEVEL

SOUND

MODE

VOL

WOOFER

SOUNDBAR

SOUND

MODE

VOL

WOOFER

SOUNDBAR

SOUND

MODE

VOL

WOOFER

SOUNDBAR

SOUND

MODE

VOL

WOOFER

SOUNDBAR

Push the button up or down to adjust the level of the woofer (bass) to -12 or between -6

to +6. To set the woofer (bass) volume level to 0 (Default), press the button.

󱂜

VOL WOOFER

SOUND

MODE

PAIR

VOLUME

SOUND

MODE

VOL

WOOFER

SOUNDBAR

SOUND

MODE

VOL

WOOFER

SOUNDBAR

SOUND

MODE

VOL

WOOFER

SOUNDBAR

SOUND

MODE

VOL

WOOFER

SOUNDBAR

Push the button up or down to adjust the volume.

• Mute

Press the VOL button to mute the sound. Press it again to unmute the sound.

ENG - 13

Using the Hidden Buttons (Buttons with more than one function)

Hidden Button

Reference page

Remote Control Button Function

WOOFER (Up) TV remote control On/Off (Standby) page 14

Up ID SET page 16

(Sound Control)

7 Band EQ page 12

Outputspecicationsforthedifferentsoundeffectmodes

Effect Input

Output

With Subwoofer Only

With Subwoofer & Wireless

Rear Speaker Kit

STANDARD

2.0 ch 2.1 ch 2.1 ch

5.1 ch 5.1 ch / 7.1 ch(DTS) 5.1 ch / 7.1 ch(DTS)

7.1 ch 7.1 ch 7.1 ch

7.1.4 ch 7.1.2 ch 9.1.2 ch

SURROUND

2.0 ch 7.1.2 ch 9.1.2 ch

5.1 ch 7.1.2 ch 9.1.2 ch

7.1 ch 7.1.2 ch 9.1.2 ch

7.1.4 ch 7.1.2 ch 9.1.2 ch

GAME PRO

2.0 ch 7.1.2 ch 9.1.2 ch

5.1 ch 7.1.2 ch 9.1.2 ch

7.1 ch 7.1.2 ch 9.1.2 ch

7.1.4 ch 7.1.2 ch 9.1.2 ch

ADAPTIVE SOUND

2.0 ch 7.1.2 ch 9.1.2 ch

5.1 ch 7.1.2 ch 9.1.2 ch

7.1 ch 7.1.2 ch 9.1.2 ch

7.1.4 ch 7.1.2 ch 9.1.2 ch

• For input sources Dolby Atmos and DTS:X, the effect modes that can be selected using the

SOUND MODE button will not be available. (See above for the effect modes.)

• When the input source is Dolby Atmos®, the Subwoofer-only setup provides 7.1.2 channel audio,

while the Subwoofer & Wireless Rear Speaker Kit setup provides 9.1.2 channel audio.

• The Samsung Wireless Rear Speaker Kit can be purchased separately. To purchase a Kit or the

Subwoofer, contact the vendor you purchased the Soundbar from.

• The Surround Speakers will not produce sounds for 2 channel output while STANDARD mode is

in use. To enable sound for the Surround Speakers, change the effect mode to SURROUND.

ENG - 14

Adjusting the Soundbar volume with a TV remote control

Adjust the Soundbar volume using the TV’s remote control.

• This function can be used with IR remote controls only. Bluetooth remote controls (remote

controls that require pairing) are not supported.

• Set the TV speaker to External Speaker to use this function.

• Manufacturers supporting this function:

VIZIO, LG, Sony, Sharp, PHILIPS, PANASONIC, TOSHIBA, Hisense, RCA

1. Turn Off the Soundbar.

2. Push up and hold the WOOFER button for 5 seconds.

Each time you push the WOOFER button up and hold it for 5 seconds, the mode switches in the

following order: “SAMSUNG-TV REMOTE” (Default mode), “OFF-TV REMOTE”, “ALL-TV REMOTE”.

Remote Control Button Display Status

SOUND

MODE

VOL

WOOFER

SOUNDBAR

5 Sec

SAMSUNG-TV REMOTE

(Default mode)

Enable a Samsung TV’s IR remote

control.

SOUND

MODE

VOL

WOOFER

SOUNDBAR

5 Sec

OFF-TV REMOTE

Disable the TV remote control.

SOUND

MODE

VOL

WOOFER

SOUNDBAR

5 Sec

ALL-TV REMOTE

Enable a third-party TV’s IR remote

control.

ENG - 15

04 CONNECTING THE SOUNDBAR

Connecting the power and units

Use the Power cord to connect the Subwoofer and Soundbar to an electrical outlet in the following order:

• For more information about the required electrical power and power consumption, refer to the

label attached to the product. (Label: Bottom of the Soundbar Main Unit)

1. Connect the Power cord to the Subwoofer.

POWER

Rear of Subwoofer

Power Cord

2. Connect the Power cord to the Soundbar.

HDMI IN 1

HDMI IN 2

ID SET

(WOOFER,

REAR)

POWER

NETWORK

SERVICE

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 1

HDMI 2

ID SET

POWER

Power Cord

Bottom of the Soundbar

Main Unit

3. Connect power to the Soundbar and Subwoofer. The Subwoofer is automatically connected when

the Soundbar is turned on.

Blue is On

ENG - 16

NOTES

• Connect the Subwoofer power before connecting to the Soundbar.

The Subwoofer will be automatically connected when turning on the Soundbar.

• If you unplug and reconnect the power cord when the product is turned on, the Soundbar turns on

automatically.

Manually connecting the Subwoofer

Before performing the manual connection procedure below:

• Check whether the power cables for the Soundbar and subwoofer are connected properly.

• Make sure that the Soundbar is turned off.

1. Turn off the Soundbar main.

2. Press and hold ID SET on the rear of the subwoofer for at least 5 seconds.

• The red indicator on the rear of the subwoofer turns off and the blue indicator blinks.

5 Sec

Rear of Subwoofer Rear of Subwoofer

Blinking blue

fast

3. Press the Up button on the remote control for 5 seconds.

• The ID SET message appears on the display of the Soundbar for a moment, and then it

disappears.

• The Soundbar will automatically power on when ID SET is complete.

SOUND

MODE

PAIR

5 Sec

ID SET

ENG - 17

4. Check if the LINK LED is solid blue (connection complete).

Blue is On

The LINK LED indicator stops blinking and

glows a solid blue when a connection is

established between the Soundbar and the

Wireless Subwoofer.

LED Indicator Lights on the Rear of Subwoofer

LED Status Description Resolution

Blue

Successfully connected

(normal operation)

Blinking

Recovering the

connection

Check if the power cable attached

to the main Soundbar unit is

connected properly or wait about

5 minutes. If blinking persists, try

manually connecting the

subwoofer. See page 16.

Red

Standby (with the

Soundbar main unit

turned off)

Check if the power cable attached

to the main Soundbar unit is

connected properly.

Connection failed

Connect again. See the

instructions for manual

connection on page 16.

Red and blue

Blinking Malfunction

See the contact information for

the Samsung Service Centre in

this manual.

NOTES

• If the main unit is powered off, the wireless subwoofer will go into stand-by mode and the

STANDBY LED on the rear of the sub-woofer will turn red after blinking in blue several times.

ENG - 18

• If you use a device that uses the same frequency (5.8GHz) as the Soundbar near the Soundbar,

interference may cause some sound interruption.

• The maximum transmission distance of the main unit’s wireless signal is about 10 m, but may vary

depending on your operating environment. If a steel-concrete or metallic wall is between the main

unit and the wireless subwoofer, the system may not operate at all because the wireless signal

cannot penetrate metal.

CAUTION

• Wireless receiving antennas are built into the wireless subwoofer. Keep the unit away from water

and moisture.

• For optimal listening performance, make sure that the area around the wireless subwoofer and the

Wireless Receiver Module (sold separately) is clear of any obstructions.

ENG - 19

Connecting an SWA-9000S (Sold Separately) to your Soundbar

Expand to true wireless surround sound by connecting the Samsung Wireless Rear Speaker Kit

(SWA-9000S, sold separately) to your Soundbar.

1. Connect the Wireless Receiver Module to 2 Surround Speakers.

– The speaker cables are colour coded.

SURROUND-LEFT

ID SET

SURROUND SPEAKERS OUT

SPEAKER IMPEDANCE : 3Ω

POWER

ID SET

SURROUND SPEAKERS OUT

SPEAKER IMPEDANCE : 3Ω

SURROUND-RIGHT

SURROUND-LEFT SURROUND-RIGHT

2. Check the standby status of the Wireless Receiver Module after plugging it into an electrical outlet.

• The LINK LED indicator (blue) on the Wireless Receiver Module should be blinking. If the

indicator does not blink, use a narrow pin to press and hold the ID SET button for 5 seconds or

longer. See the SWA-9000S user guide for more details.

ID SET

SURROUND SPEAKERS OUT

SPEAKER IMPEDANCE : 3Ω

POWER

ID SET

SURROUND SPEAKERS OUT

SPEAKER IMPEDANCE : 3Ω

STANDBY

LINK

STANDBY

LINK

Blue blinking

5 Sec

ENG - 20

3. Press the Up button on the remote control for 5 seconds.

• The ID SET message appears on the display of the Soundbar for a moment, and then it

disappears.

• The Soundbar will automatically power on when ID SET is complete.

SOUND

MODE

PAIR

5 Sec

ID SET

CAUTION

• If your Soundbar was playing music when it connects to the SWA-9000S, you may hear some

stuttering from the woofer as the connection nalises.

4. Check if the LINK LED is solid blue (connection complete).

STANDBY

LINK

STANDBY

LINK

Blue is On

The LINK LED indicator stops blinking and

glows a solid blue when a connection is

established between the Soundbar and the

Wireless Receiver Module.

5. If the SWA-9000S is not connected, repeat the procedure from Step 2.

ENG - 21

05 USING A WIRED CONNECTION TO THE TV

Method 1. Connecting with HDMI

CAUTION

• When both the HDMI cable and optical cable are connected, the HDMI signal is received rst.

• To connect the HDMI cable between the TV and Soundbar, be sure to connect the terminals

marked ARC. Otherwise, the TV sound may not be output.

• Be sure to use the cable with the premium HDMI certication logo. In addition, make sure that

the cable is a certied Type A, high-speed HDMI Ethernet cable. (HIGH SPEED HDMI CABLE

WITH ETHERNET)

Connecting the TV that supports HDMI ARC (Audio Return Channel)

HDMI IN

(ARC)

HDMI TO TV

(eARC/ARC)

Connect to the HDMI IN

(ARC) port of your TV.

HDMI Cable

(not supplied)

Bottom of the Soundbar

Connect to the HDMI TO TV

(eARC/ARC) port of the

Soundbar main unit.

Top of the Soundbar

TV ARC

1. With the Soundbar and TV turned off, connect the HDMI cable (not supplied) as shown in the

gure.

2. Turn on the Soundbar and TV.

3. “TV ARC” appears in the display window of the Soundbar main unit and the Soundbar plays TV

sound.

• When the TV sound is not output, press the (Multi Function) button at the top of the

Soundbar or the (Source) button on the remote control to select the “D.IN” mode. The

screen displays “D.IN” and “TV ARC” in sequence, and TV sound is played.

ENG - 22

• When connecting a Samsung TV that supports the eARC function, “eARC” appears on the

display and the sound is heard.

• If “TV ARC” does not appear in the display window of the Soundbar main unit, conrm that the

HDMI cable (not supplied) is connected to the correct port.

• Use the volume buttons on the TV’s remote control to change the volume on the Soundbar.

NOTES

• When you connect the TV that supports the HDMI ARC (Audio Return Channel) to the Soundbar

with an HDMI cable, you can transmit the digital video and audio data without connecting a

separate optical cable.

• We recommend you use a coreless HDMI cable if possible. If you use a cored HDMI cable, use one

whose diameter is less than 14 mm.

• This function is not available if the HDMI cable does not support ARC.

• When the audio in a broadcast is encoded in Dolby Digital and the “Digital Output Audio Format” on

your TV is set to PCM, we recommend that you change the setting to Dolby Digital. When the

setting on the TV is changed, you will experience better sound quality. (The TV menu may use

different words for Dolby Digital and PCM depending on the TV manufacturer.)

Method 2. Connecting using an Optical Cable

Pre-connection Checklist

• When both the HDMI cable and optical cable are connected, the HDMI signal is received rst.

• When you use an optical cable and the terminals have covers, be sure to remove the covers.

Bottom of the Soundbar

OPTICAL OUT

DIGITAL AUDIO IN

(OPTICAL)

HDMI 1

HDMI 2

Optical Cable

(not supplied)

Top of the Soundbar

D.IN

ENG - 23

1. With the TV and Soundbar turned off, connect the DIGITAL AUDIO IN (OPTICAL) port on the

Soundbar and the OPTICAL output port on the TV with the optical cable (not supplied), as shown in

the gure.

2. Turn on the Soundbar and TV.

3. Press the (Multi Function) button at the top of the Soundbar or the (Source) button on the

remote control to select the “D.IN” mode.

4. The TV sound is output from the Soundbar.

Using the Q-Symphony Function

For Q-Symphony, the Soundbar syncs with a Samsung TV to output sound through two devices for

optimum surround effect. When the Soundbar is connected, the menu, “TV+Soundbar” appears under

the Sound Output menu of the TV. Select the corresponding menu.

TV menu

Optical Cable (not supplied)

HDMI Cable (not supplied)

D.IN

• TV menu example: TV + [AV] Soundbar series name (HDMI)

NOTES

• It can operate according to the Codec supported by TV.

• This function is supported only when the HDMI Cable (not supplied) or Optical Cable (not supplied)

is connected.

• This function is available in Samsung TVs released in 2020 and some Soundbar models.

• When using Q-Symphony, you can only choose GAME PRO or ADAPTIVE SOUND.

ENG - 24

06 USING A WIRELESS CONNECTION TO THE TV

Connecting via Bluetooth

When a Samsung TV is connected using Bluetooth, you can hear stereo sound without the hassle of

cabling.

• Only one Samsung TV can be connected at a time.

• Samsung TV that supports Bluetooth can be connected. Check the specications of your TV.

SOUND

MODE

PAIR

Top of the Soundbar

BT PAIRING

5 Sec

The initial connection

1. Press the PAIR button on the Soundbar remote control to enter the “BT PAIRING” mode.

(OR)

a. Press the (Multi Function) button on the top panel and then select “BT”.

“BT” changes to “BT PAIRING” in a few seconds automatically or changes to “BT READY” if

there is a connect record.

b. When “BT READY” appears, press and hold the (Mic On/Off) button on the top panel of

the Soundbar for more than 5 seconds to display “BT PAIRING”.

2. Select Bluetooth mode on the Samsung TV.

(e.g. Home ( )  Settings ( )  Sound  Sound Output  Bluetooth Speaker List 

[AV] Samsung Soundbar Q900T (Bluetooth))

3. Select “[AV] Samsung Soundbar Q900T” from the list on TV’s screen.

An available Soundbar is indicated with “Need Pairing” or “Paired” on the TV’s Bluetooth device

list. To connect the Samsung TV to the Soundbar, select the message, and then establish a

connection.

• When the Samsung TV is connected, [TV Name] → “BT” appears on the Soundbar’s top display.

4. You can now hear Samsung TV sound from the Soundbar.

• After you have connected the Soundbar to your Samsung TV the rst time, use the “BT READY”

mode to reconnect.

ENG - 25

If the device fails to connect

• If you have an existing Soundbar (e.g., [AV] Samsung Soundbar Q900T) on the list of speakers

on the Samsung TV, delete it.

• Then repeat steps 1 through 3.

Disconnecting the Soundbar from the Samsung TV

Press the (Multi Function) button at the top of the Soundbar or the (Source) button on the

remote control to select the mode other than “BT”.

• Disconnecting takes time because the Samsung TV must receive a response from the Soundbar.

(The time required may differ, depending on the Samsung TV model.)

What is the difference between BT READY and BT PAIRING?

• BT READY : In this mode, you can reconnect any Samsung TV or mobile device that was

connected before.

• BT PAIRING : In this mode, you can connect a new device to the Soundbar.

(Press the PAIR button on the Soundbar remote control or press and hold the (Mic On/Off)

button on the top of the Soundbar for more than 5 seconds while the Soundbar is in “BT” mode.)

Notes on Bluetooth connection

• Locate a new device within 1 m to connect via Bluetooth communication.

• If asked for a PIN code when connecting a Bluetooth device, enter <0000>.

• The Soundbar automatically turns off after 18 minutes in the Ready state.

• The Soundbar may not perform Bluetooth search or connection correctly under the following

circumstances:

– If there is a strong electrical eld around the Soundbar.

– If several Bluetooth devices are simultaneously paired with the Soundbar.

– If the Bluetooth device is turned off, not in place, or malfunctions.

• Electronic devices may cause radio interference. Devices that generate electromagnetic waves

must be kept away from the Soundbar main unit - e.g., microwaves, wireless LAN devices, etc.

ENG - 26

07 CONNECTING AN EXTERNAL DEVICE

Method 1. Connecting using an HDMI Cable (Capable of Dolby

Atmos decoding and playback)

Pre-connection Checklist

• Dolby Atmos® and DTS:X are supported in HDMI mode only.

• If the Audio Output options include Secondary Audio, make sure Secondary Audio is set to Off.

• Make sure that the content supports Dolby Atmos®.

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

HDMI IN

(ARC)

HDMI OUT

Bottom of the Soundbar

External Device

HDMI Cable

(not supplied)

HDMI Cable

(not supplied)

Top of the Soundbar

HDMI 1

HDMI 2

1. Use an HDMI cable (not supplied) to connect the HDMI OUT port on the external device and the

HDMI port on the bottom of the Soundbar.

2. Use an HDMI cable (not supplied) to connect the HDMI IN port of the TV and the HDMI TO TV

(eARC/ARC) port on the bottom of the Soundbar.

3. Turn on the Soundbar, TV, and the external device.

4. Press the (Multi Function) button on the top of the Soundbar or the (Source) button on the

remote control to select “HDMI 1” or “HDMI 2” mode.

5. The Soundbar display indicates that “HDMI 1” or “HDMI 2” mode is currently selected and the

Soundbar will start playing sounds.

ENG - 27

NOTES

• When you use Dolby Atmos®: If the input source is Dolby Atmos®, 7.1.2 channels are outputted.

When Dolby Atmos® is active, the Soundbar’s sound effect modes controlled by the SOUND

MODE button are not available.

• When Dolby Atmos® is activated, “DOLBY ATMOS” appears in the top display.

• ConguringDolbyAtmos®onyourBDplayerorotherdevice.

Open the audio output options on the settings menu of your BD player or other device and make

sure that “No Encoding” is selected for Bitstream. For example, on a Samsung BD Player, go to

Home Menu → Sound → Digital Output and then select Bitstream (unprocessed).

Method 2. Connecting using an Optical Cable

DIGITAL AUDIO IN

(OPTICAL)

HDMI 1

OPTICAL OUT

Bottom of the Soundbar

Optical Cable

(not supplied)

BD / DVD player / Set-top

box / Game console

Top of the Soundbar

D.IN

1. Use an optical cable (not supplied) to connect the DIGITAL AUDIO IN (OPTICAL) on the Soundbar

main and the OPTICAL OUT port on the external device.

2. Turn on the Soundbar and external device.

3. To select “D.IN” mode, press the (Multi Function) button on the top of the Soundbar or the

(Source) button on the remote control.

4. Your Soundbar will play sounds from the external device.

ENG - 28

08 CONNECTING A MOBILE DEVICE

Method 1. Connecting via Bluetooth

When a mobile device is connected using Bluetooth, you can hear stereo sound without the hassle of

cabling.

• When you connect a paired Bluetooth device with the Soundbar off, the Soundbar automatically

turns on.

SOUND

MODE

PAIR

Mobile device

Top of the Soundbar

BT PAIRING

5 Sec

The initial connection

• When connecting to a new Bluetooth device, make sure the device is within 1 m distance.

1. Press the PAIR button on the Soundbar remote control to enter the “BT PAIRING” mode.

(OR)

a. Press the (Multi Function) button on the top panel and then select “BT”.

“BT” changes to “BT PAIRING” in a few seconds automatically or changes to “BT READY” if

there is a connect record.

b. When “BT READY” appears, press and hold the (Mic On/Off) button on the top panel of

the Soundbar for more than 5 seconds to display “BT PAIRING”.

2. On your device, select “[AV] Samsung Soundbar Q900T” from the list that appears.

• When the Soundbar is connected to the Mobile device, [Mobile Device Name] → “BT” appears in

the top display.

3. Play music les from the device connected via Bluetooth through the Soundbar.

• After you have connected the Soundbar to your mobile device the rst time, use the “BT

READY” mode to reconnect.

If the device fails to connect

• If you have an existing Soundbar (e.g., “[AV] Samsung Soundbar Q900T”) in the list of speakers

on the Mobile device, delete it.

• Repeat steps 1 and 2.

ENG - 29

What is the difference between BT READY and BT PAIRING?

• BT READY : In this mode, you can reconnect any Samsung TV or mobile device that was

connected before.

• BT PAIRING : In this mode, you can connect a new device to the Soundbar.

(Press the PAIR button on the Soundbar remote control or press and hold the (Mic On/Off)

button on the top of the Soundbar for more than 5 seconds while the Soundbar is in “BT” mode.)

Notes on Bluetooth connection

• Locate a new device within 1 m to connect via Bluetooth communication.

• If asked for a PIN code when connecting a Bluetooth device, enter <0000>.

• The Soundbar automatically turns off after 18 minutes in the Ready state.

• The Soundbar may not perform Bluetooth search or connection correctly under the following

circumstances:

– If there is a strong electrical eld around the Soundbar.

– If several Bluetooth devices are simultaneously paired with the Soundbar.

– If the Bluetooth device is turned off, not in place, or malfunctions.

• Electronic devices may cause radio interference. Devices that generate electromagnetic waves

must be kept away from the Soundbar main unit - e.g., microwaves, wireless LAN devices, etc.

• The Soundbar supports SBC data (44.1kHz, 48kHz).

• Connect only to a Bluetooth device that supports the A2DP (AV) function.

• You cannot connect the Soundbar to a Bluetooth device that supports only the HF (Hands Free)

function.

• When connecting the Soundbar to a Bluetooth device, place them as close to each other as possible.

• The farther the Soundbar and Bluetooth device are from each other, the lower the sound quality

will become.

The Bluetooth connection may break when the devices are out of the effective range.

• The Bluetooth connection may not function as intended in areas with poor reception.

• A Bluetooth device may experience noise or malfunction under in the following conditions:

– When the body is in contact with the signal transceiver on the Bluetooth device or Soundbar

– In corners or when there is an obstacle in proximity, such as a wall or partition, where electrical

changes may occur.

– When exposed to radio interferences by other products operating on the same frequency

ranges, such as medical equipment, microwave ovens, and wireless LAN devices.

– Obstacles such as doors and walls may still impact the sound quality even when the devices

are within the effective range.

ENG - 30

• Note that your Soundbar cannot be paired with other Bluetooth devices while using the Bluetooth

option.

• This wireless device may cause electrical interference during operation.

Disconnecting the Bluetooth device from a Soundbar

You can disconnect a Bluetooth device from the Soundbar. For instructions, see the Bluetooth device’s

user manual.

• The Soundbar will be disconnected.

• When the Soundbar is disconnected from the Bluetooth device, the Soundbar will display

“BT DISCONNECTED” on the top display.

Disconnecting the Soundbar from the Bluetooth device

Press the (Multi Function) button on the top of the Soundbar or the (Source) button on the

remote control to switch the mode from “BT”.

• Disconnecting takes time because the Bluetooth device must receive a response from the

Soundbar. (Disconnection time may differ, depending on the Bluetooth device)

• When the Soundbar is disconnected from the Bluetooth device, the Soundbar will display

“BT DISCONNECTED” on the top display.

ENG - 31

Method 2. Connecting via Wi-Fi (Wireless Network)

To connect a Soundbar to a mobile device via a wireless network (Wi-Fi), the SmartThings app is

required.

The initial connection

1. Install and launch the SmartThings app from your mobile device (smartphone or tablet).

2. On the app, follow the screen instructions to add the Soundbar.

• The automatic pop-up (the second screenshot below) may not show on some devices.

If the pop-up window does not appear, press “ ” on the Home screen. The Soundbar is added

to the app.

Launch App Add deviceAuto pop-up

SmartThings

App

ENG - 32

ConguringAmazonAlexa

• Amazon Alexa is a service provided by Amazon.

• This service is available only in some languages but not in other countries or regions.

Using Alexa, you can play music, listen to news, see weather forecasts, and control home appliances.

To use Amazon Alexa, an Amazon account is required to connect the Soundbar over the network.

1. Install the SmartThings app on your mobile device and then launch it.

2. Enter the Alexa account by following the instructions on the app and then log in the service.

3 Sec

Top of the Soundbar

"Alexa"

3. Call Alexa or press the (Multi Function) button on the Soundbar for 3 seconds to use the Alexa

service.

• Press the (Multi Function) button for 3 seconds to call Alexa. Say with the button pressed to

enable voice recognition.

ENG - 33

Use voice commands to control the Soundbar

Trigger + Command

Things to try Example of what to say

Volume control

"Alexa, turn up the volume."

“Alexa, turn down the volume”

Listening to streaming content from

Amazon Music

"Alexa,playsomejazzmusic"

Playback control

"Alexa, play next song."

“Alexa, stop the music.”

“Alexa, what is this song?”

Weather information "Alexa, what’s the weather?"

Timer scheduling “Alexa, set a timer for 10 minutes.”

ENG - 34

Using the Tap Sound

Tap the Soundbar with your mobile device to play the sound of content on the mobile device through

the Soundbar.

• This function may not be supported, depending on the mobile device.

• This function is only compatible with Samsung mobile devices with Android 8.1 or later.

Top of the Soundbar

Mobile device

SmartThings App

1. Turn on the Tap Sound function on your mobile device.

• For details on how to turn on the function, refer to “Setting the Tap Sound function” below.

2. Tap the Soundbar with the mobile device. Select “Start now” in the displayed message window.

A connection is established between the mobile device and Soundbar via Bluetooth.

3. Play the sound of content on the mobile device through the Soundbar.

• This function connects a mobile device to the Soundbar via Bluetooth by detecting vibration

that occurs when the device touches the Soundbar.

• Make sure the mobile device does not tap a sharp corner of the Soundbar. The Soundbar or

mobile device may become scratched or damaged.

• It is recommended that the mobile device be covered with a case. Lightly tap the wide area in

the upper portion of the Soundbar, without using excessive force.

• To use this function, update the SmartThings app to the latest version.

The function may not be supported, depending on the app version.

Setting the Tap Sound function

Use the SmartThings app to turn on the Tap View, Tap Sound function.

1. On the mobile device, run the SmartThings app.

2. Select ( → ) in the SmartThings app screen displayed on the mobile device.

3. Set “Tap View, Tap Sound” to On to allow the function to work when a mobile device moves close to

the Soundbar. The function is turned on.

NOTES

• When the mobile device is in power-saving mode, the Tap Sound function does not work.

• The Tap Sound function may not work if there are devices near the Soundbar that cause radio

interference such as electric devices. Make sure devices that may cause radio interference are

placed at a sufcient distance away from the Soundbar.

ENG - 35

09 INSTALLING THE

WALL MOUNT

Installation Precautions

• Install on a vertical wall only.

• Do not install in a place with high

temperature or humidity.

• Verify whether the wall is strong enough to

support the product’s weight. If not, reinforce

the wall or choose another installation point.

• Purchase and use the xing screws or

anchors appropriate for the kind of wall you

have (plaster board, iron board, wood, etc.). If

possible, x the support screws into wall

studs.

• Purchase wall mounting screws according to

the type and thickness of the wall you want to

mount the Soundbar on.

– Diameter: M5

– Length: 35 mm or longer recommended.

• Connect cables from the unit to external

devices before you install the Soundbar on

the wall.

• Make sure the unit is turned off and

unplugged before you install it. Otherwise, it

may cause an electric shock.

Wallmount Components

Wall Mount Guide

x 2

(M4 x L10)

x 2

Holder-Screw Screw

x 2

Bracket-Wall Mount

1. Place the Wall Mount Guide against the wall

surface.

• The Wall Mount Guide must be level.

• If your TV is mounted on the wall, install

the Soundbar at least 5 cm below the TV.

5 cm or more

ENG - 36

2. Align the Wall Mount Guide’s Centre Line

with the centre of your TV (if you are

mounting the Soundbar below your TV), and

then x the Wall Mount Guide to the wall

using tape.

• If you are not mounting below a TV, place

the Centre Line in the centre of the

installation area.

Centre Line

3. Push a pen tip or sharpened pencil tip

through the centre of the A-TYPE images on

each end of the Guide to mark the holes for

the supporting screws, and then remove the

Wall Mount Guide.

4. Using an appropriately sized drill bit, drill a

hole in the wall at each marking.

• If the markings do not correspond to the

positions of studs, make sure you insert

appropriate anchors or mollies into the

holes before you insert the support

screws. If you use anchors or mollies,

make sure the holes you drill are large

enough for the anchors or mollies you

use.

5. Push a screw (not supplied) through each

Holder-Screw, and then screw each screw

rmly into a support screw hole.

6. Install the 2 Bracket-Wall Mounts in the

correct orientation on the bottom of the

Soundbar using 2 Screws.

• When assembling, make sure the hanger

part of the Bracket-Wall Mounts are

located behind the rear of the Soundbar.

Rear of Soundbar

Right end of Soundbar

ENG - 37

7. Install the Soundbar with the attached

Bracket-Wall Mounts by hanging the

Bracket-Wall Mounts on the Holder-Screws

on the wall.

8. Slide the Soundbar down as shown below so

that the Bracket-Wall Mounts rest securely

on the Holder-Screws.

• Insert the Holder-Screws into the wide

(bottom) part of the Bracket-Wall

Mounts, and then slide the Bracket-Wall

Mounts down so that the Bracket-Wall

Mounts rest securely on the

Holder-Screws.

10 INSTALLING THE

SOUNDBAR

ABOVE A TV

STAND

Component

x 4

Rubber-Foot

To install, attach the Rubber-Feet to the bottom

of the Soundbar before placing it in position

above the TV stand. Make sure you attach the

Rubber-Feet so they do not lie outside the edges

of the TV stand. Refer to the gure below.

Rubber-Foot

ENG - 38

Place the Soundbar on a TV stand.

Microphone

As illustrated in the image, align the centre of the

Soundbar with the centre of the TV, carefully

place the Soundbar onto the TV stand.

At this time, place the microphone at the front of

the stand not to interfere with voice recognition.

Right end of Soundbar

NOTES

• Make sure the Soundbar is placed on a at

and solid surface.

• Insufcient gap from the TV may cause voice

recognition and acoustic problems.

11 SOFTWARE

UPDATE

Auto Update

When the Soundbar is connected to the Internet,

software updates automatically occur even when

the Soundbar is turned off.

• To use the Auto Update function, the

Soundbar must be connected to the Internet.

The Wi-Fi connection to the Soundbar will be

terminated if the Soundbar’s power cord is

disconnected or the power is cut off. If the

power is cut off, when the power comes back

on or you reconnect the power cord, turn on

the Soundbar, and then reconnect it to the

Internet.

USB Update

ID SET

HDMI IN 1

HDMI IN 2

POWER

NETWORK

SERVICE

DIGITAL AUDIO IN

(OPTICAL)

HDMI TO TV

(eARC/ARC)

HDMI 2

HDMI 1

ID SET

(WOOFER/REAR)

ID SET

(WOOFER,

REAR)

NETWORK

SERVICE

ID SET

Bottom of the Soundbar

Samsung may offer updates for the Soundbar’s

systemrmwareinthefuture.

When an update is available, you can update the

Soundbar by connecting the USB drive that

contains the update rmware to the SERVICE

port of the Soundbar.

ENG - 39

1. Go to the Samsung website

(www.samsung.com) → search for the model

name from the customer support menu

option.

• For more information about update, refer

to Upgrade Guide.

2. Download the upgrade le (USB type).

3. Unzip the le to create a folder with the le

name.

4. Store the created folder in a USB and then

connect it to the Soundbar.

5. Turn on the Soundbar. Then the product is

updated within 3 minutes with displaying the

message, “UPDATE”.

• During update, do not turn it off or

remove the USB.

• If “UPDATE” does not appear on the

display window, remove the power cord

from the Soundbar and then reconnect it.

• When the latest version is installed, no

update is performed.

• Depending on the USB type, update may

not be supported.

Initialisation

Top of the Soundbar

INIT

With the Soundbar on, press the (Volume)

buttons on the body at the same time for at least

5 seconds. “INIT” appears on the display and then

the Soundbar is initialised.

CAUTION

• All the settings of the Soundbar are

initialised. Be sure to perform this only when

initialisation is required.

ENG - 40

12 TROUBLESHOOTING

Before seeking assistance, check the following.

In case the power is not turned on

; Check whether the power cord of the

Soundbar is correctly inserted into the

outlet.

In case the functions do not work properly

; After removing the power cord, insert it

again.

; Remote the power cord from the external

device and try again.

; If there is no signal, the Soundbar

automatically turns off after a certain

period of time. Turn on the power. (See

page 10.)

In case the remote control does not work

; Operate the remote control noting the

Soundbar closely.

; Replace the batteries with new ones.

In case the Soundbar sound is not output

; The volume of the Soundbar is too low or

muted. Adjust the volume.

; When any external device (STB, Bluetooth

device, mobile device, etc.) is connected,

adjust the volume of the external device.

; For sound output of the TV, select

Soundbar. (Samsung TV: Home ( ) →

Settings ( ) → Sound → Sound Output →

Select Soundbar)

; The cable connection to the Soundbar may

not be loose. Remove the cable and

connect again.

; Remove the power cord completely,

reconnect, and turn the power on.

; Initialise the product and try again.

(See page 39.)

In case the sound of the Subwoofer speaker is

not output

; Check whether the LED indicator on the

rear of the Subwoofer is on in blue.

Reconnect the Soundbar and Subwoofer if

the indicator is blinking in blue or turned

red. (See page 16.)

; You may experience an issue if there is an

obstacle between the Soundbar and

Subwoofer. Move devices to an area away

from obstacles.

; Other devices sending radio frequency

signals in proximity may interrupt the

connection.

Keep your speaker away from such devices.

; Remove and reconnect the power plug.

The Subwoofer volume is too low

; The original volume of the content you are

playing may be low. Try adjusting the

Subwoofer level. (See page 12.)

; Bring the Subwoofer speaker closer to you.

ENG - 41

In case the TV is not connected via HDMI TO

TV (eARC/ARC)

; Check whether the HDMI cable is correctly

connected to the ARC terminal.

(See page21.)

; Connection may not be possible due to the

connected external device (set-top box,

game machine, etc.). Directly connect the

Soundbar.

; HDMI-CEC may not be activated on the TV.

Turn on the CEC on the TV menu. (Samsung

TV: Home ( ) → Settings ( ) → General

→ External Device Manager → Anynet+

(HDMI-CEC) ON)

There is no sound in when connecting to the

TV in HDMI TO TV (eARC/ARC) mode

; Your device is unable to play the input

signal. Change the TV’s audio output to

PCM or Dolby Digital.

(For a Samsung TV: Home ( ) → Settings

( ) → Sound → Expert Settings → Digital

Output Audio Format)

In case Bluetooth connection is not possible

; When connecting a new device, switch to

“BT PAIRING” for connection. (Press the

PAIR button on the remote control or

press the (Mic On/Off) button on the

body for at least 5 seconds.)

; If the Soundbar is connected to another

device, disconnect that device rst to

switch the device.

; Reconnect it after removing the Bluetooth

speaker list on the device to connect.

(Samsung TV: Home ( ) → Settings ( )

→ Sound → Sound Output → Bluetooth

Speaker List)

; The automatic TV connection may be

disabled. While the Soundbar is in “BT

READY”, press and hold the p button on

the Soundbar remote control for 5 seconds

to select ON-TV CONNECT. If you see

OFF-TV CONNECT, press and hold p button

again for 5 seconds to switch the selection.

; Remove and reconnect the power plug,

then try again.

; Initialise the product and try again.

(See page 39.)

In case Bluetooth sound breaking occurs

; Sounds may be breaking due to

interference by radio frequency or

electronic devices nearby. Keep such

devices away from the Soundbar to avoid

radio interference. Example: microwave

ovens.

; Because the device to connect is far away

from the Soundbar, sound breaking may

occur. Move the device near the Soundbar.

; If a part of your body is in contact with the

Bluetooth transceiver or the product is

installed on metal furniture, sound

breaking may occur. Check the installation

environment and conditions for use.

In case Wi-Fi connection is not possible

; Check whether your wireless router is on.

; Turn off the router, turn it back on, and then

try again.

; When the signal of the wireless router is

too weak, connection may not be possible.

Move the router near the Soundbar or

adjust the installed position with no

obstacles.

; If your wireless router is new, you will need

to recongure the speaker’s network

settings.

ENG - 42

In case Alexa does not respond

When the microphone is turned off or its

reception is poor

; Press the (Mic On/Off) button at the top

of the Soundbar to enable the microphone.

; Voice recognition may be unavailable due

to ambient noise. Reduce the noise and try

again.

When the network is disconnected

; The network may be unavailable.

Recongure the network. (See page 31)

WhenAlexaisnotconguredcorrectly

; Using the SmartThings app, recongure

Alexa. (See page 32)

; Check the Alexa supported countries at the

Amazon website. The service is unavailable

in those countries.

In case the Soundbar is not turned on as soon

as the TV is turned on

; When you turn off the Soundbar while

watching TV, power synchronization with

the TV is disabled. First turn off the TV.

13 LICENCE

Manufactured under license from Dolby

Laboratories. Dolby, Dolby Atmos, Dolby Audio,

Dolby Digital Plus, Pro Logic, and the double-D

symbol are trademarks of Dolby Laboratories.

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, the Symbol, & DTS and the Symbol

together, DTS:X, and the DTS:X logo are

registered trademarks and/or trademarks of

DTS, Inc. in the United States and/or other

The terms HDMI and HDMI High-Denition

Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other

countries.

• The Spotify Software is subject to third

party licenses found here :

www.spotify.com/connect/third-party-

licenses.

• For more information about Spotify

Connect, please visit www.spotify.com/

connect

ENG - 43

14 OPEN SOURCE

LICENCE NOTICE

To send inquiries and requests for questions

regarding open sources, contact Samsung Open

Source (http://opensource.samsung.com)

15 IMPORTANT

NOTES ABOUT

SERVICE

• Figures and illustrations in this User Manual

are provided for reference only and may differ

from actual product appearance.

• An administration fee may be charged if

either

(a) an engineer is called out at your request

and there is no defect with the product (i.e.

where the user manual has not been read).

(b) you bring the unit to a repair centre and

there is no defect with the product (i.e.

where the user manual has not been read).

• You will be informed of the administration fee

amount before a technician visits.

ENG - 44

16 SPECIFICATIONS AND GUIDE

Specications

Model Name HW-Q900T

Weight 7.1 kg

Dimensions (W x H x D) 1232.0 x 69.5 x 138.0 mm

Operating Temperature Range +5°C to +35°C

Operating Humidity Range 10 % ~ 75 %

AMPLIFIER

Rated Output power (18W x 6) + (10W x 3) + (18W x 6) + 160W

Supported play formats

Dolby Atmos (True HD / Digital Plus), Dolby Digital,

DTS Master Audio, DTS:X, DTS

WIRELESS DEVICE OUTPUT POWER

Wi-Fi max transmitter power

100mW at 2.4GHz – 2.4835GHz, 200mW at 5.15GHz

– 5.25GHz, 100mW at 5.25GHz – 5.35GHz & 5.47GHz

– 5.725GHz

WIRELESS DEVICE OUTPUT POWER

BT max transmitter power

100mW at 2.4GHz – 2.4835GHz

WIRELESS DEVICE OUTPUT POWER

SRD max transmitter power

25mW at 5.725GHz – 5.825GHz

Subwoofer Name PS-WR75BK

Weight 9.8 kg

Dimensions (W x H x D) 210.0 x 403.0 x 403.0 mm

AMPLIFIER

Rated Output power 160W

WIRELESS DEVICE OUTPUT POWER

SRD max transmitter power

25mW at 5.725GHz – 5.825GHz

ENG - 45

NOTES

• Samsung Electronics Co., Ltd reserves the right to change the specications without notice.

• Weight and dimensions are approximate.

Precaution : The Soundbar will restart automatically if you turn on/turn off Wi-Fi.

Overall Standby Power

Consumption (W)

5.2W

Wi-Fi

Port deactivation method

Press the ID SET button on the bottom panel of the Soundbar for

30 seconds to turn Wi-Fi On / Off.

Bluetooth

Port deactivation method

Press the NETWORK button on the bottom panel of the Soundbar

for 30 seconds to turn Bluetooth On / Off.

• Hereby, Samsung, declares that this equipment is in compliance with Directive

2014/53/EU.

The full text of the EU declaration of conformity is available at the following

internet address: http://www.samsung.com go to Support > Search Product

Support and enter the model name.

This equipment may be operated in all EU countries.

The 5GHz WLAN(Wi-Fi or SRD) function of this equipment may only be operated

indoors.

ENG - 46

[Correct disposal of batteries in this product]

(Applicable in countries with separate collection systems)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be

disposed of with other household waste at the end of their working life. Where marked, the chemical

symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference

levels in EC Directive 2006/66.

If batteries are not properly disposed of, these substances can cause harm to human health or the

environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of

waste and recycle them through your local, free battery return system.

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic

accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the

end of their working life. To prevent possible harm to the environment or human health from uncontrolled

waste disposal, please separate these items from other types of waste and recycle them responsibly to

promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local

government ofce, for details of where and how they can take these items for environmentally safe

recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

For information on Samsung’s environmental commitments and product specic regulatory obligations

e.g. REACH, WEEE, Batteries, visit:

www.samsung.com/uk/aboutsamsung/sustainability/environment/our-commitment/data/

This Samsung product is warranted for the period of

twelve (12) months from the original date of purchase,

against defective materials and workmanship. In the

event that warranty service is required, you should return

the product to the retailer from whom it was purchased.

However, Samsung Authorised Dealers and Authorised

Service Centres in other EC Countries will comply with

the warranty on the terms issued to purchasers in the

country concerned. In case of difculty, details of our

Authorised Service Centres are available from:

Samsung Electronics U.K. Ltd

Samsung Customer Support Centre

Selectapost38,Shefeld,S973FJ

United Kingdom

Tel : 0333 000 0333

www.samsung.com/uk/support

EIRE

Tel : 0818 717100

www.samsung.com/ie/support

@ WARRANTY CONDITIONS

1. The warranty is only valid if, when warranty

service is required, the warranty card is fully

and properly completed and is presented with

the original invoice or sales slip or conrmation,

and the serial number on the product has not

been defaced.

2. Samsung’s obligations are limited to the repair

or, at its discretion, replacement of the product

or the defective part.

3. Warranty repairs must be carried out by

Authorised Samsung Dealers or Authorised

Service Centres. No re-imbursement will be

made for repairs carried out by non Samsung

Dealers and, any such repair work and damage

to the products caused by such repair work will

not be covered by this warranty.

4. This product is not considered to be defective

in materials nor workmanship by reason that it

requires adaptation in order to conform to

national or local technical or safety standards

in force in any Country other than the one for

which the product was originally designed and

anufactured.

This warranty will not cover, and no

re-imbursement will be made for such adaptation

nor any damage which may result

5. This warranty covers none of the following:

Periodic check ups, maintenance and repair or

replacement of parts due to normal wear and

tear.

b) Cost relating to transport, removal or

installation of the product.

c) Misuse, including the failure to use this

product for its normal purposes or incorrect

installation.

d) Damage caused by Lightning, Water, Fire,

Acts of God, War, Public Disturbances,

incorrect mains voltage, improper

ventilation or any other cause beyond the

control of Samsung.

6. This warranty is valid for any person who

legally acquired possession of the product

during the warranty period.

7. The consumers statutory rights in any

applicable national legislation whether against

the retailer arising from the purchase contract

or otherwise are not affected by this warranty.

Unless there is national legislation to the

contrary, the rights under this warranty are the

consumers sole rights and Samsung, its

subsidiaries and distributors shall not be liable

for indirect or consequential loss or any

damage to records, compact discs, videos or

audio taper or any other related equipment or

material.

SAMSUNG ELECTRONICS (U.K.) LTD.

-2-

UNITED KINGDOM

EIRE

This Samsung product is warranted for the period of twelve (12) months from the origi-

nal date of purchase, against defective materials and workmanship. In the event that

warranty service is required, you should return the product to the retailer from whom it

was purchased. However, Samsung Authorised Dealers and Authorised Service Centres

in other EC Countries will comply with the warranty on the terms issued to purchasers in

the country concerned. In case of difficulty, details of our Authorised Service Centres are

available from:

Samsung Electronics U.K. Ltd. Customer Care CentrePO Box 479

GATESHEAD NE9 9BJ United Kingdom

United Kingdom

Tel : 0330 SAMSUNG (7267864)

Fax: 03307260001

www.samsung.com

Eire

Tel : 0818 717100

Fax: +44 117 915 6736

www.samsung.com

■WARRANTY CONDITIONS

The warranty is only valid if, when warranty service is required, the warranty card is fully

and properly completed and is presented with the original invoice or sales slip or confir-

mation, and the serial number on the product has not been defaced.

Samsung’s obligations are limited to the repair or, at its discretion, replacement of

the product or the defective part.

3. Warranty repairs must be carried out by Authorised Samsung Dealers or

Authorised Service Centres. No re-imbursement will be made for repairs carried

out by non Samsung Dealers and, any such repair work and damage to the prod-

ucts caused by such repair work will not be covered by this warranty.

This product is not considered to be defective in materials nor workmanship by

reason that it requires adaptation in order to conform to national or local technical

or safety standards in force in any Country other than the one for which the product

was originally designed and manufactured. This warranty will not cover, and no re-

imbursement will be made for such adaptation nor any damage which may result.

5. This warranty covers none of the following:

a) Periodic check ups, maintenance and repair or replacement of parts due to

normal wear and tear.

Cost relating to transport, removal or installation of the product.

Misuse, including the faiure to use this product for its normal

purposes or incorrect installation.

Damage caused by Lightning, Water, Fire, Acts of God, War, Public

Disturbances, incorrect mains voltage, improper ventilation or any other cause

beyond the control of Samsung.

6. This warranty is valid for any person who legally acquired

possession of the product during the warranty period.

The consumers statutory rights in any applicable national legislation

whether against

the retailer arising from the purchase contract or otherwise are not affected by this

warranty. Unless there is national legislation to the contrary, the rights under this

warranty are the

consumers sole rights and Samsung, its subsidiaries and distribu-

tors shall not be liable for indirect or consequential loss or any damage to records,

compact discs, videos or audio taper or any other related equipment or material
