Owner’s Manual
Digital Wireless Stereo Headphones
Model No. RP-HTX80B
Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
TQBM0152-2
until
2017/9/7
2
IMPORTANT SAFETY
INSTRUCTIONS
Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and
the applicable safety instructions listed below. Keep these operating instructions handy for future reference.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when unused for long periods of
time.
14 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
3
Safety precautions
For the U.S.A. and Canada only
A lithium ion battery that is recyclable powers the product you have purchased.
Please call 1-800-8-BATTERY for information on how to recycle this battery.
THE FOLLOWING APPLIES ONLY IN THE U.S.A. AND CANADA.
This device complies with Part 15 of FCC Rules and Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of
this device.
FCC ID: ACJ-RP-HTX80B
Model: RP-HTX80B
IC: 216A-RPHTX80B
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and
meets the FCC radio frequency (RF) Exposure
Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels
of RF energy that is deemed to comply without testing of specific absorption ratio (SAR).
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this
device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact: http://shop.panasonic.com/support
THE FOLLOWING APPLIES ONLY IN CANADA.
CAN ICES-3(B)/NMB-3(B)
4
∫Unit
• Avoid using or placing this unit near sources of heat.
• Do not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many areas.
• Do not listen with this unit at high volume in places where you need to hear sounds from the surrounding
environment for safety, such as at railroad crossings, and construction sites.
• Certification information can be found on the right side of the headphones. Remove the right earpad to see it.
∫Allergies
• Discontinue use if you experience discomfort with the earpads or any other parts that directly contact your
skin.
• Continued use may cause rashes or other allergic reactions.
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not expose this unit to rain, moisture, dripping or splashing.
• Do not place objects filled with liquids, such as vases, on this unit.
• Use the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to qualified service personnel.
This unit may receive radio interference caused by mobile telephones during use. If such interference occurs,
please increase separation between this unit and the mobile telephone.
This unit is intended for use in moderate and tropical climates.
3123480
CONFORMS TO
UL STD. 62368-1
CERTIFIED TO CSA STD.
C22.2 NO. 62368-1
CONFORME À LA NORME CAN/CSA
C22.2 NO. 62368-1
5
About Bluetooth
®
∫Frequency band used
This unit uses the 2.4 GHz frequency band.
∫Certification of this unit
• This unit conforms to frequency restrictions and has received certification based on frequency laws. Thus, a
wireless permit is not necessary.
• The actions below are punishable by law in some countries:
– Taking apart/modifying this unit.
– Removing specification indications.
∫Restrictions of use
• Wireless transmission and/or usage with all Bluetooth
®
equipped devices is not guaranteed.
• All devices must conform to standards set by Bluetooth SIG, Inc.
• Depending on the specifications and settings of a device, it can fail to connect or some operations can be
different.
• This unit supports Bluetooth
®
security features. But depending on the operating environment and/or settings,
this security may not be sufficient. Transmit data wirelessly to this unit with caution.
• This unit cannot transmit data to a Bluetooth
®
device.
∫Range of use
Use this unit at a maximum range of 10 m (33 feet).
The range can decrease depending on the environment, obstacles or interference.
∫Interference from other devices
• This unit may not function properly and troubles such as noise and sound jumps may arise due to radio wave
interference if this unit is located too close to other Bluetooth
®
devices or the devices that use the 2.4 GHz
band.
• This unit may not function properly if radio waves from a nearby broadcasting station, etc. is too strong.
∫Intended usage
• This unit is for normal, general use only.
• Do not use this system near an equipment or in an environment that is sensitive to radio frequency
interference (example: airports, hospitals, laboratories, etc).
Panasonic bears no responsibility for data and/or information that is compromised during a wireless
transmission.
6
Table of contents
IMPORTANT SAFETY INSTRUCTIONS .................................................................................................... 2
Safety precautions ...................................................................................................................................... 3
About Bluetooth
®
......................................................................................................................................... 5
Before use
Accessories................................................................................................................................................. 7
Maintenance................................................................................................................................................ 7
Part names.................................................................................................................................................. 8
Preparation
Charging...................................................................................................................................................... 9
Turning the power on/off ............................................................................................................................. 9
Connecting a Bluetooth
®
device................................................................................................................ 10
• Pairing (Registration) this unit with the Bluetooth
®
device for connection ..........................................10
• Connecting a paired Bluetooth
®
device ...............................................................................................11
Operation
Listening to music ..................................................................................................................................... 12
• Remote controlling.............................................................................................................................. 12
Making a phone call .................................................................................................................................. 13
Useful functions......................................................................................................................................... 14
• Activating a voice control function ...................................................................................................... 14
• Resetting the unit ............................................................................................................................... 14
• Auto power off .................................................................................................................................... 14
• Battery level notification...................................................................................................................... 14
Other
Restoring to the factory settings................................................................................................................ 15
Copyright, etc. ........................................................................................................................................... 15
Troubleshooting......................................................................................................................................... 16
• General............................................................................................................................................... 16
• Power supply and charging ................................................................................................................ 16
• Bluetooth
®
device connection .............................................................................................................16
• Sound and audio volume.................................................................................................................... 16
• Phone Calls ........................................................................................................................................ 17
Specifications ............................................................................................................................................ 18
To remove the battery when disposing of this unit .................................................................................... 19
Before use
7
Accessories
Please check and identify the supplied accessories.
Only for U.S.A.:
To order accessories, refer to “Limited Warranty (ONLY FOR U.S.A.)” on “Basic Owner’s Manual”.
Only for Canada:
To order accessories, contact the dealer from whom you have made your purchase.
Maintenance
Clean this unit with a dry and soft cloth.
• Do not use solvents including benzine, thinner, alcohol, kitchen detergent, a chemical wiper, etc. This might cause the
exterior case to be deformed or the coating to come off.
Expressions used in this document
• Pages to be referred to are indicated as “l ±±”.
• The product illustrations may differ from the actual product.
∏ 1 x USB charging cord
Before use
8
Part names
*1 Í/I: Standby/ON
*2 Hereafter referred to as “LED”
*3 Examples of lighting/blinking patterns
*4 The battery is low when it is blinking in red. (
l 14, “Battery level notification”)
Note
• Do not use any other USB charging cords except the supplied one.
• When using the unit, do not cover the right speaker with the palm of your hand. The Bluetooth
®
connection may be
blocked.
1[–(:)] button
2 [ ] button
3[+(9)] button
4 Charging terminal (DC IN)
• Connect the USB charging cord (supplied) to this
terminal when charging. (
l 9)
5 Microphone
6[Í/I ( )] button
*1
7 LED indicator light
*2*3
A Raised dot indicating the left side
B This allows you to adjust the housing position of
the headphones.
Lighting (red): Charging is in progress
Blinking alternately in blue and red: Bluetooth
®
pairing (registration) standby
Blinking slowly (blue)
*4
:Bluetooth
®
connection standby
Blinking twice about every 2 seconds
(blue)
*4
:
A Bluetooth
®
pairing (registration) has been established or a call is in
progress
Blinking (blue)
*4
: A call is being received
321
4
5
6
7
Right (R) side
Preparation
9
Charging
The rechargeable battery (installed in the unit) is not charged initially. Charge the battery before using the unit.
Connect this unit to a computer using the
USB charging cord.
• The LED lights in red when charging is in progress.
When charging is completed, the LED will go out.
• Charging will take approximately 3.5 hours from
empty state to fully charged.
Note
• The Bluetooth
®
feature cannot be used when this unit is connected to a computer using the USB charging cord.
• Charge in a room temperature between 10 oC and 35 oC (50 oF and 95 oF). Outside of this temperature range,
charging may stop and the LED may go out.
• The power cannot be turned on while charging.
• Do not use any other USB charging cords except the supplied one.
Turning the power on/off
In the power-off state, press and hold [Í/I ( )] of this unit for
approx. 3 seconds until the LED (blue) blinks.
• A beep will sound, and the LED (blue) will blink slowly.
∫ To turn the power off
Press and hold [Í/I ( )] for approximately 3 seconds. A beep will sound
and the power will be turned off.
Note
• When the unit is not operated for approximately 5 minutes, the power will automatically turn off. (l 14, “Auto power
off”)
A
:LED
B
: USB charging cord (supplied)
• Check the direction of the terminals and plug in/out
straight holding onto the plug. (It may result in
malfunction by the deforming of the terminal if it is
plugged in obliquely or in wrong direction.)
C
: Computer
Caution: Use only the supplied USB charging cord when connecting to a computer.
A
B
C
LED
[Í/I ( )]
Preparation
10
Connecting a Bluetooth
®
device
1 In the power-off state, press and hold [Í/I ( )] of this unit until the LED blinks.
• The unit starts to search for the Bluetooth
®
device for connection, and the LED will blink in blue and red
alternately.
2 Turn on the power of the Bluetooth
®
unit, and enable the Bluetooth
®
function.
3 Select “RP-HTX80B” from the Bluetooth
®
device’s menu.
• A MAC address (an alphanumeric character string that is displayed by
and unique to the device) may be displayed before “RP-HTX80B” is
displayed.
• If prompted for a passkey, input the passkey “0000 (four zeros)” of this
unit.
4 Check the connection with the Bluetooth
®
device on the
unit.
• The LED will blink in blue and red alternately until the connection with the device is completed. When the LED
(blue) blinks twice every approx. 2 seconds, pairing (registration) is completed. (Connection established)
Note
• If connection to a device is not established within approximately 5 minutes, the unit will be turned off. Perform pairing
again.
• You can pair up to 8 Bluetooth
®
devices with this unit. If a 9th device is paired, the device with the oldest connection
will be replaced. To use it, perform pairing again.
Preparation
• Place the Bluetooth
®
device within approx. 1 m (3.3 feet) from the unit.
• Check the device operation using its operation instructions as required.
Pairing (Registration) this unit with the Bluetooth
®
device for connection
When pairing a device for the first time: approx. 3 seconds
When pairing a second or subsequent devices: approx. 5 seconds
Bluetooth
Bluetooth ON
RP-HTX80B
Device
e.g.
Select
Preparation
11
1 Turn on this unit.
• Press and hold [Í/I ( )] of this unit for approx. 3 seconds until the LED (blue) blinks.
• A beep will sound, and the LED (blue) will blink slowly.
2 Perform steps 2 and 3 of “Pairing (Registration) this unit with the Bluetooth
®
device for
connection”. (
l 10)
• When the LED (blue) blinks twice every approx. 2 seconds, pairing (registration) is completed. (Connection
established)
Note
• This unit remembers the device lastly connected. Connection may be automatically established after step 1 (see
above).
• If connection to a device is not established within approximately 5 minutes, the unit will be turned off. Turn on the unit
again.
Connecting a paired Bluetooth
®
device
Operation
12
Listening to music
If the Bluetooth
®
compatible device supports the “A2DP” and “AVRCP” Bluetooth
®
profiles, music can be
played back with remote control operations on the unit.
• A2DP (Advanced Audio Distribution Profile): Transmits audio to the unit.
• AVRCP (Audio/Video Remote Control Profile): Allows remote control of the device using the unit.
1 Connect the Bluetooth
®
device and the unit. (l 10, “Connecting a Bluetooth
®
device”)
2 Select and play the music on the Bluetooth
®
device.
• The selected music is output to the speakers of the unit.
• Operating time:
The maximum playback time is approximately 6 hours. (It may become shorter depending on the usage
conditions.)
∫ Attention
• The unit might leak sound depending on the volume level.
• When the volume is increased to near maximum level, music may sound distorted. Decrease the volume until the
distortion is cleared.
You can control the Bluetooth
®
device using the unit.
• Depending on the Bluetooth
®
device or the app, even if you press buttons on the unit, some functions may not
respond or may operate differently from the descriptions below.
(Operation example)
Note
• The volume can be adjusted in 16 levels. When the maximum or minimum volume is reached, a beep will sound.
Remote controlling
Function Operation
Play / Pause Press [ ].
Increase the volume Press [+ (9)].
Decrease the volume Press [– (:)].
Forward to the start of next
track
Press and hold [+ (9)] for approximately
2 seconds.
Return to the start of current
track
Press and hold [– (:)] for approximately
2 seconds.
Operation
13
Making a phone call
With Bluetooth
®
enabled phones (cell phones or smartphones) that support the “HSP” or “HFP” Bluetooth
®
profile, you can use the unit for phone calls.
• HSP (Headset Profile):
This profile can be used to receive monaural sounds and establish two-way communication using the
microphone on the unit.
• HFP (Hands-Free Profile):
In addition to the HSP functions, this profile has the incoming and outgoing calls function.
(This unit does not have a function that allows you to make phone calls independently of a Bluetooth
®
enabled
phone.)
1 Connect the Bluetooth
®
device and the unit. (l 10, “Connecting a Bluetooth
®
device”)
2 Press [ ] on the unit and answer the incoming call.
• During an incoming call, ringtone will sound from the speaker and the LED
will blink.
• (HFP only) To reject the incoming call, press [ ] twice quickly.
3 Start talking.
• The LED will repeatedly blink 2 times during a call.
• The volume can be adjusted during a phone call. For setting instructions, see page 12.
4 Press [ ] to end the phone call.
• A beep will sound.
Note
• There may be instances when hands free setting needs to be done on the Bluetooth
®
enabled phone.
• Depending on the Bluetooth
®
enabled phone, you may hear incoming and outgoing call ringtones of the phone from
the unit.
• (HFP only) The calling device will be switched between the Bluetooth
®
enabled phone and the unit. (Press [ ]
on the unit twice quickly to switch.)
• You can have the Bluetooth
®
enabled phone make phone calls by using the microphone of the unit and an app of the
Bluetooth
®
enabled phone. (l 14, “Activating a voice control function”)
[]
Operation
14
Useful functions
You can activate the voice control function of your Bluetooth
®
device (smartphone, etc.) and control the device
by speaking to the microphone of the unit.
1 Connect the Bluetooth
®
device and the unit. (l 10, “Connecting a Bluetooth
®
device”)
2 Press and hold [ ] of this unit for approx. 3 seconds.
• The voice control app on the Bluetooth
®
device will be activated.
Note
• For details about voice control commands, refer to the operating instructions for the Bluetooth
®
device.
• Depending on the device, a voice control function may not be available.
This unit can be reset when all operations are rejected. To reset the unit, press and hold [Í/I ( )] for
10 seconds or more. All the previous operations will be canceled. (The pairing device information will not be
deleted.)
If the unit is not connected to a Bluetooth
®
device, the unit will beep and turn off automatically approximately
5 minutes after you have stopped using it.
When the battery level is low during use of the unit, the blue blinking LED will change to red. A beep will sound
every 1 minute. When the battery runs out, the power will turn off.
Activating a voice control function
Resetting the unit
Auto power off
Battery level notification
Other
15
Restoring to the factory settings
When you want to delete all pairing device information, etc., you can restore the unit to the factory settings
(original settings upon purchase). Charge the battery before restoring the unit.
1 While the unit is turned off, press and hold [Í/I ( )] for at least 5 seconds until the LED
starts blinking alternately in blue and red.
2 While the LED is blinking alternately in blue and red, press and hold [+ (9)] and
[– (:)] at the same time for at least 5 seconds.
• The default settings will be restored after the LED (blue) blinks fast and the unit turns off.
∫ Attention
• When pairing a device again, delete the registering information (Device: “RP-HTX80B”) from the Bluetooth
®
device’s
menu, and register this unit with the Bluetooth
®
device again. (l 10)
Copyright, etc.
The Bluetooth
®
word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any
use of such marks by Panasonic Corporation is under license.
Other trademarks and trade names are those of their respective owners.
Other system names and product names appearing in this document are in general the registered
trademarks or trademarks of the respective developer companies.
Note that the
TM
mark and ® mark do not appear in this document.
Other
16
Troubleshooting
Before requesting service, make the following checks. If you are in doubt about some of the check points, or if
the remedies indicated in the chart do not solve the problem, refer to “Customer Services Directory” on “Basic
Owner’s Manual” if you reside in the U.S.A., or refer to “CONTACT INFORMATION” on “Basic Owner’s Manual”
if you reside in Canada.
The unit does not respond.
• This unit can be reset when all operations are rejected. To reset the unit, press and hold [Í/I ( )] for 10 seconds or
more. (
l 14)
Cannot charge the unit.
• Make sure the computer is turned on and is not on standby or sleep mode.
• Is the USB port you are currently using working properly? If your computer has other USB ports, unplug the connector
from its current port and plug it into one of the other ports.
• If the measures mentioned above are not applicable, unplug the USB charging cord and plug it in again.
• If the charge time and operating time become shortened, the battery may have run down. (Number of charging times
of the installed battery: Approximately 300.)
LED does not light during charging. / Charging takes longer.
• Is the USB charging cord (supplied) connected firmly to the USB terminal of the computer? (l 9)
• Make sure to charge in a room temperature between 10 oC and 35 oC (50 oF and 95 oF).
The power does not turn on.
• Is the unit being charged? The power cannot be turned ON during charging. (l 9)
The device cannot be connected.
• Delete the pairing information for this unit from the Bluetooth
®
device, then pair them again. (l 10)
No sound.
• Make sure that the unit and the Bluetooth
®
device are connected correctly. (l 10)
• Check if music is playing on the Bluetooth
®
device.
• Make sure that the unit is turned on and the volume is not set too low.
• Pair and connect the Bluetooth
®
device and the unit again. (l 10)
• Check if the Bluetooth
®
compatible device supports “A2DP” profile. For details on profiles, see “Listening to music”
(
l 12). Also refer to the operating manual for the Bluetooth
®
compatible device.
Low volume.
• Increase the volume of the unit. (l 12)
• Increase the volume on the Bluetooth
®
device.
General
Power supply and charging
Bluetooth
®
device connection
Sound and audio volume
Other
17
Sound from the device is cut off. / Sound quality is bad.
• Sound may be disrupted if signals are blocked. Do not fully cover this unit with the palm of your hand, etc.
• The device may be out of the 10 m (33 feet) communication range. Move the device closer to this unit.
• Remove any obstacle between this unit and the device.
• Switch off any wireless LAN device when not in use.
• A communication problem may arise if the battery is not fully charged. Charge the unit. (
l 9)
You cannot hear the other person.
• Make sure that the unit and the Bluetooth
®
enabled phone are turned on.
• Check if the unit and the Bluetooth
®
enabled phone are connected. (l 10)
• Check the audio settings of the Bluetooth
®
enabled phone. Switch the calling device to the unit if it is set to the
Bluetooth
®
enabled phone. (l 10)
• If the volume of the other person’s voice is too low, increase the volume of both the unit and the Bluetooth
®
enabled
phone.
Cannot make a phone call.
• Check if the Bluetooth
®
compatible device supports “HSP” or “HFP” profile. For details on profiles, see “Listening to
music” (
l 12) and “Making a phone call” (l 13). Also refer to the operating manual for the Bluetooth
®
enabled
phone.
Phone Calls
Other
18
Specifications
∫ General
*1 It may be shorter depending on the operating conditions.
*2 Time taken to recharge from empty to full.
∫ Bluetooth
®
section
∫ Speaker section
∫ Terminal section
∫ Microphone section
∫ Accessory section
• Specifications are subject to change without notice.
Power supply DC 5 V, 500 mA
(Internal battery: 3.7 V (Li-polymer 430 mAh))
Operating time
*1
Approx. 24 hours
Charging time
*2
(25 oC (77 oF)) Approx. 3.5 hours
Charging temperature range 10 oC to 35 oC (50 oF to 95 oF)
Operating temperature range 0 oC to 40 oC (32 oF to 104 oF)
Operating humidity range 35%RH to 80%RH (no condensation)
Mass (Weight) Approx. 190 g (6.7 oz)
Bluetooth
®
system specification Ver. 4.1
Wireless equipment classification Class 2 (2.5 mW)
Frequency band 2402 MHz to 2480 MHz
Max RF power 4dBm
Supported profiles A2DP, AVRCP, HSP, HFP
Supported codec SBC
Operating distance Up to 10 m (33 ft.)
Driver units 40 mm (1 - 9/16 inch)
DC IN DC 5 V, 500 mA
Type Mono
USB charging cord 0.5 m (1.5 ft.)
Other
19
To remove the battery when disposing of this unit
• Disassemble after the battery runs out.
• Keep disassembled parts out of reach of children.
Regarding the handling of used batteries
• Insulate the terminals with adhesive tape or similar material.
• Do not disassemble.
∫ Batteries
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with doors and
windows closed.
• Battery mishandling can cause electrolyte leakage which can damage items the leaked fluid comes into
contact with. If electrolyte leaks from the battery, consult your dealer. Wash thoroughly with water if electrolyte
comes in contact with any part of your body.
• When disposing of the batteries, please contact your local authorities or dealer and ask for the correct method
of disposal.
1 Remove the left ear pad.
2 Remove the 4 screws, and lift and flip the part A.
3 Cut off the wires one by one with scissors, and remove the battery.
The following instructions are not intended for repairing purposes but for the disposal of this unit.
This unit is not restorable once disassembled.
• When disposing of this unit, take out the battery installed in this unit and recycle it.
12
3
Two Riverfront Plaza, Newark, NJ 07102-5490
Panasonic Corporation of North America
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
www.panasonic.com
http://shop.panasonic.com
Panasonic Corporation 2017
Panasonic Corporation
http://www.panasonic.com
TQBM0152-2
F1017HA2030
