User Manual Haier QNE27JSMSS - 36 Inch French Door Refrigerator

• Owner's manual - (English, French, Spanish)

• Spec sheet - (English)

User manual Refrigerator for Haier QNE27JSMSS

Table of contents

• RECORD KEEPING
• REFRIGERATOR SAFETY
• Proper Disposal of Your Old Refrigerator
• PARTS AND FEATURES
• INSTALLATION REQUIREMENTS
• Location Requirements
• Clearances
• INSTALLATION INSTRUCTIONS
• Preparing to Install the Refrigerator
• Appliance Dimensions
• Installing the Water Line
• Installing the Refrigerator
• Completing Installation
• REFRIGERATOR USE
• Controls
• Sabbath Mode
• REFRIGERATOR CARE
• Cleaning
• Vacation and Moving
• Replacing the Lights
• TROUBLESHOOTING
• XWF WATER FILTER CARTRIDGE
• PERFORMANCE DATA SHEET
• LIMITED WARRANTY

REHANGING THE RIGHT DOOR

• Lower the refrigerator door onto the right hinge pin.
• Make sure the door is aligned with the cabinet. Attach the hinge to the top of the cabinet loosely with bolts removed earlier.
• Replace the right hinge cover on top of the refrigerator using a Phillips screwdriver.

REHANGING THE LEFT DOOR

• Pass the wire through the slot in the hinge. Place the hinge pin into the top of the door.
• Lower the refrigerator door onto the left hinge pin.
• Make sure the door is aligned with the cabinet. Attach the hinge to the top of the cabinet loosely with bolts removed earlier.
• Plug the wire connectors together and rout the wire inside the plastic port.
• Replace the left hinge cover on top of the refrigerator using a Phillips screwdriver.

REMOVE THE BASKETS

• Open the freezer drawer until it stops.
• Pull the top basket out until it stops. Lift the basket up on the front and out to remove.
• The lower basket rests on a frame inside the freezer drawer. Lift the front of the basket and pull it forward. Release the pins from the slots on the frame to remove the basket.

REMOVE THE DRAWER FRONT

• Remove the screw on each side of the railing.
• Lift up on both sides of the freezer drawer handle to separate the drawer railings from the rail assemblies.
• Set the drawer front on a non-scratching surface.
• Push the rail assemblies back into locking position.

REINSTALL FREEZER DRAWER FRONT

• Pull the rail assemblies to the maximum extension.
• Locate the slots on the inside of each slide.
• Insert the hooks on the ends of the drawer assembly extensions into the slots near the back of the slides.
• Replace the safety screws in both sides of the slide assemblies.
• Replace lower and upper baskets (see Freezer Drawer).

INSTALLING THE FILTER IN A BOTTOM FREEZER REFRIGERATOR

• Open the filter cartridge housing by squeezing the 2 front tabs and gently pulling down.
• Line up the ports on the filter with the ports on the filter cartridge holder, and gently insert the filter.
• Slowly turn the filter to the right until it stops. DO NOT OVERTIGHTEN. As you turn the filter, it will automatically adjust itself into position. The filter will move about a 1⁄4 turn or 90 degrees, until the arrow on the filter aligns with the arrow on the filter cartridge holder.
• Slowly push the filter up into the clips.
• Close the filter cartridge housing by gently pushing the lid upwards until the tabs lock into place.
• Run water from the dispenser for 2 gallons (7.6 liters) or approximately 5 minutes to clear the system. Water may spurt out and air bubbles may be visible during this process. If water is not flowing, check to make sure the filter has been fully rotated to the right.
• Press and hold the WATER FILTER pad on the dispenser for three seconds to reset water filter.
