User Manual
Common Problems & Solutions
S/N | Problems | Causes | Solutions |
1 | The Product can not be started | The plug is not in place | Insert the plug |
The power switch is off | Turn switch on, the indicator | ||
Th fuse is burnt | Replace with a new fuse of the same mode! | ||
2 | Sound like phew or Da-da is heard during working | Normal sound generated by the motor or from the abrasion between mechanical units | No additional treatment is required |
3 | Operate the controller, but the Product no action | The electricity of batteries is worn out | Replace batteries |
The controller is too far away from the Product | The effective distance of infrared signal is 2.5M | ||
4 | Sudden stop | Default working time is up | Restart it after 10 minutes’ interval |
5 | Can not operation | Too many commands sent to the Product and they can not be responded in time | Power off and then restart |
Storage and Maintenance Surface cleaning
Before cleaning, ensure the power switch is turned off, and the attaching plug is pulled out of the socket
The rubber pedal and covers can be cleaned with a wet cloth containing detergent, and the detergent should be removed with a cloth
Notice
Do not clean the Product with corrosive detergent such as benzene or thinner, as it may cause fading, corrosion or crack on the Product. Do not splash water into the Product to avoid short circuit.
Controller
As wet cloth may cause malfunction of the controller, only dry cloth can be used
Storage and Maintenance
Make sure that the power switch is turned off and the plug is removed from the power supply
Clean offthe dust and dirt on the Product and keep it clean and away from places with high temperature or high humidity If the Product is not in use for a long period, a dustproof cover (buy it yourself) should be applied on the Product to prevent the entry of dust
Moving method
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/1_1688974922.png)
Two handles are designed on both ends of the middle cover. When moving the Product, lift the end opposite of the castor, grasp the handle and move the Productto the desired place.
Name and Function of the Product
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/2_1688974922.png)
Name and Function of Controller
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/3_1688974922.png)
Start/Stop: Insert the power plug, switch on power, then press the button to start the product. In the operation of the machine, press this button to stop working.
Time-: Time decrease:the default working time is 10 minutes, divided into 10 levels, press this button to decreasetime.
Speed+: Speed increase: Manual 1-20. Press this button to increase the speed when the machine is operating.
Time+: Timeincrease:thedefaultworkingtimeis 10 minutes, divided into 10 levels, press this button to increase time.
Speed-: Speed decrease: Manual 1-20. Press this button to decrease the speed when the machine is operating.
M : QUICK BUTTON for Levels 1610 6, press once for Level 16 and twice for LeveM 0 and 3 times for Level 6 repeatly.
Auto/Mode: Auto/Mode: Defaulttomanual mode, automatic mode is activated once pressing this button. Press the button repeatedly to cycle through the'P1" P2" P3' automatic operating mode or'88'manual mode. Auto mode, humanized programming, automatically adjusting vibration frequency. In automatic mode, speed and time is not adjustable. In the manual mode, the standby can adjust the time, the speed is not adjustable; when operating,speed adjustable, buttime is not adjustable.
Note: The effective reception range of the remote control signal is 2.5 meters, the infrared emission indicator of the controller should be aligned the infrared receiving windowon the product.
Use method
1. Stand upright on the Product,with two legs apart, the distance of two legs is mostly the sameas width of shoulder. This position can exercise waists and buttocks to relieve stress on waists and sculpture beautiful curve of buttocks
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/4_1688974922.png)
2. Stand on the Product with two legs apart and knees bent. The posture can exercise thighs to sweep pain and soreness, improve blood circulation, and reduce fat deposits
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/5_1688974922.png)
3. Seat on chair or sofa, with feet put on the Product. This posture can exercise both thigh and calf.
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/6_1688974922.png)
4. Seat on carpet,with two legs put on the Product. This posture can exercise leg.
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/7_1688974922.png)
5. Kneel on the carpet, put hands onto the Product, with body lean forward, this posture can exercise shoulder joint and arms
![](https://files.manualsfile.com/639bfb818024ea13544b9c04e3396662/8_1688974922.png)
Functions and features:
Body beauty: By reposeful and high-frequency vibration and sway, combined with various exercise postures, this machine can deeply stimulate muscle tissue, lower fat accumulation, rehabilitate elasticity of muscle, sculpture beautiful body shape, then make users vitalized and feel confident.
Exercise: Borrow health and fitness ideas from Chinese traditional culture like Kung Fu, Buddhism, Taoism, it advocates passive exercise, which allow you to exercise indoor in a relatively static manner to get mind and body relaxed, pain and soreness relieved, fatigue swept away, inner circulation improved, then make you stronger and healthier.
Safety Precautions Environmentfor use
Do not use the Product in humid or dusty environment to avoid electric shock or breakdown of the mechanical parts.
Do not use the Product when indoor temperature is over 40°C.
Do not use the Product in the oper air or under the direct sunlight.
Please the Product on flat floor.
People under these conditions below are not suggested to use the Product
It is strongly advised to consult your doctor before use Patients who are under treatment or feel not good;
Patients with malignant tumor;
Pregnant women or women in menstrual period;
People with heart disease;
Osteoporosis patients;
People with heart pacemaker or other medical electronic instrument implanted;
People with artificial limb;
People who are sensitive to vibration and strenuous exercise.
Notices during Operation
Before use,please undress watch^bangle^ell phone or other valuable objects,and keys,knife or other incisive objects,soas to avoid damage or body injury.
Do not smoke while using the Product.
Please do not use the Product together with other medical equipments. Please do not use the Product for medical treatment purpose.
Do not use the Product right after a meal or drink.
During use,please keep child or pet away from the Product.lt is forbidden to put fingers or other foreign bodies into the gap between the middle cover and base cover.
Supervision is needed for child under 10 years and the aged over 60 years during using the Product.
The load capability of the Product is 100KGS;people over this weight are not suggested to use the Product.
This product is only limited for one-person use.
Stop using the Product under the Product under below conditions, then power off and remove the plug from power supply
Water or other liquid is accidentally splashed onto the Product or controller.
Any accessory is found damaged or internal component is exposed Feel abnormal orsevere pain during use.
Powerfailure.
Thundering or lighting weather.
Plug and power cord
Check if the voltage complies with the one specified for the Product.
Do not retract the power plug with wet hand to prevent electric shock. Hold the plug rather than the power cord to pull out the power cord. Turn offthe power switch and removethe plug from the powersupply in case of electrical failure of not in use for a longtime.
Stop using the Product if the power cord has any damage,turn offthe ower switch,pull out the plug,and contact technicians for repair.
