10-24mm F/3.5-4.5 Di ll VC HLD (Model B023)
For Canon and Nikon mounts
Di II: For APS-C format DSLR cameras
Enjoy the full measure of wide-angle expression.
Expand your options with the only compact,
ultra-wide-angle zoom lens offering superior
optical performance and Vibration Compensation.
Experience the complete joy of shooting with a
compact, ultra-wide-angle zoom
Excellent optical performance across the
entire zoom range
The focus is on stability and precision
Protect your lens with Fluorine Coating and
Moisture-Resistant Construction
High performance packed into a compact body
Compatible with the TAMRON TAP-in
Console
TM
Experience the freedom of handheld
shooting with VC
This ultra-wide-angle zoom lens for APS-C DSLR cameras offers
the finest of all Tamron worlds: best-in-class* 10-24mm focal
length range (the 35mm equivalent of 16-37mm), the compact
size of our previous SP AF10-24mm F/3.5-4.5 Di ll LD Aspherical
[IF] (Model B001), plus vastly improved optical performance. It
also includes state-of-the-art Tamron technology like VC
(Vibration Compensation), a new HLD (High/Low torque-
modulated Drive), Fluorine Coating, and Moisture-Resistant
Construction. Combine this with exceptional resolution on
everything from detailed landscapes to casual snapshots and
you have a next-generation, wide-angle zoom that’s ready to go
wherever your photographic vision takes you.
The optical design includes 16 elements in 11 groups. A new
large aperture aspherical lens and LD (Low Dispersion) lens
elements deliver exceptional resolution across the complete
zoom range — combined with stable imaging across the entire
frame. The lens also corrects comatic and transverse chromatic
aberration, as well as distortion that often crops up on other
wide-angle lenses. Together with Tamron’s unique BBAR
(Broad-Band Anti-Reflection) Coating, which improves light
transmission and suppresses reflection and dispersion on the
lens surface, this new ultra-wide-angle zoom has been entirely
reimagined to control flare and ghosting. The result: clear, crisp
images, every time.
With this lens, Tamron introduces the HLD AF drive system.
The excellent driving power of the all-new HLD enables stable
and precise focusing. What’s more, the Full-time Manual Focus
override allows you to make fine adjustments — without having
to switch from AF to MF mode.
The front surface of the lens element is
coated with a protective fluorine
compound that is water- and oil-
repellant. The lens surface is easier to
wipe clean and is less vulnerable to the
damaging effects of dirt, dust, moisture
and fingerprints. Leak-proof seals
throughout the lens barrel further
protect your equipment, especially
when shooting outdoors.
A shortened overall length vastly
improves optical performance while
maintaining a compact size — even
with advancements such as VC and
the newly developed HLD. When
combined with an APS-C DSLR
camera, this lens packs a world of
performance into a lightweight,
portable body.
The optional TAP-in Console
provides a USB connection to your
personal computer, enabling you to
easily update your lens’s firmware
as well as customize features
including fine adjustments to the AF
and VC.
Tamron’s unique VC technology makes it easy to enjoy
handheld, wide-angle shooting, even in low-light environments
such as evening and indoors. Now you can unleash the power
of high quality imaging, without worrying about your images
being spoiled by the jittery effects of handheld shooting.
* Among ultra-wide-angle zoom lenses for APS-C DSLR cameras (As of January, 2017. Source: Tamron)
Image illustrates resistance to grime
(oil-based felt marker)
left side: Without Fluorine Coating
right side: With Fluorine Coating
MTF
Optical Construction
10-24mm F/3.5-4.5 Di ll VC HLD
(Model B023)
Focal Length: 10mm Exposure: F/5.6 1/750sec ISO: 200
Focal Length: 24mm Exposure: F/4.5 1/60sec ISO: 100
Focal Length: 24mm Exposure: F/5.6 1/180sec ISO: 100
Focal Length: 10mm Exposure: F/5.6 1/45sec ISO: 400
Focal Length: 10mm Exposure: F/3.5 1/6sec ISO: 100
The beauty is in the details
With this new ultra-wide-angle zoom
lens, Tamron has merged beautiful
craftsmanship with intuitive design. From the outer casing hugging the
contours of the lens, to the deftly worked Luminous Gold brand ring and
meticulous construction, the quality of this lens is second to none. Even
details like the shape of the switch box, distant-scale window, and the
precision and stability of the metallic mount reveal a commitment to
functionality, as well as design.
The result is a next-generation lens that’s easy to use, yet loaded with cutting-
edge technology.
Please read the instruction manual carefully before using the lens.
Management on Quality and Environment
Tamron is certified with international standards: ISO 9001 for quality and ISO 14001 for environmental management at its headquarters, domestic
sales offices, China plant as well as its three production facilities in Aomori, Japan, and is fully committed to striving for continued and sustainable
improvement at all levels and facets of its business operations.
Note: Information valid as of 1 2017. Information in this publication is subject to change at any time without prior notice.
Caution:
Model
…………………………....………...
B023
Focal Length
……….……….……….....
10-24mm
Max. Aperture
……….………….…….
F/3.5-4.5
Angle of View (diagonal)
………...
108°44'-60°2'
for APS-C format
Optical Construction
……….……...
16 elements in
11 groups
MOD
……….………….………….………...
0.24m (9.4 in)
Max. Mag. Ratio
……….………….....
1:5.3
Filter Size
……….………….………….…
Φ
77mm
Max. Diameter
……….………….…….
Φ
83.6mm
Length*
……….………….………….…….
84.6mm (3.3 in) Canon
82.1mm (3.2 in) Nikon
Weight
……….………….………….….…
440g (15.5 oz) Canon
440g (15.5 oz) Nikon
Aperture Blades
……….………….…..
7 (circular diaphragm)
Min. Aperture
……….………….……...
F/22-29
Stabilization Performance
…….....
4 Stops
(CIPA Standards Compliant)
For Canon: EOS-80D is used
Nikon: D7200 is used
Standard Accessories
……….…….
Lens hood, Lens caps
Compatible Mounts
……….……….
Canon, Nikon
10-24mm F/3.5-4.5 Di II VC HLD (Model B023)
Specifications, appearance, functionality, etc. are subject to change without prior notice.
* Length is the distance from the front tip of the lens to the lens mount face.
B23-EN-111-L-1701-0200
